Tascam LR-10 Instruction Manual

TASCAM LR-10 1
LR-10 Release Notes
Updates
Always use the most recent rmware for this device.
Please visit the TASCAM web site at http://www.tascam.
com to check for the latest rmware.
Maintenance items
V1.01 Fixes
If you pressed and held the
•Ôor button to
search backward or forward at the very beginning or
end of a song, the speed would return to normal. This
issue has been xed.
If the
•
AREA item on the PLAY MODE screen was
set to PLAYLIST , and you set IN (starting) or OUT
(ending) points and then made a move in the playlist
or otherwise edited it, the IN and OUT points would not
be saved correctly. This issue has been xed.
If the
•
AREA item on the PLAY MODE screen is set to
PLAYLIST , and you select a le not added on the
PLAYLIST screen and then use the LOOP button to
try to set an IN (starting) or OUT (ending) point, the
following pop-up message will now appear.
File not in PLAYLIST
Note
When operating the unit using USB bus power, if you
output sound from the speaker at near maximum volume,
depending on the computer being used, the power
supply status display might change from the icon
to the icon. This is not a problem with the unit, and
battery power is not used.
Confirmation of firmware version
Conrm the rmware version of your LR-10 before
conducting a rmware update.
1 Turn the unit’s power ON.
2 Press the MENU key to open the MENU screen.
3 Use the §/BROWS or ¶/MIC button to select
INFORMATION menu item (highlight the item),
and press the Áor ¯button to open the
INFORMATION screen.
4 Use the §/BROWS or ¶/MIC button to open the
SYSTEM (3/3) page and confirm the System
Ver. (firmware version) is displayed.
You do not need to update the unit’s rmware if
the version shown is the same as or newer than the
version that you intend to use for the update.
Firmware update procedures
NOTE
When you updated the rmware, make sure that the
batteries have enough remaining power or use an optional
AC adaptor (PS-P520). The program has been set so that the
update will not be conducted if battery power is insucient.
1 Download the most recent firmware from the
TASCAM web site (http://www.tascam.com).
2 Turn the unit’s power ON and use the included
USB cable to connect it with a computer. This unit
will be recognized as an external drive (external
storage device) by the computer.
3 Copy the downloaded firmware to the UTILITY
folder on the LR-10.
4 After copying has completed, disconnect the
unit from the computer following the correct
procedures, remove the USB cable and turn the
unit power OFF.
5 While pressing and holding both the Ôand Á
buttons, turn the unit power ON.
The unit starts up in update mode, and the update le
appears on the screen.
NOTE
If this screen does not appear, turn the power OFF. Then
•
while pressing and holding both the Ôand Ábuttons,
turn the unit’s power ON again. Continue to press and
hold the Ôand Ábuttons rmly until this screen
appears.
When rmware has been copied to this unit’s UTILITY
•
folder from a Mac, in addition to the rmware le itself,
another le with “._” added to the beginning of the
rmware name is also shown. Use the le without the “._”
at the beginning of the name.
This screen shows a list of the rmware update les inside
•
the UTILITY folder of the unit. Also, the screen shows the
rmware copied at Step 3 above. “No Update File” appears
if there is no update le in the UTILITY folder.
The screen shown is an example. The actual display diers.
•
6 Select the firmware (highlight the item) then press
Ábutton.
The following screen appears.
D01141600A

LR-10 Release Notes
2TASCAM LR-10
The current version appears on the left and the
updated version appears on the right.
NOTE
The screen shown is an example. The actual display diers.
7 Press the Ábutton to start the update.
8 When the update is complete, Update Complete
appears at the bottom of the screen and the power
turns OFF automatically. Turn the power ON again.
9 Follow the “Confirmation of firmware version”
instructions above to check that the System
Vers. is now the most recent version of the
firmware.
This completes the procedure for updating this unit.
10 Connect to a computer with USB and delete the
firmware update from the unit’s UTILITY folder.
