TAD TAD-C2000 User manual

TAD-C2000
PRE AMPLIFIER
OWNER ’S MANUAL

2
3
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
If the AC plug of this unit does not match the AC
outlet you want to use, the plug must be removed
and appropriate one fitted. Replacement and
mounting of an AC plug on the power supply cord of
this unit should be performed only by qualified
service personnel. If connected to an AC outlet, the
cut-off plug can cause severe electrical shock. Make
sure it is properly disposed of after removal.
The equipment should be disconnected by removing
the mains plug from the wall socket when left unused
for a long period of time (for example, when on
vacation).
D3-4-2-2-1a_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 20 cm at top, 20 cm at rear, and 20 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
WARNING
This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230 V
or 120 V) written on the rear panel.
D3-4-2-1-4*_A1_En
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord
when your hands are wet as this could cause a short circuit or electric shock. Do not place the unit, a piece of
furniture, etc., on the power cord, or pinch the cord. Never make a knot in the cord or tie it with other cords. The
power cords should be routed such that they are not likely to be stepped on. A damaged power cord can cause a
fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your
dealer for a replacement.
S002*_A1_En
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which requires
repair will be charged for even during the warranty
period.
K041_A1_En
CAUTION
The switch on this unit will not completely shut off
all power from the AC outlet. Since the power cord
serves as the main disconnect device for the unit,
you will need to unplug it from the AC outlet to shut
down all power. Therefore, make sure the unit has
been installed so that the power cord can be easily
unplugged from the AC outlet in case of an accident.
To avoid fire hazard, the power cord should also be
unplugged from the AC outlet when left unused for a
long period of time (for example, when on vacation).
D3-4-2-2-2a*_A1_En
European model only
UK, Singapore, Malaysia, Hong Kong model only
2
3
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
If the AC plug of this unit does not match the AC
outlet you want to use, the plug must be removed
and appropriate one fitted. Replacement and
mounting of an AC plug on the power supply cord of
this unit should be performed only by qualified
service personnel. If connected to an AC outlet, the
cut-off plug can cause severe electrical shock. Make
sure it is properly disposed of after removal.
The equipment should be disconnected by removing
the mains plug from the wall socket when left unused
for a long period of time (for example, when on
vacation).
D3-4-2-2-1a_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 20 cm at top, 20 cm at rear, and 20 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
WARNING
This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230 V
or 120 V) written on the rear panel.
D3-4-2-1-4*_A1_En
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord
when your hands are wet as this could cause a short circuit or electric shock. Do not place the unit, a piece of
furniture, etc., on the power cord, or pinch the cord. Never make a knot in the cord or tie it with other cords. The
power cords should be routed such that they are not likely to be stepped on. A damaged power cord can cause a
fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your
dealer for a replacement.
S002*_A1_En
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which requires
repair will be charged for even during the warranty
period.
K041_A1_En
CAUTION
The switch on this unit will not completely shut off
all power from the AC outlet. Since the power cord
serves as the main disconnect device for the unit,
you will need to unplug it from the AC outlet to shut
down all power. Therefore, make sure the unit has
been installed so that the power cord can be easily
unplugged from the AC outlet in case of an accident.
To avoid fire hazard, the power cord should also be
unplugged from the AC outlet when left unused for a
long period of time (for example, when on vacation).
D3-4-2-2-2a*_A1_En
European model only
UK, Singapore, Malaysia, Hong Kong model only

