TAUBIK PEAK User manual

PEAK
User Manual

1
Thank you for choosing and purchasing your E-Bike. For your
driving safety please read this manual carefully to ensure that you can
follow the correct instructions, safety warnings and precautions before
using it.
l Strictly abide by local laws and regulations and traffic laws. The
company is not responsible for any consequences caused by violation
of the above laws and regulations.
l Strictly follow the instructions in the manual for corresponding
operations. The company is not responsible for any consequences
caused by improper use, speeding, overloading etc...
l Do not use this E-Bike to do stunt, wheel or take-off, it will increase the
probability of injury and damage to the scooter.
l Please always wear a helmet.
l Do not leave the battery near fire or heat sources.
l Please regularly check whether the brake performance is good.
l Please do not modify, repair or disassemble the product on your own.
l Do not sit on the product either when driving or stationary.
l Avoid using used, defective and/or aftermarket batteries.
l People who should not ride the product include:
i. Anyone under the influence of alcohol or drugs.
ii. Anyone who suffers from disease that puts them at risk if they
engage in strenuous physical activity.
iii. Anyone who has problems with balance or with motor skills that
would interfere with their ability to maintain balance.
iv. Anyone whose weight is outside the stated limits (see
Specifications).
v. Pregnant women.
SAFETY INSTRUCTIONS

2
Model
PEAK
Max Load
120KG
Motor
500W/48V
Battery
14Ah
Suspension
Front and rear spring suspension
Max Speed
25km/h
Derailleur
Front: Shimano 3, Rear: Shimano 7
Max Distance
40km (Pure Power)
Max Distance
70km – 110km (Pedal assist）
Sensor
Speed Sensor
Frame
Aluminum
Brake Type
Hydraulic brakes
Tire Size
27.5*2.35
Tire Pressure
Min: Max:65 psi
Charger
54.6V/2A
Charge Time
7 hours
Fork
Suspension fork with lock out
Net Weight
29.5kg
SPECIFICATIONS

3
PARTS DIAGRAMS
Features & Parts
1. 27.5-inch Kenda Tire
2. Head light
3. LCD Display
4. Rear Suspension
5. Seat
6. Seat Quick Release
7. Hydraulic Disc Brake
8. Battery pack
9. Pedal
10.Kickstand

4
1. Left brake lever for front brake
2. Bell
3. LCD Display Button
4. LCD Display
5. Right Brake Lever for rear brake
6. Left shifter for front derailleur
7. Stem
8. Right shifter for rear derailleur
9. Accelerator
10. Handlebar
①
②
⑥
③
④
⑦
⑧
⑤
⑩
⑨

5
DISPLAY PANEL
①
⑧
③
④
⑦
⑤
⑤
⑤
⑥
1） Battery Display: Indicates the Battery Capacity
2） Error：Indicates the Error Code
3） Speed Display:
- MAX：Max speed
- AVG: Average Speed
- Mph：Miles per hour, km/h: Kilometer per hour
4） Headlight：Indicates the headlight on
5） Speed gear mode:
- Walk: Pedestrian mode 5km/h
- PAS：5 speeds can be adjusted
6) Mileage Display
7) Function Display:
- ODO: Total distance travelled
- Trip A: Single Distance A
- Trip B: Single Distance B
- VOL: Battery Voltage
②
- CUR: Present current
- RM: Remaining Mileage
- TM: LCD startup time

6
No.
Function
Operation Method
1
Power on / off
Press ‘ M ’ 3 seconds
2
PSA Level
10km/h
，
14km/h
，
18km/h
，
22km/h, 25km/h
Press the ‘up button’ speed +1,
Press the ‘down button’ speed -1
3
Switch Mph & Km/h
Press ‘ M ’+ ‘ UP’ at the same time
4
Switch
ODO,Trip,VOL,CUR,RM,TM
Press ‘M’ Once
5
Walk
（
Pedestrian mode)
Long Press ‘Down’ Button when walking
6
Turn on/off headlight
Press ‘up’3 seconds
DISPLAY BUTTON
Down Button
M Button
Up Button

7
Error 1
Reserve
Error 2
Brake Failure
Error 3
Power assist sensor failure (riding sign)
Error 4
6KM/H cruise
Error 5
Real-time cruise
Error 6
Battery undervoltage
Error 7
Motor failure
Error 8
Handlebar failure
Error 9
Controller failure
Error 10
Communication reception failure
Error 11
Communication sending failure
Error 12
BMS communication failure
ERROR CODE

