WSPR Without Tears

Table of Contents

Introduction................................................................................................................................................1

Approach....................................................................................................................................................2

Raspberry Pi...............................................................................................................................................3

What you'll need to complete the assembly...............................................................................................3

Programming an SD ard..........................................................................................................................4

Setup......................................................................................................................................................4

Program SD ard..................................................................................................................................4

Install SD ard into Pi...........................................................................................................................5

Assemble WWoT and Pi............................................................................................................................6

Setup and Adjustment................................................................................................................................7

What You Need......................................................................................................................................7

Getting SSID and Passkey.....................................................................................................................8

Initial Setup...........................................................................................................................................8

Locate the Pi IP Address........................................................................................................................8

Setting WSPR onfiguration..............................................................................................................10

Restart Pi.............................................................................................................................................11

Measure RF Output.............................................................................................................................11

IP Addresses........................................................................................................................................12

WWoT Schematic....................................................................................................................................12

Troubleshooting - It Doesn't Work ..........................................................................................................14

Appendix 1 – ommunicating With the Pi over SSH..............................................................................16

Appendix 2 – Postprocessing Data..........................................................................................................17

WSPRnet Map.....................................................................................................................................17

Downloading Data...............................................................................................................................19

WSPR Data Filter................................................................................................................................19

Introduction

Thank you for purchasing the WSPR Without Tears transmitter (WWoT). We hope you’ll be pleased

with it. WWoT is our attempt to put together a WSPR transmitter transmitter that avoids (hopefully)

most of the problems associated with building a fairly complicated digital mode transmitter. All of the

information, data and files are accessible through the TAPR website:

tapr.org/kits_WsprWithoutTears

WSPR stands for Weak Signal Propagation Reporter Network. It's a digital mode used by hams. The

process is similar to a beacon. WSPR is a wonderful communication mode created by Joe Taylor

(K1JT). WWoT is our attempt at simplifying the process of getting an actual transmitter up and running

so you can enjoy working with WSPR and avoid dealing with the headaches associated with building a

working system.

WSPR Without Tears

What makes it really interesting is that WSPR is optimized for operating at very low power. For

example, it's normal to transmit with 200 mW from the US and be received in Australia or Europe.

There are hams all over the world with WSPR receivers. They record what they receive in a central

database that can be queried over the Internet. So you put your WSPR transmitter on the air and

monitor its performance from the Internet. Monitoring WSPR is sort of addictive. It's fascinating to see

what effect time of day, seasons, and weather have on propagation.

There is a wide array of choices for setting up a WSPR beacon. The most obvious and possibly the

simplest is to use your regular transceiver. This requires a computer and sound card connection. Most

of us have at least one computer in the shack and many of us are already using digital modes, so the

equipment is already in place to run WSPR. All you have to do is download the software (free) and

you're off to the races. This approach works well and the price is right if you're already are set up for

digital modes. Even if you're not set up for digital modes, the interface between your transceiver and

computer can be had for less than $100.

Using your base station for WSPR is an excellent approach. The downside is that you are tying up your

station while WSPR is on, so leaving WSPR on for an extended length of time gets in the way of radio.

A second point, the output power of many transceivers can't be adjusted below 5 watts. An output

power of 5 watts will certainly work, but it's interesting to see how little power you can get away with

and the useful power range is a lot less than 5 watts.

The alternative to using your regular station for WSPR is to have a completely separate WSPR station.

That's a lot more realistic when you're dealing with output powers in the range of milliwatts. When we

started down this path we looked at different approaches. One approach we looked at was high quality

and well done, but there are some operational complaints we had with it that we wanted to fix. This is

our version for a fix.

Approach

We found an alternate approach using a Raspberry Pi (Pi) computer to generate WSPR transmissions. A

Pi is about the size of a deck of playing cards and costs about $40. It has an amazing amount of

computing power for something so small and so cheap. It runs the Linux operating system.