English
2
3
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
If the AC plug of this unit does not match the AC
outlet you want to use, the plug must be removed
and appropriate one fitted. Replacement and
mounting of an AC plug on the power supply cord of
this unit should be performed only by qualified
service personnel. If connected to an AC outlet, the
cut-off plug can cause severe electrical shock. Make
sure it is properly disposed of after removal.
The equipment should be disconnected by removing
the mains plug from the wall socket when left unused
for a long period of time (for example, when on
vacation).
D3-4-2-2-1a_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 20 cm at top, 20 cm at rear, and 20 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
WARNING
This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230 V
or 120 V) written on the rear panel.
D3-4-2-1-4*_A1_En
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord
when your hands are wet as this could cause a short circuit or electric shock. Do not place the unit, a piece of
furniture, etc., on the power cord, or pinch the cord. Never make a knot in the cord or tie it with other cords. The
power cords should be routed such that they are not likely to be stepped on. A damaged power cord can cause a
fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your
dealer for a replacement.
S002*_A1_En
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which requires
repair will be charged for even during the warranty
period.
K041_A1_En
CAUTION
The switch on this unit will not completely shut off
all power from the AC outlet. Since the power cord
serves as the main disconnect device for the unit,
you will need to unplug it from the AC outlet to shut
down all power. Therefore, make sure the unit has
been installed so that the power cord can be easily
unplugged from the AC outlet in case of an accident.
To avoid fire hazard, the power cord should also be
unplugged from the AC outlet when left unused for a
long period of time (for example, when on vacation).
D3-4-2-2-2a*_A1_En
European model only
UK, Singapore, Malaysia, Hong Kong model only
2
3
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
If the AC plug of this unit does not match the AC
outlet you want to use, the plug must be removed
and appropriate one fitted. Replacement and
mounting of an AC plug on the power supply cord of
this unit should be performed only by qualified
service personnel. If connected to an AC outlet, the
cut-off plug can cause severe electrical shock. Make
sure it is properly disposed of after removal.
The equipment should be disconnected by removing
the mains plug from the wall socket when left unused
for a long period of time (for example, when on
vacation).
D3-4-2-2-1a_A1_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 20 cm at top, 20 cm at rear, and 20 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product,
and to protect it from overheating. To prevent fire
hazard, the openings should never be blocked or
covered with items (such as newspapers, table-cloths,
curtains) or by operating the equipment on thick carpet
or a bed.
D3-4-2-1-7b*_A1_En
WARNING
This equipment is not waterproof. To prevent a fire or
shock hazard, do not place any container filled with
liquid near this equipment (such as a vase or flower
pot) or expose it to dripping, splashing, rain or
moisture.
D3-4-2-1-3_A1_En
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230 V
or 120 V) written on the rear panel.
D3-4-2-1-4*_A1_En
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord
when your hands are wet as this could cause a short circuit or electric shock. Do not place the unit, a piece of
furniture, etc., on the power cord, or pinch the cord. Never make a knot in the cord or tie it with other cords. The
power cords should be routed such that they are not likely to be stepped on. A damaged power cord can cause a
fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your
dealer for a replacement.
S002*_A1_En
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which requires
repair will be charged for even during the warranty
period.
K041_A1_En
CAUTION
The switch on this unit will not completely shut off
all power from the AC outlet. Since the power cord
serves as the main disconnect device for the unit,
you will need to unplug it from the AC outlet to shut
down all power. Therefore, make sure the unit has
been installed so that the power cord can be easily
unplugged from the AC outlet in case of an accident.
To avoid fire hazard, the power cord should also be
unplugged from the AC outlet when left unused for a
long period of time (for example, when on vacation).
D3-4-2-2-2a*_A1_En
European model only
UK, Singapore, Malaysia, Hong Kong model only

4
5
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
CAUTION
This product satisfies FCC regulations when shielded
cables and connectors are used to connect the unit
to other equipment. To prevent electromagnetic
interference with electric appliances such as radios
and televisions, use shielded cables and connectors
for connections.
D8-10-3a_A1_En
Information to User
Alterations or modifications carried out without
appropriate authorization may invalidate the user’s
right to operate the equipment.
D8-10-2_A1_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product may expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
Wash hands after handling.
D36-P5_B1_En
U.S. model only
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Product Name: PREAMPLIFIER
Model Number: TAD-C2000
Responsible Party Name: PIONEER ELECTRONICS (USA) INC.
SERVICE SUPPORT DIVISION
Address: 1925 E. DOMINGUEZ ST. LONG BEACH, CA 90810-1003, U.S.A.
Phone: [phone]
URL: http://www.pioneerelectronics.com
D8-10-4*_C1_En
U.S. model only
4
5
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
CAUTION
This product satisfies FCC regulations when shielded
cables and connectors are used to connect the unit
to other equipment. To prevent electromagnetic
interference with electric appliances such as radios
and televisions, use shielded cables and connectors
for connections.
D8-10-3a_A1_En
Information to User
Alterations or modifications carried out without
appropriate authorization may invalidate the user’s
right to operate the equipment.
D8-10-2_A1_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product may expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
Wash hands after handling.
D36-P5_B1_En
U.S. model only
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Product Name: PREAMPLIFIER
Model Number: TAD-C2000
Responsible Party Name: PIONEER ELECTRONICS (USA) INC.
SERVICE SUPPORT DIVISION
Address: 1925 E. DOMINGUEZ ST. LONG BEACH, CA 90810-1003, U.S.A.
Phone: [phone]
URL: http://www.pioneerelectronics.com
D8-10-4*_C1_En
U.S. model only

English
4
5
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
CAUTION
This product satisfies FCC regulations when shielded
cables and connectors are used to connect the unit
to other equipment. To prevent electromagnetic
interference with electric appliances such as radios
and televisions, use shielded cables and connectors
for connections.
D8-10-3a_A1_En
Information to User
Alterations or modifications carried out without
appropriate authorization may invalidate the user’s
right to operate the equipment.
D8-10-2_A1_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product may expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
Wash hands after handling.
D36-P5_B1_En
U.S. model only
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Product Name: PREAMPLIFIER
Model Number: TAD-C2000
Responsible Party Name: PIONEER ELECTRONICS (USA) INC.
SERVICE SUPPORT DIVISION
Address: 1925 E. DOMINGUEZ ST. LONG BEACH, CA 90810-1003, U.S.A.
Phone: [phone]
URL: http://www.pioneerelectronics.com
D8-10-4*_C1_En
U.S. model only
4
5
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
CAUTION
This product satisfies FCC regulations when shielded
cables and connectors are used to connect the unit
to other equipment. To prevent electromagnetic
interference with electric appliances such as radios
and televisions, use shielded cables and connectors
for connections.
D8-10-3a_A1_En
Information to User
Alterations or modifications carried out without
appropriate authorization may invalidate the user’s
right to operate the equipment.
D8-10-2_A1_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product may expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
Wash hands after handling.
D36-P5_B1_En
U.S. model only
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Product Name: PREAMPLIFIER
Model Number: TAD-C2000
Responsible Party Name: PIONEER ELECTRONICS (USA) INC.
SERVICE SUPPORT DIVISION
Address: 1925 E. DOMINGUEZ ST. LONG BEACH, CA 90810-1003, U.S.A.
Phone: [phone]
URL: http://www.pioneerelectronics.com
D8-10-4*_C1_En
U.S. model only

