Taylor-Dunn TC-030-60L Manual

The Best Way
To Go
About Your
Business
Tiger Tractor
A Division of Taylor-Dunn
®
Manufacturing
MANUAL MT-030-60L-A
Operation, Maintenance, and
Replacement Parts Manual
Models Inlcuded:
TC-030-60L
Published: 12/28/2010
Revision: A
Shown with optional Cab
Serial Number: 183635

Taylor-DunnContactinformation
Service, Parts, Sales:
Taylor-Dunn has a network of dealers distributed around the globe to support our
vehicles. Information regarding vehicle sales, replacement parts, or service should be
obtained through your local dealer. A dealer locator can be found on the Taylor-Dunn
website at www.taylor-dunn.com.
If you do not have access to the internet, you can call the factory direct at:
01(714)956-4040
Feedback regarding this or any Taylor-Dunn vehicle manual can be sent to:
Taylor-Dunn Manufacturing
Attn:TechWriter
2114 West Ball Road
Anaheim,CA92804

The Taylor-Dunn Corporation:
Leading Provider of Commercial & Industrial Vehicles since 1949
Taylor-Dunn Manufacturing:
From the day we shipped our first vehicle in 1949, we have pursued a singular goal: to build tough, rugged, dependable vehicles to help our
customers move personnel, equipment, and materials. It's that simple. For over sixty years, our standard and custom vehicles - Burden
Carriers, Personnel Carriers, Stock Chasers, Electric Carts,Tow Tractors & more - have been the leading solution for customers in a broad
range of industrial, commercial, and ground-support markets.
Decades of experience are an invaluable asset, and it is an asset we cherish and protect. Our guiding principle is to provide application-
specific solutions, which are reliable, efficient, and economical.
Our domestic and international network of quality Taylor-Dunn Dealers and Parts & Service Support keeps our customers moving.
Tiger Tractor:
Tiger manufacturing has become a leading manufacturer of internal combustion industrial tractors and ground support equipment. With
tractor capacities ranging from 3,000 - 12,000 pounds drawbar pull, they are ideal for industrial applications as well as aircraft ground
support.As with all Taylor-Dunn vehicles; quality, service, support and reliability are built into all TigerTractor products.
Metro Crown International (MCI):
Metro Crown International, located in Lee's Summit, Missouri is one of the world's leading suppliers of replacement parts for industrial
applications and the airline ground support industry. MCI is the factory authorized OEM distributor for parts for Tiger Tractor, United
Tractor, Kalamazoo, and FMC Challenger Belt Loader brands. Both domestic and international customers have come to depend upon MCI
to provide quality, personalized service and to count on them for accurate, reliable answers.
Shown below is just a small sample of what Taylor-Dunn has to offer to keep your business moving:

Section IndeSection Inde
Section IndeSection Inde
Section Indexx
xx
x
Introduction
Safety Rules and Operating Instructions
General Maintenance
Front Axle Service
Steering Component Service
Engine Service
Fuel System
Cooling System
Transmission Service
Transmission Repair
Rear Axle Service
Brakes Service
Suspension
Tires and Wheels
Battery Service
Wiring/Hydraulics
Illustrated Parts
Appendix A
Special Tools
Appendix B
Suggested Torque Values
Appendix C
Brake Lining Handling Precautions
Tiger Tractor
Model TC-030-60L
Operator and Service Manual Section Index
This quick reference section index guide will assist you in
locating a desired topic or procedure.
Refer to each sectional Table of Contents for the page
number location for specific topics or procedures.

