Taylor-Dunn Tiger TC-030-60 Manual

The Best Way
To Go
About Your
Business
Tiger Tractor
A Division of Taylor-Dunn
®
Manufacturing
MANUAL MT-030-60-C
Operation, Maintenance, and
Replacement Parts Manual
Models Inlcuded:
TC-030-60
Published: 11/17/2010
Revision: A
Shown with optional
overhead guard
Serial Number Range:
183370 - 183373

Taylor-DunnContactinformation
Service, Parts, Sales:
Taylor-Dunn has a network of dealers distributed around the globe to support our
vehicles. Information regarding vehicle sales, replacement parts, or service should be
obtained through your local dealer. A dealer locator can be found on the Taylor-Dunn
website at www.taylor-dunn.com.
If you do not have access to the internet, you can call the factory direct at:
01(714)956-4040
Feedback regarding this or any Taylor-Dunn vehicle manual can be sent to:
Taylor-Dunn Manufacturing
Attn:TechWriter
2114 West Ball Road
Anaheim,CA92804

Section IndeSection Inde
Section IndeSection Inde
Section Indexx
xx
x
Introduction
Safety Rules and Operating Instructions
General Maintenance
Front Axle Service
Steering Component Service
Engine Service
Fuel System
Cooling System
Transmission Service
Transmission Repair
Rear Axle Service
Brakes Service
Suspension
Tires and Wheels
Battery Service
Wiring
Illustrated Parts
Appendix A
Special Tools
Appendix B
Suggested Torque Values
Appendix C
Brake Lining Handling Precautions
Tiger Tractor
Model TC-030-60
Operator and Service Manual Section Index
This quick reference section index guide will assist you in
locating a desired topic or procedure.
Refer to each sectional Table of Contents for the page
number location for specific topics or procedures.

The Taylor-Dunn Corporation:
Leading Provider of Commercial & Industrial Vehicles since 1949
Taylor-Dunn Manufacturing:
From the day we shipped our first vehicle in 1949, we have pursued a singular goal: to build tough, rugged, dependable vehicles to help our
customers move personnel, equipment, and materials. It's that simple. For over sixty years, our standard and custom vehicles - Burden
Carriers, Personnel Carriers, Stock Chasers, Electric Carts,Tow Tractors & more - have been the leading solution for customers in a broad
range of industrial, commercial, and ground-support markets.
Decades of experience are an invaluable asset, and it is an asset we cherish and protect. Our guiding principle is to provide application-
specific solutions, which are reliable, efficient, and economical.
Our domestic and international network of quality Taylor-Dunn Dealers and Parts & Service Support keeps our customers moving.
Tiger Tractor:
Tiger manufacturing has become a leading manufacturer of internal combustion industrial tractors and ground support equipment. With
tractor capacities ranging from 3,000 - 12,000 pounds drawbar pull, they are ideal for industrial applications as well as aircraft ground
support.As with all Taylor-Dunn vehicles; quality, service, support and reliability are built into all Tiger Tractor products.
Metro Crown International (MCI):
Metro Crown International, located in Lee's Summit, Missouri is one of the world's leading suppliers of replacement parts for industrial
applications and the airline ground support industry. MCI is the factory authorized OEM distributor for parts for Tiger Tractor, United
Tractor, Kalamazoo, and FMC Challenger Belt Loader brands. Both domestic and international customers have come to depend upon MCI
to provide quality, personalized service and to count on them for accurate, reliable answers.
Shown below is just a small sample of what Taylor-Dunn has to offer to keep your business moving:

Table of Contents
Chapter -
Introduction
1
About this manual ..........................................2
Who Should Read This Manual .....................2
Responsibilities ..............................................2
How To Use This Manual ...............................3
Conventions............................................................ 3
How to Identify Your Vehicle..........................4
Taking Delivery of Your Vehicle .....................5

