MANUAL: HYDRANT MASTER
REMOTE CONTROL HYDRANT SLIDE VALVE
INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE
WARNING Read instruction manual before use. Operation of this device without understanding the manual
and receiving proper training is a misuse of this equipment. Please call 800-348-2686 with any
questions.
WARNING This instruction manual is intended to familiarize firefighters and maintenance personnel with
the operation, servicing, and safety procedures associated with the Hydrant Master.
WARNING This manual should be kept available to all operating and maintenance personnel.
OPERATING RANGE:
Pressure Max 300 PSI
Pressure Min 10 PSI
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com 3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219- 462-6161 • Fax [phone]

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefighting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefighting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynnfield, MA 01940 • www.FEMSA.org
Table Of Contents
1.0 MEANING OF SAFETY SIGNALWORDS
2.0 SAFETY
3.0 GENERALINFORMATION
3.1 VALVE SPECIFICATIONS
3.2 WIRELESS HANDHELD REMOTE CONTROLSPECIFICATIONS
3.3 CORROSION
3.4 USE WITH SALT WATER
3.5 LOW TEMPERATURE USE
3.6 FEATURE IDENTIFICATION
3.7 DISPLAY & CONTROLPANEL
3.7.1 PRESSURE DISPLAY
3.7.2 PHOTO SENSOR
3.7.3 BUTTONS
3.7.4 LEDS
3.7.5 VALVE POSITION INDICATORS
3.8 POWER SAVE MODE
3.9 VALVE POSITION INDICATOR & MECHANICALOVERRIDE
3.10 FLOW CONTROLFEATURE
3.11AUTOMATIC DRAIN
3.12AIR FLUSH PORT
4.0 INSTALLATION & CONFIGURATION
4.1 VALVE STORAGE BRACKETINSTALLATION
4.2 HANDHELD REMOTE CONTROLSTORAGE BRACKETINSTALLATION
4.3 SECONDARYHANDHELD REMOTE CONTROL
5.0 USE
5.1 PREPARING VALVE FOR USE
5.2 OPERATOR INSTRUCTIONS & VALVE FUNCTION
5.3 PRESSURE LOSS
6.0 MAINTENANCE
6.1 CHANGING BATTERIES
6.2 TROUBLESHOOTING
7.0 EXPLODED VIEW
7.1 PARTS LIST
7.2 INLET COMPONENTS
7.3 OUTLET COMPONENTS
8.0 WARRANTY

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
3
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a
particular hazard. Per ANSI standard Z535.6-2006, the definitions of the four signal words are as follows:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
2.0 SAFETY
WARNING Injury or death may occur by attempting to use a damaged valve.
Per NPFA 1962, the device shall be inspected and tested at least quarterly.
Before use, inspect for damage resulting from:
• Failure to drain valve followed by exposure to freezing conditions
• Exposure to temperatures in excess of 160 degrees F
• Missing parts, physical abuse
WARNING This equipment is intended for use by trained personnel for firefighting. Its use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
WARNING Kinks in supply hose may reduce water flow and cause injury or death to persons dependant
on water flow. Avoid tight bends to minimize risk of hoseline kinks.
WARNING The Hydrant Master is not rated for use in explosive atmospheres.
WARNING The valve may be damaged if frozen while containing significant amounts of water. Such
damage may be difficult to detect visually and can lead to possible injury or death. Any time
the valve is subject to possible damage due to freezing, it must be hydrostatically tested by
qualified personnel before being considered safe for use.
WARNING Minimum operating pressure 5 psi (0.3 bar). Inadequate water pressure will prevent valve from
opening and may result in a lack of water flow and cause injury or death to persons dependant
on water flow. Ensure there is adequate water pressure supplied to inlet of valve.
CAUTION Maximum operating pressure is 300 psi (20 bar). Exceeding 300 psi (20 bar) on either side of
the valve may damage valve and could cause injury.
CAUTION Valve must be properly connected. Mismatched or damaged connectors may cause leaking or
uncoupling under pressure and could cause injury.
