First steps with your CD-VT1
First steps with your CD-VT1..... 5
Making connections .................. 7
Using the menus........................ 9
Using the CD player................. 10
Pitch and tempo changes ........ 12
Using effects............................ 13
Facts & gures (specications) 15
About this manual
hen we refer to a key or connector
or control on the  we write it
like this PLAY 
hen we refer to an item shown on the
display we write it like this MENU 
Inserting batteries
e  uses four  
batteries not supplied e recom
mend the use of rechargeable i
batteries alkaline batteries may also
be used
 lways use batteries of the same
type
 lways replace all batteries to
gether
 f you are not going to use the
 for some time remove
the batteries
 lace the batteries following the +
and – markings inside the battery
compartment
 aximize battery life by using
the unit in the following tempera
ture range ˚ to ˚ ˚ to
˚ ickelhydride batteries
may exhibit reduced performance
in an environment under ˚
˚ lso if these batteries
are not used for some time after
charging they may also exhibit
reduced performance
 e performance of alkaline bat
teries also depends on temperature
and time since manufacture low
temperatures and longer periods
mean shorter battery life regard
less of the battery indicator as
shown on the display ear this
in mind when operating the unit
and use freshly recharged nickel
hydride batteries new alkaline
batteries or use an  adapter if
battery life seems inadequate
 lways dispose of used batteries
as recommended by your local
authorities

6 — TASCAM CD-VT1
TASCAM CD-VT1 — 7
First steps with your CD-VT1
hen the battery level drops the unit
automatically shuts down and must be
restarted with the POWER switch after
the batteries have been replaced
ote that the battery indicator on the
display only provides a rough estimate
of remaining battery life and under
some circumstances there may not be
enough power in the batteries to power
the  despite the battery
power indication on the display
Using an AC adapter
nly use a   adapter
not supplied sing another type of
 adapter may damage your 

lways make sure that the  voltage
matches the voltage written on the 
adapter
NOTE
Always remove batteries when operating the
unit with an AC adapter. If batteries are ac-
cidentally left in the unit when it is operated
with an AC adapter, always switch off the
unit before changing from AC adapter to
battery power or switching from battery to
AC adapter operation.
Switching on the unit
e  has two power switches
se the rst POWER switch sliding
switch to turn the power to the whole
unit on and o
e second switch MIC ON/OFF 
controls the power to the MIC jacks
and eect unit f this section is o you
cannot use these jacks or use any of the
vocalrelated menu systems eect and
voice changer
lso note the HOLD switch that locks
the s controls and keys when
it is in the ON position  HOLD appears in
the display when this switch is on
Auto power-save
f the unit is powered using batteries
for more than  minutes in stop mode
or with no disc loaded or opened the
 player shuts down display shows
CD OFF  but you can still use the vocal
section
estart the  player alone by using
the y / J key or use the POWER
switch if both the  and vocal sec
tions are turned o

6 — TASCAM CD-VT1
TASCAM CD-VT1 — 7
Making connections
Inputs
Connecting microphones
nly use lowimpedance dynamic
microphones you can use highimped
ance microphones but the quality may
suer or selfpowered condenser mi
crophones preferably with unbalanced
connectors o connect a microphone
to the unit simply connect the plug at
the end of the microphone cord to one
of the MIC IN jacks of the 
f you are using only one microphone
you can connect it to MIC IN 1 or MIC
IN 2 
ake sure the MIC ON/OFF power
button is pushed to activate the micro
phone and eects etc
Connecting a stereo line source
ou can also connect a stereo line
source such as the outputs from a syn
thesizer a guitar preamplier or rack
mount eects unit or a cassette deck
etc to the  se the LINE IN
minijack beside the MIC IN jacks is
unit will not be able to use the eects
of the 
WARNING
You should NEVER connect the speaker out-
puts of a bass or guitar amplier to anything
except speakers. If you are in any doubt at all
about what you can connect to your CD-VT1,
ask someone who knows.
Outputs
onnect the unit to a stereo systems
 input the inputs of a cassette
 or  recorder or mixer input
etc using a suitable stereo cable not
supplied connected to the s
LINE OUT stereo minijack
onnect a pair of headphones not
supplied to the PHONES stereo mini
jack for private listening
NOTE
If you are singing, and listening through
speakers, you should site the microphones
and speakers to avoid feedback.

