Task Force Tips CrewProtect 20 Programming manual

©Copyright Task Force Tips LLC 2022 1 LIC-020 May 5, 2022 Rev00
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
G-Force
INSTRUCTION FOR INSTALLATION, OPERATION, AND MAINTENANCE
CrewProtectTM20
Multi-Threat Air Decontamination System
DANGER
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serial-number.
This instruction manual is intended to familiarize installers, end users, and maintenance personnel
with the operation, servicing, and safety procedures associated with this product. This manual
should be kept available to all operating and maintenance personnel.

©Copyright Task Force Tips LLC 2022 2 LIC-020 May 5, 2022 Rev00
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 GENERAL INFORMATION
2.1 PART IDENTIFICATION
2.2 SPECIFICATIONS
3.0 INSTALLATION
3.1 CARTRIDGE INSTALLATION
3.2 MOUNTING
3.3 WIRING
4.0 OPERATION
5.0 WARRANTY
6.0 MAINTENANCE
6.1 CARTRIDGE LIFECYCLE
6.1 CHANGING THE CARTRIDGE
6.2 DISPOSING OF THE CARTRIDGE
7.0 REPAIR
8.0 OPERATION AND INSPECTION CHECKLIST
The member companies of FEMSA that provide emergency
response equipment and services want responders to know and
understand the following:
1. Firefighting and Emergency Response are inherently
dangerous activities requiring proper training in their hazards
and the use of extreme caution at all times.
2. IT IS YOUR RESPONSIBILITY to read and understand
any user’s instructions, including purpose and limitations,
provided with any piece of equipment you may be called on
to use.
3. IT IS YOUR RESPONSIBILITY to know that you have been
properly trained in Firefighting and/or Emergency Response
and in the use, precautions, and care of any equipment you
may be called upon to use.
4. IT IS YOUR RESPONSIBILITY to be in proper physical
condition and to maintain the personal skill level required to
operate any equipment you may be called upon to use.
5. IT IS YOUR RESPONSIBILITY to know that your equipment is
in operable condition and has been maintained in accordance
with the manufacturer’s instructions.
6. Failure to follow these guidelines may result in death, burns or
other severe injury.
Fire and Emergency Manufacturers and Service Association, Inc.
PO Box 147, Lynnfield, MA 01940 • www.FEMSA.org
© 2020 FEMSA. All Rights Reserved.
PERSONAL RESPONSIBILITY CODE
DANGER

©Copyright Task Force Tips LLC 2022 3 LIC-020 May 5, 2022 Rev00
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
2.0 GENERAL INFORMATION
The CrewProtect 20 cabin air decontamination system is connected to the vehicle power system to decontaminate the air in the cabin
anytime the truck is actively powered. Periodic replacement of cartridges ensures maximum decontamination of harmful particulates,
VOCs, viruses, bacteria, and mold.
2.1 PART IDENTIFICATION
Figure 2.1
2.2 SPECIFICATIONS
Table 2.2
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
Dimensions inch (mm) 7 x 6 x 4 (178 x 152 x 102)
Decontamination Protection Particulates, VOCs, Viruses, Bacteria, Mold
Cartridge Status Indicator Tri-color LED
Flow Rate 20 CFM (nominal)
Operating Pressure 1 Atmosphere
Current Draw 1A @ 12V or .5A @ 24V
Power Draw 12W (nominal)
Recommended Fuse 2A for 12V or 1A for 24V
Sound (fan running) 45 dB (nominal)
Mounting
Bracket
Decontamination
Cartridge
Insert
Cartridge
Removal Tabs
Air Ducts
Cartridge Status
LED

©Copyright Task Force Tips LLC 2022 4 LIC-020 May 5, 2022 Rev00
3.0 INSTALLATION
3.1 CARTRIDGE INSTALLATION
The cartridge is shipped in the unit with a protective wrap covering. Prior to starting the unit, remove the protective wrap and reinstall the
cartridge following the instructions in "Changing the cartridge" on page 7.
3.2 MOUNTING
1. Choose a mounting location.
2. To ensure proper hole location, use the mounting bracket as a template.
A. Remove (2) screws from the right and left sides of the unit to separate the mounting bracket from the unit.
3. Secure the bracket using (4) nuts and bolts (not provided).
4. Secure the unit to the bracket by replacing the screws removed in step 2A.
Figure 3.2
NOTICE
Protective plastic wrap should not be removed from the cartridges until ready for installation as the
effectiveness of the molecular material starts degrading after exposure to oxygen.
Failure to remove the protective wrap from the cartridge prior to installation will cause the unit to
overheat and turn off due to lack of air flow.
WARNING
An inadequately secured unit may become dislodged as a result of a sudden stop or collision,
causing injury or equipment damage. To reduce the risk of injury:
• Mount the device on a surface material capable of supporting 50 pounds in the direction of truck
travel and 15 pounds in any other direction, per NFPA 1901.
• Use fasteners of a size, strength, and length adequate to securely hold the device.
NOTICE
To ensure proper air flow and function of the CrewProtect:
• Choose a location where there is at least 1” of free space around all air ducts.
• Keep air ducts free from obstruction by loose items such as clothing, paper, dirt, or equipment.
• Do not place heavy objects on the unit.
• Do not use the unit as a shelf.
7.3 (185)
6.1 (155)
3.0 (76)
5.44 (138)
4X R.100
(2.5)
MOUNTING BRACKET
HOLE PLACEMENT
COMPLETE UNIT
OVERALL DIMENSIONS

