Tanaka TED-262HS Setup guide

IllustrIllustr
IllustrIllustr
Illustraa
aa
ated Pted P
ted Pted P
ted Parar
arar
arts Mants Man
ts Mants Man
ts Manualual
ualual
ual
Model Number:
TED-262HS
HIGH SPEED PORTABLE DRILL
P/N 30058
Rev 000
Date 4-1-08
Unit shown equipped
with optional Wet Kit
Order#29898
Nikko Tanaka Engineering U.S.A.,Ltd.• 1028 4th Street SW, Bldg B • Auburn, WA 98001 • Phone: [phone] • Fax: [phone]
www.tanakapowerequipment.com [email protected]

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 1
TED-262HS
CYLINDER, PISTON & CRANKSHAFT • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-1 0010160090 SET,CYLINDER 1 Includes gasket
1-2 01801805200 PLUG,SPARK 1
1-3 1570097A900 CAP,SPARK PLUG,ASS'Y 1
1-4 01701620200 GASKET,CYLINDER 1
1-5 04101601200 RING,PISTON 2
1-6 0300162090 PISTON SET 1 Includes rings and circlips
1-7 03701700200 PIN,PISTON 1
1-8 03900000201 CIRCLIP,PISTON PIN 2
1-9 0460162S81 CRANKSHAFT 1
1-10 99962091338 BEARING,NEEDLE,KTV91313 1
1-11 06810100200 KEY,WOODRUFF,3X13X4.5 1
1-30 99461050164 BOLT,HEX,5X16,S 1

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 2
TED-262HS
CRANKCASE, IGNITION COIL, FLYWHEEL • FIGURE 2
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
2-12 07102007200 SHIM,15.2X20X.05 1
2-12 07102007210 SHIM,15.2X20X.10 1
2-12 07102007220 SHIM,15.2X20X.15 1
2-12 07111600230 SHIM,16X21X.20 1
2-12 07111600240 SHIM,16X21X.30 1
2-13 99961600200 BEARING,BALL,#6002 1
2-14 99961600115 BEARING,BALL,6001 C3 1
2-15 99966152564 SEAL,OIL,UD15257 1
2-16 99966122240 SEAL,OIL,#12227 1
2-17 0900060120 GASKET,CRANKCASE 1
2-18 07201620900 CRANKCASE,ASS'Y 1 Includes bearings, seals and gasket
2-19 35910112203 WASHER,CLUTCH B 1
2-20 79801630200 PULLEY,STARTER 1
2-21 1552172080 ROTOR,MAGNETO 1
2-22 1650162V200 PLATE,COIL HOLDING 1
2-23 1672054790 COIL,IGNITION 1
2-32 99101080011 NUT,8 1
2-34 99200080011 WASHER,8 1
2-36 99101080011 NUT,8 1
2-42 99461050304 BOLT,HEX,5X30S 4
2-44 99414050161 SCREW,5X16/S 2
2-46 99416040186 SCREW,WS,4X18 2
2-53 1780160080 CORD 1
2-55 56020517200 CAP,RUBBER 1
2-56 1782054420 LEAD,HIGH TENSION 1

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 3
TED-262HS
FUEL TANK, CARBURETOR, FUEL SYSTEM • FIGURE 3

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 4
TED-262HS
FUEL TANK, CARBURETOR, FUEL SYSTEM • FIGURE 3
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
3-5 65301620200 BRACKET,TANK 1
3-7 65506100200 CUSHION,TANK 4
3-33 4030160020 GASKET,INLET MANIFOLD 1
3-34 4040160091 INSULATOR SET 1 Includes gasket
3-35 4020602K21 GASKET,CARBURETOR 1
3-36 4550160090 CARBURETOR SET 1 Includes gasket ~Z207350
3-36 4550160290 CARBURETOR SET 1 Includes gasket Z207351~
3-37 2230650090 PIPE,FUEL,ASS'Y 1
3-40 6750608A900 FILTER,FUEL 1
3-41 68000731201 CLIP 6.3 1
3-42 5950656B90 CAP,FUEL BLACK,NON VENT 1 ~Z207350
3-42 5950300290 CAP,TANK (BLACK/RED) 1 Z207351~
3-53-1 5910160020 TANK,FUEL 1 ~Z207350
3-53 5910162080 TANK,FUEL 1 Z207351~
3-57 99415040182 SCREW,PS,4X18 2
3-74 99416050601 SCREW,5x60WS 2
3-81 99415040142 SCREW,4X14/PS 2
3-86 99416050241 SCREW 5x24WS 2
3-110 53432710200 GROMMET,FUEL PIPE 1 Z207351~
3-111 7000300507 PIPE,FUEL,3X5X75 1 Z207351~
3-121 5640661190 VENT,AIR ASS'Y 1 ~Z2073510
3-122 5650441020 PIPE,AIR VENT 1
3-123 6460661290 VALVE 1

