TA R-Net LED User manual

OPERATING MANUAL
R-Net LED/LCD
R-Net Attendant
This product fulfils the requirements of
Regulation (EU) 2017/745 on medical devices.
300-61 UM JSM, CJSM & attended - GB - 06.2021, vers. 1:0

2
Table of Contents
Symbol key 5
Introduction 5
Models 5
Specications 5
Usage 5
Adjustment 6
Use after a period of storage 6
Product life span 6
Safety precautions 6
Connection of two JOYSTICK MODULES 7
Overview 8
JSM <LED> joystick module 8
Push-button control panel 8
LED indicators 8
CJSM <LCD> joystick module 9
Push-button control panel 9
LED indicators 9
LCD display 10
Attendant module 11
Push-button control panel 11
LED indicators 11
Buttons and symbols 12
Attendant control 13
Preparations BEFORE use 15
Charging the batteries 15
Turning on the wheelchair 15
Locking the joystick module 16
Using the keypad to activate the lock 16
Deactivating the lock 17
Auto-shutdown 18

3
Pre-drive inspection 19
Battery indicator 19
Interpretation 19
Pre-set maximum speed 20
Attendant control 21
Speed levels 22
Mode menu 23
Drive mode 23
Settings mode 23
Joystick 24
Driving and steering manoeuvres 24
Braking the electric wheelchair 24
Attendant control 25
Selecting a control mode 25
Electronic adjustments 26
Selecting an electronic adjustment 26
<LED> joystick module 26
<LCD> joystick module 27
Standard electronic adjustments 27
Complex electronic adjustments 28
Special features of the <LCD> joystick module 29
Odometer (total kilometres) 29
Trip counter 29
Resetting the trip counter 29
Driving program 30
Settings menu 31
Accessing the Settings menu 31
Menu navigation 31
Gyro 32
Enabling/disabling the gyro 32
External connectivity options 33
Connecting external accessories 33
Removing external accessories 33

4
Troubleshooting 34
<LED> joystick module 34
Display of errors via the battery indicator 34
Display of information via the battery indicator 36
Display of information via the pre-set maximum speed indicator 37
<LCD> joystick module 38
Maintenance/repair 41
Repairs 41
Service 41
Technical safety inspections 41
Daily inspections 41
Weekly inspections 41
Annual inspections 41
Technical data 42
Warranty/guarantee 42
Warranty/guarantee form 43

5
SYMBOL KEY
Safety precautions with a coloured back-
ground must always be followed!
☞This symbol designates a precaution or
recommendation.
[ ] Refers to an image number.
( ) Refers to a functional component in an
image.
INTRODUCTION
Read this manual before you use the
wheelchair for the first time and follow
the instructions carefully. If children or
teenagers will be using the wheelchair,
they should first read this manual along
with their parents or guardians before us-
ing the chair.
The electric wheelchair is controlled via the
joystick module.
☞Accessories and extra features such as
e.g. external push buttons are not part
of the standard delivery.
If you use the joystick module or its acces-
sories inappropriately, you may put yourself
or others at risk, therefore, it is important to
learn to use the equipment properly.
This operating manual will help you get
comfortable using the joystick module so
that you can avoid accidents.
For visually impaired users, PDF files with
additional information about our products
are available on our website.
☞Contact your distributor if you have any
questions.
Your electric wheelchair’s Operating man-
ual also includes information on product
safety as well as any product recalls that
may be in effect.
MODELS
This operating manual applies to the fol-
lowing joystick modules:
JSM <LED> joystick module
CJSM <LCD> joystick module
Attendant module
SPECIFICATIONS
The joystick module has been developed
for electric wheelchairs with R-Net electron-
ics.
USAGE
The joystick module must only be connect-
ed to the electric wheelchair via the R-Net
electronics.

