Systembuild Evolution 2135408COM User manual

2135408COM
2 Door 1 Drawer Base Cabinet
B342135408COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Follow Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough
Secure Your Furniture
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
Visit ameriwoodhome.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Parts are labeled on the surface or edge of the part
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P
12
34
Press parts together so CAM BOLT inserts
into edge hole.
Press CAM BOLT into hole. Press CAM LOCK into hole.
End hole
Using a screwdriver, turn the CAM LOCK clockwise to
lock the CAM LOCK and CAM BOLT into their holes
and fastening parts together.
Arrow to point towards end
hole in edge of part.

4
systembuild.com
Before You Start
Quick
Assembly
Tip
Please Note:
You may need to lightly tap the wood dowels into the holes during
your assembly process.

5
systembuild.com
Board Identification
Not actual size
Left Panel
32135408010 Right Panel
32135408020
Top
32135408030
Bottom
32135408040
Adjustable Shelf
34888408050 Left Door
32135408060 Right Door
32135408070
ABC
D
EFG
Drawer Front
32135408080
H
False Drawer Front
32135407090 Left Drawer Side
32135407100
Right Drawer Side
32135407110
I
JK
Drawer Back
32135407120
L
Drawer Bottom
32135407130 Drawer Brace
32135000140
MN

6
systembuild.com
Board Identification
Not actual size
A
B
C
D
O
G
F
E
H
I
J
K
L
M
N
Back Panl
K488840800
O
This part is made of paperboard
construction. It is not made
from wood, but is required for
the assembly of your unit.

7
systembuild.com
Part List
Actual Size
(x26)
#A12105
7/16" pan head screw
12
3
15
11
(x4)
#A22700
cam lock
(x4)
#A22710
cam bolt
(x4)
#A21670
wood dowel
(x4)
#A23030
confirmat screw
(x4)
#A17400
7/8" bolt
(x30)
#A21110
nail
(x4)
#A80250
shelf support
(x2)
#A11170
5/8" pan head screw
(x2)
#A11210
3/4" pan head screw
(x14)
#A12810
1" pan head screw
(x2)
#A89020
plastic stop
(x1)
#A55410
slide bolt
5
610
7
16 18
9
17
(x6)
#A11070
euro screw
14
(x12)
#A13410
1-3/4" flat head screw
4
(x2)
#A17410
7/8" bolt
13

8
systembuild.com
Part List
Not Actual Size
(x1)
#A84050
safety bracket
(x4)
#A65615
hinge
(x3)
#A55010
handle
(x5)
#A44710
foot
(x1)
#A55055
lock
19
20 21
8a
12a
12b
12c
12d
12e
(x2)
#A92550
base plate kit
22
(x1)
#A56100
drawer slide
23
8
8b
8c
8d
12

9
systembuild.com
STEP1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
(x2)
13
(x2)
1
3
1
3
A
14 23
(x3) (x1)
Locate the slide kit (21). Extend the slide as shown and press the release lever to remove the inner
slide. Set the inner slide aside for later. Start by attaching the slide to the panels at the rear of the
slide. While sliding the middle slide locate the holes in the panels with the access hole in the middle
slide and fasten with screws (20) as shown.
14
outer slide
inner slide
release lever middle slide
use these holes
23
14
14
access hole

10
systembuild.com
STEP2
13
(x2) (x2)
1
3
B
13
14 23
(x3) (x1)
14
inner slide
release lever middle slide outer slide
use these holes
access hole
14
14
23

11
systembuild.com
STEP3
8a
8b
2
(x4) (x1)
2
8a
8b
C
2
2
2
Finished Edge
Do not fully tighten screw.

12
systembuild.com
STEP4
16
6
16
6
D
(x2)
(x2)

13
systembuild.com
STEP5
15
(x4)
Finished Edges
Face Up
C
D
A
B
UNLOCKLOCK
15
15
15
15

14
systembuild.com
STEP6
18
(x30)
Finished Edges
Face Down
18
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY.
Carefully turn the unit over on its front side.
Position back panel as shown. Align squarely with all edges and nail straight into back edges as
shown.
Assure that our unit is square.
Distance from corner to corner
must be equal as shown.
Flush bottom edge of the back
panel with the bottom edge of
bottom (D).
Raw Surface Shown
B
D

15
systembuild.com
STEP7
20
7
D
B
20
7
7
(x10) (x5)
x5

16
systembuild.com
STEP8
5
22
(x20) (x2)
F
G
22
5
5
5
5

17
systembuild.com
STEP9
10 17
11
19 21
(x2)
(x2) (x1) (x2) (x1)
F
11
11
19
19
21
17
10
10

18
systembuild.com
STEP10
11
19 21
G
11
11
21
19
19
(x2) (x2) (x1)

19
systembuild.com
STEP11
G
Teeth of lock nut will tighten
against the surface of the
door.
12a
12b
12c
12d
12c
Insert the barrel of the lock (12a) into the hole as shown.
With the teeth of the lock nut (12c) facing the door
surface, tighten the lock nut (12c). Position lock bar (12b)
and attached the barrel of the lock (12a) with the lock
screw (12d). Lock bar (12b) will point straight left. When
you turn the lock with the key, lock bar will rotate
counter-clockwise pointing straight down (unlock
position).
Flat /smooth
surface of
lock barrel.
Keyway Vertical
12d
12b
12a 12c 12e

20
systembuild.com
STEP12
F
G
When mounting the right door (G),
be sure the lock bar (12b) is
pointing straight down.
When mounting the left door (F),
be sure the slide bolt (17) is
positioned in the up position.
17