6
CONTENTS
INTRODUCTION ...................................................................................................................................................7
Features.............................................................................................................................................................................7
BEFORE YOU START............................................................................................................................................8
Checking what’s in the box..............................................................................................................................................8
Inserting the batteries......................................................................................................................................................8
Controls and displays.......................................................................................................................................................9
Remote control ...............................................................................................................................................................11
INSTALLATION AND CONNECTIONS ................................................................................................................12
Installation.......................................................................................................................................................................12
Connecting your equipment..........................................................................................................................................13
Connections to input source components...................................................................................................................................13
Connection to output components (basic connection) ..............................................................................................................13
Connections to output components (Bi-AMP connections).......................................................................................................14
Connecting the power cord ...........................................................................................................................................................15
OPERATION........................................................................................................................................................16
Select input source.........................................................................................................................................................................16
Adjust sound volume......................................................................................................................................................................16
Changing settings ..........................................................................................................................................................................16
USB connections............................................................................................................................................................................17
About USB 2 (Audio Class 2.0) mode...........................................................................................................................................17
RESET button ..................................................................................................................................................................................17
TO BEGIN PLAYBACK ........................................................................................................................................18
Before turning on the power..........................................................................................................................................................18
Operation.........................................................................................................................................................................................18
TROUBLESHOOTING..........................................................................................................................................19
SPECIFICATIONS ................................................................................................................................................20
Maintenance ...................................................................................................................................................................................21
Thank you for buying this TAD product. Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.

English
7
T AD-C2000
INTRODUCTION
Inspiring the joy of listening
Technical Audio Devices Laboratories, Inc. (TADL) grew from the spirit to discover technologies to perfectly recreate the pure
sound of live performances with uncompromising craftsmanship. We have inherited our philosophy from Bart Locanthi—
recognized across the globe as the ultimate sound technologist—who believed that genuine technology is true to the basics
and that genuine technology places greater importance on sound quality than on technology for its own sake.
At TADL, we are honing our technology to create equipment that reproduces musical sounds that evoke both the energy and
impact of live music.
Features
The TAD-C2000 is a preamplifier featuring the newest in technology for a new age, complete with three digital
inputs and four analog inputs.
High-fidelity DAC with Ultra-high-Precision Crystal Generator (UPCG)1.
The master clock features an UPCG*1 with ultra-high C/N*2 ratio originally developed for the TAD-D600. The D/A converter
uses dual Burr-Brown PCM1794A digital-audio converters in a parallel balanced output, thereby producing both high fidelity
and high S/N ratio. A sampling rate converter is also featured; by reclocking with the ultra-high C/N master clock UPCG, the
D/A converter supports sampling frequencies from 32 kHz to 192 kHz, providing the ultimate in reproduction of input PCM
signals.
*1 Ultra-high-Precision Crystal Generator
*2 Carrier to Noise ratio
Asynchronous USB audio data transmission2.
Of the three digital inputs, one is designed for USB input (USB 2.0 high-speed) that supports USB Audio Class 2.0 for USB
audio data transmission. This makes it possible to use widely distributed music player software to listen to high-fidelity audio
sources with data rates up to 192 kHz*3.
This unit features an asynchronous USB audio data transmission engine uniquely developed by Pioneer to control the
transmission of input audio data. By reading the incoming data with the internal high-precision clock, a very high level of
audio quality is achieved.
*3 Supported USB sampling rates differ depending on the operating system of your computer.
The Quest for Symmetry: Duallogic-Circuit Technology3.
In order to most accurately transmit audio signals, it is critical that the circuitry be complete symmetrical in relation to the
polarity of the music signal. The unit’s analog circuitry utilizes full-balanced amplifying from input to output, while the L/
R audio circuits feature a symmetric layout of dual circuit board units, in these and other ways seeking for the utmost in
symmetry of circuit layout and L/R identity.
Damping Technology4.
Machined from an enormous block of solid aluminum, the silver upper case acts as the chassis that houses the electronic
parts determining sound quality. The massive, seamless chassis not only strongly resists external vibrations, but its
electrically stable ground potential facilitates achieving even greater stability in sound quality. Finally, the three-point
suspension insulators utilize gray cast iron with its excellent damping characteristics, and each insulator contacts the lower
case with a point-contact structure that further contributes to stable sound reproduction.
Custom electronic parts contribute to high-precision operation and high sound quality5.
The shaft bearings found in the INPUT SELECTOR and VOLUME dial feature a newly developed structure utilizing high-
precision bearings, entirely eliminating any sense of looseness, and enabling high-precision operation. The high-precision
volume circuitry enlists a newly developed high-precision resistance-ladder control, delivering low distortion (0.0005% or less
in the volume circuitry), and high-precision volume control (1/0.5 step select). Further, by designing the INPUT SELECTOR
and VOLUME dial as independent right-left controls, stable auditory lateralization and ambience is realized, while the full-
balanced volume circuitry preserves signal symmetry at any volume setting, making possible vibrant music reproduction
even at low sound volumes.