6
ADJUSTMENT
Read this manual before you use the
wheelchair for the first time and follow
the instructions carefully. If children or
teenagers will be using the wheelchair,
they should first read this manual along
with their parents or guardians before us-
ing the chair.
As a general rule, any type of adjustment
or customisation must be performed by a
distributor.
Before you use the joystick module for the
first time, your distributor must adjust it.
Aside from your driving experience and
special needs, this adjustment must also
take into account the environment in which
the wheelchair primarily will be used.
If your needs or requirements change, the
distributor can adjust the sensitivity of the
joystick.
☞We recommend routine inspection of
the joystick module settings to ensure
optimal long-term comfort, including
whenever your medical/disability situ-
ation changes.
USE AFTER A PERIOD OF
STORAGE
The joystick module may be put into use
again. Before any reuse, the module must
be thoroughly inspected for any defects or
malfunctions.
☞Hygienic measures, including disinfec-
tion, must be performed in accordance
with a validated hygiene plan.
PRODUCT LIFE SPAN
We estimate that the product should have
an expected average life span of 4 years,
provided it is used for its intended purpose
and all maintenance and service require-
ments are met. The actual life span depends
on how frequently the product is used, the
environment where it is used and the care
that it receives. Replacement parts may al-
low you to prolong the product’s life span.
As a rule, replacement parts can still be ob-
tained for up to 5 years after a model has
been phased out of production.
☞This indicated estimated life span shall
not constitute any expression of the
warranty period.
SAFETY PRECAUTIONS
☞Do not throw or drop the dismantled
joystick module. Handle it carefully at
all times! This is the only way to ensure
continuous, error-free operation.
☞Do not unplug the connector while
driving.
☞When driving, only press the ON/OFF
button in an emergency.
– This stops the electric wheelchair
(emergency braking).
☞Do not plug any objects aside from the
manufacturer’s original charger plugs
into the joystick module charging sock-
et.
– Risk of a short circuit!

7
CONNECTION OF TWO
JOYSTICK MODULES
This must only be performed by the dis-
tributor.
It is possible to connect two joystick mod-
ules to the R-Net system.
This option may be helpful if an attendant
will be operating the electric wheelchair
and the joystick module does not need to
be moved to the back of the wheelchair.
The second joystick module can be used for
other functions, such as e.g. an external joy-
stick or on/off button, turn signals, a horn
etc.
The joystick module that is turned on will
be set on Drive mode.
Both joystick modules show the same dis-
play concurrently. Either of the joystick
modules can be used to turn off the wheel-
chair.
In the top left corner, you can see which
joystick module is active. See point 25 on
page 10

4
7
10
5
8
11
3
6
9
15
16
12
13
14
17
18
2
1
8
OVERVIEW
JSM <LED> joystick module
(1) Joystick
(2) Charging socket
Push-button control panel
(3) Left turn signal, on/off
(4) Deceleration
(5) Hazard light, on/off
(6) Horn
(7) Joystick module, on/off
(8) Lights, on/off
(9) Mode selector
(10) Acceleration
(11) Right turn signal, on/off
LED indicators
(12) Left turn signal
(13) Selected electronic adjustment (mode)
(14) Hazard light
(15) Battery charge level and error messages
(16) Lights turned on
(17) Information and pre-set speed
(18) Right turn signal
☞The LED indicators light up whenever a
function is activated.

6
9
12
7
10
13
5
8
14
18
15
16
17
19
3
2
1
4
11
9
CJSM <LCD> joystick module
(1) Joystick
(2) Charging socket
(3) Jack for external Mode push button (11)
or external controller
(4) Jack for external On/o push button (9)
Push-button control panel
(5) Left turn signal, on/off
(6) Deceleration
(7) Hazard light, on/off
(8) Horn
(9) Joystick module, on/off
(10) Lights, on/off
(11) Mode selector
(12) Acceleration
(13) Right turn signal, on/off
(14) Driving profile (selector)
LED indicators
(15) Left turn signal
(16) LCD display
(17) Hazard light
(18) Lights turned on
(19) Right turn signal
☞The LED indicators light up whenever a
function is activated.

23
26
25
19
17
27
24
29 28
22
30
10
LCD display
(17) Battery level indicator
(19) Maximum speed setting
(22) Speed display
(23) Display of elapsed kilometres
(24) Clock
(25) Symbol displaying the active joystick
module
☞Only appears if two joystick mod-
ules are connected
(26) Battery symbol
(27) Display of actual driving speed or elec-
tronic power consumption.
☞The number of illuminated seg-
ments increases in line with your
driving speed or power consump-
tion.
(28) Warning symbol
(29) Display of the selected profile
(30) Display in the event of active braking
(orange) or stopping (flashing red).
If the symbol is yellow, the wheelchair's
speed has been reduced. This is be-
cause the seat lift has been adjusted
higher than 5.5 cm and/or the seat tilt
exceeds 14°. If the symbol is red, the
wheelchair's Drive mode has been dis-
abled.

