Tanda zap User manual

instructions for use
mode d’emploi
instrucciones de uso
22680a3SyneTandaZapManual.indd 1 6/11/12 11:48 AM

1
3
4
2
Thank you...
for purchasing the Zap. The Zap acne spot treatment
device is clinically proven to clear individual acne blemishes
fast. Powerful blue LED light destroys acne-causing bacteria,
while sonic vibration and gentle warming help open pores
so bacteria have nowhere to hide. No pain. No dryness.
No irritation. And best of all no pimple!
Device components:
• Zap treatment head (1)
• Indicator light (2)
• Power button (3)
• Battery compartment
opening (4)
22680a3SyneTandaZapManual.indd 1 6/11/12 11:48 AM

tanda.com 1
Customer service contact:
Toll free (NA): 1.877.651.1177
Email: [email protected]
Hours of operation:
Mon-Fri, 9am-5pm Eastern Standard Time
MANUFACTURER
Syneron Beauty Inc.
11-380 Jamieson Parkway
Cambridge, ON, N3C 4N4
22680a3SyneTandaZapManual.indd 1 6/11/12 11:48 AM

TANDA
2
What is the device used for?
The Zap is indicated for the treatment of mild to moderate
inammatoryacne(several/manyinamed(red)pimples).
The Zap will not work on severe nodular or cystic acne.
Contraindications
• CAUTION! Never use this device over any lesion other than
mild to moderate acne. Doing so can result in delaying
the best medical treatment.
• CAUTION! Do not allow children under the age of 14 to use
this device unsupervised. Doing so may result in injury if the
device in inappropriately used.
• CAUTION! Do not use if you are sensitive to light. Doing so
may result in a photosensitive reaction. It is recommended
that you conduct a light sensitivity test by using the device
on a small area such as your forearm.
22680a3SyneTandaZapManual.indd 2 6/11/12 11:48 AM

tanda.com 3
Light sensitivity test
Follow these instructions to see if you are sensitive to light:
1. Press the orange power button.
2. The device will vibrate and the bacteria-killing blue light
will illuminate.
3. Lightly place and hold the Zap on your inner arm for the
2 minute treatment cycle.
4. Press the orange power button again to do another 2
minute treatment on the same area of your inner arm.
5. Wait 24 hours. You should NOT
experience any adverse reaction
during the next 24 hours.
6. An adverse reaction is pain or
discomfort in the treatment areas
or any prolonged skin redness.
22680a3SyneTandaZapManual.indd 3 6/11/12 11:48 AM

TANDA
4
• CAUTION! Do not use if you are taking drugs known
to make you sensitive to light. Common examples of
drugs that may make you sensitive to light include:
Antihistamines used in cold and allergy medicines;
Non-steroidalAnti-inammatoryDrugs(NSAIDs),usedto
controlpainandinammation;andAntibiotics,including
tetracyclines and the sulfonamides, or “Sulfa” Drugs.
• CAUTION! Do not use with liniments, salves or ointments
that contain heat-producing ingredients, which could
result in skin burn.
• CAUTION! Do not use over or near a recent steroid
injection. Doing so may result in a photosensitive reaction.
• CAUTION! Do not use on or around your eyes or eyelids,
and do not stare directly into the blue light. This could
cause serious eye injury, including blindness or temporary
loss of vision, or a headache.
• CAUTION! Do not use over the thyroid gland (neck area).
Doing so may stimulate the gland.
22680a3SyneTandaZapManual.indd 4 6/11/12 11:48 AM

tanda.com 5
Warnings
Warning: To reduce the risk of electrical shock that may
cause injury or death:
• Do not place or store the device where it can fall into a
tub or sink. Do not place or drop into water or other liquids.
• Never drop or insert any object into any openings
on the device.
• Only use the batteries recommended for this device.
• Never operate this device if it is not working properly; if it
has been dropped or damaged, or submerged in water.
Return the device to Syneron Beauty Inc. for examination
and repair.
• Remove the batteries from the device if you anticipate
thatitwillnotbeusedforasignicantperiodoftime,such
as one month.
• Do not disassemble or modify the device as this may
causeunitdamage,malfunction,electricalshock,reor
personal injury. There are no user-serviceable parts inside
the unit.
22680a3SyneTandaZapManual.indd 5 6/11/12 11:48 AM