8
BEFORE YOU START
Checking what’s in the box
Please check that you have received the following supplied accessories in the accessory box.
Power cord (U.S. model)
'
CAUTION
Incorrect use of batteries may result in such hazards as leakage and bursting. Observe the following precautions:
Do not mix new and old batteries, or different brands of batteries.
'
Insert the plus and minus sides of the batteries properly according to the marks in the battery case.
'
Use type AAA (SUM-4, R03) Manganese or Alkaline dry cell batteries.
'
When not using the remote control for a long period of time (1 month or more), remove the batteries from the remote
'
control, to prevent damage from inadvertent leakage. If battery leakage occurs, wipe up any battery exudate from inside
the case and replace with new fresh batteries.
When disposing of used batteries, please comply with
governmental regulations or environmental public
institution’s rules that apply in your country/area.
D3-4-2-3-1_B1_En
WARNING
Do not use or store batteries in direct sunlight or other
excessively hot place, such as inside a car or near a heater. This
can cause batteries to leak, overheat, explode or catch fire. It
can also reduce the life or performance of batteries.
D3-4-2-3-3_A1_En
Remote control x 1
'
TAD-C2000
AMP

ANALOG
VOLUME
MUTE
+
–
1 2 3
4
DIGITAL
1 2 USB
RESET
DISP
Operating Instructions (this document)
'
1 2 3
Inserting the batteries
Power cord (Europe, Asia model)
'
Replace the batteries when you notice a reduction in the operating range of the remote control unit.
2 pins plug type (For use in
Europe except in the UK)
3 pins plug type (For use
in the UK, Singapore,
Malaysia, Hong Kong)
AAA/IEC R03 dry cell
'
batteries x 2

English
9
T AD-C2000
Controls and displays
INPUT SELECTOR
DISP
VOLUME
MENU SELECT
– + EXIT
MUTE

Front panel
1 2 3 4 5
7
8 9 10 11
6
Power indicator1
Indicates Power status.
Lighted Yellow: ON
Lighted Red: Standby
Power switch2
Use to switch Power between ON and Standby modes.
INPUT SELECTOR3
Use to switch between input sources.
DISP button4
Use to turn the LCD display ON/OFF.
LCD display5
Displays unit input selection and volume.
Remote sensor6
Point the remote control unit at this sensor to operate
the unit (functions within distance of approximately 7
meters).
MENU button7
Use to switch between setting items.
VOLUME dial8
Use to adjust sound volume.
Rotate to the right (clockwise) to increase volume, and to left
(counterclockwise) to lower volume.
SELECT (+/−) buttons9
Use for making various settings.
EXIT button10
Use to confirm various settings.
MUTE button11
Press to temporarily mute the audio playback.

10
BALANCED BALANCED
USB
XLR COAXIAL
AC IN
12 V TRIGGER
IN
123
4 5
DIGITAL INPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
OUTPUT 12 V
TOTAL 125 mA MAX
R L
LINE 1
BALANCED
LINE 2 LINE 4LINE 3LINE 1
BALANCED
LINE 2 LINE 4LINE 3
D2
D3
D1
ANALOG INPUT ANALOG OUTPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
ANALOG INPUT ANALOG OUTPUT
OUT
Rear panel
17 19 16
12 13 1514
18
ANALOG INPUT R connectors12
Select either balanced (XLR-3-31) or unbalanced (RCA pin jack)
connectors in accordance with the type of connectors on the
component to be connected.
ANALOG OUTPUT R connectors13
Select either balanced (XLR-3-32) or unbalanced (RCA pin jack)
connectors in accordance with the type of connectors on the
power amplifier to be connected.
ANALOG INPUT L connectors14
Select either balanced (XLR-3-31) or unbalanced (RCA pin jack)
connectors in accordance with the type of connectors on the
component to be connected.
ANALOG OUTPUT L connectors15
Select either balanced (XLR-3-32) or unbalanced (RCA pin jack)
connectors in accordance with the type of connectors on the
power amplifier to be connected.
DIGITAL INPUT connectors16
Select either USB, COAXIAL, or XLR in accordance with the
type of connectors on the component to be connected.
12 V TRIGGER IN connector17
When an external component with a 12 V TRIGGER connector is
connected, this unit’s ON/Standby power state can be changed
by operation of the power control on the external component.
Connector: Ø 3.5 mm monaural mini-jack
Operating conditions:
During power Standby mode, when input signal’s voltage
changes from L to H .................................Power switches to ON.
During power ON mode, when input signal’s voltage changes
from H to L ........................................Power switches to Standby.
When an H signal is being input to the 12 V TRIGGER IN
connector, the unit’s power switch cannot be used to change to
Standby mode.
12 V TRIGGER OUT connectors18
When an external component with a 12 V TRIGGER connector
is connected, operating this unit’s power switch will change
the external component’s power state (ON/Standby).
Connector: Ø 3.5 mm monaural mini-jack
Operating conditions:
When this unit is in power ON mode, an H signal is output.
When this unit is in power Standby mode, a L signal is output.
When linked to other components with 12 V TRIGGER input
connectors, a total of five connectors and maximum 125 mA
can be output. Output exceeding 125 mA is not possible, so
take care to avoid excessive current.
AC IN connector19
Connect the accessory power cord here.

