TAC Xenta OP Handbook Foreword
Foreword
Welcome to the manual of TAC Xenta OP, version VMX 3.2 and
higher.
Should you discover errors and/or unclear descriptions in this manual,
please contact your TAC representative.
You may also want to send an e-mail to [email protected].
This edition, -4, applies to TAC Xenta OP version VMX 3.2 or later.
The procedure for de-installation of the OP has been clarified and put
in a separate section, 2.7.
The possibility to select which unit system (SI or US Imperial) is used,
when connecting to TAC Xenta 100, is now described in section 3.2.

TAC Xenta OP Handbook Foreword
4 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
Copyright © 2001 TAC AB.
This document, as well as the product it refers to, is only intended for licensed users of the product and the document.
TAC AB owns the copyright of this document and reserves the right to make changes, additions or deletions.
TAC AB assumes no responsibility for possible mistakes or errors that might appear in this document.
Do not use the product for any other purposes than those indicated in this document.
Only licensed users of the product and the document are permitted to use the document or any information therein.
Distribution, disclosure, copying, storing or use of the product, the information or the illustrations in the document
on the part of non-licensed users, in electronic or mechanical form, as a recording or by other means, including
photocopying or information storage and retrieval systems, without the express written permission of TAC AB, will
be regarded as a violation of copyright laws and is strictly prohibited.
TAC Xenta®, TAC Menta® and TAC Vista® are registered trademarks of TAC AB in Sweden and other countries.
All other brand names are trade marks of their respective owners.
Revisions list
Art no Comments Editor Date
0-004-7506-0 First version. KW 1996-08-08
0-004-7506-1 This document has been revised to cover TAC Xenta v 3.0. KW 1997-09-01
The following major changes have been made:
- The Chapter contents have been rearranged.
- A new chapter has been added, showing how to communicate
with Xenta 100 and how to reach the Network Variables.
Trade mark change from TA to TAC. KW 1998-06-11
0-004-7506-2 This document has been revised to cover TAC Xenta v 3.2. KW 1999-01-26
0-004-7506-3 The explanation of the OP communication mode has been KW 2000-08-08
expanded (section 2.6).
The OP/RU model with Cyrillic characters added.
0-004-7506-4 The de-installation procedure has been clarified (section 2.7). KW 2001-08-08
Switching between SI and I-P units has been added to section 3.2.

TAC AB, 2001-08-08 0-004-7506-4 (EN), 5 (36)
TAC Xenta OP Handbook Contents
TAC Xenta OP
Handbook
Subject to modification.
Contents
1 Introduction .................................................................................................................... 7
1.1 TAC Xenta OP .......................................................................................................................................7
1.2 This manual............................................................................................................................................7
1.3 More information ..................................................................................................................................8
2 Connection and Basic Functions................................................................................... 9
2.1 Description .............................................................................................................................................9
2.2 Connecting to TAC Xenta 100 ........................................................................................................... 10
2.3 Connecting to TAC Xenta 300/401 .................................................................................................... 11
2.4 Keys...................................................................................................................................................... 12
2.5 Local functions of the OP Service menu........................................................................................... 13
2.6 Selecting the OP communication mode ............................................................................................ 15
2.7 De-installing the OP ........................................................................................................................... 17
2.7.1 Tool: MetraVision ................................................................................................................................. 17
2.7.2 Tool: LonMaker .................................................................................................................................... 18
3 Dialogs with TAC Xenta 100........................................................................................ 19
3.1 General ................................................................................................................................................ 19
3.2 Connecting to TAC Xenta 100 ........................................................................................................... 19
3.3 Setting the Node state in TAC Xenta 100.......................................................................................... 21
3.4 Reading/checking NVs in TAC Xenta 100 ........................................................................................21
3.5 Initiate Service pin message............................................................................................................... 22
4 Dialogs with TAC Xenta 300 and 401 ......................................................................... 23
4.1 The menus ........................................................................................................................................... 23
4.2 Find and change a setpoint ................................................................................................................ 24
4.3 View/acknowledge alarms.................................................................................................................. 25
4.4 Change the Time channels ................................................................................................................. 26
4.5 Access Code ......................................................................................................................................... 28
4.6 Edit access code................................................................................................................................... 29
4.7 Overriding inputs/outputs.................................................................................................................. 29
4.8 Daylight saving.................................................................................................................................... 30
4.9 Log off.................................................................................................................................................. 30