B2-48 With Stake Side Dump Bed Option
SC1-00 Stock Chaser
E4-55 Sit Down Tow Tractor
C4-25 Sit Down Tow Tractor

Table of Contents
Chapter -
Introduction
1
About this manual ..........................................2
Who Should Read This Manual.....................2
Responsibilities..............................................2
How To Use This Manual ...............................3
Conventions............................................................ 3
How to Identify Your Vehicle .........................4
Taking Delivery of Your Vehicle.....................5

INTRODUCTION
Page-2 TC 30-60
WHO SHOULD READ THIS MANUAL
Thismanualisintendedforusebyanyonewhoisgoing
to operate, own, perform maintenance on, service, or
order parts for this Tiger Tractor Each person should
be familiar with the parts of this manual that apply to
their use of this vehicle.
ABOUT THIS MANUAL
The purchase of this vehicle shows a belief in high
quality products manufactured in the USA.
Taylor-Dunn®, a leading manufacturer of electric and
internalcumbustionengine poweredburden,personnel
carriers,andtow tractors since 1949, wantsto be sure
this vehicle provides years of reliable service. Please
continueto readthismanual andenjoythis highquality
Taylor-Dunn®vehicle.
This manual is to serve as a guide for the service,
repair, and operation of Tiger Tractors and is not
intended as a training guide. Taylor-Dunn®has made
everyefforttoinclude as muchinformationas possible
about the operation and maintenance of this vehicle.
Included in this manual are:
•Vehicle Description
•Safety Rules and Guidelines
•Operational Information
•Operator Responsibilities
•Owner Responsibilities
•Control Operation and Location Information
•Maintenance and Troubleshooting Information
•Standard Parts List
Before servicing, operating, training or performing
maintenance on this or any other Tiger Tractor, read
the appropriate Tiger Tractor manual.
Each manual references the applicable models and
serial numbers on the front cover.
Please,beawareofall cautions,warnings,instructions,
and notes contained in this manual.
RESPONSIBILITIES
Of the Owner...
The owner of this or any Taylor-Dunn®vehicle is
responsible for the overall maintenance and repairs
of the vehicle, as well as the training of operators.
Owners should keep a record of conducted training
and maintenance performed on the vehicle. (OSHA
Regulation, 29 CFR 1910.178 Powered Industrial
Truck Operator Training).
Of the Operator...
The operator is responsible for the safe operation of
the vehicle, preoperational and operational checks
on the vehicle, and the reporting of any problems to
service and repair personnel.
Of the Service Personnel...
Theservice personnelareresponsible fortheservice
and maintenance of the vehicle.At no time should a
service person allow any untrained personnel to
service or repair this or any Taylor-Dunn®vehicle.
For the purposes of training, a qualified service
person may oversee the repairs or services being
made to a vehicle by an individual in training. At no
time should an untrained individual be allowed to
service or repair a vehicle without supervision. This
manual is not a training guide.
Of the Passengers ...
The passengers are responsible to remain fully
seated, keeping their hands, arms, and legs inside
the vehicle at all times. Each passenger should be
fully aware of the vehicle’s operation. All forms of
recklessness are to be avoided. Do not engage in
horseplay.

INTRODUCTION
Page-3
TC 30-60
HOW TO USE THIS MANUAL
This manual is organized into five main sections:
INTRODUCTION
Thissectiondescribes how to use this service manual
and how to identify your vehicle.
Safety Rules and Operating Instructions
Thissection outlinesthesafety andoperational issues,
locationandoperation of controls, and theoperational
checks that are to be performed on this vehicle. It
alsoincludesvarious subjects that shouldbeincluded
in the operator and service training program.
Maintenance Service and Repair
These sections gives specific information on the
servicing of the vehicle and a schedule for
maintenance checks.
Illustrated Parts
This section provides an illustrated view of various
assemblies. The illustrations are accompanied by
tables identifying the parts.
Conventions
Symbols and/or words that are used to define
warnings, cautions, instructions, or notes found
throughout this manual. Refer to the examples below.
Note: Alerts the reader to additional
information about a subject.
A shaded box with the word “Warning” and
the symbol above denotes a warning. A
warning alerts the reader of a hazard that
may result in injury to themselves or
others. Be sure to follow any instructions
contained within a warning and exercise
extreme care while performing the task.
A shaded box with and the word “Warning”
and the symbol above denotes a
warning. This warning alerts the reader of
a high voltage hazard that may result in
injury to themselves or others. Be sure to
follow any instructions contained within a
warning and exercise extreme care while
performing the task.
A box with the word “CAUTION” and the
symbol above denotes a caution and is
used to inform the reader that property
damage may occur. Be sure to exercise
special care and follow any instructions
contained with in a caution.