English
11
T AD-C2000
Remote control
TAD-C2000
AMP

ANALOG
VOLUME
MUTE
+
–
1 2 3
4
DIGITAL
1 2 USB
RESET
DISP
4
6
5
1
2
3
AMP1 button
Use to switch power to ON/Standby.
ANALOG buttons2
Use to select to analog inputs.
1: Select LINE 1.
2: Select LINE 2.
3: Select LINE 3.
4: Select LINE 4.
DIGITAL buttons3
Use to select digital inputs.
1: Select D1:XLR.
2: Select D2:COAX.
USB: Select D3:USB. Press this button when a USB cable is used to connect
amplifier to a computer.
RESET: Press this button to correct faulty music playback when a USB cable is
used to connect amplifier to a computer.
VOLUME (+/−) buttons4
Press + button to raise sound volume, and – button to lower volume.
MUTE button5
Press to turn off sound.
DISP button6
Press to switch amplifier display ON/OFF.
Remote control operating range
When using the remote control unit to operate the TAD-C2000, point the remote
control at the main unit’s remote sensor within the ranges shown in the accompanying
illustration.
The remote control may not operate properly if obstructions exist between the
'
remote control unit and the remote sensor, or if the angle between the remote
control and the remote sensor is poor.
Malfunctions may occur if the TAD-C2000 is used nearby other appliances that emit
'
infrared light, or if remote control units for other devices utilizing infrared light are used nearby. Alternately, using this
remote control unit near other appliances that also utilize infrared light may cause those appliances to malfunction.
Replace the batteries when you notice a reduction in the operating range of the remote control unit.
'
The remote control may not operate correctly if strong sunlight or light from fluorescent lamps is allowed to strike the
'
remote sensor directly. In such cases, change the installation location, or remove the fluorescent lamps to a more
distant location.

12
Installation
WARNING
When installing, choose a level and flat surface that can sufficiently withstand the weight of this unit. Failure to do so
'
could cause the unit to fall, resulting in an accident.
It is recommended that the unit be installed directly on a solid floor surface. If installed on a shelf, the user is responsible
for confirming that the location is fully able to support the heavy weight of the amplifier.
To promote heat-emission, do not put objects on top of this unit or cover with a sheet (such as cloth or curtains) while
'
operating. Failure to do so could cause the unit to malfunction through abnormal heating.
This amplifier rests on three large main legs and two auxiliary legs. The two auxiliary legs are provided to prevent the unit
'
from suddenly striking the floor in the event that sudden weight is placed on the unit, but they do not contact the floor
under normal conditions.

CAUTION
To prevent interruption of cooling air flow to the unit, do not install it on carpets, rugs, or other soft materials, or in narrow
'
locations without sufficient surrounding clearance.
INSTALLATION AND CONNECTIONS
Leave 20 cm (0.66 ft.) open

English
13
T AD-C2000
Connecting your equipment
Connections to input source components
Connection to output components (basic connection)
BALA NCED BALA NCED
USB
XLR COAXIAL
AC IN
12 V TRIGGER
IN
123
4 5
DIGITAL INPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
OUTPUT 12 V
TOTAL 125 mA MAX
R L
LINE 1
BALA NCED
LINE 2 LINE 4LINE 3LINE 1
BALA NCED
LINE 2 LINE 4LINE 3
D2
D3
D1
ANALOG INPUT ANALOG OUTPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
ANALOG INPUT ANALOG OUTPUT
OUT
SPEAKER LSPEAKER R
INPUT R INPUT L
11
2
2
1
2
BALANCEDUNBALANCEDUNBALANCEDBALANCED
BiAMP
UNBALANCED
4CHANNEL
BALANCED
12V
TRIGGER
IN
ON AUTO
POWER
DOWN
OFF
AC IN
BiAMP
1
2
BiAMP
+
When using power amp with balanced
input connectors
（TAD-M4300）
When using power amp with RCA
pin-jack input connectors
R L
2
1
3
1 : Ground
2 : Hot
3 : Cold
Balanced output connectors
(equivalent to XLR-3-32)
When connecting this unit to a
power amplifier with 12 V TRIGGER
input connector, use a commercially
available Ø 3.5 mm monaural pin
cable (without resistor).
BALA NCED BALANCED
USB
XLR COAXIAL
AC IN
12 V TRIGGER
IN
123
4 5
DIGITAL INPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
OUTPUT 12 V
TOTAL 125 mA MAX
R L
LINE 1
BALA NCED
LINE 2 LINE 4LINE 3LINE 1
BALA NCED
LINE 2 LINE 4LINE 3
D2
D3
D1
ANALOG INPUT ANALOG OUTPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
ANALOG INPUT ANALOG OUTPUT
OUT
Components with RCA pin-jack type
output connectors
R L
Components with analog balanced
output connectors
（TAD-D600）
XLR
D1
DC2 DC1
R
UNBALANCED
BALANCED
L
R L
XLR
DIGITAL INPUT
DC INPUT
COAXIAL
D2
DIGITAL OUTPUT
ANALOG OUTPUT
12
3
Component with digital
output connector
Computer with USB connector Component with digital
output connector
Component with 12 V
output connector
* Switch the unit’s input source to D3 after turning
on power to both this unit and the computer.
When the unit is connected to the computer via a
USB cable, the proper driver will be automatically
installed on the computer (page 17).
1
2
3
1 : Ground
2 : Hot
3 : Cold
Balanced input connectors
(equivalent to XLR-3-31)
When connecting this unit to a
power amplifier with 12 V
TRIGGER output connector,
use a commercially available
Ø 3.5 mm monaural pin cable
(without resistor).