TANDA
6
Warning:Topreventreorpossibleburns:
1. Keepawayfromanyammableaerosolproductsbeing
used or where oxygen is being administered.
2. Turn off the device if it becomes unusually warm to touch.
Warning: Stop immediately if you experience any adverse
effects or develop prolonged redness. You may be
experiencing a photosensitive reaction.
Precautions
• Read all the instructions before using your Zap device.
• Use this device only for its intended use as described
in this manual. Failure to do so may result in a delay
in receiving appropriate treatment.
• Discontinue use if you encounter any discomfort.
You may be sensitive to light.
• Do not operate this device in an environment where
other devices that intentionally radiate electromagnetic
energy in an unshielded manner are being used.
Portable or mobile radio frequency communication
equipment can affect medical electrical equipment.
22680a3SyneTandaZapManual.indd 6 6/11/12 11:48 AM

tanda.com 7
• Prolong or excessive use beyond the recommended
treatment time of 2-3 per day may cause the treatment
surface of the device to become warm. The temperature will
not go beyond 43°C when used at room temperature (25°C),
but if applied may cause you to experience adverse effects
such as discomfort, or prolonged redness in the area.
How to use
Please note some people are sensitive to light. If you think
you may be sensitive to light, you should not use the Zap
devicewithoutdoingalightsensitivitytestrst.Referto
light sensitivity test described on page 3.
Steps:
1. Press the orange power button.
2. The device will vibrate and the bacteria-killing blue light
will illuminate. Do not stare directly into the beam of light.
3. Lightly place and hold the Zap device over your blemish
for 2 minutes. When the vibration stops, the treatment
cycle is complete.
4. Repeat 2 to 3 times daily.
22680a3SyneTandaZapManual.indd 7 6/11/12 11:48 AM

TANDA
8
Zap life indicator
You may stop a treatment at any time by pushing the
orange power button. If you stop the treatment within the
rst30seconds,thedevicewill not count the treatment.
If you stop the treatment after 30 seconds the device will
count the treatment.
Your Zap device delivers 1000 treatments. When your Zap
has less than 50 treatments remaining, the orange power
button will glow a steady red after each treatment to
remind you that you need to get a replacement.
Once your Zap has completed the 1000 treatments, the
device will no longer turn on and the orange power button
with glow a steady red.
22680a3SyneTandaZapManual.indd 8 6/11/12 11:48 AM

tanda.com 9
Device indicators
Steady vibration
and blue light The device is delivering a treatment
Orange power button is
blinking red for 10 seconds
after each treatment
The device batteries
are running low
Orange power button is
a solid red for 10 seconds
after each treatment
The device has less than
50 treatments remaining
Device will not turn on and
orange power button is
a solid red for 10 seconds
The device is out of
treatments. Time to buy
a new Zap!
Battery life and replacement
When your Zap batteries are running low, the orange power
button will blink red after each treatment as an indication.
When replacement is needed, use AAA alkaline batteries
(IEC LR03).
22680a3SyneTandaZapManual.indd 9 6/11/12 11:48 AM

TANDA
10
Be environmentally friendly! Tanda recommends that
you purchase a set of rechargeable AAA batteries.
Note: Remaining battery life may vary when using
rechargeable batteries. NiMH batteries, composed of nickel
metal hydride, are recommended.
To install or change the batteries in your Tanda Zap device,
follow these instructions:
1. Turn the top of the device counterclockwise to align
the two triangles, located on the top and bottom of the
2 sections of the device.
2. Remove the used batteries from the battery holder.
3. Install 3 new AAA batteries according to the symbols
located on the battery holder.
4. To close the Zap device, align the
two triangles, push and turn the top
of the device clockwise until the
triangle is aligned with the vertical
line and feels secure.
22680a3SyneTandaZapManual.indd 10 6/11/12 11:48 AM

tanda.com 11
DISPOSAL
Waste Electrical and Electronic
Equipment (WEEE)
The Zap is considered an electronic device and should
be disposed of as you would any electronic waste. Ensure
you remove and recycle used batteries from your device
according to local regulations. For more information and
instructions regarding the proper disposal of this product in
your location, please visit tanda.com.
Cleaning instructions
Use a damp, soft, lint-free cloth and a mild alcohol-free
detergent to clean the Zap treatment surface after
each use.
Warranty
Register your Tanda Zap device warranty at tanda.com
Your Tanda product is warranted to be free from defect
in material and workmanship for a period of one year after
its original purchase date under normal use or 1000 uses.
22680a3SyneTandaZapManual.indd 11 6/11/12 11:48 AM

TANDA
12
This warranty extends only to the original retail purchaser
with original proof of purchase and only when purchased
from an authorized Tanda retailer or reseller.
If the product should become defective within the warranty
period, contact Syneron Beauty Inc. In North America,
call our customer service team at 519.651.1177 or toll free
at 1.877.651.1177 for replacement. If you are outside of
North America, contact your local distributor. Contact
information can be found at tanda.com. Syneron Beauty
Inc. reserves the right to replace a defective product with
the most comparable product currently available. Your
exclusive remedy for any defective product covered by this
limited warranty is limited to the repair or replacement of
the defective product. Syneron Beauty Inc.’s entire liability
for any defective product shall in no event exceed the
purchase price for the defective product.
This warranty does not cover products determined by
Syneron Beauty Inc. to be damaged by any of the following:
• Accident, misuse, abuse or alteration
• Servicing by unauthorized persons
22680a3SyneTandaZapManual.indd 12 6/11/12 11:48 AM

