T-Fal EMERIL User manual

www.t-fal.com
User Guide
A
B
C
D
E
F
G
E1
Réf. 2551149-04 - 7/2012
ESPACE GRAPHIQUE
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:42 PageC1

Fig. 1
1
2
1
1
2
2
Fig. 3
Fig. 4
1
2
Fig. 5
1
2
Fig. 7
Fig. 8
Fig. 2
Fig. 6
1
1
Fig. 9
4
Congratulations on ecoming the owner of an Emeril y T-fal ice-cream maker!
An easy way of making a whole range of tasty and creamy iced desserts.
IMPOR AN SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed including the following:
• Read all instructions for use carefully before using your
appliance for the first time: the manufacturer does not
accept responsibility for use that does not comply with the
instructions.
• o protect against risk of electrical shock do not put (Motor
unit with on/off switch) in water or other liquid.
• Close supervision is necessary when any appliance is used
by or near children.
• Unplug from outlet when not in use, before putting on or
taking off parts, or before cleaning.
• Avoid contacting moving parts.
• Do not operate any appliance with a damaged cord or plug
or after the appliance malfunctions, or is dropped or
damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or electrical
or mechanical adjustment.
• he use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
• Do not use outdoors (this may be omitted if it is specially
designed for outdoor use.
• Do not let cord hang over edge of table or counter or touch
hot surface.
• .Do not place on or near a hot gas or electric burner or in a
heated oven.
• Do not heat the cooling bowl to a temperature of more
than 105°F.
Do not put in a dishwasher, oven or microwave oven and do
not fill with a hot liquid.
• Your appliance is designed for domestic use only. Any com-
mercial use, inappropriate use or failure to comply with the
This warranty does not apply to any product that has een tampered with, or
to damages incurred through improper use and care, faulty packaging y the
owner or mishandling y any carrier.
The T-fal manufacturer's warranty applies only for products purchased and
used in USA, Canada & Mexico. Where a product purchased in one country
and then used in another one:
a) The T-fal guarantee duration is the one in the country of usage of the
product, even if the product was purchased in another listed country
with different guarantee duration.
) The T-fal guarantee does not apply in case of non conformity of the
purchased product with the local standards, such as voltage,
frequency, power plugs, or other local technical specifications.
c) The repair process for products purchased outside the country of use
may require a longer time if the product is not locally sold y T-fal.
d) In cases where the product is not repaira le in the new country, the
T-fal guarantee is limited to a replacement y a similar product or an
alternative product at similar cost, where possile.
Consumer Statutory Rights
This T-fal manufacturer's warranty does not affect the statutory rights a
consumer may have or those rights that cannot e excluded or limited, nor
rights against the retailer from which the consumer purchased the product.
This warranty gives a consumer specific legal rights, and the consumer may
also have other legal rights which vary from State to State or Country to
Country or Province to Province. The consumer may assert any such rights at
his sole discretion.
Additional information
Accessories, Consuma les and end-user replacea le parts can e purchased,
if locally availa le, as descri ed in T-fal internet site.
: www.t-fal.com
U.S.A.
GROUPE SEB USA
2121 Eden Road
Millville,
NJ 08332
800-526-5377
13
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:42 PageC4

5
instructions, the manufacturer accepts no responsibility
and the guarantee will not apply.
• Where applicable, always attach plug to appliance and
check that the control is OFF before plugging cord into wall
outlet. To disconnect, turn the control to OFF, then remove
plug from wall outlet.
• Do not use appliance for other than intended.
• Do not pull on the cord to unplug the appliance.
• All appliances are subject to strict quality control procedures.
These include actual usage tests on randomly selected
appliances, which would explain any traces of use.
SAVE THESE I STRUCTIO S
POLARIZATIO PLUG
• This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electrical shock, this plug will fit in a
polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not modify the plug in any way.
Description
A. Motor unit with on/off switch
B. id
C. Paddle
D. Upper ring
E. Freezing bowl
E1. Freezing Indicator
F. ower ring
G. ower ring grip handles
Before using for the first time
TAKI G APART
• Turn the lid counter clockwise to unlock it then lift it out
(Fig. 1). Remove the motor unit located in the bowl and
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page5