14
Connections to output components (Bi-AMP connections)
Bi-AMP connections utilize two amplifiers and two sets of speaker cables, one connected to the speakers’ low-range input
connectors (Low) and the other connected to the speakers’ high-range input connectors (High).
Note
When using balanced (XLR-3-32) connections, use output connectors 1 or 2.
'
When using unbalanced (RCA pin-jack) connections, use output connectors 3 or 4.
'
When using multiple power amplifiers, use either power amplifiers with four inputs, 2 identical stereo power amplifiers, or
'
4 identical monaural power amplifiers.
Use the same power amplifier for L and R channels.
'
Proper balance values for high and low ranges will not be obtained if the amplifiers used for high and low ranges have
'
different gain characteristics.
BALA NCED BALANCED
USB
XLR COAXIAL
AC IN
12 V TRIGGER
IN
123
4 5
DIGITAL INPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
OUTPUT 12 V
TOTAL 125 mA MAX
R L
LINE 1
BALA NCED
LINE 2 LINE 4LINE 3LINE 1
BALA NCED
LINE 2 LINE 4LINE 3
D2
D3
D1
ANALOG INPUT ANALOG OUTPUT
BALANCED
1. GROUND 2. HOT(+) 3. COLD(-)
ANALOG INPUT ANALOG OUTPUT
OUT
Speaker
Rear of speaker
when using bi-amp
connections
+-
High
Low
+
-
Low
High
Rear of speaker
when using bi-amp
connections
Speaker
BALANCEDUNBALANCEDUNBALANCEDBALANCED
AC IN
12V
TRIGGER
IN
ON AUTO
POWER
DOWN
OFF
SPEAKER LSPEAKER R
UNBALANCED
BALANCED
INPUT R INPUT L
+-+
-
BALANCEDUNBALANCEDUNBALANCEDBALANCED
AC IN
12V
TRIGGER
IN
ON AUTO
POWER
DOWN
OFF
SPEAKER LSPEAKER R
UNBALANCED
BALANCED
INPUT R INPUT L
+-+
-
（TAD-M2500）（TAD-M2500）
CAUTION
Do not turn on power to this unit and other components until all connections and switch settings have been completed.
'
The same sound volume will be output from the analog output connectors 1, 2, 3, and 4 for the same channel (L or R).
'
In order to prevent negative effects on the amplifier from the speakers when using Bi-AMP connections, the speakers’
'
accessory High-Low short bar must be removed. For details, consult the operating instructions for your speakers.
Do not connect anything other than dedicated XLR cables to the XLR input/output connector.
'

English
15
T AD-C2000
Connecting the power cord
Once all connections have been made, connect the power cord to an AC power outlet (U.S. model: AC 120 V; all other
models: AC 220 V to 240 V).
Although the power cord to the unit is removable, do not attempt to use a power cord other than•
the supplied cord.
When the power plug is connected to an AC power outlet, the unit’s power indicator will light red. When the power switch•
is set to ON, power is supplied to the unit.
When not using the unit for a long period of time (due to travel or other reasons), be sure to unplug the power cord from•
the power outlet.
Always turn the power switch off before unplugging the power cord to the unit.•
How to connect the power cord
Connect the supplied power cord to the AC IN connector of this unit.1.
Connect to AC outlet (U.S. model: AC 120 V; all other models: AC 220 V to 240 V).2.
BALANCED
AC IN
ANALOG OUTPUT
Power cord (supplied)
Power outlet

16
Select input source
When the INPUT SELECTOR is rotated, the input source changes as follows:
When rotated clockwise
'
When rotated counterclockwise
'
Note
When power is switched from Standby to ON, the input source automatically switches to the last one used before power
'
was previously set to Standby.
When the power plug is disconnected and reconnected, the input source reverts to LINE 1 (default setting).
'
Adjust sound volume
Rotate the VOLUME dial to adjust the sound volume. Rotate clockwise to increase sound volume, and counterclockwise to
reduce sound volume. Press the SELECT (+/−) button to engage the volume control mode.
+ button
'
Sets volume control to FINE mode. In this mode, the volume can be adjusted in units of 0.5 step.
− button
'
Sets volume control to NORMAL mode. In this mode, the volume can be adjusted in units of 1.0 step.
Changing settings
Press the MENU button to change the unit’s setting items. Settings 1 to 4 can be selected by pressing the MENU button the
respective number of times. To make a setting, press the SELECT (+/−) button to choose a setting, the press the EXIT button
to confirm the selection.
LCD volume display1.
Selects whether the LCD display’s sound volume as a LEVEL meter display (default setting) or dB (input-output ratio)
display.
L-R balance setting2.
Press the + button to lower the L channel level and shift the sound localization toward the R channel. Press the –
button to lower the R channel level and shift the sound localization toward the L channel. Default value is both L/R
channels set to “0”.
Input level setting3.
This unit allows individual input level settings to be made for different source components, to compensate for
differences in sound volume between high-volume components and low-volume components. Input levels can be set
between 0 dB and +20 dB.
Auto power-down mode4.
This setting allows the unit to automatically switch to Standby when not in use. Press the + button to set the mode to
ON, and the – button to set the mode to OFF. When set to ON, the unit will switch to Standby if no volume adjustment
or key input is made for 3 hours.
Factory default (220 V to 240 V model for Asia/Europe): ON
If no control activity occurs for 3 hours, the power switches automatically to Standby, even if the unit is currently
playing.
Factory default (120 V model for U.S.A.): OFF
ALL RESET5.
To reset all settings to factory defaults, place the unit in Standby mode, then press the MENU button for 5 seconds
while holding the MUTE button depressed. The Auto power-down mode turns OFF.
LINE 1 (default setting) LINE2 LINE3 LINE4
D1:XLR
D2:COAX
D3:USB
LINE 1 (default setting)
LINE2 LINE3 LINE4
D1:XLR
D2:COAX
D3:USB
OPERATION