TAC Xenta OP Handbook Contents
6 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
This manual contains a total of 36 pages.
5 Technical data............................................................................................................... 31
Index ....................................................................................................................................... 33

TAC AB, 2001-08-08 0-004-7506-4 (EN), 7 (36)
TAC Xenta OP Handbook 1 Introduction
1 Introduction
1.1 TAC Xenta OP
TAC Xenta OP is a small operator panel designed to be used together
with TAC Xenta 100, 300, 401 and 901 units.
The operator panel gives the user access to parameters and alarms
without communicating with a central system. Additionally, it is used
to monitor status, adjust setpoints and time channels. All values are
displayed with an explanatory text in the alphanumeric display win-
dow.
Please note!
The TAC Xenta OP and the other products of the Xenta family must
not be used for any other purpose than that for which it was designed.
Installation and repair may only be performed by authorized person-
nel.
1.2 This manual
This handbook has the following contents:
Chapter 2
In this chapter the connection of the operator panel, TAC Xenta OP,
to the TAC Xenta 100 and TAC Xenta 300/401 controllers is shown.
Chapter 3
The use of the OP together with TAC Xenta 100 and the principles for
handling display of Network Variables are explained in this chapter.
Chapter 4
The use of the OP together with TAC Xenta 300/401 controllers and
the most common menus are discussed here

8 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 1 Introduction
Chapter 5
This chapter contains technical data on the TAC Xenta OP.
1.3 More information
TAC Xenta OP is also described or mentioned in the following
documents:
• the TAC Xenta OP Operator panel data sheet (C-98-05)
• the handbooks for the different TAC Xenta controller units
• the “TAC Menta User’s manual”
Stand-alone TAC Xenta 300/3000 controllers and I/O modules can be
commissioned by using the Service menu of TAC Xenta OP (which is
not the same as the local OP service menu). This procedure is de-
scribed in the TAC Xenta 300 and 401 Handbook.

TAC AB, 2001-08-08 0-004-7506-4 (EN), 9 (36)
TAC Xenta OP Handbook 2 Connection and Basic Functions
The TAC Xenta OP operator panel
LCD display
Connectors
(rear) Push buttons
+
–
2 Connection and Basic Functions
2.1 Description
The TAC Xenta OP Operator panel has an LCD display with 4*20
characters and six push buttons. A modular socket or four screw
terminals are used for communication and for connecting the power
supply. These connectors are placed on the rear. There is also a
potentiometer to adjust the contrast of the display, on the rear.
The OP has an LCD display that can be lighted from beneath. The
light is controlled from the OP Service menu (section 2.5).
The operator panel is used to monitor status and to adjust setpoints
and time channels. It also makes it possible to list the alarms without
communicating with a central system.
The operator panel is controlled from a master, a TAC Xenta 100, 300
or 401 controller. When you start using the operator panel, it will send
a message to the master telling it what button was pushed. The master
contains the dialogue messages and will direct the operator panel what
to show on the display. Thus the operator panel will act as a dumb
terminal.

10 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 2 Connection and Basic Functions
COMFORT
ECONOMY
OFF
TAC Xenta 100
Wall Module
Connecting the TAC Xenta OP to TAC Xenta 100 via the Wall Module
2.2 Connecting toTAC Xenta 100
Normally the TAC Xenta OP is connected to the modular jack on the
lower side of the Wall Module. In this way the Xenta OP will get
power supply from the TAC Xenta 100 unit.
Cable between controller and Operator panel...................... max. 10 m
The contrast of the display can be adjusted with the potentiometer on
the rear of the operator panel; please refer to the figure in the next
section.