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 5
TED-262HS
MUFFLER, COVER, FLYWHEEL, CLUTCH • FIGURE 4

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 6
TED-262HS
MUFFLER, COVER, FLYWHEEL, CLUTCH • FIGURE 4
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
4-1 7380162021 PROTECTOR,MUFFLER 1
4-3 2030630B201 GROMMET,CORD,PRIMARY 1
4-8 35902103200 WASHER,CLUTCH,B 2
4-9 29001620800 SHOE,CLUTCH 2
4-10 3420630B200 SPRING,CLUTCH 1
4-11 35802103200 WASHER,CLUTCH A 2
4-12 3570075T200 BOLT,STEP 2
4-18 1120162S801 CASE,FAN 1
4-25 13301620220 SHIELD,HEAT 1
4-26 73701620200 GASKET,MUFFLER 1
4-27 7040162T90 SET,MUFFLER 1
4-28 73901620210 GASKET,MUFFLER COUPLING 1
4-29 7170162T800 BODY,MUFFLER,B 1
4-30 71601620210 BODY,MUFFLER,A 1
4-63 99415050122 SCREW,5X12/PS 3
4-63 99416050122 SCREW,5X12/WS 2
4-64 99415050162 SCREW,5X16/PS 1
4-77 99413040122 SCREW,4X12/P 2
4-79 99051050453 BOLT,HEX,5X45 2
4-80 99201050061 WASHER,5 2
4-84 99414050161 SCREW,5X16/S 4
4-89 99413050101 SCREW,5X10/P 1
4-91 13201620200 DEFLECTOR,AIR 1

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 7
TED-262HS
AIR FILTER • FIGURE 5
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
5-0 4100650D90 AIR CLEANER ASSY 1
5-1 4240602K201 CAP,CLEANER 1
5-2 4460072Z20 ELEMENT CLEANER 1
5-3 4530602K200 COLLAR 1
5-4 47000025200 COLLAR 2
5-5 5280635A200 PLATE,CHOKE 1
5-6 4230072Z81 BODY,CLEANER 1

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]
Page 8
TED-262HS
ITEM PART NUMBE
R
DESCRIPTION QTY COMMENTS
6-0 7620094090 STARTER,RECOIL ASS'Y 1
6-2 78500940200 HANDLE,STARTER 1
6-3 77200940801 BODY,STARTER 1
6-4 78000940200 SPRING,RECOIL 1
6-5 78300940200 ROPE,STARTER 1
6-6 77400940200 REEL,STARTER ROPE 1 ~V202950
6-6 7740163021 PULLEY,STARTER 1 V202951~
6-7 7880163021 PAWL,STARTER 1
6-8 80105015200 WASHER,STARTER PULLEY 1
6-10 8370501521 PLATE,FRICTION 1
6-11 82205015200 SHIM,PULLEY 1 ~V202950
6-11 8220423020 SHIM,STARTER PULLEY 1 V202951~
6-12 8390423020 BOLT,SET 1
STARTER • FIGURE 6

www.tanakapowerequipment.com
PARTS INFORMATION
[email protected]m
Page 9
TED-262HS
CARBURETOR •FIGURE 7
1-0
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
teksaglcnI-053702ZN/SerofebstinU1TESROTERUBRAC09006105540-1-7
7-1-1 51425100200 SCREW,THROTTLE SET 2
1ELBAC,TSUJDA,YATS002461524451-4-7
1LEVIWS002021529351-5-7
1POTS,GNIR002001529841-7-7
1GNIR-O002001520551-01-7
15.73#NIAM,TEJ73WA0029951-11-7
tiKbraC009.42152.056nidedulcnI~1PMUP,TEKSAG~~~1-21-7
)yllaudividnidlostonsmeti(1PMUP,MGARHPAID~~~1-31-7
1TELNI,NEERCS002700
528751-61-7
1PMUP,YDOB08251525751-71-7
1MGARHPAID,TEKSAG~~~1-81-7
7-19-1 ~ ~ ~ DIAPHRAGM,METERING 1
1MGARHPAID,REVOC002400526741-02-7
4TES,WERCS002101528451-12-7
1ELBAC,RETSUJDA002731524161-22-7
16,TUN310060101991-32-7
1RENAELC,TEKSAG002C43601341-42-7
1TSURHT,REHSAW02561529451-14-7
Tanaka Parts Update
To Convert To The Primer Type
Fuel System Order The Following Parts*;
455.01602.90 Carburetor
591.01620.80 Fuel Tank
700.03005.350 Fuel Pipe
534.32710.200 Grommet
595.03002.90 Gas Cap
*Only For Use With Units With Serial Numbers
Before Z207350