8
STORAGE INSTRUCTIONS
Storage: Do not store the batteries in high temperature or humid environments.
REMOVING THE BATTERY PACK
• Ensure the E-BIKE is turned off.
• Unplug battery pack from cable if battery is charging.
• Use the key to unlock the battery from the keyhole first, then,slide the battery
pack buckle.
• Take out the battery from front to remove it from the bike frame.
NOTE: Make sure the battery does not drop suddenly, please hold the battery
with your hand when unlock.
BATTERY PACK
Keyhole
Battery Capacity
Display Button
Battery pack buckle
Charging port

9
Only use the provided charging cable to charge your PEAK's battery pack.
Using any other unauthorized charger may cause damage to your battery pack
and/or.
CHARGING THE BATTCRY RACK
• Ensure the EBIKE is turned off.
• Remove the battery pack from the battery dock.
• Ensure that the charging port is clean and dry.
• Make sure that there is no dust, debris or dirt inside the port.
• Plug the charger into a grounded wall outlet.
• The charging indicator light ON, the charger will be green.
• Connect the cable with the power supply (100V~240V; 50/60 Hz).
• Align and connect the 1-pin charging cable into the charging port of the
battery pack.
DO NOT FORCE OR BEND THE CHARGING CABE INTO THE
CHARGING PORT, AS IT MAY CAUSE THE PRONG TO BEND OR BREAK.
CHARGING
CAUTION

10
FAILURE TO FOLLOW ANY OF THE FOLLOWING SAFETY
PRECAUTIONS CAN AND MAY LEAD TO DAMAGE TO YOUR DEVICE, VOID
YOUR MANUEACIURER WARRANTY
；
LEAD TO PROPERIY DAMAGE,
CAUSE SERIOUS BODIIY INJURY, AND CAN LEAD TO DEATH.
OPERATING CONDITIONS
Any PEAK that does not work properly can cause you to lose
control and fall. Inspect the entire device thoroughly before
every ride, and do not ride it until any problems have been
corrected.
KICKSTAND
Never ride your EBIKE with the kickstand down.
OPERMING YOUR E-bike
Make sure the battery pack is fully charged before the first Initial use. Before
turning on your E-bike, sit on it like a standard bicycle to get comfortable with
the device before using It with the motor.
GEARS
Your Ebike is equipped with 5 gears. The lowest gear (1) is for easier and uphill
pedaling, and the highest gear (5) is for maximum speed on level or downhill
terrain. Change gears only while pedaling.
The rear wheel contains 5 chain sprockets. When the chain is around the
largest sprocket you are in 1st gear, or the lowest gear. When the chain is
around the smallest sprocket, you are in 5th gear, or the highest gear.

11
PROBLEM
POSSIBLE CAUSES
SOLUTION
Motor will not engage
1. Low battery
2. Battery loose or
unplugged
3. Severed wire connection
1. Recharge battery
2. Make sure battery
connections are secure
3. Contact customer
support
Feels shaky when driving
1. Low tire pressure
2. Wheel is not securely
fastened
1. Inflate to 40 psi
2. Fasten wheel securely
3. Replace bearings
3. Bearings in steering system
are worn out
Mileage not being
recorded correctly
1. Infrequently charged
2. Defective or worn out
battery pack
3. Cold temperature
affecting battery
performance
4 Defective or incorrect
charger damaged battery
1. Charge battery pack
more often
2. Replace battery pack
3. Allow battery pack to
reach room temperature
and fully recharge it.
4. Contact customer
support
LCD Display not
registering
1. Low battery
2. Display is broken
3. Bad battery cells
4. Faulty charger burns out
display
1. Recharge battery pack
2. Replace display
3. Replace battery pack
4. Contact customer
support
TROUBLE SHOOTING

12
PROBLEM
POSSIBLE CAUSES
SOLUTION
Brakes squealing
1. Dirty brake pad
2. Hard edges on new
brakes
3. Brake pads are too tight
1. Clean the brake pad
2. Squealing will stop ttie
more you ride
3. Adjust brake pads to l-
2mm gap from wheel
Stiffness when steering
1. Grime build-up in steering
system
2. Bearings in steering
system are worn out
1. Clean steering system
2. Replace bearings
The above table is only meant to act as a guide to help you figure out any
problems you may have with your EBIKE. If you are unable to get your EBIKE
to operate properly, please ask for support.