The Pi can be configured to generate the WSPR signal without any external components! That's just

amazing to me. Somebody figured out how to modulate the clock/oscillator and generate a WSPR

signal. The Pi will also set the time by calling an NTP server and use the time information to adjust the

frequency, eliminating the need for any calibration or timing setup.

There are two problems with using the Pi for WSPR. First, the output signal is a square wave with

harmonics from here out to next Tuesday. A low pass filter is necessary to keep other hams and the

WSPR Without Tears

F happy. Second, the output power is around 10 mW. We talked about the thrill of using low power

to make contacts, but it's nice to start with a little more power than that.

Our WSPR Pi is a circuit board (pcb) that plugs into the Pi 40-pin header. It boosts the signal level to

about 200 mW and contains a seven pole low pass filter to keep out-of-band transmissions down by 43

dB. It also contains an LED that lights when transmitting and a crude output power indicator. (We

found it annoying to not know when and how well our system was working without connecting a 'scope

or power meter and wanted something simple as a sanity check.)

The Pi is a computer, and most computers need to be shutdown properly rather than just have the power

turned off. We added a push button to the circuit board to initiate a shutdown sequence in the Pi. We

wrote a program to run in the background that monitors the push button and shuts the Pi down when it's

pressed.

Raspberry Pi

The Pi is a computer and is subject to all of the headaches associated with computers. We wanted to

make life easier for anybody trying to duplicate our WSPR experience by limiting the amount of

computer exposure you're subjected to. Loading the software into the Pi is not difficult, but there are

quite a few areas that can go wrong and it can be frustrating if you've never done it before. It only takes

one problem to kill the whole process. There are a lot of steps involved in getting to a working WSPR

transmitter.

We created a version of the software that runs automatically when the Pi is turned on. There are several

parameters that you (the user) have to set: callsign, grid square and WiFi (if you're using wifi). We

programmed a web server in the Pi (we told you it's a computer :-) that lets you fill this stuff in from a

web page onyour P . In other words, you bring up Internet Explorer or hrome or Firefox and type in

the Pi's address (we'll get to that) and the web page comes up and you enter the data. This means no

programming of the Pi at all. Bring up the web page, type in your callsign, grid square, and WiFi

parameters and you're up and running.

The operating system (Linux) and all of the software are stored on a micro SD card. The SD card is

plugged into the Pi. Set it and forget it. You need a card reader (<$10) and software (from the TAPR

website) and an SD card to do this. We'll repeat the important part: you have to burn the image onto the

SD card (similar to burning a D/DVD) and then plug it into the Pi. There's *no* programming.

What you'll need to complete the assembly

1. Raspberry Pi 2.0 Model B or Raspberry Pi 3.0

2. 2 amp (minimum) power supply w/micro USB connector.

WSPR Without Tears

3. Ethernet cable.

4. WiFi USB dongle. You only need this if you're using an Pi 2.0 and you want to use WiFi. WiFi

is built into the Pi 3.0.

5. SD card (4 GB min, grade 10)

6. SD card reader (micro SD card to USB)

7. antenna (mate to BN connector on WWoT)

Programming an SD Card

Setup

1. You need an SD ard; at least 4GB, 8GB is better. lass 10.

2. SD ard reader/writer. We've got a Targus Micro SD/T-F. It doesn't really matter what card

reader/writer you use. It connects your SD card to a USB port.

1. Win32DiskImager – It's a freebee. Download it from: tapr.org/kits_WsprWithoutTears or

source orge.net/projects/win32diskimager/.

2. Install Win32DiskImager.

3. Disk Image – Download it from: tapr.org/kits_WsprWithoutTears (file

WSPR_Baseline_********* where the *'s are a date. This is a big file (e.g. 500+ meg).

4. Unzip the file after it's finished downloading (it will take a while).

Program SD Card

1. Plug the SD ard reader/writer into a USB port.

2. Plug the SD ard into the reader/writer.

Figure 1: Win32DiskImager

WSPR Without Tears

3. Start Win32DiskImager.

4. lick on the folder icon in the upper right and find the disk image you downloaded and

unzipped.

