Tacony Powr-Flite NM2000 Installation and operation manual

OPERATOR’S MANUAL & PARTS LIST
WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL
COMPLETELY BEFORE OPERATING THIS EQUIPMENT.
©Tacony, Inc., All rights reserved
Save These Instructions
1600 RPM
Model NM1600
2000 RPM
Model NM2000
2000 RPM
Model NM2000DC
Ultra High Speed Burnishers
X8442A 12-2016

2
Your new Powr-Flite®Ultra High Speed Burnisher will afford you many years of trouble-free operating satisfaction provided it is given
proper care. Prior to packaging, your Powr-Flite®Ultra High Speed Burnisher was inspected by a Quality Control Technician.
SAFETY INSTRUCTIONS
This Floor Machine should be grounded while in use to protect the
operator from electric shock. This machine is equipped with a 3-conductor
cord and a 3-prong grounded type attachment cap plug to fit the proper
grounding type receptacle. The green (or green and yellow) conductor in
the cord is the grounding wire. Never connect this wire to anything other
than the grounding blade.
The Floor machine is provided with an attachment cap plug, as shown in
Sketch A, and is intended for use on a nominal 120 volt circuit. If a properly
grounded receptacle, as shown in Sketch A, is unavailable, an adaptor, as
shown in Sketch C, is available and should be installed, as shown in Sketch
B, if the outlet box that houses the receptacle is grounded. Be sure to fasten
the grounding tap to the faceplate screw.
These guidelines are presented for your protection and convenience.
Please read them carefully, since a failure to heed these precautions could
result in discomfort or injury. When using an electrical appliance, basic
safety precautions should always be followed.
ONE LAST REMINDER!
Read All Instructions, Warnings and Cautions Before Using!
WARNING
TO AVOID FIRE, DO NOT USE WITH A FLAMMABLE OR
COMBUSTIBLE LIQUID TO CLEAN FLOOR.
METAL SCREW
COVER OF GROUNDED
OUTLET BOX
( B )
( A )
GROUNDING PIN
GROUNDING
MEANS
ADAPTER
( C )
WARNINGS
READ THIS OPERATOR’S MANUAL!
WARNING: You must have training in the operation of this machine before using.
WARNING: Machines can burn flammable materials and vapors. Do not use this machine with or near fuels, grain dust, solvents, thinners or other
flammable materials.
WARNING: Do not operate this machine unless it is completely assembled.
WARNING: Do not use this machine as a step or to move furniture.
WARNING: When disconnecting power cord from electrical outlet, grasp the plug. Pulling it out by the cord itself can damage cord insulation and internal
connection to plug. To prevent electric shock, always remove the electrical plug from the electrical outlet before doing any repairs or maintenance to
this machine.
WARNING: To prevent injury, always remove the electrical plug from the electrical outlet before changing the polishing pad and before leaving the machine.
WARNING: To prevent injury, keep hands, feet and loose clothing away from the rotating pad.
WARNING: Maintenance and repairs must be done by authorized personnel only.
WARNING: Keep all fasteners tight. Keep adjustments according to specifications.
WARNING: Keep the electrical parts of the machine dry. For storage, keep the machine in a building.
WARNING: Always use a three-wire electrical system connected to the electrical ground. For maximum protection against electric shock, use a circuit that is protected
by a ground fault circuit interrupter. Consult with your electrical contractor.
WARNING: To prevent damage to the power cord, do not let the pad, pad driver or wheels touch the power cord when the machine is running. Always lift the power
cord over the machine.
WARNING: Make sure all labels, decals, warning, cautions and instructions are fastened to the machine.