INTRODUCTION
Page-4 TC 30-60
HOW TO IDENTIFY YOUR VEHICLE
This manual applies to vehicles with the same model and serial numbers listed on the front cover.
These vehicles are designed for driving on smooth surfaces in and around facilities such as industrial plants, ,
airports, nurseries, institutions, motels, mobile home parks, and resorts. They are not to be driven on public
highways.
The locations of the model and serial numbers are illustrated below:
This vehicle is not designed to be driven on public roads or highways. It is available in maximum
designed speeds ranging from 10 to 13 mph. Do not exceed the maximum designed speed.
Exceeding the maximum designed speed may result in steering difficulty, motor damage, and/
or loss of control. Do not exceed locally imposed speed limits. Do not tow at more than 5 mph.
Thisvehicleconforms to requirementsall applicable sections as described in O.S.H.A. StandardSection1910.178
(PoweredIndustrialTrucks)andwithallapplicableportions oftheAmericanNationalStandardfor OperatorControlled
Industrial Tow Tractors (ANSI B56.9).
The frame serial number is located on the kick panel
below the shifter. The Vehicle Data Plate is located on the firewall to the right of the steering column.

INTRODUCTION
Page-5
TC 30-60
The only personnel authorized to repair,
modify, or adjust any part of this or any
Tiger tractor, is a factory authorized service
technician. Repairs made by unauthorized
personnel may result in damage to the
vehicles systems which could lead to an
unsafe condition resulting in severe bodily
injury and/or property damage.
Unauthorized repairs may also void the
vehicles warranty.
What To Do If a Problem is Found
Ifthere is a problem ordamageasa result of shipping,
note the damage or problem on the bill of lading and
file a claim with the freight carrier. The claim must be
filed within 48 hours of receiving the vehicle and its
accessories. Also, notify your Taylor-Dunn®dealer of
the claim.
If there is a problem with the operation of the vehicle,
DO NOT OPERATE THE VEHICLE. Immediately
contact your localTiger Trasctor distributor and report
theproblem.Thereport must be madewithin24hours
of receiving the vehicle and its accessories.
The only personnel authorized to repair, modify, or
adjust any part of this or any Taylor-Dunn®vehicle is
a factory authorized service technician.
TAKING DELIVERY OF YOUR
VEHICLE
Inspect the vehicle immediately after delivery. Use
the following guidelines to help identify any obvious
problems:
•Examine the contents of all packages and
accessories that may have come in separate
packages with the vehicle.
•Make sure everything listed on the packing slip
is there.
•Check that all wire connections, battery cables,
and other electrical connections are secure.
•Check battery cells to be sure they are filled.
•Check the tire pressure, tightness of lug nuts,
and for any signs of damage.
Check the operation of each of the following controls:
•Accelerator
•Brake
•Parking Brake
•ReverseAlarm (if equipped)
•Lights and electrical accessories
•Steering
•Horn
•Instruments and Gauges
New front wheel bearing adjustment must be
inspected after the first 24 hours of operation.
This includes new vehicle installations. Failure
to inspect the bearings after the break in period
may result in premature failure of the bearings.