5. lick Write and go get a cup of coffee. Note: Win32DiskImager shows a small message box

when it's done writing the SD card. Unfortunately, the message box likes to hide behind

anything else you have up on the screen so you can't see it. Be forewarned that you might have

to go looking for it.

6. lick Exit.

7. Remove the SD card and install it into the Pi. Make sure that power is disconnected from the Pi

before doing this.

If you haven't annoyed the gods of the Internet too much today you should be in luck and everything

will work!

Install SD Card into Pi

First, insert the SD card into the Pi ( Figure 2: Inserting SD ard into Pi and Figure 3: SD ard

Installed in Pi). The SD card sorta slides in up side down. On Pi 2.0 it ratchets in (pops in then out a

little and sorta locks in place). On Pi 3.0 there's a friction fit, so there's no locking.

Figure

Figure 2: Inserting SD Card into Pi

WSPR Without Tears

Assemble WWoT and Pi

Attach the WWoT board to the Pi. The BN connector is on the opposite side from the Pi USB

connectors( Figure 4: WWoT and Pi Assembly). The micro USB power connector is coming out of the

Figure 4: WWoT and Pi Assembly

WiFi

Adaptor

RF Out

Micro USB Power

onnector

Figure 3: SD Card Installed in Pi

USB onnectors

WSPR Without Tears

lower left. RF output comes through a BN connector shown in the upper left. A WiFi dongle is

plugged into one of the USB ports (pi 2.0 only - it's built it to Pi 3.0). The Pi LEDs are on the left hand

side of the Pi board below the WWoT board. They are not visible in the picture.

The side view of the completed assembly ( Figure 5: WSPR Beacon (Side View)) shows how the

WWoT is plugged into the Pi. It's definitely possible to connect them incorrectly, so don't do that.

Notice from this view that the Pi USB connectors are on the right hand side and the WWoT BN

connector is on the left. That's how it should be. Also, make sure that the Pi pins and the WWoT plug

are lined up. It is possible to offset one from the other, so you only have one row of pins connected.

Setup and Adjustment

What ou Need

I'm assuming that you have -

1. Assembled Pi/WWoT

2. 2+ amp power supply for the Pi

3. Ethernet cable to connect Pi to your router

4. SSID and passkey for your router (see below if you don't have these)

5. P connected to your network

6. Optional: USB WiFi adapter for Pi 2.0 (Pi 3.0 has WiFi built in)

Figure 5: WSPR Beacon (Side View)

USB onnectors

WSPR Without Tears

Getting SSID and Passkey

Start by looking on the router for login information. Also, try the Internet for a router manual (we

know, we hate to read directions, too).

Next, you're looking for your router's web page. Open a browser and type the IP address 192.168.0.1

into the address textbox at the top (just as if you were typing www.google.com). If nothing happens try

192.168.1.1 and 192.168.2.1.

Log into the router using the username and password printed on the side of the router or in the manual.

Look through the various wireless setting for SSID and passkey (or something similar). We're sorry, but

we can't offer too much more because each router will be different.

Initial Setup

The power is off at this point.

1. Make sure that the power is turned off.

2. onnect the Pi to your router with the Ethernet cable. This part is a little tricky. The Pi has to be

connected to a DH P server. That's normally your router. It won't work i you plug the Pi into

your laptop, at least not without some advanced setup.

Locate the Pi IP Address

1. Working from your P , download WSPR Executables (zip file) from the web site

(tapr.org/kits_WsprWithoutTears), unzip the zip file, and extract the program WSPR_Locate.exe

to a suitable work area.

2. Execute WSPR_Locate.exe. The program will take about five minutes to execute and will

(hopefully) give you the IP address of the Pi.

Some assumptions have been made: 1) your network is a private lass network (IP addresses

begin with 192.168..), and 2) you have DH P enabled on your router (router hands out IP

addresses). If you have no idea what we're talking about then don't worry about it – these are

typical settings for a home network.