INTRODUCTION
Page-2 MT-030-60-C Model TC 30-60
WHO SHOULD READ THIS MANUAL
Thismanualisintendedforusebyanyonewhoisgoing
to operate, own, perform maintenance on, service, or
order parts for this Tiger Tractor Each person should
be familiar with the parts of this manual that apply to
their use of this vehicle.
ABOUT THIS MANUAL
The purchase of this vehicle shows a belief in high
quality products manufactured in the USA.
Taylor-Dunn®, a leading manufacturer of electric and
internalcumbustionengine poweredburden,personnel
carriers,andtow tractors since 1949, wantsto be sure
this vehicle provides years of reliable service. Please
continueto readthismanual andenjoythis highquality
Taylor-Dunn®vehicle.
This manual is to serve as a guide for the service,
repair, and operation of Tiger Tractors and is not
intended as a training guide. Taylor-Dunn®has made
everyefforttoinclude as muchinformationas possible
about the operation and maintenance of this vehicle.
Included in this manual are:
•Vehicle Description
•Safety Rules and Guidelines
•Operational Information
•Operator Responsibilities
•Owner Responsibilities
•Control Operation and Location Information
•Maintenance and Troubleshooting Information
•Standard Parts List
Before servicing, operating, training or performing
maintenance on this or any other Tiger Tractor, read
the appropriate Tiger Tractor manual.
Each manual references the applicable models and
serial numbers on the front cover.
Please,beawareofall cautions,warnings,instructions,
and notes contained in this manual.
RESPONSIBILITIES
Of the Owner...
The owner of this or any Taylor-Dunn®vehicle is
responsible for the overall maintenance and repairs
of the vehicle, as well as the training of operators.
Owners should keep a record of conducted training
and maintenance performed on the vehicle. (OSHA
Regulation, 29 CFR 1910.178 Powered Industrial
Truck Operator Training).
Of the Operator...
The operator is responsible for the safe operation of
the vehicle, preoperational and operational checks
on the vehicle, and the reporting of any problems to
service and repair personnel.
Of the Service Personnel...
Theservice personnelareresponsible fortheservice
and maintenance of the vehicle.At no time should a
service person allow any untrained personnel to
service or repair this or any Taylor-Dunn®vehicle.
For the purposes of training, a qualified service
person may oversee the repairs or services being
made to a vehicle by an individual in training. At no
time should an untrained individual be allowed to
service or repair a vehicle without supervision. This
manual is not a training guide.
Of the Passengers ...
The passengers are responsible to remain fully
seated, keeping their hands, arms, and legs inside
the vehicle at all times. Each passenger should be
fully aware of the vehicle’s operation. All forms of
recklessness are to be avoided. Do not engage in
horseplay.

INTRODUCTION
Page-3
MT-030-60-C Model TC 30-30
HOW TO USE THIS MANUAL
This manual is organized into five main sections:
INTRODUCTION
Thissectiondescribes how to use this service manual
and how to identify your vehicle.
Safety Rules and Operating Instructions
Thissection outlinesthesafety andoperational issues,
locationandoperation of controls, and theoperational
checks that are to be performed on this vehicle. It
alsoincludesvarious subjects that shouldbeincluded
in the operator and service training program.
Maintenance Service and Repair
These sections gives specific information on the
servicing of the vehicle and a schedule for
maintenance checks.
Illustrated Parts
This section provides an illustrated view of various
assemblies. The illustrations are accompanied by
tables identifying the parts.
Conventions
Symbols and/or words that are used to define
warnings, cautions, instructions, or notes found
throughout this manual. Refer to the examples below.
Note: Alerts the reader to additional
information about a subject.
A shaded box with the word “Warning” and
the symbol above denotes a warning. A
warning alerts the reader of a hazard that
may result in injury to themselves or
others. Be sure to follow any instructions
contained within a warning and exercise
extreme care while performing the task.
A shaded box with and the word “Warning”
and the symbol above denotes a
warning. This warning alerts the reader of
a high voltage hazard that may result in
injury to themselves or others. Be sure to
follow any instructions contained within a
warning and exercise extreme care while
performing the task.
A box with the word “CAUTION” and the
symbol above denotes a caution and is
used to inform the reader that property
damage may occur. Be sure to exercise
special care and follow any instructions
contained with in a caution.

INTRODUCTION
Page-4 MT-030-60-C Model TC 30-60
HOW TO IDENTIFY YOUR VEHICLE
This manual applies to vehicles with the same model and serial numbers listed on the front cover.
These vehicles are designed for driving on smooth surfaces in and around facilities such as industrial plants, ,
airports, nurseries, institutions, motels, mobile home parks, and resorts. They are not to be driven on public
highways.
The locations of the model and serial numbers are illustrated below:
This vehicle is not designed to be driven on public roads or highways. It is available in maximum
designed speeds ranging from 10 to 13 mph. Do not exceed the maximum designed speed.
Exceeding the maximum designed speed may result in steering difficulty, motor damage, and/
or loss of control. Do not exceed locally imposed speed limits. Do not tow at more than 5 mph.
Thisvehicleconforms to requirementsall applicable sections as described in O.S.H.A. StandardSection1910.178
(PoweredIndustrialTrucks) andwithallapplicableportions oftheAmericanNationalStandardfor OperatorControlled
Industrial Tow Tractors (ANSI B56.9).
The frame serial number is located in the engine
compartment on the left wheel well. The Vehicle Data Plate is located on the right side of
the instrument panel