CAUTION Any alterations to the valve and its markings could diminish safety and constitutes a misuse
of this product.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
4
3.0 GENERAL INFORMATION
The Hydrant Master is a lightweight, low friction-loss hydrant valve that can be used in many water distribution applications. The
valve is powered by (4) AA batteries, pressure activated, and equipped with a power-save mode. A handheld controller with
pressure display and valve position feedback controls the valve up to 1200 feet (366 m) away. Both the valve and handheld are
equipped with backlighting for use in low-light situations. The valve opens and closes with a sliding plug which is compliant with
NFPA 1965 slow close requirements. The valve’s position is controlled by operating a control valve which can be moved manually,
operated electronically from push buttons on the valve, or by wireless remote control.
3.1 VALVE SPECIFICATIONS
Main LDH Waterway size (at valve seat): 4.5” (114 mm)
Meets NFPA 1965 3.3.11.3 Slow-Operating Valve requirement.
Minimum Operating Pressure: 5 psi (0.7 Bar) NOT FOR SUCTION USE.
Maximum Operating Pressure: 300 psi (20 bar)
Hydrostatic Proof Test Pressure: 900 psi (62 bar)
Temperature Rating*: -25°F to 135°F (-32°C to 57°C)
Batteries: 4 AA batteries, Lithium recommended
Expected valve battery life: 140 hours lithium, 100 hours alkaline
*For temperatures below 32°F (0°C), valves must be drained after use to avoid damage. See section 3.5 LOW TEMPERATURE
USE
Environmental Rating: All components designed to meet minimum rating of NEMA 4 (IP65).
3.2 WIRELESS HANDHELD REMOTE CONTROL SPECIFICATIONS
Batteries: 4 AA batteries, Lithium recommended
Expected handheld remote control battery life: 55 hours lithium, 40 hours alkaline
Specifications 900 MHz 2.4 GHz
Transmitting Power 100mW 10mW
Operating Range (Line of sight) 1200 ft (366m) 600 ft (183m)
Operating Frequency 900 MHz (902-928 MHz) 2.4GHz (2.410-2.470 GHz)
Agency Approvals 900 MHz 2.4 GHz
FCC MCQ-XBEEXSC OUR-XBEEPRO
Industry Canada (IC) 1846A-XBEEXSC 4214AXBEEPRO
Europe N/AETSI N/A ETSI
Finished Good # AU-RU-900 Contains FCC ID: MCQ-XBEEXSC The enclosed device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (i.) this device may not cause harmful interference and (ii.) this device must
accept any interference received, including interference that may cause undesired operation.
Finished Good # AU-RF-2400 Contains FCC ID: OUR-XBEEPRO The enclosed device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (i.) this device may not cause harmful interference and (ii.) this device must
accept any interference received, including interference that may cause undesired operation.
3.3 CORROSION
Most hose couplings are attached using polymer bearing rings which provide electrical insulation to help galvanic corrosion.
The parts are hard anodized, and powder coated to help prevent corrosion. The effects of corrosion can be minimized by good
maintenance practice. See section 3.12 AIR FLUSH PORT & 6.0 MAINTENANCE.
3.4 USE WITH SALT WATER
Use with salt water is permissible provided valve is thoroughly cleaned with fresh water after each use. The service life of the valve
may be shortened due to the effects of corrosion and is not covered under warranty.
