Tamerica EZ-Comb21 User manual

IMPORTANT !!!
It will be beneficial to first get yourself acquainted with the features of your EZ Comb21 before
attempting to use. Keep in mind all operational instructions, tips, and safety reminders every time
you use your EZ Comb21 to best achieve desirable results.
EZ Comb21
Comb Binding Machine
OPERATING MANUAL
SAFETY REMINDERS & OTHER USEFUL TIPS
1. This machine is not a toy, therefore children should not be allowed to operate it.
2. Make sure your EZ-Comb21 is placed on top of a sturdy surface before use.
. Keep hair, fingers, jewelry and all loose clothing away from all moving parts of your EZ-Comb21 as they
may accidentally be pulled into the machine causing damage to it or worse, injury to the user.
4. Use a test sheet to punch to determine if there will be any holes running off the sides then disengage
the appropriate pins.
5. Do not punch more than 20 sheets of 20lb. paper when punching. Preferably, punch no more than 15-
18 sheets at a time to help extend the life of your EZ-Comb21.
6. When punching on PVC or PP covers, it is recommended that you punch at a maximum of 2 sheets at a
time.
7. Periodically check and empty the waste drawer. An overfilled waste drawer may damage the machine
when punching.
8. Protect your EZ-Comb21 keeping it from the elements such as water or excessive heat.
9. Your EZ-Comb21 should not be used other than its intended purpose and function.
10. Always call the authorized dealer first for technical issues or any malfunction. Trying to fix the machine
by yourself might not only be dangerous, but may also void the warranty.
WARRANTY INFORMATION
Our machines are guaranteed against defects in materials and workmanship for a period of one year from
the date of original purchase from an authorized dealer of TAMERICA PRODUCTS, INC. If you perceive
or experience any issue with the machine, kindly report it to the dealer within 10 business days of said
purchase to avail of free pickup and redelivery from TAMERICA’s Service Center. After the first 10 days,
you will either receive service instructions and parts via mail free of charge for the duration of the warranty.
Note that when returning the machine for warranty claims, the machine should be returned in its complete
original packaging to avoid incidental or consequential damages that may void the claim. A copy of the
invoice or other proof of purchase also needs to be sent with the machine.
Upon evaluation of the machine and the determination of the actual defect, the machine will be restored to
its regular working condition by the Service Center and shipped back to you free of charge. If you change
your mind and simply want to return the machine, a 20% restocking fee is charged even within the 10-day
grace period. Further, you will have to cover freight to return the machine and it has to be in brand-new
resalable condition, otherwise, you might incur more charges.
This warranty covers all defects incurred in the normal use of the equipment except in the
following cases:
1. Loss or damage to the equipment due to improper operation, abuse, mishandling or failure to follow the
operating instructions.
2. Removal or alteration of the serial number.
. The machine being serviced or modified by anyone other than a certified technician authorized by
TAMERICA.
This warranty is valid only within the United States or its provinces and territories.

SET UP
SPECIFICATIONS
Binding Material : Plastic Comb
Binding Capacity : 450 sheets (20lb. paper)
Punching Capacity : 20 sheets (20lb. paper)
Punching Length : 11.7”
Punching Format : Manual
Hole Distance : 14. mm
Hole Spec : x 8mm rectangle
Depth Margin : 2.5 / 4.5 / 6.5mm
Punch Holes : 21
Disengageable Pins : 21
Machine Dimensions : 17. ” x 11” x 9”
Machine Weight : 18.7lbs (8.5kgs)
Warranty : 1 Year
MACHINE OPERATION
2. Adjust depth margin from 2.5mm to 6.5mm. This
controls how far or how close you want the holes to
be in relation to the edge of the document.
. Disengage pins that would punch off the edge of
the document by pulling them towards you.
TIP: Punch a few test sheets first in order to get
the proper alignment.
1. Adjust the ruler guide according to the size of your
document.
4. Grasp the punch handle with 1 or 2 hands and
pull down to punch holes on the document.
6. Insert the document into the comb making sure
all teeth go through the holes then release the
handle to close the comb.
Use this guide to help determine the necessary comb diameter to be used based on sheet capacity. This may also be
used to select the correct depth margin setting by way of the depth margin control.
1
4
FEATURES
Comb Spreader
Waste Drawer
Disengageable Pins
Depth Margin Control
Ruler Guide
Punch Handle
Punch throat
3
290
2mm
1-1/4”
60
8mm
1-1/2”
450
45mm
1- /4”
6.54.52.5
Depth
Margin
5002502 022015012010080604020
Sheet
Capacity
50mm28mm25mm22mm20mm16mm14mm12mm10mm8mm6mm
2”1-1/8”1"7/8"/4"5/8"9/16"1/2"/8”5/16"1/4"
Comb
Diamater
2
5. Select the appropriate comb element for your
project then insert into the comb spreader. Grab
the punch handle and push forward to open the
comb.
4
56
TIP: Periodically empty the waste bin to help ensure
uninterrupted use.
Please turn to next page for safety reminders
and other useful tips on the proper operation of
your EZ-Comb21.
14. mm
x 8mm
. . . COMB 2:1
