Setting the Combination
Cable Lock
Combination windows Reset screw
Combination dials
TARGUS NOTEBOOK SECURITY
DEFCON® RETRACTABLE
COMBINATION CABLE LOCK
Thank you for purchasing the Targus Notebook Security
DEFCON®Retractable Combination Cable Lock. The Cable Lock
helps protect your valuable notebook computer fromtheft using a
resettable four-digit combination lock. The resettable combination
lock eliminates the need for keys and enables you to change your
combination periodically for increased security.
In addition to this user’s guide, this package contains:
• Retractable Cable Lock
• DEFCON®SecureSpacers
1 Locate the combination dials and windows on the lock.
Locking button
2 Using the dials, enter the current combination.
If you are setting the combination for the first time, enter the
preset combination 0000.
3

3
4
5
6
WARNING: To use the Cable Lock or reset the combination you must
set the lock to the current combination.
The combination appears in the windows.
Using a small flat-head screwdriver or similar object, push in
and rotate the reset screw 90 degrees clockwise so that the
screw’s groove appears horizontal.
Using the dials, enter the new combination.
Rotate the reset screw 90 degrees counterclockwise, back to
its original vertical position, to save the new combination.
Record the combination in either the space provided at the
end of this guide or another secure, easy-to-find place.
Testing the Combination
Before attaching the lock to your notebook computer:
1 Turn the dials to disguise the combination.
2 Return to the combination you set.
3 Check that the locking button (to the left of the combination
windows) depresses completely.
4

1
Press
Securing the Cable Lock
Select an object in the room to which you will secure your
notebook computer with the Cable Lock.
NOTE: Choose a large, heavy piece of furniture such as a table or desk,
or an immovable fixture such as a closet hanging bar.
Press the release button to extend the cable and wrap it
around the selected object.
NOTE: Wrap the cable around a part of the object that will deter an
intruder from slipping the cable off (for example, a table or desk leg
with a cross bar or a drawer handle).
2 Feed the lock through the handle of the cable housing.
5

1
2
3
4
Locking the Cable Lock to your
Notebook Computer
Using the dials, enter the correct combination.
The combination appears in the windows.
Press and hold the locking button to align the locking
teeth.
NOTE: For the locking button to depress completely you must
enter the correct combination.
Insert the Cable Lock into your notebook computer’s
lock slot and release the locking button.
NOTE: Due to the variation in the size of the security slots on
various notebook models, you may find that there is some
slack between the lock and the computer. The supplied
DEFCON SecureSpacer is the best solution for optimal fit and
security.
Turn the dials to conceal your combination.
6

1 Insert your DEFCON locking device into the
computer’s lock slot.
2 Pull the DEFCON locking device away from the
computer and check whether the gap is excessive.
3 If so, try each of the SecureSpacers to determine
which one fits the gap. The SecureSpacers come in
three sizes: 1.6 mm, 0.8 mm, and 0.4 mm.
4
Using the DEFCON SecureSpacers
NOTE: DO NOT REMOVE THE ADHESIVE STRIP FROM ANY OF THE SECURESPAC-
ERS UNTIL YOU DECIDE WHICH ONE TO USE.
Once you know which SecureSpacer you are going to
use, remove the locking device from the computer.
Then remove the adhesive strip from the back of the
SecureSpacer and attach the spacer to the DEFCON
lock.
7

1
Unlocking the Cable Lock
WARNING: Do not attempt to remove the Cable Lock without using the
combination. To do so will physically damage your notebook computer.
Using the dials, enter the correct combination.
The combination appears in the windows.
Press and hold the locking button to realign the locking
teeth.
2
3Remove the Cable Lock from your notebook
computer’s lock slot.
8

Technical Support
For technical questions, please visit:
Internet http://www.targus.com/support.asp
English http://www.targus.com/uk/support.asp
French http://www.targus.com/fr/support.asp
German http://www.targus.com/de/support.asp
Spanish http://www.targus.com/sp/support.asp
Italian http://www.targus.com/it/support.asp
Our knowledgeable staff is also available to answer your
questions through one of the following telephone
numbers.
Austria 01 795 676 42
Belgium 02-717-2451
Denmark 45 35-25-87 51
Finland 922948016
France 01-6453-9151
Germany 0211-6579-1151
Italy 02-4827-1151
Netherlands 02 0504 0671
Norway 022577729
Portugal [phone]
Spain 91 745 6221
Sweden 08-751-4058
Switzerland 01-212-0007
United Kingdom 020-7744-0330
Eastern Europe & others [phone]
9

Product Registration
Targus recommends that you register your Targus accessory
shortly after purchasing it. To register your Targus accessory, go
to: http://www.targus.com/registration.asp
You will need to provide your full name, email address, phone
number, and company information (if applicable).
Warranty
Targus warrants this product to be free from defects in materials
and workmanship for two years. If your Targus accessory is found
to be defective within that time, we will promptly repair or replace
it. This warranty does not cover accidental damage, wear and
tear, or consequential or incidental loss. Under no conditions is
Targus liable for loss of, or damage to a computer; nor loss of, or
damage to, programs, records, or data; nor any consequential or
incidental damages, even if Targus has been informed of their
possibility. This warranty does not affect your statutory rights.
