Tamarack Technologies Airetrak 1A ADVANTAGE User manual

The Airetrak 1A Advantage programmable
bathroom fan control can be set to run the
bathroom fan on a constant low flow, or a duty
cycle every hour on the hour for a time and fan
speed set by the occupant. It features a full flow
override for either 20 or 40 minutes when either
the fan or fan/light button is pressed. At the end
of the override, the fan will return to its’ duty cycle.
Equipped to operate bath fans with, or without a
light, it features an LCD clock and comes in the color
white. Requires a Decora switch plate. (not included)
PRODUCT GUIDE
Features a full function 24 hour clock display with
independent fan and light control. Can switch up
to 3.0 amps and has a 5.0 amp field replaceable
fuse. Choose from a wide range of programming
capabilities. Your program is maintained in the
event of a power outage. The Airetrak 1A
Advantage carries a one year warranty.
Airetrak 1A
Patented
ETL Listed
™
Specifications
Input . . . . . . . . . .120 VAC 60 Hz
Maximum Power
Output . . . . . . . . . . . .300 Watts
Dimensions
Mountin Flan e . . . . . . . .4 1/8”x 1 3/4”
Housin . . . . . . . . .2 3/4”x 1 3/4”x1 5/8”
WARNING: State and local electrical codes may require that the
Airetrak1A Advanta e be installed by a licensed electrician, check with
your local code officials before installin . Some ventilation equipment
should not be used with a solid state speed control. Please check with
the manufacturer. Not for use with (AFCI) arc fault circuits.
Advantage
T
1A
ADVANTAGE
LIKE US ON
FACEBOOK
FOLLOW US
ON TWITTER
20 Patterson Brook Rd, Suite 7
West Wareham, A 02576
774-678-4433 / 800-222-5932 / Fax [phone]

Patented
ETL Listed
1. To set the clock: Push the Power button. Hold both the Fan/Light
and Fan Onl buttons down until the LCD starts flashing (about 5
seconds). The Fan/Light button will adjust the time up. The Fan Onl
button will adjust the time down (holding either of these buttons
down will adjust the time more quickly). After the time is set, push
the Power button again. this will set the time into memory.
2. T
o program the Time Set (TS): This determines how many hours
each day the Advantage will operate the fan, either 24 hours or
12 hours. The 12 hour period can be from 6A to 6P or from
6P to 6A . Push the Power button again. Push the button
marked TS the display will show the default or current setting. To
change the setting, push the Fan/Light or Fan Onl button to shift
from (“24”, “12”+”A ”, or “12”+”P ”).
3. To program the Speed Set (SS): This determines the speed at
which the fan will operate. 1 is full speed. As you go higher in
number, the fan speed will be lower. Push the button marked SS
twice. The display will show 1-12. To change the speed, push the
Fan/Light or Fan Onl button to set your number.
4. To program the Dut C cle (DC): This determines how many
minutes of each hour the Advantage will operate the fan. The
time is in 5 minute intervals. Push the button marked DC twice.
The display will show 5, 10, 15 minutes etc. To change, push the
Fan/Light or Fan Onl button to set the run time.
5. To program the Override (OVR): This determines how long the fan
will run at full speed when either the Fan/Light or Fan Onl button is
pressed. 1 is continuous, 2 is 20 minutes and 3 is 40 minutes run
time. Push the button marked OVR twice. The display will show 1,
2 or 3. To change the override, push the Fan/Light or Fan Onl
button. The programming is now complete. the display will flash
for 15 seconds, then return to the clock display.
6. After programming is complete and if you wish to hide the set
buttons, apply the vinyl tape to the face of the Airetrak 1A
Advantage in such a way that the button holes are covered.
• The program will now run the fan at the top of the hour at the
speed and duration you have set.
• To avoid having the Fan or Light time out, restart the timer by
pushing the Fan/Light button twice.
• If you just want to leave the fan running for the 20 or 40 minutes
Override when exiting the bathroom, push the Fan Onl button.
Programming the Airetrak™1A Advantage
LI ITED WARRANTY IF, WITHIN THE PERIOD OF ONE YEAR FRO DATE OF PURCHASE THE AIRETRAK1A ADVANTAGE™ (THE PRODUCT) IS
DEFECTIVE OR ALFUNCTIONS IN NOR AL HO E USE, TA ARACK WILL REPAIR OR REPLACE THE PRODUCT AT ITS DISCRETION WITHOUT
CHARGE FOR LABOR OR ATERIALS. CUSTO ER IS RESPONSIBLE FOR SHIPPING CHARGES.