B2-48 With Dump Bed Option B2-10 Ambulance
B2-48 with Steel Cab, Foldaway
4-Passenger Seat and Stake Sides
ET 3000
ET1-50 Full Size Truck
P2-50 30,000 Pound Tow Tractor

TABLE OF CONTENTS
Chapter -
Safety Rules and
Operating Instructions
Standard Specifications* .................... 2
Safety Rules and Guidelines ............. 3
Driver Training Program .................... 3
Driver Qualifications......................................... 3
Vehicle Controls................................. 4
Instrument Panel ............................... 4
1) Check Engine Light ...................................... 4
2) Switch for Optional Components ................. 4
3) Instrument Panel ........................................... 4
4) Low Fuel (LPG) Light................................... 4
5) Park Brake Warning Light ............................ 4
6) Brake Warning Light..................................... 4
7) Headlight Switch .......................................... 4
8) Coolant Temperature..................................... 5
9) Hour Meter .................................................... 5
10) Oil Pressure ................................................. 5
11) Ignition Switch ............................................ 5
1) Throttle Pedal ................................................ 6
2) Foot Brake Pedal ........................................... 6
3) Park Brake..................................................... 6
4) Transmission Shift Lever .............................. 6
Steering.............................................................. 6
Horn Switch....................................................... 6
Seat Interlock Switch (optional)........................ 6
Directional Signals (Optional) .......................... 7
Hazard Light Switch (Optional)........................ 7
Speedometer ...................................................... 7
Vehicle Operation .............................. 8
Safety Guidelines .............................................. 8
Starting-Gasoline/LPG Engine.......................... 8
Driving .............................................................. 9
Parking .............................................................. 9
Towing Loads: ................................................... 9
Towing This Vehicle .......................................... 9
Refueling ........................................................... 10
Loading and Unloading..................................... 10
Draw Bar Pull (DBP), definition....................... 10
PM Checklist ..................................... 11
Maintenance Guidelines for
Severe DutyApplications ............... 12
Daily Visual inspection: .................................... 12
2