TAC AB, 2001-08-08 0-004-7506-4 (EN), 11 (36)
TAC Xenta OP Handbook 2 Connection and Basic Functions
2.3 Connecting toTAC Xenta 300/401
Cable between controller and Operator panel...................... max. 10 m
When connecting the operator panel there are two alternatives (please
refer to the adjacent figures):
• Use the modular socket on the front of the TAC Xenta 300 or 401
controller and the corresponding socket on the back of the operator
panel. This requires a special cable.
• Use the screw terminals on the back of the operator panel, la-
belled 1–4. Terminals 1 and 2 are used for communication and
terminals 3 and 4 for 24 V AC (or DC).
At the controller you use the terminals C1, C2 and G, G0.
TAC Xenta 300/401
controller
TAC Xenta OP connectors and contrast potentiometer
Contrast
adjustment
(on the rear)
The contrast of the display can be adjusted with the potentiometer on
the rear of the operator panel.
(The Service pin is available from the rear if, in special cases, the
network configuration procedure requires this. When the pin is
pressed, a unique hardware identity code is sent on the network.)
Socket for
connection to the
operator panel
Socket and screw terminals for
the TAC Xenta controller
connection
4
3
21
C1 C2 G G0
Service pin
Modular socket
on the OP

12 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 2 Connection and Basic Functions
2.4 Keys
The TAC Xenta OP keys:
+
–
is used to step up one level in the directory hierarchy
(“Home”). There may be several levels in the hierarchy. The
cursor will return to the line selected the last time this level
was active. This button does not by itself make changes
effective.
–
is used to decrease values. If this button is kept depressed,
the stepping speed increases.
+
is used to increase values. If this button is kept depressed,
the stepping speed increases.
is used to move the cursor upwards in a menu list or to move
to previous alarm or logged record.
is used to move the cursor downwards in a menu list or to
move to previous alarm or logged record.
is used to select a line, indicated by the cursor (“Enter”) or
to move between the different adjustable values.
This button also makes changes effective.

TAC AB, 2001-08-08 0-004-7506-4 (EN), 13 (36)
TAC Xenta OP Handbook 2 Connection and Basic Functions
2.5 Local functions of the OP Service menu
For simple hardware check of the OP and for certain system param-
eters there is a local Service menu in the operator panel. The OP
functions are quite independent of the other TAC Xenta units and only
require that the operator panel is connected to the network and that the
panel has not been set in the TAC Xenta 100 communication mode
(see below).
The Service menu appears if both the keys . and are
pressed for about three seconds simultaneously.
OP Service menu
1. Exit service mode
2. Keyboard test
3. Display test
4. LON address
5. National text
6. SW version
7. LonTalk status
8. Display backlight
9. Service pin
10. OP mode
Select the required function and press .
Two hardware tests
2. Keyboard test is a simple test of the keyboard functions:
Keyboard test
* * * Press keys!
* * Double-press
* for QUIT
Each asterisk corresponds to a key. Double pressing on any key means
leaving the test.
3. Display test will test all display positions in a number of steps.
Each step is initiated by pressing any key.
System information
4. LON address shows the current Domain/Subnet/Node address for the operator
panel.
6. SW version lists the current version of the operator panel version and
7. LonTalk status shows statistics from the network communication.
9. Service pin is a way to send the unique Neuron ID on the network.
Mainly used for testing purposes.

14 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 2 Connection and Basic Functions
Selecting the language of the OP messages
5. National text means that the operator can switch between different languages for
those messages that are generated in the OP.
Select language
No reply ...
Wait ...
Press Enter to save!
If you press or the language will change, for example into
German:
Select language
Keine Antwort ...
Bitte warten ...
Press Enter to save!
When you have selected a suitable language you press
(“Enter”) and then leave the menu.
Controlling the display light
8. Display backlight controls the background light of the OP display.
There are three modes: OFF, ON and AUTO.
OFF means that the backlight is always turned off,
ON means that the light is turned on permanently and
AUTO means that the light is turned on as soon as a button is
pressed, but goes off about 30 minutes after the last key has been
pressed.
Use
+
and
–
to select the required mode.
As the display light may cause loss of contrast if turned on perma-
nently, we recommend the AUTO or OFF mode.
Leaving the OP Service menu
1. Exit service mode means leaving the local OP service menu.
This will also happen if no key has been used during about 40 seconds.
Selecting the OP mode
10. OP mode In TAC Xenta networks the OP may work in one of two
communication modes:
- for communication with Base units, TAC Xenta 300 and 400
- for communication with TAC Xenta 100
Furthermore, the OP can be more or less mobile, depending on the
way the OP is connected to the network.
Please refer to the next section!