English
17
T AD-C2000
USB connections
By using a USB cable to connect this unit to a computer, playback software applications can be used to play music from the
computer on this unit.
Use the unit’s INPUT SELECTOR or the remote control’s USB button to select D3:USB input.1.
Turn on the computer.2.
Use a USB cable to connect this unit to the computer; the driver will be installed automatically.3.
Note
D3:USB supports USB AUDIO CLASS 1.0.
'
Supported sampling rates include 44.1 kHz, 48 kHz, 88.2 kHz, and 96 kHz.
'
Supports USB 2.0 high-speed.
'
Confirmed to operate under Windows 7 (32 Bit), Windows Vista, Windows XP, Mac OS 10.6, and Mac OS 10.5. No
'
warranties are made regarding operation under other OS’s and versions.
Some changes to computer application settings may be required to play music with high sampling rates (24 bit/96 kHz,
'
24 bit/88.2 kHz, etc.). For details, consult your playback software specifications.
About USB 2 (Audio Class 2.0) mode
In addition to the aforementioned default settings, you can also use USB 2 (Audio Class 2.0) mode with support for sampling
rates of 176.4 kHz and 192 kHz.
Note
Operation is confirmed using Windows 7, Windows Vista, and Mac OS 10.6, and later versions.
'
When using Mac OS 10.6, connecting this unit to the computer via USB cable causes the proper driver to be automatically
'
installed on the computer.
When using Windows 7 or Windows Vista, go to the TAD website (http://tad-labs.com) to download the proper driver,1.
and install it on your computer. Consult the TAD website for instructions regarding installation of the driver.
With this unit in the Stanby mode, press the Power switch while simultaneously depressing both the main unit’s MUTE2.
and MENU buttons.
Turn on power to your computer.3.
With this unit connected to the computer via USB cable, set this unit’s source input to D3.4.
The message “D3:USB2” will appear in the unit’s LCD display. When using Mac OS 10.6, the driver will be
automatically installed on the computer.
To cancel this mode, place this unit in the Standby mode, then press the Power switch while simultaneously pressing the5.
main unit’s MUTE and MENU buttons. The ALL RESET (page 16) operation will occur, thus canceling the D3 mode.
CAUTION
When using a Windows computer without a device driver for this unit, or when using Mac OS 10.5 or other OS that does
'
not support the USB 2 (Audio Class 2.0) mode, do not attempt to connect the unit to the computer in the USB 2 mode,
since the computer may lock up.
RESET button
On rare occasions when playing music with the unit connected to a computer, sound may drop due to computer conditions.
In this event, try disconnecting and reconnecting the computer’s USB cable and reconfirming operation, or press the remote
control’s RESET button.
CAUTION
If the RESET button is pressed when music is being played normally, playback will be temporarily interrupted. Press the
'
RESET button only when you are experiencing problems with playback. If the button is pressed by mistake, the sound
currently playing from the computer may stop. In this case, restarting the playback application or rebooting the computer
may be necessary.

18
Before turning on the power
Make sure that the input terminals and output terminals are securely connected.
Operation
Set the power switch to ON.1.
Set the unit’s VOLUME dial to its minimum setting.2.
Set the power amplifier’s power switch to ON.3.
Adjust the unit’s VOLUME dial to produce the desired level of sound.
When finished playing, set the unit’s VOLUME dial to its minimum setting and turn OFF (Standby) the power switches to4.
the power amplifier and this unit.
TO BEGIN PLAYBACK