3
UNCRATING
Your Powr-Flite Ultra High Speed Burnisher was protectively packed to prevent damage
in shipment. We suggest that upon removing the unit from its carton, you carefully inspect it for
any possible damage in transit. If damage is discovered, immediately notify the transportation
company who delivered your machine. As a manufacturer, we are unable to act upon any claim
for concealed damage; you must originate the claim.
IMPORTANT SAFEGUARDS
This machine is designed to be safe when used to perform the functions specified in this
Operator’s Manual. Should damage occur to electrical or mechanical parts, the machine
should be repaired by the manufacturer or competent service station before using in order
to avoid further damage to the machine or physical injury to user. Your floor machine is
equipped with a safety switch lockout device designed for your safety. Do not attempt to
bypass or defeat the safety lockout device. Never use any device to lock the power switch
triggers in the ON position.
INSTRUCTIONS
Application
The NM1600, NM2000 and NM2000DC Ultra High Speed Burnishers are used to achieve and/
or maintain a high gloss appearance on an established floor finish. The high pad revolution
of the floor burnisher combined with a good polishing pad will turn properly established
cleaned floor finish into a high gloss, hardened finish known as the “wet look shine”. The
pads recommended with the NM1600, NM2000 and NM2000DC are the Powr-HD beige or
white synthetic pads or the natural hogs hair blended pads.
Preparation of Surface
Before each use of this machine, the floor must be dust mopped with a treated mop and if
necessary clean the floor with a damp mop, using a solution of water and neutral cleaner.
PREPARE THE MACHINE FOR OPERATION
WARNING: To prevent injury, always remove the electrical plug from the electrical outlet
before changing the polishing pad and before leaving the machine.
• With the handle locked, tip the machine back until the handle is lying flat on the floor.
• To remove the pad-lock pad holder from the flexible pad driver, grasp the center support
with your thumb and forefinger and turn the collar counter-clockwise. (Fig 1)
• Place a clean or new 20” buffing pad over the alignment ring on the pad holder.
• Replace the collar by turning clockwise until snug. (Fig 2)
• Step back and lift the burnisher to the upright position.
• Connect the power cord into a grounded, 3-wire outlet.
• The NM1600 Burnishers should be operated with the handle in the unlocked “floating”
position to provide excellent maneuverability and automatic
pad contact.
The NM2000 and NM2000DC are designed for maintenance of large, open areas.
To prevent excessive pad drag or uneven burnishing where tight, repetitive turns are
necessary, lock the handle for manual control of pad contact.
NOTE: The hardened steel cam release lever does not require extreme tightening to
effectively hold the handle in position. Over-tightening will shorten the functional life of
the lever. (Fig 3)
CAUTION: Do NOT operate the Millennium dust-control
burnisher (Item# NM2000DC) without a dust skirt.
Fig 1
Fig 2
Fig 3

4
HOW TO OPERATE THE MACHINE
• Plug the machine in as directed and lower the handle to the desired operating height and
leave the cam lever unlocked. Push the safety switch forward (Fig 4) and squeeze the switch
triggers beneath the handle grips. This activates the motor and starts the block, brush or
attachment in operation. Each time you release the triggers the safety switch will reset. You
will need to follow the direction above to restart the machine. CAUTION: When leaving the
machine unattended, disconnect the wall plug and return the handle to the “locked”
upright position to prevent accidental starting.
• Push the machine forward in a straight line, at a slow walking speed. Overlap each pass by
about 1 inch (25 mm).
AFTER USING THE MACHINE
• Upon completion, dust mop with treated mop to pick up all burnishing residue.
• The condition of the floor pad has direct affect on the performance of your burnisher. When
the pad becomes dirty, turn it over and use the other side. When finished, wash the pad out
and allow it to dry completely before using again.
• Unplug the power cord and wrap it under the cord hook and over the right handle grip.
• Tip the machine back and remove floor pad.
• Wipe off the machine housing and the cord. This will prevent build-up of unnecessary
residue.
TRANSPORTING
Use the rear wheels for transporting the NM1600, NM2000 and NM2000DC. This
will insure that the operating wheels remain clean and smooth for use on clean floor
surfaces. (Fig 5)
MAINTENANCE
• Once a month, remove the motor cover of the unplugged NM1600, NM2000 and
NM2000DC by removing the motor cover screws.
• Vacuum out any dust or debris which has accumulated in the motor. (Fig 6)
• Replace motor cover and replace the motor cover screws.
• Check and maintain tightness of all fasteners.
WARNING: do not over-tighten switch housing screws.
• Keep the burnisher clean, especially at the handle tube and collar so the
handle tube will move freely through the collar.
• Inspect cord and plug for cuts, gashes or loose prongs; replace as needed.
• For the NM2000DC dust-control burnisher, periodic cleaning and filter/filter tube inspection
for clogs, debris, and/or obstructions is recommended. If the filter is no longer serviceable,
contact Powr-Flite for a replacement filter, P/N 19069.
• The length of the carbon brushes should be inspected annually. If they are no longer
extended past the holder window, they should be replaced.
• Replacement of carbon brushes should be done only by a qualified service technician.
• Disassembly of this motor voids the warranty.
• Improper disassembly and assembly of this motor can permanently damage the armature.
Fig 5
Fig 6
Switch
Trigger
Safety
Switch
Fig 4

