t.akustik WDS-7 User manual

GLUEING DIFFUSORS
This manual is for the following products : WDS-7, Diusor Wave.
Open the package carefully! Inserting sharp objects
into the package can damage the diuser. Avoid
using long, sharp tools for opening the package!
UNBOXING
While determining the mounting positions, it helps
to mark the walls and ceiling using a level and
tape measure, in order to achieve even spacing in
relation to corners and sound sources.
DETERMINE THE POSITION
Carefully remove the products from the package
and remove the protective lm. Also remove the
mounting clips and set them aside.
REMOVE PRODUCTS
FROM PACKAGING
MOUNTING INSTRUCTIONS
The following tools are needed for installation:
✓Box Cutter ✓ Level
✓Caulk Gun ✓Folding ruler or tape measure
✓Pencil ✓t.akustik glue
We recommend using our t.akustik glue for installation.
TOOLS
EN

Thomann GmbH · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
DocID: 448985_398905_493157_493131_..._19.03.2021
Carefully open the glue cartridge using a utility knife.
Take care to point the knife away from your body.
Thread the included nozzle onto the opening. Insert
the cartridge into the caulk gun. For thicker lines of
glue, you can use the knife to enlarge the opening of
the nozzle.
PREPARE THE CAULK GUN
Apply the glue to the back of the diuser in an even line
along the outer edge. It also helps to apply some glue to
the center of the diuser in an X pattern, in order to hold
the center rmly in place. Depending on the condition of
the walls, we recommend using a generous amount of
glue along the outer edges.
APPLY THE GLUE
Press the diuser onto the wall in the marked
position and apply even pressure along the
lines of glue for 2 minutes. We recommend
checking the alignment using a level and
making necessary adjustments by slightly
rotating the element. That’s it!
INSTALL THE DIFFUSER
TIP:
Before mounting the diuser on the wall, let the glue
set for 5 minutes on the element. This ensures that it
can develop its full holding strength.
LET GLUE SET FOR 5 MINUTES
Depending on the condition of the wall, it is recommended to apply a thicker line of glue by enlarging the nozzle of the cartridge using a utility knife.
EN
This product is intended to be used to optimise the room acoustics. Any other use or use un-
der other operating conditions is considered to be improper and may result in personal inju-
ry or property damage. No liability will be assumed for damages resulting from improper use.
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within
reach of babies and young children. Choking hazard!
When opening the glue cartridge using a knife or a cutter, pay attention not to injure
your ngers/hands. Risk of cutting!
For the transport and protective packaging, environmentally friendly materials have
been chosen that can be supplied to normal recycling. Ensure that plastic bags, pa-
ckaging, etc. are properly disposed of. Do not just dispose of these materials with
your normal household waste, but make sure that they are collected for recycling.
Please follow the notes and markings on the packaging.