3.5 LOW TEMPERATURE USE
The valve is designed with self-draining waterways. In extreme freezing conditions, extra precautions should be taken to ensure
control waterways remain free from ice. Residual water should be cleared from the valve after each use. See section 3.12 AIR
FLUSH PORT.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
5
3.6 FEATURE IDENTIFICATION
AIR FLUSH PORT
CONTROL VALVE
SLIDING PLUG
CONTROL VALVE
BLEED DRAIN
AUTOMATIC DRAIN VALVE
CONTROL
VALVE FILTER
INLET
OUTLET
BATTERY
COMPARTMENT
VALVE INDICATOR AND
MECHANICAL OVERRIDE
ANTENNA
DISPLAY AND
CONTROL PANEL
HANDHELD
REMOTE CONTROL

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
6
3.7 DISPLAY & CONTROL PANEL
OPEN BUTTON
VALVE POSITION
FEEDBACK INDICATORS
CLOSE BUTTON
POWER BUTTON
PRESSURE DISPLAY
PHOTO SENSOR
RADIO LINK LED LOW BATTERY LED
3.7.1 PRESSURE DISPLAY
Pressure remote controls will flash when valve is turned on. The pressure display shows the current hydrant pressure on both valve
and handheld while valve is in use. When inlet pressure exceeds 250psi, “HI” is displayed.
3.7.2 PHOTO SENSOR
Turns backlighting on in low-light situations. Adjusts display brightness to improve readability in sunlight.
3.7.3 BUTTONS
BUTTON FUNCTION
Power Turns unit on and off *
Open Opens valve
Close Closes valve
* Valve will not turn off with button press if pressure exceeds 5 psi (0.3 bar).
3.7.4 LEDS
LED COLOR STATUS MEANING
Radio Link Green On Radio link present between valve and handheld remote control.
Radio Link Green Off Radio link not present. Move handheld remote control closer to valve.
Low Battery Red Off Battery voltage is adequate to power valve or handheld.
Low Battery Red Blinking Battery voltage is low. Replace Batteries.
See Section 6.1 Replacing Batteries.
3.7.5 VALVE POSITION INDICATORS
The Hydrant Master is equipped with a valve position feedback system to indicate the control valve position and actual sliding plug
position.
LED STATUS CONTROL VALVE POSITION ACTUAL SLIDING PLUG POSITION
Green On Open Fully open position
Yellow & Green Alternating Open Moving to open position
Yellow & Red Alternating Closed Moving to closed position
Yellow On Unknown Between open and closed position
Yellow Flashing Unknown No position feedback to handheld
Red On Closed Fully closed position

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
7
3.8 POWER SAVE MODE
The Hydrant Master is equipped with a power save mode. The valve automatically enters the power save mode when no buttons
have been pressed for five minutes. The display and backlighting will turn off. The valve position feedback system will continue
to update and flash the current position every 3 seconds. To exit power save mode, push either the open or closed button. The
handheld remote control will automatically power down after five minutes of no button presses. Turning the handheld remote control
back on will not change the valve’s position.
3.9 VALVE POSITION INDICATOR & MECHANICAL OVERRIDE
The valve is equipped with a valve indicator which shows the position of the control valve. The sliding plug will be open when the
control valve is open and there is more than 5psi (0.3 bar) pressure. The valve indicator can be used as a mechanical override In
case of electronic failure. Swing the arm to the open position to open the valve or to the closed position to close the valve.
VALVE POSITION INDICATOR
AND MECHANICAL OVERRIDE
CLOSED POSITION OPEN POSITION
FLOW CONTROL POSITION
3.10 FLOW CONTROL FEATURE
The Hydrant master is equipped with a flow controlling program to maintain a maximum flow of 1000 gpm for the first 15 seconds
the valve is opening. The valve position indicator will move to the full open position, move back to the flow control position, and then
return to the full open position after 15 seconds. The flow controlling program prevents a hose line from charging at a rapid rate and
helps avoid water hammer situations.
WARNING Minimum operating pressure 5 psi (0.3 bar). Inadequate water pressure will prevent valve from
opening and may result in a lack of water flow and cause injury or death to persons dependant on
water flow. Ensure there is adequate water pressure supplied to inlet of valve.
3.11 AUTOMATIC DRAIN
The Hydrant Master is equipped with an automatic drain that will empty trapped water from the main waterway of the valve. The
automatic drain closes when the internal pressure is approximately 5 psi (0.3 bar) or above and opens when the internal pressure
is below 5psi (0.3 bar).