set it aside.
• Disassemble the upper ring by pushing or pressing on one
of the levers on the handle (Fig. 2). Remove the upper ring
with your other hand.
• Disassemble the lower ring by pushing or pressing on BOTH
levers of the handle, and pressing downwards (Fig. 3).
CLEA I G
• Before using the ice-cream maker, clean it to eliminate
any residues from manufacturing.
• Never immerse the motor unit in water. It may be cleaned
with a damp cloth.
• Clean the freezing bowl, lid, rings and paddle with warm,
soapy water.
• NEVER clean parts with abrasive or harsh products. You
could damage them.
• Carefully dry all parts before use.
Preparing ice cream, yogurt and sorbets
• Remove the rings from the cooling bowl. Make certain that
the bowl is perfectly dry inside and out before leaving the
empty bowl to cool for at least 24 hours in a freezer at a
temperature of 0°F or colder, or at least 4 to 6 hours in bet-
ween making batches. The freezing time may be longer in
a combination refrigerator/freezer. Make sure the bowl is
upright to ensure an even distribution of the liquid between
the walls when it freezes.
• A snowflake with blue arrows around it will appear on the
exterior of the freezer bowl about 6 hours after the container
has been placed in the freezer compartment and it shows
that your bowl is in the process of chilling. If nothing
appears after around 10 hours, try lowering the temperature
of your freezer.
• Prepare the ice cream mix (see recipes section). The colder
your freezer is, the faster your ice cream maker will work
and the better the results will be. For recipes where the in-
gredients needs to be heated, make sure you allow your
dessert to chill completely! On the other hand, for recipes
using fresh ingredients, follow the recipes or get creative
6
You may leave
your freezing
bowl in the
freezer
permanently so
that you can
make your
desserts
anytime.
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page6

7
and make your own creations.
• As the mix will increase in volume during preparation, do not
exceed 4.2 cups of mix for sorbets and 4.22 cups for ice
creams (Fig. 8). Recommended Mixture: 2.53 cups full-cream
milk (3.5% fat) and 1.69 cups whipping cream (3.5% fat).
• Make certain the appliance is unplugged and start assembling
the components. When removing the bowl from the freezer,
take care to protect your hands to prevent freezer burn.
a) - Place the bowl in the lower ring.
- Holding it by its handles, lift up the ring then turn it
until it gets to the notches: a click signals its atta-
ched.
- Take the upper ring and while still holding the lower
ring by its handles, clip it in place (use the markings
to guide you). (Fig. 4).
b) Secure the motor unit to the lid and attach the
paddle into the motor unit (Fig. 5). Make sure the
motor unit is securely attached.
c) Place the lid (with the motor unit and the paddle) on
the bowl and turn clockwise to lock it (Fig. 6). Make
sure that the 4 locks are properly engaged.
• After connecting the ice cream maker, run it immediately
to avoid the paddle from freezing to the extremely cold
bowl.
• Always pour your mixture through the filling opening, once
the appliance is running. (Fig. 7).
• At any moment you can concoct your very own dessert by
carefully adding other ingredients through the opening
(nuts, fruits, sweets, etc.).
• It will take between 20 and 40 minutes to make the pre-
paration according to the recipe, the quantity of ice cream
and initial temperature of the ingredients. Once you have
obtained the desired consistency, turn off the appliance
and unplug it.
• When the ice cream or sorbet starts to set at the sides of
the bowl or on the surface, it is ready. To prevent strain on
the motor, the appliance will change the direction of
rotation when the mix becomes too compact. If this occurs
repeatedly, this means the ice cream preparation is ready.
Press the ON/OFF button to turn the appliance off. The
light will go off.
The paddle will
stir your
mixture evenly
throughout.
This ensures air
is circulated
into the dessert
(expansion) and
prevents the
formation of
crystals,
allowing you to
produce an ice
cream which is
nice and
creamy.
ATTE TIO !
The freezing
bowl is not
suitable for
storing the ice
cream for a
long time in the
freezer as it will
become too
hard. To store
the ice cream,
transfer to a
storage
container with
a lid.
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page7