INTRODUCTION
Page-5
MT-030-60-C Model TC 30-30
The only personnel authorized to repair,
modify, or adjust any part of this or any
Tiger tractor, is a factory authorized service
technician. Repairs made by unauthorized
personnel may result in damage to the
vehicles systems which could lead to an
unsafe condition resulting in severe bodily
injury and/or property damage.
Unauthorized repairs may also void the
vehicles warranty.
What To Do If a Problem is Found
Ifthere is a problem ordamageasa result of shipping,
note the damage or problem on the bill of lading and
file a claim with the freight carrier. The claim must be
filed within 48 hours of receiving the vehicle and its
accessories. Also, notify your Taylor-Dunn®dealer of
the claim.
If there is a problem with the operation of the vehicle,
DO NOT OPERATE THE VEHICLE. Immediately
contact your localTiger Trasctor distributor and report
theproblem.Thereport must be madewithin24hours
of receiving the vehicle and its accessories.
The only personnel authorized to repair, modify, or
adjust any part of this or any Taylor-Dunn®vehicle is
a factory authorized service technician.
TAKING DELIVERY OF YOUR
VEHICLE
Inspect the vehicle immediately after delivery. Use
the following guidelines to help identify any obvious
problems:
•Examine the contents of all packages and
accessories that may have come in separate
packages with the vehicle.
•Make sure everything listed on the packing slip
is there.
•Check that all wire connections, battery cables,
and other electrical connections are secure.
•Check battery cells to be sure they are filled.
•Check the tire pressure, tightness of lug nuts,
and for any signs of damage.
Check the operation of each of the following controls:
•Accelerator
•Brake
•Parking Brake
•ReverseAlarm (if equipped)
•Lights and electrical accessories
•Steering
•Horn
•Instruments and Gauges
New front wheel bearing adjustment must be
inspected after the first 24 hours of operation.
This includes new vehicle installations. Failure
to inspect the bearings after the break in period
may result in premature failure of the bearings.

Notes:

TABLE OF CONTENTS
Chapter -
Safety Rules and
Operating Instructions
StandardSpecifications* .................... 2
Safety Rules and Guidelines.............. 3
Driver Training Program..................... 3
Driver Qualifications......................................... 3
Vehicle Controls................................. 4
Instrument Panel ............................... 4
1) Ignition Switch.............................................. 4
2) Work Lights ................................................... 4
3) Oil Pressure ................................................... 4
4) Check Engine Light ...................................... 5
5) Coolant Temperature ..................................... 5
6) Battery Volt Meter ......................................... 5
7) Fuel Gauge .................................................... 5
8) Hour Meter .................................................... 5
9) Horn Switch .................................................. 5
10) Heater Blower Switch ................................. 6
11) Heater Water Valve...................................... 6
12) Windshield Wiper Switch ........................... 6
Instrument Panel (continued)............. 6
13) 12 Volt Electrical Outlet ............................. 6
14) Warning Light, Hydraulic Pressure............. 6
1) Throttle Pedal ................................................ 7
2) Foot Brake Pedal ........................................... 7
3) Park Brake..................................................... 7
4) Transmission Shift Lever .............................. 7
Steering.............................................................. 7
Vehicle Operation .............................. 8
Safety Guidelines .............................................. 8
Starting .............................................................. 8
Stopping The Engine ......................................... 8
Driving .............................................................. 9
Hydraulics ......................................................... 9
Parking .............................................................. 9
Towing Loads: ................................................... 9
Towing This Vehicle .......................................... 9
Refueling ........................................................... 10
Loading and Unloading..................................... 10
Draw Bar Pull (DBP), definition....................... 10
Circuit Breaker (CB) Panel ................ 11
PM Checklist...................................... 12
Maintenance Guidelines for
Severe DutyApplications ............... 13
Daily Visual inspection: .................................... 13
2