1
2
5
4
3
87
6
11
Attendant module
(1) Joystick
(2) Support plate
Push-button control panel
(3) Pre-set maximum speed
(4) Mode selector
(5) Toggle button (user/attendant control)
LED indicators
(6) Control mode (user)
(7) Control mode (attendant)
(8) Pre-set maximum speed levels

12
BUTTONS AND SYMBOLS
On/o To turn the wheelchair on or off
☞On start-up, the electronics perform a system test.
Horn An audible tone sounds the entire time the button
remains depressed.
Prole When pressed, switches to the next driving profile.
☞Only for the LCD joystick module.
☞Follow the instructions in the chapter Driving program on page 30.
Max. pre-set
Plus speed.
Increases the max. speed one level at a time (20%).
☞We recommend only using the Plus button
when the electric wheelchair is in a stationary
position.
☞Level 1 (20%) up to a max. level of 5 (100%).
Max. pre-set
Minus speed.
When pressed, decreases the max. speed one level at
a time (20%).
☞For safety reasons, we recommend only using
the Minus button when the wheelchair is in a
stationary position.
☞Level 5 (100%) down to a min. level of 1 (20%).
Hazard light When pressed, turns the hazard light on or off.
☞The indicator lamp flashes in time with the turn signal.
Lights When pressed, turns the lights on or off.
☞The indicator lamp flashes when the lights are turned on.
Left turn
signal
When pressed, switches the turn signal on or off.
☞A rapidly flashing indicator lamp means that a turn signal is defective.
Right turn
signal
When pressed, switches the turn signal on or off.
☞A rapidly flashing indicator lamp means that a turn signal is defective.
Mode When pressed, toggles between Drive mode and Set-
tings mode.
☞Only press the Mode button when the electric wheelchair is in a sta-
tionary position.
☞Follow the instructions in the chapter Mode menu on page 23.

13
BUTTONS AND SYMBOLS
Electronic
adjustment
The illuminated area within the symbol indicates
which electronic setting is selected.
☞Follow the instructions in the chapter Electronic adjustments on
page 26.
LCD display When the wheelchair is turned on, various indicators
appear on the LCD display.
☞Follow the instructions in the chapter Special features of the < LCD >
joystick module on page 29.
Battery indi-
cator
The number of segments that light up on the battery
indicator decreased in line with the battery’s charge
level.
☞Follow the instructions in the chapter Battery indicator on page 19.
Display of the
max. speed
The number of illuminated diodes/segments (LCDs)
indicates the maximum speed.
Each LED/segment corresponds to an additional 20%
level.
Attendant control
Pre-set speed When the button is pressed, increases the max. pre-
set speed one level at a time (20%).
☞Level 1 (20%) up to a max. level of 5 (100%).
Display of the
max. speed
The number of illuminated diodes (LEDs) indicates
the pre-set maximum speed.
☞Each LED corresponds to an additional 20% level.
Control mode Toggles between user and attendant control with
each press of the button.
Pre-set con-
trol mode
indicator
The illuminated diodes (LED) below the symbols
show which control mode has been selected.

14
Attendant control
Mode When pressed, toggles between Drive mode and Set-
tings mode.
☞Only press the Mode button when the electric wheelchair is in a sta-
tionary position.
☞Follow the instructions in the chapter Mode menu on page 23.

2
9
9
17
19
15
PREPARATIONS BEFORE
USE
Charging the batteries
Do not insert objects aside from the safe-
ty plug and battery charger plug into the
charging socket. – Risk of a short circuit!
To charge the batteries, first turn off the joy-
stick module and plug the charger into the
joystick module’s charging socket (2), then
plug the power cord into the wall socket.
☞See also Electric wheelchair operating
manual.
Turning on the wheelchair
Do not touch or move the joystick during
the start-up phase (lasts approx. one sec-
ond)!
Press the ON/OFF button (9) to turn on the
joystick module. The electronics will now
perform a system test.
Once the battery indicator lights up continu-
ously, the electronics are ready for use.
☞Flashing lights or a sequential series
of lights in the battery indicator (17) or
pre-set maximum speed indicator (19),
respectively, indicate various error mes-
sages or information. – Follow the in-
structions in the chapter Troubleshoot-
ing on page 34.
☞If the pre-set maximum speed indicator
fails to light up when the wheelchair
starts up, it means that the chair is in
attendant control mode. – Follow the
instructions in the chapter Attendant
control on page 25.
When you have finished driving, turn off the
joystick module by pressing the on/off but-
ton (9). This disables the electric wheelchair.