5
Drive Belt Adjustment
See picture Fig 7
1. Remove three (3) phillips head screws holding the pad center grip.
2. Remove four (4) large, slot head screws holding drive pad.
3. Loosen pulley mount bolts (A) with 9/16” deep socket wrench.
Do not remove the bolts.
4. Using a 1/2 box wrench, turn adjustment nut (B) until it touches the adjustment bolt head.
Turn the adjustment bolt to tighten or loosen the belt tension.
5. Correct belt tension allows belt (C) no more than 1/4” of side movement.
6. Tighten the four (4) pulley mount bolts with the 9/16” socket wrench.
7. Loosen the adjusting bolt (D) until it is snug against adjustment stop molded in housing
and turn adjustment nut against pulley mount bracket.
8. Replace pad driver and pad center grip.
TROUBLESHOOTING
Burnisher tends to move to the right.
• Do not lift up on handle while operating the burnisher.
• Do not operate with handle set too high. Recommended handle height is from your waist
with your arms extended forward.
Burnisher does not run.
• Circuit breaker has tripped. Allow circuit breaker to cool two minutes before resetting
(NM2000 and NM2000DC only).
Prevent circuit overload.
• Do not spray buff with the NM1600, NM2000 and NM2000DC. Apply a restorer, such as
Powr-Gloss®, allow to dry, then burnish.
• Check pad and change if dirty or rough.
• Check area being burnished for cleanliness, area should be damp mopped, scrubbed or
swept with treated broom.
• Operator should not continually force the machine with handle pressure.
• Operator should not try to operate burnisher in a side-to-side motion.
• Eliminate any extension cord that is smaller than 12/3 wire or greater than 25 feet in length.
Burnisher will not start.
• Plug is broken or has loose contact. Replace.
• Switch is defective. Replace switch.
• Rectifier is defective. Replace.
Fig 7
A
B
D
C

6
14
13
15
16
17
18
19
20
22
21
23
24
25
25
26
27
28
28
28
30
29
29
31
32
32
33
33
34
35
36
36
38
38
38
37
39
40
41
42 43
44
46
46
45 47
48
49
50
51
52 54
53
55
56
57
58
59
60
2
2
1
3
4
5
6
7
8
10
9
11
12
Models NM1600, NM2000

7
ref# order description QTY
17BG004 Grommet 1
27CY001 Washer #10 3
3M1407G Cord 1
4SR36 Strain relief washer 2
5SR37 Strain relief 1
6X1039 Switch 25a 1.5Hp 1
7X1184 Cam lever 1
8X1456 Handle clamp assembly 1
9X1457 Motor cover, m series, blue 1
10 X8008N Steel conduit 1
11 X8013 Cord hook 1
12 X8016 Knob 1
13 X8020 Washer, countersunk, axle 4
14 X8022 Inline cord 1
15 X8024 Wheel black 5” x 1-1/4” 2
16 X8027L Bracket brace handle, left 1
17 X8027R Bracket brace handle 1
18 X8028 Washer, cam w/slot 1
19 X8030J Bumper 1
20 X8037-TI Motor 120v 1
21 X8050AP Housing, black 1
22 X8091 Shaft and plate weldment 1
23 X8092 Bearing spacer 1
24 X8096 Main pulley 1
25 X8098 Bearing 2
26 X8101 Wave spring washer 2
27 X8151B Plug 1
28 X8207 Screw 10-24 x 1/2 phil pan 5
29 X8212 Washer-lock (1/4”) 4
30 X8216 Screw 5/16-18 x 1-1/2 phil at 4
31 X8217 5/16 Spring washer 1
32 X8218 Washer 5/16 sae at zinc 4
33 X8219 Washer 3/8 sae at zinc 4
34 X8222 Set screw 1
35 X8223 Screw 3-8/16 x 3/4 hex cap 4
36 X8226 Screw 1/4-20 x 1-1/4” hex
head cap zinc plated
4
37 X8227 Bolt 5/16-18 x 1 1/4 hex tap 1
38 X8230 Washer 3/8 uss at zinc 6
39 X8231 Nut 5/16 hex nish zinc 1
40 X8258A Bumper 1
41 X8258AS Screw 1
42 X8265 Screw 1/4-20 x 3/4 at phil 4
43 X8811 Pivot shaft handle 1
44 X8813 Pivot shaft brace 1
45 X8816 Axle 1/2” x 14-1/2” 1
46 X8821 Screw, #8-32 x 1/2”l, pnhd,
ph, zp
6
ref# order description QTY
47 X8822 Spacer 2
48 X8862 Flexible pad driver kit 1
49 X8889 /
X9298
1600 Rpm pulley / 2000 rpm
pulley
1
50 X8911 Handle 1
51 X8914 Thumb switch actuator 1
52 X8915 Spring thumb actuator 1
53 X8916 Spring trigger 2
54 X8917 Trigger handle 1
55 X8918 Roll pin 1
56 X8922 Insulation sheet 1
57 X8935 Wheel 4x1-1/2”, black 2
58 X8936 Axle 13 3/4’ x 1/2’ 1
59 X8941 Handle grip 2
60 X9327 Screw 5/16 x 3/4 hex cap 1