WSPR Without Tears

With any luck, the display will look something like Figure 6: WSPR Locater. Look for the line starting

with eth0. The line below it shows inet addr: 192.168.1.210. Your setup should be similar except for

the last two numbers (it will begin with 192.168, but the last two numbers will probably be different).

Record the full number (192.168.aaa.bbb – aaa and bbb are the numbers for your Pi) for the next step.

That's the IP address of your Pi. If the program fails to find the Pi, try it again. If that fails, go to the

Troubleshooting section.

Note: The first time you run WSPR_Locater inet addr will be displayed for eth0, the Ethernet

connection. After setting the WiFi portion of the WSPR configuration (see Figure 7: WSPR

onfiguration Screen), WSPR_Locater will display inet addr for eth0 if the Ethernet cable is still

connected and inet addr for wlan0, the WiFi connection.

Figure 6: WSPR Locater

WSPR Without Tears

Setting WSPR Configuration

05/20/2019

Figure 7: WSPR Con iguration Screen

WSPR Without Tears

1. Open a web browser (Internet Explorer, Firefox, hrome, …) and type in the IP address you

just recorded (192.168.0.67 for example). This will bring up the configuration screen shown in

Figure 7: WSPR onfiguration Screen -

2. Enter your callsign and gridsquare parameters.

3. Enter the SSID and passkey (password) for your WiFi network. These are what you use to

enable your cell phone and things like Roku to use your home network. If you don't know what

they are you'll have to go digging through your router to figure them out (see the

Troubleshooting section).

If you elect to not use WiFi then you don't need to enter SSID and Passkey. You will have to

keep the Pi connected to the network by Ethernet cable because the Pi uses the Internet for time

synchronization.

4. heck/uncheck the transmit every 2 mins checkbox. (I recommend leaving it unchecked.)

A WSPR message takes just under two minutes to send. The fastest you can send WSPR

messages is every two minutes. It's considered bad form to flood the WSPR servers with

messages. The default is to send a WSPR message every ten minutes. If you check the transmit

every 2 mins checkbox then messages will be sent every two minutes. This setting is useful for

testing and short term experiments.

5. Set the Transmit Power and Transmit Band to 23 dBm and 30m or 30m and 20 dBm and 40m

or 40m.

6. When all done click on the update button. This will store the data on the Pi.

Restart Pi

1. Press the pushbutton on the WWoT. Hold for two seconds and release. This commands the Pi to

enter shutdown mode (you're always supposed to shutdown a computer properly or the file

system can be damaged – pulling the plug is bad).

2. Unplug the power supply, wait 10 sec, then plug the power supply back in and wait until the

LEDs on the Pi stop flashing.

Measure RF Output

The LED on the WWoT turns on when the WWoT is transmitting. Wait until the LED is on and

measure the voltage across the test points labeled RF Level and Gnd. This should be in the

range of 3-5 volts, indicating the WSPR transmitter is generating full power.

05/20/2019

WSPR Without Tears

IP Addresses

Ignore this section i you’re not using WiFi.

We have made the assumption that you are using WiFi to connect to the Pi. This is our preference, but

it is by no means necessary. What may be confusing is that initially you have to use an Ethernet (wired)

connection to talk to the Pi. This is because the WiFi login information has not yet been programmed

into the Pi.

After you have set up WiFi (see Figure 7: WSPR onfiguration Screen) you will have two valid IP

addresses assigned to the Pi. Either one will work. You probably wouldn’t have gone to the trouble of

setting up WiFi if you were just going to use Ethernet. So now is the time to remove the Ethernet cable.

Your Pi will now have one IP address. There is no advantage to having two IP addresses, so you should

remove the Ethernet cable if you’re planning on using WiFi.

WWoT Schematic

The WWoT schematic is shown in Figure 8: WWoT Schematic.

Congratulations! Connect an antenna and you're done.

05/20/2019

WSPR Without Tears

Figure 8: WWoT Schematic

05/20/2019

WSPR Without Tears

Troubleshooting - It Doesn't Work ...