19
9
1
16
Locking the joystick module
The electric wheelchair can be locked to
prevent unauthorised use. While this is not
configured by default, your distributor can
add this feature on request.
The lock is engaged when:
<LED> joystick module - The speed indica-
tor (19) displays a sequential series of lights.
<LCD> joystick module - The LCD display
shows a padlock symbol [1].
Using the keypad to activate the lock
1. While the joystick module is turned on,
depress and hold the on/off button (9)
until you hear a short, audible <beep>,
then release it.
2. Push the joystick all the way forward
(normal forward driving) and wait until
you hear a short <beep>.
3. Push the joystick all the way back (re-
verse) and wait until you hear a short
<beep>.
4. Release the joystick.
☞When a prolonged <beeeeep> tone
sounds, it signals that the lock has been
activated.
The electronics disable Drive mode, and the
joystick module automatically turns off after
a few seconds.

2
1
9
17
The lock key feature
After you turn on the joystick module, plug
the lock key [1] into the charging socket (2).
Remove the lock key plug after you hear a
short <beep>.
☞The electronics disable Drive mode,
and the joystick module automatically
turns off after a few seconds.
Deactivating the lock
Push-button operation
1. Turn on the joystick module by press-
ing the on/off button (9).
2. Push the joystick all the way forward
(forward driving) and wait until you
hear a short <beep>.
3. Push the joystick all the way back (re-
verse) and wait until you hear a short
<beep>.
4. Release the joystick.
☞A prolonged <beeeeep> signals that
the lock has been deactivated.
5. The wheelchair is now ready for use.
The lock key feature
After you turn on the joystick module, plug
the lock key [1] into the charging socket (2).
Remove the lock key plug after you hear a
short <beep>.
☞The lock is now deactivated.
The wheelchair is now ready for use.

18
Auto-shutdown
To conserve battery power, your electric
wheelchair can be configured to shut down
automatically.
While this is not the default setting, it can be
configured by your distributor.
Unless you move the joystick or press a
button, once your chosen timeout period
expires, the wheelchair shuts down auto-
matically.
☞The timeout period can be set from 1
to 30 minutes.

17
17
19
PRE-DRIVE INSPECTION
Battery indicator
After you turn the joystick module on, after
a short system test, the battery indicator
(17) displays the battery charge level.
As the batteries drain, the battery indicator
will show an increasingly smaller number of
illuminated segments (17).
☞This indicator is made up of 10 seg-
ments (3 red, 4 yellow/orange and 3
green).
The colour of the segments indicates:
Green The batteries are charged.
☞The battery level corre-
sponds to the number of
green indicators that light
up.
Yellow Recharging is advisable.
Red The batteries are empty. Re-
charge as soon as possible.
☞The battery indicator is only accurate
when travelling on flat surfaces.
☞When driving up or down a gradient,
the reading will be unreliable.
Interpretation
The battery indicator has been designed for
the discharge properties of the manufactur-
er's original batteries. Aftermarket or other
batteries may have divergent properties
that negatively affect reliability.
Moreover, since an accurate reading is con-
tingent on the age of the batteries and the
temperature and load to which they are ex-
posed, certain limitations apply.

19
19
6
12
6
12
20
Pre-set maximum speed
Risk of an accident due to:
– Inappropriately set maximum speed
level.
– Select a lower maximum speed level
while driving!
The max. speed level must be selected
according to your personal circumstances
and particular driving situation!
When driving downhill adjust the max.
speed in proportion to the steepness of
the gradient. Never exceed the maximum
allowable speed. – Risk of an accident!
When you turn the joystick module on, it
automatically recalls and reactivates the last
max. speed setting.
The number of diodes (LEDs) or segments
that light up in the pre-set max. speed indi-
cator (19) indicate the max. speed level set-
ting.
Before or while driving, pressing button (6)
or (12), respectively, increases or decreases
the maximum speed one level at a time.
☞Please see chapters Speed levels on
page 22 and Buttons and symbols on
page 12 in this context.