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 2
STANDARD SPECIFICATIONS*
ITEM Model SPECIFICATION
Occupancy Driver only, no passengers
Dimensions 105 L x 56 W x 56 H Inches (2,667 L x 1422 W x 1422 H mm)
Wheel Base 65 inches (1,663 mm)
Ground Clearance 6.5 inches (165 mm)
Turning Radius 144 inches (3,657 mm)
Dry Weight TC-30 4,105 pounds (2,055 kg)
Battery Group 24M, 800CCA, 135 minute reserve
Transmission Ford C6, 3-Speed Automatic
Engine General Motors Industrial 3.0 liter, 4 cylinder
Fuel System Gasoline
Cooling System, Coolant Type 50/50 mixture of DexCool Long Life coolant and water
DriveAxle Helical gearing primary reduction into standard hypoid ring and
pinion secondary reduction
Suspension Front Leaf spring, Solid Mount Rear Axle
Towing Capacity TC-30 3,000 pounds (1,360 kg)
(draw bar pull, see definition later in this section)
Brakes Rear Wheel Dual Caliper Hydraulic Disc
Hand Operated Parking Brake
Steering Power Hydrostatic Steering
Tires Front: 6.50 x 10 Pneumatic Load range E
Rear: LT225/75R16 Load Range D
Instrumentation Oil pressure, Coolant temperature, Battery volts, Fuel level,
Hour meter
Lights Headlight, Tail/Brake Light, Reverse light
This vehicle conforms to applicable sections as described in O.S.H.A. Standard Section 1910.178 (Powered
Industrial Trucks) and with all applicable portions of theAmerican National Standard for Operator Controlled
Industrial Tow Tractors (ANSI B56.9).
* - Specifications are for standard vehicle and are subject to change without notice.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 3
SAFETY RULES AND
GUIDELINES
Itis theresponsibility ofthe ownerofthisvehicleto assure
that the operator understands the various controls and
operating characteristics of this vehicle. As well as,
followingthe safety rules and guidelinesoutlinedinANSI
B56.9 and listed below.
These vehicles are designed for driving on smooth
surfacesin and aroundfacilitiessuch as industrialplants,
nurseries, institutions, motels, mobile home parks, and
resorts. They are not to be driven on public highways.
Refer to Vehicle Operational Guidelines, Safety
Guidelines section for important safety information
regarding operating this vehicle.
Read and follow all of the guidelines listed
below. Failure to follow these guidelines
may result in severe bodily injury and/or
property damage.
These vehicles are not designed to be driven
on public roads or highways. They are
available in maximum designed speeds
ranging from 10 to 13 mph. Do not exceed
the maximum designed speed. Exceeding
the maximum designed speed may result
in steering difficulty, motor damage, and/
or loss of control. Do not exceed locally
imposed speed limits. Do not tow this
vehicle at more than 5 mph.
Before working
on a vehicle:
Make sure the ignition switch is in the “OFF”
position.
Place the transmission shift lever in the
Parkor neutral position.
Set the park brake.
Place blocks under the front wheels to
prevent vehicle movement.
If working on the elctrical system, remove
the negative cable from the battery.
DRIVER TRAINING PROGRAM
Per ANSI B56.9, the owner of this vehicle shall conduct
an Operator Training program for all those who will be
operating this vehicle. The training program shall not be
condensed for those claiming to have previous vehicle
operation experience. Successful completion of the
Operator Training program shall be required for all
personnel who operate this vehicle.
The Operator Training program shall include the
following:
•Operation of this vehicle under circumstances
normallyassociated withyourparticularenvironment.
•Emphasis on the safety of cargo and personnel.
•All safety rules contained within this manual.
•Proper operation of all vehicle controls.
•A vehicle operation and driving test.
Driver Qualifications.
Only those who have successfully completed the
Operator Training program are authorized to drive this
vehicle. Operators must possess the visual, auditory,
physical, and mental ability to safely operate this vehicle
asspecifiedin theAmerican National StandardsInstitute
Controlled Personnel and Burden CarriersANSI B56.9.
The following are minimum requirements necessary to
qualify as an operator of this vehicle:
•Demonstrate a working knowledge of each control.
•Understand all safety rules and guidelines as
presented in this manual.
•Know how to properly load and unload cargo.
•Know how to properly park this vehicle.
•Recognize an improperly maintained vehicle.
•Demonstrate ability to handle this vehicle in all
conditions.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 4
VEHICLE CONTROLS
INSTRUMENT PANEL
7) Headlight Switch
The headlight switch is located on the left sideof the
instrumentpanel.Pull the switch out to turnthelightson.
Push the switch in to turn the lights off.
1) Check Engine Light
When the Check Engine Light is on while the engine is
running, then the ECU has detected conditions that
indicate the engine is not operating correctly.
Ifthe CheckEngine Lightturnson thenthevehicle should
beimmediatelyremoved from service to beinspectedby