3.12 AIR FLUSH PORT
The valve is equipped with an air flush port. Remove the cap. Use a standard air chuck to apply a minimum of 20 psi (1.4 bar) to the
air flush port. Open and close the control valve. Residual water will be forced out through the filter and control valve bleed drain.
CAUTION The sliding plug is pinch hazard that can cause injury. Keep hands and fingers outside of the
valve any time air is applied to air flush port.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
8
4.0 INSTALLATION & CONFIGURATION
4.1 VALVE STORAGE BRACKET INSTALLATION
A storage bracket is available for the Hydrant Master. The valve can be stored with hose pre-connected to the inlet and/or outlet
of the valve. The storage bracket can be mounted vertically or horizontally as shown with the included self-tapping stainless steel
screws. The bracket requires 12.5” x 11.1” (317.5mm x 281.9mm) of panel space.
To purchase a bracket, order TFT part numberAU-BRACKET.
4.2 HANDHELD REMOTE CONTROL STORAGE BRACKET INSTALLATION
The storage bracket for the handheld remote control is supplied with (3) ¼-20 stainless steel self-tapping screws. Make sure the
area on the backside of the mounting surface is clear of obstructions. A minimum thickness of 3/32” (.093” – 2.4mm) in aluminum
or 5/64” (.078” – 2mm) in steel is recommended. See the chart below to determine the correct pilot hole size.
Select proper location for mounting storage bracket. Panel space required will be 6.0” x 11.2” (152 x 285mm). Refer to graphic
below for dimensions. Bracket can be used as a template. Be sure spring is in position.
5"
[127mm]
6"
[152mm]
Drill (3) Pilot Holes (refer to hole size chart)
Mount Bracket with (3)
(be sure spring is in position)
1/4-20 Self-Tapping Screws.
Tighten Securely.
SPRING
Material Hole Size Use Material Hole Size Use
Thickness Inches mm Drill Thickness Inches mm Drill
5/64-3/32 .206 5.2 #5 3/32 .213 5.4 #3
1/8 .213 5.4 #3 1/8 .221 5.6 #2
3/16 .221 5.6 #2 3/16 .228 5.8 #1
ALUMINUM STEEL
Hole Size Chart For Self Tapping Screws

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
9
4.3 CONFIGURING HANDHELD REMOTE CONTROL
Every valve has a unique ID code that allows multiple valves to be used in one location without interference. This unique ID code
must be “taught” or “transferred” to the handheld remote control. Each valve’s primary wireless handheld remote control will be
shipped from the factory pre-taught. The valve can be controlled with secondary handheld remote controls. Secondary handheld
remote control must be taught the valve’s unique ID code. Perform the following procedure to teach the handheld remote control.
NOTE: Before teaching, valve should be powered down.
NOTE: If multiple valves are present, apply power only to the valve being taught, otherwise possible conflicts may occur.
NOTE: If handheld remote control is unable to be taught, it will exit teach mode by powering down after one minute.
On handheld remote control:1. Press and hold the Open and Closed buttons.• Press and release the Power button.• Continue to hold the Open and Closed buttons for 3 seconds.• Three decimal points on the display will turn on, indicating the Handheld remote control is in Teach Mode.• Release the Open and Closed buttons.•
On Valve:2. Press and hold the Open and Closed buttons.• Press and release the Power button.• Continue to hold the Open and Closed buttons for 3 seconds.• Three decimal points on the display will turn on, indicating the valve is in Teach Mode.• Release the Open and Closed buttons.• The display will toggle between three bars on bottom and three bars on top while the ID is being transmitted to the• Handheld.
The handheld will automatically exit the teach mode upon successfully receiving a valid ID. The Radio Link LED will be lit for3. 5 seconds.
Cycle power off and back on to valve to complete the process.4.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
10
5.0 USE
5.1 PREPARING VALVE FOR USE
The Hydrant Master MUST be hooked to hose or hydrant on BOTH sides of the valve before use.