Well, we'd hoped that you wouldn't ever have to get to this page, but …

We've tried very hard to make sure that everything is correct, however sometimes stuff happens ;-) The

good news is it's all fixable. Follow the steps in the order given. We're assuming that something isn't

working right at this point, so let's find out what it is.

1. heck that the pcb is plugged into the Pi correctly.

2. heck that you've got the Pi Ethernet cable plugged into the Pi and that the other end of the

Ethernet cable is going to your router (not your laptop).

3. heck that the red LED on the Pi turns on when power is applied.

4. Verify that the software is working by bringing up the web page (type the IP address into the

address line of your browser on your P /Mac/Linux box: 192.168.aaa.bbb). If the web page

displays then the software is probably working okay. The Pi should have power for this test.

You may have to run the WSPR_Locater program to find the IP address of the Pi and then enter

the IP address into the address bar of the browser.

If the web page doesn't display or WSPR_Locater can't find the Pi then press and hold the

shutdown button for 2 sec and unplug the power supply. Wait for 30 sec and plug in the power

supply. Wait for the LED's to stop blinking and try to access the web page again. If this fails to

work there may be a problem with the software load on the SD card.

5. Press the pushbutton on the WWoT and hold for two seconds. Wait until the LED's on the Pi

stop flashing and unplug the power to the Pi.

6. Unplug the power supply and remove the WWoT from the Pi. Look at the board. Is anything

odd looking or out of place? Look at both sides of the board.

7. Okay, it's time to reassemble the circuit board to the Pi header, get our your voltmeter and turn

on the power. The voltmeter ground lead should be connected to the ground test (Gnd) point

next to the push button.

We've listed voltages in the schematic (above) as transmit/idle, so for example, the voltage on the

power supply rail (top wire in the schematic) is shown as (4.51/4.67). This means that we measured

4.51 volts between the power supply rail and ground (Gnd) while the unit was transmitting, and 4.69

volts when is was not transmitting (idle).

Keep in mind that we're using a cheap DVM, you're probably using a cheap DVM, and component

tolerances could be all over the place. This means that if your readings are within, say 10%-20% of

ours that they're probably okay.

05/20/2019

WSPR Without Tears

We'd suggest printing out the schematic and measuring and recording the voltages listed. Actually, it's

probably simpler to just measure the voltages (and write them down) on both sides of R5, both sides of

L1, and both sides of R2.

The higher voltage across R5 is the power supply rail. It should be between 4.5-5.0 volts. The voltages

on both sides of L1 should be about the same when not transmitting and one significantly lower than

the other when transmitting (LED on). The voltages on both sides of R2 should be about the same

whether transmitting or not. The voltages at R2 will vary depending on how pot R1 is set. The

important part is that they're above 0.0 volts and have pretty much the same voltage on either side of

R2.

If you find voltages that differ significantly from what's listed on the schematic, start by looking for bad

solder joints. If that fails, let us know because we're probably looking at a bad component, which we

will be happy to replace.

05/20/2019

WSPR Without Tears

Appendix 1 – Communicating With the Pi over SSH

This sorta seems like the antithesis of what we've been trying to accomplish. We wanted to hide the

hard details so that you could concentrate on getting a WSPR signal on the air. Okay, you're not afraid

of Linux and you want to talk to your Pi over SSH. Actually, we sympathize – that's our favorite mode

for talking to the Pi.

1. Download the program KiTTY.exe (no, not a cat) as part of the WSPR Executables from

tapr.org/kits_WsprWithoutTears or from http://www.9bis.net/kitty/?page=Download.

2. Get the IP address of the Pi from WSPR_Locater.

3. Run the KiTTY and enter the IP address for the Pi. This will open a command window.

4. Username: pi Password: wspr

05/20/2019

WSPR Without Tears

Appendix 2 – Postprocessing Data

The first thing you're going to want to do once your WSPR transmitter is up and running is to see how

your signal is getting out. Go to the website www.wsprnet.org (enter www.wsprnet.org in a browser)

and click on Map in the upper right hand corner.