a qualified technician.
The Check Engine Light should be on when the ignition
switch is ON but the engine has not yet been started. If
the light does not come on then the vehicle should be
immediately removed from service to be inspected by a
qualifiedtechnician.
4) Low Fuel (LPG) Light
2) Switch for Optional Components
3) Instrument Panel
5) Park Brake Warning Light
This light will be ON when ever tha parking brake is set.
6) Brake Warning Light
This light monitors the differential pressure between the
front and rear pots of the master cylinder. If this light is
ON then there is a fault in one of the two systems and
thevehicleshould be immediately removed from service
to have the brake system inspected.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 5
10) Oil Pressure
Thisgauge indicates the engine oil
pressure,notthe oillevel. However,
if your engine’s oil level is low, it
could affect the oil pressure.
Typical normal oil pressure range
when engine is hot is 6 to 18 PSI.
With the engine running, the pointer should move into
the NORMAL range. If the pointer drops below the
NORMAL range while the engine is running, you have
lostoilpressureandcontinuedoperationwillcausesevere
engine damage. If the pointer exceeds the NORMAL
range then there may be obstructions in the engine
lubrication system and continued operation will cause
severe engine damage.
If the oil pressure is low, pull to the side of the road and
immediately shut the engine off. Check and add oil as
needed and restart the engine. If the oil pressure is still
low, turn the engine off and have the vehicle towed to a
repairfacility.
If the oil pressure is high, pull to the side of the road and
immediately shut the engine off and have the vehicle
towed to your authorized Tiger Tractor repair facility.
8) Coolant Temperature
This gauge indicates the
temperatureoftheengine coolant,
not the coolant level. If the coolant
is not at its proper level or mixture,
the gauge indication will not be
accurate.
The pointer moves from the left to the right side of the
gauge as your engine coolant warms up.
Oncethe engineiswarmed up,the typicalnormalcoolant
temperature range is 180 to 210 degrees (F).
Under normal driving conditions, the pointer should stay
in the NORMAL range. It is acceptable for the pointer to
fluctuate within the NORMAL band under normal driving
conditions,andunder certain driving conditions such as,
heavy stop and go traffic, driving up hills in hot weather,
or towing hevy loads for the pointer to indicate at the top
of the NORMAL band.
If, under any circumstances, the pointer moves above
the NORMAL range, the engine is overheating and
continued operation may cause engine damage.
• Theengine ECU will reducepowerif the temperature
exceeds 220 degrees.
• The engine ECU will shut the engine down if the
temperature exceeds 230 degrees.
If your engine coolant overheats:
1. Pull off the road as soon as safely possible.
2. Turn off the engine.
3.Lettheenginecool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS
COOL.
4. Check the coolant level following the instructions
on checking and adding coolant to your engine.
• If the coolant continues to overheat, have the
coolant system serviced.
9) Hour Meter
Thehour meterrecords thenumber
of hours the vehicle has been in
operation.
11) Ignition Switch
Note: Rotary switch shown. Also
available as a keyed switch.
The ignition switch has 3-positions:
OFF, RUN, START.
Rotatingtheswitch clockwisetothe first
position turns the ignition system ON.
Rotating the switch to the START position engages the
engine starter motor. This is a momentary position and
the switch will return the START position when it is
released. Once the switch has been released from the
START position, it must be turned to OFF before it can
be turned back to the START position.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 6
Seat Interlock Switch (optional)
Aswitch located under the driver's seat disables the power to the vehicle when the driver leaves the seat. The driver
must be seated for the vehicle to operate.
Wheneverthedriver leaves the vehicle, the drivershouldturnthe startswitch off,place the forward-off-reverseswitch
in the center “OFF” position, and set the park brake.
2) Foot Brake Pedal
The foot brake pedal, is located to the left of the throttle pedal and
is intended to be operated with the drivers right foot only. It works
similar to the brake in an automobile. Applying pressure to the
brakepedal slows the vehicle accordingtotheamount of pressure
applied. Relieving pressure from the pedal releases the braking
action.
3) Park Brake
The parking brake is actuated with a hand lever, which is located to the right of the driver. To set the parking brake,
push down on the brake pedal and pull the lever up until it locks. To release the park brake, depress the foot brake
pedal, pull up on the park brake handle, push the release button, and lower the handle.
1) Throttle Pedal
The throttle pedal is located on the floorboard and is intended to
be operated by the drivers right foot. It controls the speed of the