BEFORE USE SAFETY
Make connections to
hydrant or fire hose on
each side of valve.
Ensure that flow will
move in the direction
indicated on the valve.
WARNING
Valve will not properly open or close
if flow direction does not match arrow
printed on exterior of valve. Reducing
or interrupting of flow may cause
injury or death to persons dependent
on water flow.
Verify that valve indicator
is in closed position
to ensure that valve is
closed.
CAUTION
Pressurizing hydrant with valve in
open position could prematurely
charge hose line.
Raise antenna on valve. CAUTION
Leaving antenna in the lowered
position may reduce range of
handheld remote control.
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability
to unscrew the threads and complete loss of thread engagement over time. Per NFPA 1962
(2008 edition), if dissimilar metals are left coupled together, an anti-corrosive lubricant should
be applied to the threads. Also, the coupling should be disconnected and inspected at least
quarterly.
CAUTION Use care when handling male fire hose couplings. Threads are sharp and can cause injury when
mishandled.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
11
5.2 OPERATOR INSTRUCTIONS AND VALVE FUNCTION
OPERATOR INSTRUCTIONS
Open hydrant to pressurize valve.
Use Power button to activate handheld remote control.
VALVE FUNCTION
Pressure inside valve exceeding 10 psi automatically activates
valve electronics.
POSITION FEEDBACK
Constant red LED indicates valve is closed.
OPERATOR INSTRUCTIONS
When water is required, push the Open button on handheld
remote control or valve.
VALVE FUNCTION
Electronics opens control valve, allowing water pressure to
build in control chamber and open sliding plug.
POSITION FEEDBACK
Flashing yellow & green LEDs indicate sliding plug is moving
to open position.
Constant green LED indicates sliding plug in fully open
position.
OPERATOR INSTRUCTIONS
When water is no longer desired, push the Close button on
handheld remote control or valve.
VALVE FUNCTION
Electronics closes control valve, allowing the water from control
chamber to drain to ground and close sliding plug.
POSITION FEEDBACK
Flashing red & yellow LEDs indicate sliding plug is moving to
closed position.
Constant red LED indicates sliding plug in fully closed
position.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
12
5.3 PRESSURE LOSS
RC HYDRANT SLIDE VALVE - LOSS
0.0
0.5
1.0
1.5
2.0
2.5
3.0
0 200 400 600 800 1000 1200 1400 1600 1800 2000
FLOW (GPM)
LOSS (PSI)
6.0 MAINTENANCE
This valve should be disconnected, cleaned and visually inspected inside and out at least quarterly for proper function per NFPA
1962 Section 8.2, or as water quality and use may require. Moving parts should be checked for smooth and free operation. Seals
shall be greased as needed with a silicone-based grease such as Dow Corning 112. Any scrapes that expose bare aluminum
should be cleaned and touched up with enamel paint such as Rust-Oleum.
In particular assure that:
• There is no damage such as cracks or dents
• There is no corrosion
• The waterway is clear of obstructions
• The sliding plug moves freely (Use Air Flush Port to test according to section 3.12 AIR FLUSH PORT)
Replace any missing or damaged parts before returning to service. Any repaired device must be tested before being placed in
service.
CAUTION Any alterations to the device and its markings could diminish safety and constitute a misuse
this product.
6.1 CHANGING BATTERIES
HANDHELD CONTROLLER
• Four (AA) Batteries required, Lithium strongly recommended.
• Remove two (2) screws on backside of handheld remote control.
• Slide bottom half of rubber bumper off enclosure.
• Replace batteries, verifying polarity is correct.
• Replace bumper and retaining screws.
VALVE
• Four (AA) Batteries required, Lithium strongly recommended.
• Remove retaining screw from battery compartment lid.
• Slide lid open.
• Replace batteries, verifying polarity is correct.
• Replace lid and retaining screw.