8
14
13
15
16
17
18
19
20
22
21
23
24
25
26
27
28 28
28
30
29
31
32
32
33
34
35
36
38
37
39
40
41 42
43
44
46
46
45
47
48
49
50
51
52
54
53
21
3
4
5
6
7
8
10
9
11
12
Models NM2000DC

9
ref# order description QTY
119069 Filter 1
27BG004 Grommet 1
37BS003 Screw 1/4-20 x 1/2 phil pan 8
4M1407G Cord 12/3 sjtw 75' gray 1
5PX73 Screw, #8-32 x 1/2"l, pnhd,
ph, zp
2
6SR37 Strain relief 1
7X1039 Switch 25a 1.5Hp 1
8X1184 Cam lever handle 1
9X1454 Pulley cover, dust control 1
10 X1455 Housing, 20" dust control 1
11 X1456 Handle clamp assembly 1
12 X1457 Motor cover, m series, blue 1
13 X1459 Axle, wheel, 1/2" x 16.475" 1
14 X1460 Axle, wheel, 1/2" x 15.25" 1
15 X1461 Skirt, 20" dust control 1
16 X1465 Tube, lter mount dust control 1
17 X1469 Clamp 1
18 X8013 Cord hook 1
19 X8016 Knob 1
20 X8020 Washer, countersunk, axle 4
21 X8022 Inline cord 49" 14/3 1
22 X8024 Wheel black 5" x 1-1/4" 2
23 X8027 Brace 2
24 X8028 Washer, cam, slotted 1
25 X8091 Shaft and plate weldment 1
26 X8092 Bearing spacer 1
27 X8098 Bearing ball rubber 2
28 X8207 Screw 10-24 x 1/2 phil pan 9
29 X8217 Washer, split lock 5
30 X8219 Washer 3/8 sae at zinc 9
31 X8227 Bolt 5/16-18 x 1 1/4 hex tap 1
32 X8230 Washer 3/8 uss at zinc 2
33 X8265 Screw 1/4-20 x 3/4 at phil 4
34 X8811 Pivot shaft handle 1
35 X8862 Flexible pad driver kit 1
36 X8889
X9298
"1600 O-groove pulley 1
37 X8911 2000 O-groove pulley" 1
38 X8914 Handle 1
39 X8915 Thumb switch actuator 1
40 X8916 Spring thumb actuator 2
41 X8917 Spring trigger 1
42 X8918 Trigger handle 1
43 X8922 Roll pin 1
44 X8935 Insulation sheet 2
45 X8941 Wheel 4x1-1/2", black 2
46 X9327 Handle grip 1" 9
ref# order description QTY
47 X9444 Screw 5/16 x 3/4 hex cap 4
48 X9676 Front strap 1
49 X8008N 8-18 3/4 Long hi lo screw 1
50 X8037-TI Nut, lock, 1/2" steel 1
51 X8096A Burnisher motor 120v ti 1
52 X8099-5 Pulley 1
53 X8151B Belt 40.5" 1
54 X8258A Plug plastic black bumper 1

A Tacony Company
3101 Wichita Court • Ft. Worth, TX 76140-1755
1-800-880-2913 • Fax: [phone] • www.Powr-Flite.com
X8442A 12-2016