CONDITIONS, EXCLUSIONS, AND LI ITATIONS -THIS WARRANTY IS SUBJECT TO THE FOLLOWING CONDITIONS, EXCLUSIONS AND
LI ITATIONS. THIS WARRANTY DOES NOT COVER PROBLE S RESULTING FRO INSTALLATION, OPERATION OR AINTENANCE THAT HAS
BEEN UNDERTAKEN OTHER THAN IN ACCORDANCE WITH THE INSTRUCTIONS. THIS WARRANTY DOES NOT COVER PROBLE S RESULTING
FRO DEFECTS IN OR CAUSED BY ASSOCIATED EQUIP ENT (FURNACES, SOLARIA, ETC.) ; FRO REPAIRS OR ODIFICATIONS ATTE PTED
BY PERSONS OTHER THAN TA ARACK.; FRO ABUSE, ACCIDENTAL OR SHIPPING DA AGE, ACTS OF GOD. THIS WARRANTY DOES NOT
APPLY TO THE PRODUCT USED OUTSIDE THE UNITED STATES, ITS TERRITORIAL POSSESSIONS AND CANADA. EXCEPT AS SET FORTH ABOVE,
NO EXPRESS OR I PLIED WARRANTY IS GIVEN OR AUTHORIZED BY TA ARACK. AND ALL OTHER SUCH WARRANTIES ARE EXPRESSLY DIS-
CLAI ED. ANY WARRANTY OR ERCHANTABILITY OF FITNESS FOR ANY PARTICULAR PURPOSE SHALL BE LI ITED TO THE WARRANTY HERE-
UNDER. OREOVER, ANY LIABILITY OF TA ARACK FOR THE PRODUCT SHALL BE LI ITED TO THE REPLACE ENT OF THE PRODUCT. IN NO
EVENT SHALL TA ARACK BE LIABLE FOR ANY INCIDENTAL DA AGES OR FOR ANY CONSEQUENTIAL PROPERTY OR CO ERCIAL DA AGES,
IRRESPECTIVE OF THE CAUSE THEREOF, OCCURRING EITHER DURING OR AFTER THE WARRANTY PERIOD. INCLUDING WITHOUT LI ITATION
ANY DA AGE TO ANY PART OF A BUILDING OR ITS CONTENTS. NOTE: SO E STATES DO NOT ALLOW THE EXCLUSION OR LI ITATION OF INCI-
DENTAL OR CONSEQUENTIAL DA AGES AND SO E STATES DO NOT ALLOW LI ITATIONS ON HOW LONG AN I PLIED WARRANTY LASTS, SO
THE ABOVE LI ITATIONS OR EXCLUSIONS AY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU AY ALSO
HAVE OTHER RIGHTS THAT VARY FRO STATE TO STATE.
PROOF OF PURCHASE REQUIRED.
Intended for installation in either a metal outlet box or a plastic outlet box.
AA-9
Note: For Fans without a Light, cap the BLACK wire at the
Airetrak1A Advantage. Not for use with (AFCI) arc fault circuits.
The Airetrak™1A Advantage after a Power Loss
When power is restored to the Airetrak Advantage after a power loss and left
untouched the clock auto resets to 12A and will flash for 10 -15 seconds
before going dark. The Advantage must be turned back on by pushing the
POWER button. The program will NOT be lost. The Time Set, Speed Set,
Duty Cycle and Override settings remain as they were programmed. If the power
loss is approximately 45 seconds or less the clock may not need to be reset.
Please keep this in mind that if the clock is never re-set to the correct time the
only thing that will be noticeable after turning the POWER back on is the clocks
readout is wrong. The Airetrak Advantage works the same way as it was pro-
grammed for. It will run at the top of every hour using the same program that the
installer has set it for.
Fan/Light
button adjusts
time up
OVR: Override Button - Determines how
long fan will run at full speed when
either Fan/Light or Fan Only is pressed.
DC: Duty Cycle Button - Determines
how many minutes of each hour
the Advantage will operate the fan.
Set in 5 minute intervals.
SS: Speed Set - Determines the
speed at which the fan operates.
TS: Time Set - Determines
how many hours each day
the Advantage will operate
the fan, either 12 or 24 hours.
Fan Only
button adjusts
time down
Power