CAUTION Properly dispose of old batteries. Do not puncture, incinerate, or disassemble batteries. Do
not mix battery types.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
13
6.2 TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE REMEDY REFERENCE
No power LED. Low or drained batteries Replace batteries 6.1 CHANGING
BATTERIES
Power LED on but no
operation. Battery voltage too low Replace batteries 6.1 CHANGING BATTERIES
No radio link LED.
Handheld remote control
does not operate valve,
valve controls do work.
Handheld is out of range. Move handheld closer
to valve or eliminate
interference.
Valve and handheld remote
control are not linked
properly.
Teach handheld. 4.3 CONFIGURING
HANDHELD REMOTE
CONTROL
Handheld is flashing yellow
LED
Valve is off. Power up valve. 4.3 CONFIGURING
HANDHELD REMOTE
CONTROL
Valve and handheld remote
control are not linked
properly.
Teach handheld.
Control valve opens but
yellow and green LEDs
continue to flash.
Valve is installed
backwards Reinstall valve so flow arrow matches flow
direction.
5.1 PREPARING VALVE
FOR USE
Inadequate pressure. Increase inlet pressure.
Debris or ice in control
passages. Clear control passages. 3.12 AIR FLUSH PORT
Valve position feedback
system malfunctioning. Consult Task Force Tips Service Department.
Red and Green LEDs
flashing Valve position feedback system malfunctioning Consult Task Force Tips Service Department.
Pressure display reads “Hi” Inlet pressure is above
250psi. Decrease inlet pressure.

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
14
7.0 EXPLODED VIEW
26

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
15
7.1 PARTS LIST
ID QTY PART # DESCRIPTION
11 SEE CHART GASKET
21 SEE CHART INLET COUPLING
31 SEE CHART PLASTIC STRIP
46 VT31-18SH1.0 5/16-18 X 1 SOCKET HEAD SCREW
51 A2120 CONTROL VALVE FILTER
61 SEE CHART VALVE BODY
74 A2037 MOUNTING FOOT
81 VO-130 O-RING-130
91 VT25-28BH500 1/4-28 X 1/2 BUTTON HEAD SCREW
10 1 VW687X281-50 FLAT WASHER 1/4"
11 1 X382 DRAIN VALVE
12 1 X375 DRAIN HOUSING
13 3 A2135 SPACER - .14ID X 1.00LONG
14 1 A2210 SERVO - FUTABA
15 1 A2132 GEAR
16 3 VT06-32SH1.2 6-32 X 1 1/4 SOCKET HEAD SCREW
17 1 VOM-1.9X2.8 O-RING METRIC 1.9 x 2.8
18 1 A2123 CONTROL VALVE SHAFT
19 1 A2131 GEAR
20 1 A2215 SWITCH - PRESSURE 10 PSI
21 1 A2185 ELECTRONICS COMPARTMENT LID
22 4 VT25-20SH500 1/4-20 X 1/2 SOCKET HEAD SCREW
23 1 VR4250 SNAP RING 1/2" EXTERNALX .035
24 1 VO-014 O-RING-014
25 1 A2230 ANTENNA - 1/4 WAVE
26 1 VO-167 O-RING-167
27 1 A2141 BATTERY COMPARTMENT LID
28 4 --- BATTERY - AA1.5 VOLT LITHIUM
29 1 VO-154 O-RING-154
30 4 VT25-20BH375 1/4-20 X 3/8 BUTTON HEAD SCREW
ID QTY PART # DESCRIPTION
31 2 A2136 TRANSDUCER RETAINER
32 1 A5845 TRANSDUCER - PRESSURE
33 2 A2220 SWITCH - REED
34 2 VO-013 O-RING-013
35 2 A2121 CONTROL VALVE SEAT
36 1 A2122 CONTROL VALVE BALL
37 1 VP188X.375 DOWEL PIN .188DIAX .375LONG
38 1 A2110 VALVE SHAFT
39 1 VO-220 O-RING-220
40 1 A2111 VALVE SLEEVE
41 1 A2126 RETURN SPRING
42 1 VO-236 O-RING-236
43 1 A2112 SLIDING PLUG