8 — TASCAM CD-VT1
TASCAM CD-VT1 — 9
Use the INPUT
control to adjust the
MIC IN level(s)
You can't adjust the
input level of LINE IN
from the CD-VT1
Use the OUTPUT
control to adjust
the overall level
to the LINE OUT
and headphones
The CD plays at a fixed
level, but the MIX
feature (5 and b keys
outside menu mode)
adjusts the balance
betwen input and CD
Making connections
Adjusting the balance
Inputs
e  has three input sources
 the  being played
 the microphones connected to
the MIC IN jacks
 any stereo input connected to the
LINE IN jack
e rst and last of these cannot have
their input levels changed by the 
 but see below for details of how
to balance the  with the input
 se the level control of the device
connected to LINE IN to adjust the
level of this source remember that
this source cannot be eected by
the s eects
 se the s INPUT control
to adjust the level of the micro
phones before they are sent to the
eect
 hen a menu is not selected you
can use the 6 and n keys to set
the relative balance of the micro
phone inputs but not the LINE
IN source compared to the output
from the  player is MIX value
can be set to between –5 and +5 
emember that this is only pos
sible when not in menu mode or
when editing eects
Outputs
ere are two outputs the line and the
headphones ese cannot have their
levels set separately—use the OUTPUT
control to set the overall output level

8 — TASCAM CD-VT1
TASCAM CD-VT1 — 9
Using the menus
ee the table on this page for details of
the two menus and their settings
o enter the menu system press the
LCD MENU key until the menu you
want appears shown in a ashing re
versed box and the rst menu item is
shown on the main part of the screen
se the up or down keys 6 and
n to set the value of the rst menu
item
ote that you do not need to press
ENTER to set the values e settings
change as soon as the key is pressed
ress ENTER to move to the next
menu item in the list
ress MENU to move to the next menu
and its rst menu item
xit the menu system using the
DISPLAY/ESC key
Menu Menu
item Values Notes
KEY
KEY I5 to O5 sets key change in semitones
FINE –50 to +50 sets key change in cents
SSA 0, –8, –16, –32, –50 sets slow speed audition speed
MENU PLAY
ALL/SGL all or single play
CUE CUE/FLS cue or “ash play” operation

10 — TASCAM CD-VT1
TASCAM CD-VT1 — 11
Using the CD player
e s  player works
in much the same way as other 
players with a few minor dierences
and special features as explained on
this page
oad s label side up shiny side
down in the  pen and
close the player door by hand by lifting
the door tab marked PULL 
e display shows OPEN when the door
is opened CLOSE when it is closed and
TOC READ when a s able of on
tents  is being scanned by the
unit after being loaded
NOTE
The CD-VT1 cannot play unnalized CD-R/
RW discs. In addition, some nalized CD-R/
RW discs may be unplayable on the CD-VT1.
Playback
ress the playpause Á/π key to
start playback and to pause playback
ress the stop key ª to stop play
back
Display
se the DISPLAY/ESC key to change
the display between track elapsed
time track remaining time and total
remaining time you cannot do this in
menu mode
Skipping between tracks
se the two skipsearch keys marked
as Ô? and ¯?, to move
back and forward a track at a time by
pressing and releasing the appropriate
key
Searching within tracks
se the skipsearch keys to search
within the disc by pressing and hold
ing the appropriate key
The CUE key
e CUE key is a special feature of the
 hen you press this key the
playback position returns to the last
point where playback started
hat happens next depends on the
CUE menu item setting in the MENU
menuf this is set to CUE  playback is
paused at the cue point but if it is set
to FLS  playback restarts from the cue
point  FLASH is shown on the display
Looping (track)
sing the PLAY menu item set SGL sin
gle play ress the LOOP key so that
you see LOOP 1 on the display bottom
left e current track will repeat
Looping (disc)
sing the PLAY menu item set ALL play
all the disc ress the LOOP key so
that you see LOOP alone on the display
bottom left e whole disc will
repeat
Looping (I/O points)
se the I/O key to set the start in
point of the loop then use the key to
set the end out point e section be
tween the points will repeat seamlessly
ressing the I/O key again clears the
loop points and cancels loop mode