tanda.com 13
• Use with unauthorized accessories or use other
than as instructed
• Any other conditions beyond our control
TO THE EXTENT PERMITTED BY LAW, SYNERON BEAUTY
INC. SHALL NOT BE RESPONSIBLE FOR ANY DIRECT OR
INDIRECT DAMAGES RESULTING FROM THE USE OR
MISUSE OF THIS PRODUCT INCLUDING ANY GENERAL,
INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES.
ALL IMPLIED REPRESENTATIONS, WARRANTIES OR
CONDITIONS INCLUDING BUT NOT LIMITED TO ANY IMPLIED
REPRESENTATIONS, WARRANTIES OR CONDITIONS OF FITNESS
AND MERCHANTABILITY ARE LIMITED IN DURATION TO ONE
YEAR FROM DATE OF ORIGINAL PURCHASE.
Thiswarrantygivesyouspeciclegalrights,andyou
may also have other rights that vary depending on your
state, province or other jurisdiction. Some jurisdictions
do not allow the exclusion or limitation of incidental
or consequential damages, or limitations on how long
an implied warranty lasts, so the above limitations and
exclusions may not apply to you.
22680a3SyneTandaZapManual.indd 13 6/11/12 11:48 AM

TANDA
14
Specifications
Tanda Zap Device = TANDA SERIES 4
TYPE BF APPLIED PART
Attention, consult ACCOMPANYING DOCUMENTS
RISK GROUP 2
CAUTION Possibly hazardous optical radiation emitted
from this product. Do not stare at operating lamp.
May be harmful to your eyes.
OperatingSpecications: Ambient Temperature:
5°C To 40°C RH: 15% To 93%, Non-Condensing;
Atmospheric Pressure: 700 –1060 hPa;
Transport/StoreEnvironmentalSpecications: Ambient
Temperature: 0°C To 60°C; RH: 10% To 90%
Follow instructions for use.
TUVCerticationMark Degrees of protection
IPx5
22680a3SyneTandaZapManual.indd 14 6/11/12 11:48 AM

tanda.com 15
FCC – DECLARATION OF CONFORMITY:
Model: Tanda Zap conforms to the following
specication:FCCPart15,SubpartB:2006.
Supplemental Information: This device complies with
Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept
any interference received, including interference that
may cause undesired operation.
INDUSTRY CANADA NOTICE:
This Class B digital apparatus complies with Canadian
ICES-003.
Copyright © Syneron Beauty Inc. 2012, Tanda and
Tanda Zap, are trademarks of Syneron Beauty Inc. All
rights reserved. Patents pending.
22680a3SyneTandaZapManual.indd 15 6/11/12 11:48 AM

1
3
4
2
Merci...
pour votre achat du appareil Zap. Le nouvel appareil
de traitement ponctuel de l’acné Zap est cliniquement
éprouvé pour supprimer les poussées d’acné individuelles
rapidement. La lumière à LED bleue puissante détruit les
bactéries à l’origine de l’acné, des vibrations sonores
et un effet chauffant doux aident à ouvrir les pores; les
bactéries ne peuvent donc plus se cacher. Sans douleur.
Sans assèchement. Sans irritation. Et le plus important : plus
de boutons!
Contenu de l’emballage :
• Surface de traitement (1)
• Voyant lumineux (2)
• Touche de mise en marche (3)
• Ouverture du compartiment
de la pile (4)
22680a3SyneTandaZapManual.indd 16 6/11/12 11:48 AM

tanda.com 1
Coordonnées du service à la clientèle :
Appel sans frais (Amérique du Nord) : 1-877-651-1177
Courriel : [email protected]
Heures d’ouverture :
Du lundi au vendredi, de 9 h à 17 h, heure de l’Est
FABRICANT
Syneron Beauty Inc.
11-380, Jamieson Parkway
Cambridge, ON, N3C 4N4
22680a3SyneTandaZapManual.indd 1 6/11/12 11:48 AM

TANDA
2
À quoi sert l’appareil
Zapestindiquépourletraitementdesinammations
acnéiqueslégèresàmodérées(plusieurs/beaucoupde
boutonsenammés(rouges)).Zapnefonctionnepassur
l’acné nodulaire ou l’acné kystique grave.
Contre-indications
• MISE EN GARDE! N’utilisez jamais cet appareil sur une
lésion, quelle qu’elle soit, autre que celles de l’acné
légère ou modérée. Le fait de ne pas respecter cette
mise en garde peut entraîner un retard des meilleurs
traitements médicaux.
• MISE EN GARDE! Ne pas laisser les enfants de moins de 14
ans utiliser cet appareil sans surveillance – le fait de ne pas
respecter cette mise en garde peut entraîner des blessures
aux yeux.
• MISE EN GARDE! Ne pas utiliser cet appareil si vous êtes
sensible à la lumière. Vous vous exposez à une réaction
photosensible. Il est recommandé de tester une petite zone
de la peau moins sensible (votre avant-bras, par exemple).
22680a3SyneTandaZapManual.indd 2 6/11/12 11:48 AM