TAC AB, 2001-08-08 0-004-7506-4 (EN), 15 (36)
TAC Xenta OP Handbook 2 Connection and Basic Functions
2.6 Selecting the OP communication mode
Xenta 100: ON/OFF When delivered, the OP is set for Base unit (TAC Xenta 300, 400)
communication. To change the communication mode, you have to call
up the OP Service menu and go to the 10.OP mode menu, where the
TAC Xenta 100 mode can be turned on/off.
Change OP mode
Xenta 100 : OFF
Bindable : TAC
Use
+
or
–
to change the Xenta 100 mode and press .
When the OP is set to allow the Xenta 100 mode, the operator is given
a choice to access TAC Xenta 100 (in stead of TAC Xenta 300/400)
by pressing “Enter”, each time an OP is connected.
The OP Service menu cannot be reached when the OP is in the Xenta
100 mode.
If you want to turn OFF the Xenta 100 mode, once you are in this
mode, you must temporarily disconnect the OP and let the OP revert to
the Base unit communication mode in order to be able to reach the
Service menu and from there select the 10. Change OP mode
menu.
The TAC Xenta 100 OP communication is described in the next chapter.
“Bindable” is explained after the Summary below.
Summary
To turn ON the Xenta 100 mode
1 Connect the OP and wait for message on display.
2 Press both keys . and for about three seconds
simultaneously.
3 Select 10.OP mode menu.
4 Press
+
or
–
to set the Xenta 100 mode ON and press
.
5 Temporarily disconnect the OP and wait for message on display.
6 Press to access Xenta 100.
7 Wait for message on display.
Connecting to
Xenta Base unit
OP Service menu
1. Exit service mode
2. Keyboard test
3. Display test
.
10 OP mode
Change OP mode
Xenta 100 : ON
Bindable : TAC
Press enter to
access Xenta 100
Connecting to
Xenta 100 ...

16 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 2 Connection and Basic Functions
To turn OFF the Xenta 100 mode
1 (Disconnect and then) connect the OP; wait for a couple of
seconds for the Base unit message to appear.
2 Press both keys . and for about three seconds
simultaneously.
3 Select 10.OP mode menu.
4 Press
+
or
–
to set the Xenta 100 mode OFF and
press .
5 Select the 1.Exit service mode menu and press .
Press enter to
access Xenta 100
(wait)
Connecting to
Xenta Base unit
OP Service menu
1. Exit service mode
2. Keyboard test
3. Display test
.
10 OP mode
Change OP mode
Xenta 100 : OFF
Bindable : TAC
1. Exit service mode
Bindable “Bindable” is a LonWorks term, describing how the OP is connected
and addressed in the network. This, in turn, affects the mobility of the
OP.
Use
+
or
–
to select Bindable mode from the following.
•TAC OP movable. Two available addresses following each
TAC Xenta Base unit.
•INST OP permanently electrically connected to the network;
installed with a binding tool.
•MAN OP movable, the domain ID of the network has to be
programmed via OP Service menu – 4.LON address
(communication is here limited to Base units on the same
channel).
For OP version 3.11 and earlier the following modes can be chosen.
•OFF OP movable. Two available addresses following each
TAC Xenta Base unit.
•ON OP permanently electrically connected to the network;
installed with a binding tool.
Confirm your choice by pressing .