10 — TASCAM CD-VT1
TASCAM CD-VT1 — 11
Using the CD player
ith these points set  I-O shown on the
display you can restart the  loop
mode if it has been canceled using the
LOOP key
Canceling looping
ress the LOOP key so that LOOP does
not show on the display bottom left
Vocal Cancel
e ocal ancel feature allows you
to reduce the volume of the vocals
recorded on stereo s when they
are played back without reducing the
volume of the backing allowing you
to sing to a karaoketype backing f
you are playing back a mono  the
feature does not work and on some
s the eect is more pronounced
than on others
se the VOCAL CANCEL switch at
the side of the unit to turn the eect
on or o

12 — TASCAM CD-VT1
TASCAM CD-VT1 — 13
Pitch and tempo changes
ere are two modes for changing the
way a  is played back
ese modes help you to sing along at
a dierent key andor a dierent tempo
so that you can learn your favorite vo
cal lines
TIP
Use these together with the looping function
to help your practice.
KEY mode
e key mode changes the key of the
music by ve semitones up or down
e tempo does not change
e value is set in semitones and cents
ths of a semitone
hen this mode is on the top of the
display shows the amount that the key
has been shifted 
se this mode when you nd the key
of the  track dicult to sing
SSA mode
e  low peed udition mode
slows down the tempo without chang
ing the key e settings are  o –
– – and – all percent
hen this mode is active the display
left side shows SSA  se this mode to
practice dicult fast vocal lines
Making SSA settings
ress the MENU key so that the KEY in
dicator ashes and then press ENTER
until SSA is shown elect the  value
from  o – – – or – rep
resenting the percentage by which the
playback speed is reduced e 
mark appears on the display when the
value is not 
Making KEY settings
se the menu system to set the values
for the pitch settings key choose
KEY from the KEY menu and make the
KEY semitone and FINE settings
e  uses blob symbols at
the top of the display to show indicat
ing the current setting in semitones
hile editing a à mark is shown if
the new pitch is above or a â if the new
pitch is below the real pitch
1
2
3
n the example above 1 indicates no
change to the pitch 2 is a tone at
below and 3 is three semitones sharp
above the original pitch e sharp
and at marks are only visible while the
pitch is being edited
Remember!
 hift pitch alone and keep speed =
KEY
 low down and keep pitch = SSA