©Copyright Task Force Tips LLC 2022 5 LIC-020 May 5, 2022 Rev00
3.3 WIRING
The CrewProtect 20 is wired to the truck electrical system, allowing continuous decontamination of cabin air while the truck is actively
powered. Use the provided wiring diagram to ensure proper wiring.
Figure 3.3
4.0 OPERATION
Because the CrewProtect 20 is wired directly to the truck electrical system, continuous air decontamination occurs the entire time the
truck is actively powered.
Regular cartridge replacement ensures optimal air decontamination. See section 6.0 on page 7 for cartridge lifecycle and replacement
instructions.
NOTICE
Always disconnect power before installing or servicing electrical components. Failure to do so
could cause damage to the circuit boards.
Internal
Pigtails
Requirements:
Minimum Wire Gauge - 18 AWG
Minimum Fuse
12V system - 2A slow blow fuse
24V system - 1A slow blow fuse
12V/24V
(fuse)

©Copyright Task Force Tips LLC 2022 6 LIC-020 May 5, 2022 Rev00
5.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the three (3) year period from the date of purchase. TFT’s obligation under this warranty is specifically limited to
replacing or repairing the equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to
TFT. To qualify for this limited warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is
a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT
will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is an
intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental damages
for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 2022 7 LIC-020 May 5, 2022 Rev00
6.0 MAINTENANCE
6.1 CARTRIDGE LIFECYCLE
The cartridge will function for 1,800 hours of continuous usage or 6 months of intermittent use. The current condition of the cartridge is
tracked via the three LED lights on the prominent face of the device with the following statuses:
Table 6.0
6.1 CHANGING THE CARTRIDGE
Figure 6.1
6.2 DISPOSING OF THE CARTRIDGE
The cartridge material is designed to neutralize the toxins captured in the cartridge, rendering them no longer hazardous. Used
cartridges can be disposed of in normal refuse.
Hours of Continuous Use
or
Months of Intermittent Use LED Color
0-1500 0-4.9 Solid Blue
1501-1799 5-5.9 Solid Yellow
1800+ 6+ Solid Red
NOTICE
To ensure the device is optimally decontaminating the cabin air, the cartridge should be changed
when the LED color is YELLOW.
When the indicator turns RED, the device will stop operating until the cartridge is replaced with a
new cartridge.
NOTICE
All replacement parts must be obtained from Task Force Tips and its approved dealer network to
assure proper performance and operation of the device.
1
2
3
To Change the Cartridge:
1. Press the cartridge tabs in on both sides.
2. Pull the old cartridge off of the unit.
3. Place the new cartridge into the unit.
The cartridge only fits in 1 orientation.
Push the new cartridge in until the
tabs click into place.

©Copyright Task Force Tips LLC 2022 8 LIC-020 May 5, 2022 Rev00
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
7.0 REPAIR
Factory service is available. Factory serviced equipment is repaired by experienced technicians, tested to original specifications, and
promptly returned. All returns require a Returns Goods Authorization (RGA) number. Call TFT service department at 1-800-348-2686 to
troubleshoot and if needed, obtain an RGA and directions for return.
8.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE and BEFORE BEING PLACED BACK IN SERVICE, the CrewProtect 20 must be inspected to this checklist:
1. There is no obvious damage such as missing, broken or loose parts, damaged labels, etc.
2. The unit is securely fastened to the truck.
3. LED status lights indicating cartridge status are in the acceptable range (Blue or Yellow).
4. All air ducts are clean and unobstructed.
5. The area around the device is clean and free of loose debris.
6. There are no objects sitting on top of the device.
7. All markings are legible.
CAUTION Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is a
misuse of this equipment.
