Tactical Power Products 12Vdc 2.5A Series User manual

DESIGNED & MANUFACTURED
12Vdc 2.5A Series
Installation Manual
MODELS :
TPS12-2.5DC
TPS12-2.5DC-B
TPS12-2.5DC-BD10
TPS12-2.5DC-BX
TPS12-2.5DC-BXD10
© 2016 The contents of
this manual are copyright
and may not be reproduced
without the written
permission of Tactical
Power Products Pty Ltd.
Engineered for CCTV

DANGER
HIGH VOLTAGE
CAUTION
Dangerous Voltages Inside !
No user serviceable parts inside
Do not remove covers
Dangerous internal voltages exceeding
400 Volts - DO NOT REMOVE COVERS !
Equipment must be installed & serviced
by suitably qualied service personnel in
a restricted access area.
M_TPS12-2.5DC_RevC.pdf www.tacpower.com.au
General
These power supplies are part of the Tactical ECO Range and are designed for indoor use only.
NOTE: DO NOT connect loads which exceed the output rating of the supply (2.5A) Failure to observe this precaution can lead to output
failure, requiring factory service.
TPS12-2.5DC models are high performance, extremely low noise, Dual Channel Switch Mode power supplies offering 12.4Vdc at 2.5A
continuous.
When operating from mains, these models provide an output of 12Vdc ( to power connected equipment) and are configured with a
separate 13.8Vdc battery charging channel. Battery charge current is approximately 700mA @ 13.8Vdc (total supply output current 3.2A )
In the event of mains failure, battery voltage is clamped to 12.4Vdc and instantaneously powers the load - this is particularly useful for
powering voltage sensitive loads such as CCTV cameras.. When the mains voltage is restored, batteries are disconnected from the load
and recharging commences automatically.
Output short-circuit and overload protection are provided . Removal of the fault / short circuit condition will return the power supply
to normal operation ( Auto-Reset ).
Model Variants
TPS12-2.5DC Single 2.5A Output + battery charger, supply only - no cabinet (225L x 120W x 60H )
TPS12-2.5DC-B Single 2.5A Output + battery charger, in small steel enclosure ( 250W x 310H x 100D mm )
TPS12-2.5DC-BD10 10 x 250mA Outputs + battery charger, in small steel enclosure ( 250W x 310H x 100 mm )
TPS12-2.5DC-BX Single 2.5A Output + battery charger, in medium steel enclosure ( 340W x 436H x 145D mm )
TPS12-2.5DC-BXD10 10 x 250mA Outputs + battery charger, in medium steel enclosure ( 340W x 436H x 145D mm )
Connection
Single Output Models Multiple Output Models
10-way removable terminal block provides the following:
( See over the page for a layout )
* 12.4Vdc Output
* 13.8Vdc Output for SLA (Sealed Lead Acid) Batteries
* AC OK Relay Output (Relay is NC when mains is OK)
* Battery Fault / Low Battery Relay Output ( SPDT )
(This relay is NO when Battery is OK, going NC when Battery
voltage drops below approx. 10.5V during AC Fail)
12Vdc Output is via individually fused outputs ( 10 way )
10-way removable terminal block provides the following:
( See over the page for a layout )
* 13.8Vdc Output for SLA (Sealed Lead Acid) Batteries
* AC OK Relay Output ( Relay is NC when mains is OK )
* Battery Fault / Low Battery Relay Output ( SPDT )
(This relay is NO when Battery is OK, going NC when Battery
voltage drops below approx. 10.5V during AC Fail)
Caution when handling batteries:
Exercise care when terminating and connecting batteries. Mishandling or short circuit of SLA batteries can cause severe damage and fire.

DESIGNED & MANUFACTURED
AOutput Terminals ( Multi Output models only ) BPDM Input ( Multi Output models only )
CIndividual Circuit Status LEDs ( Multi Output Models ) DIndividual Circuit Fuses ( Multi Output models only )
EAC Mains OK Output ( NO / COM / NC ) FBattery Low / Fault Output ( NO / COM / NC )
G- Battery + (Connect Sealed Lead Acid Battery) H- Output 12.4Vdc + ( Connect to load or PDM )
INot used in this model JBattery Test Fail LED ( Red ON = Fail )
KBattery Fuse Fail LED ( Red ON = Fail ) LAC Mains OK LED ( Green ON = OK )
MReverse Battery LED ( Red ON = Fail ) N240V IEC Mains Socket
OCompliance / Date of Manufacture Label ~
LAYOUT
www.tacpower.com.au
M_TPS12-2.5DC_RevC.pdf
E F G H
I J K
L M
A
B
C
D
Multi-Output Models TPS12-2.5DC Module Front Face
( e.g. TPS12-2.5DC-BD10 )
NO CO NC NO CO NC - + - +
N
Rear View
O

Designed & Manufactured
2.5DC 2.5DCB 2.5DC-BD10 2.5DC-BX 2.5DC-BXD10
Output Voltage 12.4 Vdc
Output Current 2.5A Continuous
Output Channels 1 1 10 1 10
Output per Channel 2.5A 2.5A 250mA 2.5A 250mA
Input Voltage 240 V ac ( +6% / -10% ) 50Hz
Input Current 0.4A @ full load
Input In-Rush Current <20A ( 25C cold start up )
Battery Charger 13.8Vdc / 700mA (Max)
Low Battery Indicator 1 x SPDT relay & Red LED
AC Input Indicator 1 x SPDT Relay & Green LED
Weight (Approx) 1.2Kg 4Kg 6Kg
Dimensions (mm) 226L x 123W x 60H 250W x 310H x 100D 340W x 436H x 145D
Overload Protection Hysteretic thermal shutdown with automatic fault recovery. Additional fuse for overload/over voltage
Load Regulation < 1% from open to full load
Line Regulation < 0.2%
Output Ripple 25mV p-p @ full load (Typical)
Working Temperature 0 - 50C
Revision D
Safety Standards AS NZS 60950:2003
EMC Standards AS/NZS CISPR 11:2004 ( Class B Conducted and Radiated )
Specications : ( In the interests of product improvement, Tactical reserves the right to change specifications without notice)