WSPRnet Map

Scroll down to the bottom of the graph and change Band as appropriate (30m, 40m, etc), insert your

callsign, change the Time Period to 24 hours, click on the Day/Night overlay checkbox if you want to

see it and then click on the Update button. You can pan and zoom to see how far your signal has gotten.

05/20/2019

Figure 9: WSPRnet Display

WSPR Without Tears

Here's a typical view.

Now click on the Database button (next to Map) in the upper right hand corner. lick on Speci y query

parameters just below Database in the upper left and change Band to the appropriate band (30m, 40m,

etc) and add your callsign. lick the Update button.

05/20/2019

Figure 10: WSPRnet Display - Zoom

Figure 11: WSPRnet Database

WSPR Without Tears

This gives the particulars for the contacts – their gridsquares and the distance traveled. (Multiply km by

0.62 to get miles.)

Downloading Data

We're fascinated to see how far our signal goes using just a piece of wire strung around the room (that's

all we've done with our antenna). It's also interesting to see the effect of daytime vs nighttime on

propagation.

After you've run your transmitter for a while you might be tempted to play with the data some more.

The WSPRnet people have stored information on all of the transmissions in files that you can download

and process. This is under the Downloads tab. The files are stored by year-month. They are available in

gzip or zip format.

Pick a month that you'd like to investigate and click on the word zip. We're amused by what can only be

described as wishful thinking on the part of the people who put together the web page. The writeup at

the top says “ ompressed file sizes range from 1-20MB.” The compressed files will be much closer to

300 MB and uncompressed go to about 1.4 GB.

Most of the entries were not information we cared about – they list all of the contacts in a particular

month. We only want to see our contacts.

WSPR Data Filter

We wrote a program to extract only our contacts. The program is called WSPR_Data_Filter.exe and can

be downloaded from the web site (part of the executables file). The program removes everything but

your contacts from the downloaded data making it a much more reasonably-sized file.

05/20/2019

Figure 12: WSPR Data Filter

WSPR Without Tears

Here is how you use it -

1. Download a month's worth of data from WSPRnet.org.

2. Unzip the file (these are big files – it will take some time).

3. Download Run WSPR_Data_Filter (download from tapr.org/kits_WsprWithoutTears, click on

WSPR Executables and extract the program from the .zip file).

4. Run WSPR_Data_Filter.

5. Enter your callsign

6. lick the Open button, select the file you unpacked (not the .zip file), and click Open.

7. lick the Save button, enter a ilename to save the output as, and click Save.

8. lick the Filter button.

9. lick the Exit button when processing is done.

The output can be read into any spreadsheet program (e.g. Excel) directly for processing and graphing.

05/20/2019

This manual suits for next models

Table of contents

Popular Transmitter manuals by other brands

Marmitek

Marmitek SURROUND ANYWHERE 220 user manual

AJAX

AJAX vhfBridge user manual

Siemens

Siemens SITRANS FUS060 HART quick start

Panametrics

Panametrics DigitalFlow XGM868i Programming manual

Long Range Systems

Long Range Systems T74USB user manual

Verint

Verint S1704e installation guide

CEBEK

CEBEK TL-11 manual

Geo

Geo Web Pack quick start guide

Semtech

Semtech TSWITX-G4-EVM user guide

Emerson

Emerson Rosemount 326L quick start guide

MiTEC

MiTEC MTX-596437-60-ES-20 Operation and maintenance manual

Fukuda Denshi

Fukuda Denshi LX-7230N Operation manual

Vaisala

Vaisala HUMICAP HMT120 Series quick guide

SpreadNet

SpreadNet SN960-PENDANT installation instructions

Endress+Hauser

Endress+Hauser Proline 500 digital PROFIBUS DP Brief operating instructions

Produal

Produal KLU 100 user guide

Camel RF Electronic

Camel RF Electronic transmitter instruction manual

M-system

M-system M3LM instruction manual

TAPR WSPR Without Tears User manual

Popular Transmitter manuals by other brands