• Remove the lid, raise the motor unit slightly and turn it
counter-clockwise. Remove the paddle. Disassemble the
motor unit pressing down on the 2 marks on the sides (Fig. 9).
• Using metal utensils could damage the freezing bowl. Only
use a wooden or plastic spatula to remove the ice cream.
• The ice cream can be kept in the freezing bowl before
serving or transferred to a storage container with a lid and
placed in the freezer.
Making second batch of ice cream or
sorbet
• Wash the bowl in warm water and dry thoroughly. Do not
use very hot or boiling water as the sudden temperature
change could damage the bowl. Return to the freezer. The
bowl will be partially chilled, so it will require less time in
the freezer, about 4-6 hours.
Safety features
• The product is equipped with a safety device that stops
the appliance automatically if it overheats. Overheating
may occur if the recipe you are preparing is very thick or if
the ice cream maker runs for too long or if the ingredients
added (e.g. walnuts, etc.) are not chopped finely enough.
To start the ice cream maker again, press the ON/OFF
button and let it cool down. After a few minutes you can
start it up again.
• Do not run the ice cream maker longer than necessary.
Cleaning instructions
• Disassemble the appliance.
• Only the lid (without the motor unit) and the paddle can
be washed in the upper rack of the dishwasher.
• The bowl and rings can be cleaned in warm soapy water
(do not use hot water).
• The motor unit must not be washed in the dishwasher.
Just wipe it with a damp cloth.
• Never clean the parts with abrasive products, as this could
damage them.
8
CAUTIO :
Do not run the
ice cream
maker inside
the freezer or
the refrigerator.
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page8

9
• Dry the bowl thoroughly before putting it back in the
freezer (without the rings).
Advice and tips
REDUCED FAT A D FAT-FREE RECIPE SUGGESTIO S
• Heavy cream gives ice cream its rich flavor and thick,
creamy consistency. However, to reduce calories and fat
content, the heavy cream used in the T-Fal recipes can be
replaced with light cream.
• To reduce calories and fat even further, substitute the
total amount of heavy cream and milk called for in a
recipe with an equal amount of regular or even fat-free
half-and-half cream. For example, if the recipe calls for 1
cup heavy cream and 1 ½ cups milk, replace total amount
with 2 ½ cups half-and-half cream.
• You may also replace full-fat sweetened condensed milk
with low-fat or even fat-free.
• While low fat or fat-free ice cream may not be as soft and
rich as full-fat ice cream, it will, however, be equally
delicious.
PREPARATIO
• Ice cream preparations containing a high proportion of
sugar, fats or alcohol may require more time to freeze or
may not stiffen.
• Only add alcohol once the ice-cream maker is running and
the preparation is already half frozen.
• We advise you to prepare the ingredients before taking
the bowl out of the freezer so that the bowl will be as cold
as possible on start-up.
• On start-up, any preparation poured into the freezing bowl
must be liquid. Do not use stiff ingredients like whipped
cream or already frozen liquids to prepare the ice cream.
• Plan your ice-cream or sorbet making the previous day.
Some recipes require the ingredients to be chilled for a
minimum of 12 hours in the refrigerator, before
transferring to the ice-cream maker for freezing.
• Some recipes require the milk to be heated to just below
boiling point, then it is whisked into the beaten eggs and
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page9