vehicleandoperatessimilartothe throttle pedal in an automobile.
Depress the pedal to increase speed and release the pedal to
decrease speed.
Steering
The steering wheel and steering system are similar to an automobile. To
turn right, turn the steering wheel clockwise. To turn left, turn the steering
wheelcounter-clockwise.
4) Transmission Shift Lever
Selects the direction of travel and gear range. Detailed description of operation is in the Vehicle Operation section
later in this chapter.
Horn Switch
The horn switch is located in the center of the steering wheel. To sound the horn, depress the center area of the
steering wheel hub.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 7
Directional Signals (Optional)
The turn signal lever is located on the left side of the steering column. Push
the lever forward to activate the right turn signal and pull the lever back to
activate the left turn signal.
Hazard Light Switch (Optional)
The hazard light switch is located on the left side of the steering column. The
switchisasmall tab. To activate the hazard lights,pullthetab out. To turnthe
hazard lights off, push forward or pull back the directional signal lever.
Speedometer
Cyberdyne 3-3/8 Ultragage.
This is a high performance speedometer. Some of the functions do not apply to a low speed vehicle.
Displays:
There are two displays on the gauge:
The upper display will show the vehicles current speed in miles per hour (MPH).
This cannot be changed to KPH. One MPH = 1.609 KPH.
The lower display has the following functions:
• Odometer
• Trip Odometer
• High Speed Recall
• 0-60 Time Recall (does not apply)
• ¼ Mile Time Recall (does not apply)
Press and release the button on the speedometer to toggle through all of the available functions.
Function Descriptions:
• Odometer: When selected, displays the total miles traveled.
• Trip Odometer: When selected, displays the miles traveled since last reset. It can display up to 999.9 miles. To
reset the trip odometer, toggle the display until the trip odometer is displayed, then press and hold the button until
it resets to 0
• High Speed Recall: When selected, “SP” will be displayed along with the highest speed attained since the vehicle
was started.
The following functions are built in to the speedometer but do not apply to this vehicle:
• 0-60 Time Recall: When selected, “60” will be displayed along with how long it takes for the vehicle to accelerate
to 60 MPH.
• ¼ Mile Time Recall: When selected, “25” will be displayed along the time it takes to travel ¼ mile.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions
Page 8
VEHICLE OPERATION
Safety Guidelines
•Only qualified and trained operators may drive this
vehicle.
•Driveonlyon level surfaces or on surfaces havingan
incline of no more than 10% (5.6 degrees).
•Drive slowly when making a turn, especially if the
ground is wet or when driving on an incline.
•This vehicle may overturn easily if turned sharply or
when driven at high speeds.
•Observe all traffic regulations and speed limits.
•Keep all body parts (head, arms, legs) inside this
vehicle while it is moving.
•Keep the vehicle under control at all times.
•Yield right of way to pedestrians, ambulances, fire
trucks, or other vehicles in emergencies.
•Donot overtakeanothervehicleat intersections,blind
spots, or other dangerous locations.
•Do not drive over loose objects, holes, or bumps.
•Yield right of way to pedestrians and emergencies
vehicles.
•Stay in your driving lane under normal conditions,
maintaining a safe distance from all objects.
•Keep a clear view ahead at all times.
Starting-Gasoline/LPG Engine
For additional information, refer to the engine operator’s
manual included with your vehicle.
Perform all necessary vehicle preparation steps,
inspections,ormaintenancebeforeoperatingthisvehicle.
NOTE: The vehicle may be equipped with a various
startinterlock switches.Allinterlock switches
must be closed to allow the engine to start.
1. Placethe transmissionshiftlever inPark orNeutral.
2. Set the parking brake.
3. Depress the foot brake pedal.
4. Rotate the ignition switch to the start position and
hold (see notes below) until the engine starts and
then release the switch.
Starting Notes:
Starting when engine is cold:
• Attemperatures10°F(-12°C) andbelow,Iftheengine
does not start in 15-seconds on the first try, turn the
ignitionswitchtoOFF, waitapproximately 10-seconds
soyoudo not flood the engine or overheat thestarter
motor, then try again.
• Attemperatures10°F(-12°C) andbelow,Iftheengine
does not start in 5-seconds on the first try, turn the
ignitionswitchtoOFF, waitapproximately 10-seconds
soyoudo not flood the engine or overheat thestarter
motor, then try again.
Starting when engine is warm:
• Do not hold the ignition switch in the STARTposition
formorethan5-seconds at a time. If the engine does
not start within 5-seconds on the first try, turn the
ignition switch to the OFF position. Wait wait
approximately 10-seconds so you do not flood the
engine or overheat the starter motor, then try again.
