T.C.FILTER T.C. 2 User manual

Product Manual
T.C. 2/ T.C. 2S/ T.C. DS

filter media
cleaning tap
water inlet
for mounting screws
wall
clean water
tap
for mounting screws
activated carbon
ion-exchange resin
Parts & accessories
Installation Guide
Use a 3-way pipe to install from the water source. Installation
near the raw water tap is most suitable. Additional pipework is
needed if the raw water tap is far away from the desired
installation site.
1. Assemble the taps
2. Find a suitable location for installation
3. Mount the filtration system to the wall
4. Connect the corrugated hose to the water inlet (use a 3-way
pipe on the other side of the hose)
Installation Steps

water inlet
3-way pipe
Corrugated
hoses
for mounting screws
wall
clean water
tap
for mounting screws
activated carbon
ion-exchange resin
Activated carbon preperation
Soak activated carbon in tap water for at least 30 minutes.
Dispose of the water and clean the media with more water
until the residue in the water is not visible.
Ion-exchange resin preperation
Soak ion-exchange resin in tap water. Add table salt (25 - 50 g)
into the mix. Wait for at least 30 minutes before disposing of
the water. Clean the media with more tap water.
Illustration of installed
water filter
(see page 10 for water media filling method)

Middle column (ceramic filter)
for T.C. 2S/ DS only
o-ring cover
o-ring
ceramic filter
water faucet
cap nut
Before inserting ceramic filter clean ceramic filter lightly with
tap water
Warning: Do not drop the ceramic filter.
The filter may break.

Valve A
Valve B
filter media
cleaning tap
close
open
Valve position
clean water tap
- open valve A
- close valve B
- turn on clean
water tap
Normal operation
(filtration)
In the case of water having color or odor
- Check valve positions
- If valve positions are correct, turn on the clean water tap for
2 - 3 minutes (until color and odor disappear) before using
the water.
Normal operation (filtration)
activated carbon
ion-exchange resin

filter media
cleaning tap
Valve A
Valve B
clean water tap
Media cleaning with tap
(every 1 - 2 months)
Activated carbon cleaning (regeneration)
1. Close valve A
2. Open valve B
3. Turn on the filter media cleaning tap
(refer to the fiture above for valves and taps position)
activated carbon
ion-exchange resin

Ion-exchange cleaning (regeneration)
1. Close valve A and valve B
2. Turn on the clean water tap to drain left-over water
3. Remove the end cap nut at the top of the ion-exchange resin
column
4. Dissolve salt (about 25 g to 500 ml water)
5. Pour salt water into the ion-exchange resin column
6. Close the end cap nut
7. After about 30 minutes, open valve A (valve B remains closed).
8. Turn on the clean water tap to let the water flows for 5 - 10
minutes or until the salty taste has disappeared from the clean
water
activated carbon
ion-exchange resin
filter media
cleaning tap
Valve A
Valve B
clean water tap
pour salt water
into the ion-
exchange resin
column

Cleaning ceramic filter
activated carbon
ion-exchange resin
activated carbon
ion-exchange resin
remove bolts
remove ceramic filter
1. Remove both fastening bolts on the cover of the ceramic
filter column
2. Use an abrasive sponge to clean the ceramic filter
3. Clean the ceramic filter with tap water and install it back
into the column
Warning: Do not use soap or detergent to
clean the ceramic filter. If possible, use a new
abrasive sponge.

activated carbon
ion-exchange resin
open valve A
close valve B
External method for media cleaning
(every 3 - 4 months)
Ion-exchange cleaning (regeneration)
1. Prepare a container or bucket and put it right under the
ion-exchange resin column
2. Remove the end cap nut at the bottom of the ion-exchange
resin column
3. After emptying the media into the bucket, drain some
water out of the bucket.
4. Mix 25 - 50 g of salt into the mixture and wait for at least 30
minutes.
5. Clean the ion-exchange resin with clean tap water
6. See page 10 for filter media refilling
Ion-exchange cleaning (regeneration)

activated carbon
ion-exchange resin
Activated carbon cleaning (regeneration)
1. Prepare a container or bucket and put it right under the
ion-exchange resin column
2. Remove the end cap nut at the bottom of the activated
carbon column
3. Clean the media with clean tap water
4. See page 10 for filter media refilling
*When draining filter media, open valve A and close valve B.
When the filter media is nearly fully drained, close valve A
open valve A
close valve B

activated carbon
ion-exchange resin
Filling filter media
1. Remove the end cap nut at the top of the respective
column
2. Close valve A and valve B
3. When filling the filter media, turn on the clean water tap
(preferably, fill in ion-exchange resin first)
4. Use a funnel to fill the column with the mixture of filter
media and water
5. After filling, screw the end cap nut back
clean water tap
open valve A
close valve B
valve A
valve B
close
open
Valve position