10
sugar, similar to making homemade custard. The mixture
is then returned to the heat, stirring constantly, until it
thickens slightly and forms a film over the back of a
wooden spoon. Do not let it boil or the mixture will
separate. If the mixture curdles at any stage during
preparation it can be processed in a blender or food
processor for one minute to make it smooth.
• Make sure that the ice cream maker is thoroughly clean,
especially the parts that come in contact with the mixture,
and all the equipment and utensils used when preparing
the mixture. Always use fresh ingredients that are within
their best before date, especially eggs, milk and cream.
• Add additional ingredients like chopped chocolate or
chocolate chips, finely chopped nuts or raisins through the
lid opening halfway through preparation when the
mixture just starts to freeze. If the pieces are too large
they may obstruct the paddle from turning.
Ice Cream Making Tips for Optimal Freezing
• The optimum refrigerator temperature for safe food
storage is between 35 and 38 degrees F. When making ice
cream, the prepared ice cream mixture should be chilled
at least 12 hours, or to 35 to 38 degrees F.
• You can speed up the ice cream making process of recipes
that do not require cooking. To do so, all ingredients must
be well-chilled in the refrigerator over night, including fruit
and canned milk products. Check the mixture temperature
with an instant read thermometer. If warmer than 38
degrees F, chill in the refrigerator, checking the
temperature periodically. When cold enough, quickly
prepare the mixture as called for in the recipe and make
ice cream immediately.
• Adding alcohol for flavoring may inhibit the ice cream
mixture from freezing thoroughly. To avoid this from
happening, use flavored extracts like rum and vanilla, or
add small quantities of alcohol towards the end of the ice
cream making process.
• Avoid using the ice cream maker when the kitchen is very
hot or near a hot stove or oven, as mixture may not freeze
well.
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page10

11
STORI G & SERVI G
• Ice cream and sorbet tastes best when freshly made, and
will lose its texture and fresh flavor if kept too long.
• It is normal for homemade ice cream to harden when
stored and the texture is different from the original soft,
spoonable consistency. To make serving stored ice cream
easier, remove from the freezer about 5–10 minutes
beforehand and store in the refrigerator to allow it to
soften slightly. Remember sorbets defrost quicker than
ice-cream.
• Defrosted or partially defrosted ice cream must never be
re-frozen.
Environment protection first !
HELP PROTECT THE E VIRO ME T!
Your appliance contains valuable materials which can be
recovered or recycled.
Please take this to your local recycling center for disposal.
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page11

12
MA UFACTURER's WARRA TY
: www.t-fal.com
With a strong commitment to the environment, most of T-fal products are
repairable during and after the warranty period. Before returning any
defective products to the point of purchase, please call T-fal consumer
service directly at the phone number below for repair options. Your help to
sustain the environment is appreciated!
The Warranty
This product is guaranteed by T-fal for 1 year against any manufacturing
defect in materials or workmanship, starting from the initial date of purchase.
The manufacturer's warranty by T-fal is an extra benefit which does not affect
consumer's Statutory Rights.
The T-fal warranty covers all costs related to restoring the proven defective
product so that it conforms to its original specifications, through the repair or
replacement of any defective part and the necessary labor. At T-fal’s
choice, a replacement product may be provided instead of repairing a
defective product.
T-fal’s sole obligation and your exclusive resolution under this warranty are
limited to such repair or replacement.
Conditions & Exclusions
The T-fal warranty only applies within USA, Canada & Mexico, and is valid only
on presentation of a proof of purchase. The product can be taken directly in
person to an authorized service centre or must be adequately packaged and
returned, by recorded delivery (or equivalent method of postage), to a T-fal
authorized service centre. Full address details for each country’s authorized
service centre are listed on the T-fal website ((www.t-fal.ca)) or by calling the
appropriate telephone number listed below to request the appropriate postal
address.
T-fal shall not be obligated to repair or replace any product which is not
accompanied by a valid proof of purchase.
This warranty will not cover any damage which could occur as a result of
misuse, negligence, failure to follow T-fal instructions, use on current or voltage
other than as stamped on the product, or a modification or unauthorized
repair of the product. It also does not cover normal tear and wear,
maintenance or replacement of consumable parts, and the following:
- using the wrong type of water or consumable
- damage due to water, dust or insects entering the product;
- mechanical damages, overloading
- damages or bad results due to wrong voltage or frequency
- accidents including fire, flood, lightning, etc
- professional or commercial use
- damage to any glass or porcelain ware in the product
TF_SORBETIERE_2551149-04_EMERIL 16/07/12 08:41 Page12