12 — TASCAM CD-VT1
TASCAM CD-VT1 — 13
Using effects
ress the EFFECT key so that EFF:OFF ap
pears on the display
se the 6 and  keys to select the
eect you want to use  01 through 18 
ee the table of eects for an explana
tion of the dierent eects available
hen an eect is active the EFFECT sym
bol appears in the display
ress ENTER to start editing the eects
parameter with the 6 and  keys
ress the DISPLAY/ESC key to exit
the eect settings e inverse EFFECT
is shown on the display as long as
an eect is active ie EFF:OFF is not
selected
Effect presets and
parameters
e dierent presets are described here
is table also shows the dierent pa
rameter ranges for each eect
OFF Off —
01 Large “pop” reverb
sound 1
0 – 20
02 Large “pop” reverb
sound 2
0 – 20
03 Large “pop” reverb
sound 3
0 – 20
04 Lively “rock” reverb 1 0 – 20
05 Lively ‘rock” reverb 2 0 – 20
06 Lively “rock” reverb 3 0 – 20
07
Vibrato and echo 1 (enka)0 – 20
08
Vibrato and echo 2 (enka)0 – 20
09
Vibrato and echo 3 (enka)0 – 20
10 Emphasizes “buried”
vocals
0 – 20
11 Detuned choral effect 0 – 20
12 Strong vocal vibrato 0 – 30
13 A anged vocal sound 0 – 30
14 Pans the voice between left
and right channels
0 – 30
15 Distorted “shouting” vocal
sound
0 – 20
16 Lo-delity vocal sound 0 – 20
17 Vocal sound through a
megaphone
0 – 99
18 Mixed duet in harmony -17 to
+17
Enka is a form of apanese popular
song usually slow and sentimental
and often with a tangolike backing

14 — TASCAM CD-VT1
TASCAM CD-VT1 — 15
Using effects
Voice changer
ou can also change the pitch of your
voice up or down using the voice
changer function you can use this
with the other eects as it is indepen
dent from them
ress the VOICE CHANGER key so
that the display shows VCHG OFF 
se the 6 and  keys to set the
voice changer to up  UP  or down  DN 
ress the DISPLAY/ESC key to exit the
voice changer mode

14 — TASCAM CD-VT1
TASCAM CD-VT1 — 15
Disc types 8cm single, 12cm
CD
AD/DA 16-bit
Digital signal processing 32-bit
Nominal output level
(LINE OUT)
–10dBV
Maximum output level
(LINE OUT)
0dBV (1Vrms)
Output impedance 1kΩ
Maximum output level
(PHONES)
> 18mW (into
32Ω
Nominal input levels
LINE IN
MIC IN (1/2)
–10dBV
–40dBV
CD playback characteristics
Frequency response 20Hz to 20kHz
±1.0dB
Dynamic range > 88dB
S/N ratio > 88dB
THD < 0.015%
Voltage requirements DC 9V (PS-PS5 AC
adapter)
AA batteries x 4
(NiMH or alkaline)
Power consumption 4W (PS-PS5 AC
adapter)
Dimensions (w x d x h)
including feet
232 x 138 x 40
(mm)
9.1 x 5.4 x 1.6 (in)
Weight (excluding
batteries)
620g / 1lb, 6oz
Facts & gures (specications)

Printed in China MA-0838
TEAC CORPORATION
3-7-3 Nakacho Musashino-shi Tokyo 180-8550 JAPAN
[phone] www.tascam.com
TEAC AMERICA, INC
7733 Telegraph Road Montebello CA 90640 USA
[phone] www.tascam.com
TEAC CANADA LTD.
5939 Wallace Street Mississauga Ontario L4Z 1Z8 CANADA
[phone] www.tascam.com
TEAC MEXICO, S.A de C.V
Campesinos No. 184 Colonia Granjas Esmeralda Delegacion Iztapalapa CP 09810 Mexico DF MEXICO
[phone] www.tascam.com
TEAC UK LIMITED
5 Marlin House, Croxley Business Park Watford Hertfordshire WD18 8TE UNITED KINGDOM
[phone] www.tascam.co.uk
TEAC DEUTSCHLAND GmbH
Bahnstrasse 12 65205 Wiesbaden-Erbenheim GERMANY
[phone] www.tascam.de
TEAC FRANCE SA
17 Rue Alexis-de-Tocqueville CE 005 92182 Antony Cedex FRANCE
[phone] www.tascam.fr
TEAC ITALIANA S.p.A.
Via C Cantu 11 20092 Cinisello Balsamo Milano ITALY
[phone] www.teac.it
TEAC AUSTRALIA PTY., LTD.
280 William St Melbourne Victoria 3000 AUSTRALIA
[phone] www.teac.com.au
» CD-VT1