TAC AB, 2001-08-08 0-004-7506-4 (EN), 17 (36)
TAC Xenta OP Handbook 2 Connection and Basic Functions
2.7 De-installing the OP
If the OP is to be de-installed from the network, it should be restored
to the original factory setting to avoid problems, if used in another
network.
Depending on which binding tool has been used, the de-installation is
made according to one of the methods shown below.
2.7.1 Tool: MetraVision
1 Select OP Service menu – 10. OP mode and set
Bindable to “TAC” or, in OP version < 3.11, ”OFF”.
2 Disconnect the OP electrically from the network.
3“Remove” the OP node from the data base.
Factory setting If the OP has been labelled ”Unconfig”, which may happen if step 3
above was executed before step 2, or for any other reason; the OP may
be restored to the factory setting in one of two ways:
A Reconnect the OP to the network, reinstall it and perform the steps
above in the correct order,
or,
B use the Nodutil program and do the following.
1 Select OP Service menu – 10. OP mode and set
Bindable to “TAC” or, in OP version < 3.11, “OFF”.
2 Start Nodutil.
3 Press the Service pin of the OP.
4 Type “G”.
5 Type “1”, press Enter.
6 Type “M”.
7 Type “S”.
8 Type “C”.

18 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 2 Connection and Basic Functions
2.7.2 Tool: LonMaker
1 Check in the OP Service menu – 10. OP mode that
Bindable is set to “TAC” or, in OP version < 3.11 to “OFF”.
2 Start the LonMaker Browser.
3 Click right, choose Properties.
Restore SNVT_config_src from cfg_external (1) to cfg_local (0).
SNVT_config_src is called var_2 in the Browser.
4 Disconnect the OP electrically from the network.
5 Remove the OP from the data base of LonMaker.
Factory setting If the OP has been de-installed in an incorrect way, it may be restored
to the factory setting in one of two ways:
A Reconnect the OP to the network, reinstall it and perform the steps
above in the correct order,
or,
B use the Nodutil program and perform the following.
1 Select OP Service menu – 10. OP mode and set
Bindable to “TAC” or, in OP version < 3.11, “OFF”.
2 Start Nodutil.
3 Press the Service pin of the OP.
4 Type “G”.
5 Type “1”, press Enter.
6 Type “M”.
7 Type “S”.
8 Type “C”.
9 Type “U”.
10 Type “2”, press Enter.
11 Type “00”, press Enter.
Please note!

TAC AB, 2001-08-08 0-004-7506-4 (EN), 19 (36)
TAC Xenta OP Handbook 3 Dialogs with TAC Xenta 100
3 Dialogs withTAC Xenta 100
3.1 General
TAC Xenta OP can be used as a service and limited commissioning
tool for the TAC Xenta 100 Zone Controllers. These controllers use
Network Variables of the LonWorks standard type (“SNVT”, Standard
Network Variable Type) for all data communication on the network.
All Network Variables, including the configuration parameters can be
accessed via the keypad and the LCD display.
In order to separate this general kind of communication from the
dedicated communication used with TAC Xenta 300 and 401 con-
trollers, the TAC Xenta OP has two different communication modes.
3.2 Connecting toTAC Xenta 100
Note! The very first time a TAC Xenta OP is connected to a Xenta network,
the TAC Xenta 100 communication mode is, by default, in the Off
state. Please refer to the end of chapter 2 for the necessary procedures
to change the communication mode. When this has been done, the
operator is given a choice to access TAC Xenta 100 (in stead of the
Base units, TAC Xenta 300 or 401):
Press enter to
access Xenta 100
Press the key to get the display
Connecting to
Xenta 100 ...
Check that the LED on the Wall Module will flash for some 10
seconds or that the red Service LED turns on and then off after a
couple of seconds, on the connected controller.
If contact is established without the LED flashing, Xenta OP has
connected to another node in the network. In this case disconnect
Xenta OP and then reconnect.

20 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 3 Dialogs with TAC Xenta 100
Wait for the display
Xenta 100 is:
Configured
Press <DOWN> to
continue
Press the key and wait for a display looking like:
Xenta 103v1.00-10
103/A/v10003
units as SI [^]
NV index? 000
The first two lines, showing software versions, are displayed the first
time only.
The third line shows which unit system is used, when SNVT values
are presented in the OP menus.
The key toggles between SI (metric) and US Imperial
(Inch-Pound) units.
From this display (normally only lines 3-4 appear) the different
Network Variables can be selected.
