Tamerica OfficeOro-46E User manual

IMPORTANT !!!
It will be beneficial to first get yourself acquainted with the features of your OfficePro-4 E before
attempting to use. Keep in mind all operational instructions, tips, and safety reminders every time
you use your OfficePro-4 E to best achieve desirable results.
OfficePro-46E & Ei
Electric Coil Binding Machine
OPERATING MANUAL
SAFETY REMINDERS & OTHER USEFUL TIPS
1. Make sure your OfficePro-46E is placed on top of a sturdy surface before use & that the electrical chord
is securely attached to a wall outlet (11 V).
2. This machine is not a toy, therefore children should not be allowed to operate it.
3. Keep hair, fingers, jewelry and all loose clothing away from all moving parts of your OfficePro-46E as
they may accidentally be pulled into the machine causing damage to it or worse, injury to the user.
4. When not in use, keep the foot pedal away from reach and turn the machine off.
5. Never operate your machine near water or any type of liquid to reduce the risk of electric shock.
6. Periodically check the electrical chord of your OfficePro-46e for any visible sign of damage and avoid
using it when it is present. Keep it also away from any hot surface which may cause damage to it.
7. Use a test sheet to punch to determine if there will be holes running off the sides. If there are,
disengage the appropriate pins.
8. Do not punch more than 2 sheets of 2 lb. paper when punching. Preferably, punch 12-15 sheets at a
time to help preserve the machine.
9. When punching on PVC or PP covers, it is recommended that you punch at a maximum of 2 sheets at a
time.
1 . Periodically check and empty the waste drawer. An overfilled waste drawer may damage the machine
when punching.
11. Protect your OfficePro-46E keeping it from the elements such as water or excessive heat.
12. Your OfficePro-46E should not be used other than its intended purpose and function.
13. Always call the authorized dealer first for technical issues or any malfunction. Trying to fix the machine
by yourself might not only be dangerous, but may also void the warranty.
WARRANTY INFORMATION
Our machines are guaranteed against defects in materials and workmanship for a period of one year from
the date of original purchase from an authorized dealer of TAMERICA PRODUCTS, INC. If you perceive
or experience any issue with the machine, kindly report it to the dealer within 1 business days of said
purchase to avail of free pickup and redelivery from TAMERICA’s Service Center. After the first 1 days,
you will either receive service instructions and parts via mail free of charge for the duration of the warranty.
Note that when returning the machine for warranty claims, the machine should be returned in its complete
original packaging to avoid incidental or consequential damages that may void the claim. A copy of the
invoice or other proof of purchase also needs to be sent with the machine.
Upon evaluation of the machine and the determination of the actual defect, the machine will be restored to
its regular working condition by the Service Center and shipped back to you free of charge. If you change
your mind and simply want to return the machine, a 2 % restocking fee is charged even within the 1 -day
grace period. Further, you will have to cover freight to return the machine and it has to be in brand-new
resalable condition, otherwise, you might incur more charges.
This warranty covers all defects incurred in the normal use of the equipment except in the
following cases:
1. Loss or damage to the equipment due to improper operation, abuse, mishandling or failure to follow the
operating instructions.
2. Removal or alteration of the serial number.
3. The machine being serviced or modified by anyone other than a certified technician authorized by
TAMERICA.
This warranty is valid only within the Contiguous USA, Hawaii and Alaska excluded.

FEATURES
Coil Inserting Roller
Paper Entrance Cover
Foot Pedal
(for “Ei” model)
Waste Drawer
Power Switch
Punch Switch
Disengageable Pins
Coil Crimper Pliers
Depth Margin Control
Coil Inserting Roller Toggle Switch
6.553.52.5Depth Margin
22191551211958575542Sheet Capacity
25.4mm22mm19mm16mm14.3mm12.7mm11mm9.5mm8. mm6.9mm4.8mm
1"7/8"3/4"5/8"9/16"1/2"7/16"3/8"5/16"1/4"3/16"
Coil Diameter
SET-UP
Reference the table above in determining the necessary coil diameter size based on sheet capacity. This
may also be used in selecting the correct depth margin setting by turning the depth margin control dial.
For safety reminders and other useful tips on the proper operation of your OfficePro-46E, please
turn to the back page.
SPECIFICATIONS
Binding Material : Plastic Coil
Binding Capacity : 25mm
Punching Capacity : 2 sheets (2 lb. paper)
Punching Length : 11.7” (A4)
Punching Format : Electric
Hole Pitch : 6.35mm (4:1)
Hole Spec : 4mm
Depth Margin : 2.5 – 6.5mm
Punch Holes : 46
Disengageable Pins : 46
Power Supply : 11 V/6 Hz
Machine Dimensions : 17.3”x11”x9”
Machine Weight : 42.9 lbs (19.5kgs)
Warranty : 1 Year
1.Open paper entrance cover & place document on the
paper feeder. Adjust side margin guides according to
size of document and/or ruler guide. 2. Disengage
pins that would punch off the edge of the document.
3. Press punch switch for punching. (Machine should
be plugged into a 11 v outlet.)
Side Margin Guides
PUNCHING
COIL INSERTING / BINDING
1. (for “Ei” model) Connect the foot pedal jack into the
female plug below the power switch at the back of the
machine.
2. Align the punched document and manually insert the
coil into the first 4 holes as shown.
4. Make sure coil inserting roller toggle switch is in
the “ON” ( I ) position. 5. (For “Ei” model) Press the
foot pedal & the coil will automatically insert itself
into the document. Release the foot pedal & pull
your document away when the coil is already
completely inserted.
6. Use the handheld coil crimper pliers to crimp the
ends to keep the document from unbinding.
1
3
2
1
2
345
Ruler Guide
3. Grasp your document with both hands & align the
coil with the inserting roller.