44 1 VO-214 O-RING-214
45 1 A2113 VALVE SHAFT END
46 1 VO-243 O-RING-243
47 1 VO-211 O-RING-211
48 1 VT75-10LNT 3/4" LOCK NUT
49 1 VT25-20SH500 1/4-20 X 1/2 SOCKET HEAD SCREW
50 1 VO-111 O-RING-111
51 1 A2114 VALVE SEAT
52 1 VO-252 O-RING-252
53 1 SEE CHART OUTLET MATE
54 1 SEE CHART CUP SEAL
55 1 SEE CHART PLASTIC STRIP
56 1 SEE CHART LOCKOUT SCREW
57 1 SEE CHART OUTLET COUPLING
58 1 Y5946 LATCH SPRING
59 1 Y5945 HOLSTER
60 1 A2270 WIRELESS HANDHELD
7.2 INLET COMPONENTS
ID QTY DESCRIPTION 4.0" STORZ 5.0" STORZ 6.0" STORZ 4.0" FEMALE 4.5" FEMALE 5.0" FEMALE
61 VALVE BODY A2101 A2101 A2101 A2101 A2100 A2100
11 GASKET -- -- -- V3198 V3210 V3220
21 INLETCOUPLING A4124 A4125 A4126 A4562N A4568NR A4573NT
31 PLASTICSTRIP A1292 A1291 A1291 A1291 A1293 A1293
1 CUPSEAL A1597 A1596 A1596 -- -- --
1 LOCKOUTSCREW A1294 A1294 A1294 -- -- --
1 NFSRING -- -- -- A4561 -- --
1 O-RING -- -- -- VO-248 -- --
1 MATE PSM4.25 X PSF5.25 A4730 -- -- -- -- --
1 CUPSEAL A1596 -- -- -- -- --
1 PORT COVER A1298 -- -- -- -- --
1 PLASTICSTRIP A1291 -- -- -- -- --

©Copyright Task Force Tips, Inc. 2011-2012 LIA-520 April 25, 2011 Rev01
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com 3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219- 462-6161 • Fax [phone]
8.0 WARRANTY
Task Force Tips, Inc., 3701 Innovation Way, Valparaiso, IN 46383-9327 (*TFT*) warrants to the original purchaser of its Hydrant
Master (*equipment*), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the five (5) year period from the date of purchase.
TFT’s obligation under this warranty is specifically limited to replacing or repairing the equipment (or its parts) which are shown by
TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited warranty, the claimant must return
the equipment to TFT, at 3701 Innovation Way, Valparaiso, IN 46383-9327, within a reasonable time after discovery of the defect.
TFT will examine the equipment. If TFT determines that there is a defect attributable to it, TFT will correct the problem within a
reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT. It is
agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this warranty if the equipment is, or has been, misused or neglected (including failure to provide
reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT
ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR
PURPOSE. THERE IS NO WARRANTY OFANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
7.3 OUTLET COMPONENTS
ID QTY DESCRIPTION 4.0" STORZ 5.0" STORZ 6.0" STORZ 4.0" MALE 4.5" MALE 5.0" MALE
53 1 OUTLETMATE A2115 A2115 A2115 A2115 A2115 A2115
54 1 CUPSEAL A1597 A1596 A1596 A1596 A1596 A1596
55 1 PLASTICSTRIP A1292 A1291 A1291 A1291 A1291 A1291
56 1 LOCKOUTSCREW A1294 A1294 A1294 A1294 A1294 A1294
57 1 OUTLETCOUPLING A4124 A4125 A4126 A4620N A4625N A4630N
1 PORT COVER A1298 -- -- -- -- --
1 PORT PLUG A1299 A1299 A1299 A1299 A1299 A1299
1 MATE PSM4.25 X PSF5.25 A4730 -- -- -- -- --
1 CUPSEAL A1596 -- -- -- -- --
1 PLASTICSTRIP A1291 -- -- -- -- --