English
19
T AD-C2000
Incorrect operations are often mistaken for trouble and malfunctions. If you think that there is something wrong with this
component, check the points below. Sometimes the trouble may lie in another component. Investigate the other components
and electrical appliances being used. If the trouble cannot be rectified even after exercising the checks listed below, ask your
dealer.
Symptom Possible cause Remedy
No sound even when
source is selected. The input connectors are improperly connected.•The MUTE function is enabled (MUTING indicator•is flashing).
Sound volume is set too low.•
Check connections.•Press the MUTE button on the main unit or the•remote control to disable the MUTE function.
Adjust the sound volume properly.•
Noise is heard even when
no input is selected. Noise is present in the power source itself.•Confirm that no other digital appliance is•connected to the same power outlet.
No sound from digital
input. Digital connections are not correct.•If a CD player or other component with digital•output level setting function is connected, the
output level setting is too low.
The playback software’s digital format is not•supported.
Check digital connections.•Adjust the CD player or other component’s digital•output setting.
If the output component is set to a non-PCM mode•(Dolby Digital, DTS, etc.), change the setting to
PCM.
No sound from USB
input. Another component is selected by computer•settings. The computer is set to MUTE.
Connections are incorrect. The computer is not•detecting this unit (TAD-USB1).
The file type, OS, or software is not supported.•
Check the computer’s sound settings.•Check connections. Try pressing the remote•control’s RESET button to make the computer
detect this unit.
Check supported operating systems, software, and•file sampling frequencies (page 17).
The USB input’s sampling
frequency is always the
same.
Depending on the computer’s settings, the•sampling frequency may remain the same, even
though the sampling frequency of played files is
different.
Check computer settings.•
Computer sounds other
than music are audible
from USB inputs.
Depending on computer settings, sounds such as•boot beeps and error beeps may be played from
this unit.
Check computer settings.•
When playing non-USB
sources, the computer’s
software cannot be
played.
With non-USB sources, this unit’s USB circuit•power is set to OFF, so the computer does not
detect it.
Select USB input source.•
When the remote
control’s RESET button
is pressed, sound is
interrupted, or the
playback software
program stops.
When the RESET button is pressed,•communication between this unit and the
computer is temporarily interrupted, with the
result that the computer’s software playback will
also be interrupted or stop.
Do not press the RESET button during playback.•
Power doesn’t turn off. The 12 V TRIGGER input connector is receiving an•H-level signal. Shut off the signal at the component generating•the 12 V TRIGGER signal.
Power turns off by itself. If the auto power down function is set to ON, the•unit will automatically switch to Standby after
three hours of inactivity.
Set auto power down function to OFF (page 16).•
Can’t see display. The display detection area is 45° to right and left.•The display is set to OFF.•Look at the display directly from the front.•Press the DISP button to cancel display OFF.•
Can’t be remote
controlled. The remote control’s batteries are depleted.•Distance is too far. Angle to the signal sensor is
too extreme. An object is interrupting the signal
path. A strong fluorescent or other light is directed
toward the signal sensor.
Try replacing the batteries in the remote control.•Be sure to operate within 7 m and a 30° angle of
the remote sensor on the front panel. Check that
there are no obstacles between the receiver and
the remote control. Make sure that there is no
fluorescent or other strong light shining on to the
remote sensor.
TROUBLESHOOTING

20
SPECIFICATIONS
Amplifier Section
#
Input connectors
Analog .............................................................................................................................................. Balanced x 2, Unbalanced x 2
Digital ................................................................................................. Balanced x 1, Unbalanced x 1, USB (standard type B) x 1
Output connectors
Analog .............................................................................................................................................. Balanced x 2, Unbalanced x 2
Rated output voltage .................................................................................................................... Balanced 1.5 V, Unbalanced 0.75 V
Maximum output voltage ..................................................................................................... Balanced 16 Vrms, Unbalanced 8 Vrms
Rated distortion (T.H.D.) ............................................................................................................................................................ 0.003 %
IHF SN .......................................................................................................................................................................................... 120 dB
Frequency response ....................................................................................................................................... 10 Hz to 100 kHz, −1 dB
Gain ................................................................................................................................................................................................. 12 dB
Analog maximum permissible input voltage (−40 dB) ................................................................. Balanced 20 V, Unbalanced 10 V
Supported sampling frequencies (XLR/RCA) ............................................. 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Supported sampling frequencies (USB) ............................. 44.1 kHz*1*2, 48 kHz*1*2, 88.2 kHz*1*2, 96 kHz*1*2, 176.4 kHz*2, 192 kHz*2
*1 Windows XP and later versions; Mac OS 10.5 and later versions
*2 Windows 7, Windows Vista, Mac OS 10.6, and later versions
USB environment conditions
USB connector ..................................................................................................................................................... USB 2.0 Hi-speed
Power section/miscellaneous
#
Power requirements
U.S. model ................................................................................................................................................................ AC 120 V, 60 Hz
Europe, Asia model ........................................................................................................................ AC 220 V to 240 V, 50 Hz/60 Hz
Power consumption ....................................................................................................... 37 W (during Standby mode: 0.5 W or less)
External dimensions .................................................... 440 mm (W) x 140 mm (H) x 393 mm (D) (maximum external dimensions)
17 5/16 in. (W) x 5 1/2 in. (H) x 15 1/2 in. (D)
Weight ............................................................................................................................................................................ 23.5 kg (51.8 lb)
Accessories
#
Remote control ...................................................................................................................................................................................... 1
AAA/IEC R03 dry cell batteries ............................................................................................................................................................. 2
Power cord
Operating Instructions (this document)
Note
Specifications and the design are subject to possible modifications without notice, due to improvements.
'
Microsoft, Windows, Windows Vista and Windows XP are either registered trademarks or trademarks of Microsoft Corporation in the•United States and/or other countries.
The following abbreviations are used in this manual:•Microsoft Windows 7 operating system: Windows 7
Microsoft Windows Vista operating system: Windows Vista
Microsoft Windows XP operating system: Windows XP
Apple, Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.•