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 2
STANDARD SPECIFICATIONS*
ITEM Model SPECIFICATION
Occupancy Driver and one passenger
Dimensions 103.5 L x 55.5 W x 63 H Inches (2,629 L x 1,410 W x 1,600 H mm)
Wheel Base 58.5 inches (1,486 mm)
Ground Clearance 6.5 inches (165 mm)
Turning Radius 115 inches (2,921 mm)
Dry Weight TC-40 5,500 pounds (2,496 kg)
Battery Group 24M, 800CCA, 135 minute reserve
Transmission Ford C6, 3-Speed Automatic
Engine Cummins B4.5-C Diesel
Fuel System Diesel
Cooling System, Coolant Type 50/50 mixture of DexCool Long Life coolant and water
DriveAxle Helical gearing primary reduction into standard hypoid ring and
pinion secondary reduction.
Suspension Leaf spring (front and rear)
Towing Capacity TC-40 4,000 pounds (1,814 kg)
(draw bar pull, see definition later in this section)
Brakes Rear Wheel Hydraulic Disc with Hand Operated Parking Brake.
Front Wheel Brake Optional.
Steering Power Hydrostatic Steering
Tires Front: 6.50 x 10 Laod Range E, Foam Filled
Rear: LT225/75R16 Load Range E, Foam Filled
Instrumentation Oil pressure, Coolant temperature, Battery volts, Fuel level,
Hour meter
Lights Headlight, Tail/Brake Light, Reverse light
This vehicle conforms to applicable sections as described in O.S.H.A. Standard Section 1910.178 (Powered
Industrial Trucks) and with all applicable portions of theAmerican National Standard for Operator Controlled
Industrial Tow Tractors (ANSI B56.9).
* - Specifications are for standard vehicle and are subject to change without notice.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 3
SAFETY RULES AND
GUIDELINES
Itis theresponsibility ofthe ownerofthisvehicleto assure
that the operator understands the various controls and
operating characteristics of this vehicle. As well as,
followingthe safety rules and guidelinesoutlinedinANSI
B56.9 and listed below.
These vehicles are designed for driving on smooth
surfacesin and aroundfacilitiessuch as industrialplants,
nurseries, institutions, motels, mobile home parks, and
resorts. They are not to be driven on public highways.
Refer to Vehicle Operational Guidelines, Safety
Guidelines section for important safety information
regarding operating this vehicle.
Read and follow all of the guidelines listed
below. Failure to follow these guidelines
may result in severe bodily injury and/or
property damage.
These vehicles are not designed to be driven
on public roads or highways. They are
available in maximum designed speeds
ranging from 10 to 13 mph. Do not exceed
the maximum designed speed. Exceeding
the maximum designed speed may result
in steering difficulty, motor damage, and/
or loss of control. Do not exceed locally
imposed speed limits. Do not tow this
vehicle at more than 5 mph.
Before working
on a vehicle:
Make sure the ignition switch is in the “OFF”
position.
Place the transmission shift lever in the
Parkor neutral position.
Set the park brake.
Place blocks under the front wheels to
prevent vehicle movement.
If working on the elctrical system, remove
the negative cable from the battery.
DRIVER TRAINING PROGRAM
Per ANSI B56.9, the owner of this vehicle shall conduct
an Operator Training program for all those who will be
operating this vehicle. The training program shall not be
condensed for those claiming to have previous vehicle
operation experience. Successful completion of the
Operator Training program shall be required for all
personnel who operate this vehicle.
The Operator Training program shall include the
following:
•Operation of this vehicle under circumstances
normallyassociated withyourparticularenvironment.
•Emphasis on the safety of cargo and personnel.
•All safety rules contained within this manual.
•Proper operation of all vehicle controls.
•A vehicle operation and driving test.
Driver Qualifications.
Only those who have successfully completed the
Operator Training program are authorized to drive this
vehicle. Operators must possess the visual, auditory,
physical, and mental ability to safely operate this vehicle
asspecifiedin theAmerican National Standards Institute
Controlled Personnel and Burden CarriersANSI B56.9.
The following are minimum requirements necessary to
qualify as an operator of this vehicle:
•Demonstrate a working knowledge of each control.
•Understand all safety rules and guidelines as
presented in this manual.
•Know how to properly load and unload cargo.
•Know how to properly park this vehicle.
•Recognize an improperly maintained vehicle.
•Demonstrate ability to handle this vehicle in all
conditions.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 4
VEHICLE CONTROLS
INSTRUMENT PANEL
1) Ignition Switch
Note: Rotary switch shown. Also
available as a keyed switch.
The ignition switch has 3-positions:
OFF, RUN, START.
Rotatingtheswitch clockwisetothe first
position turns the ignition system ON.
Rotating the switch to the START position engages the
engine starter motor. This is a momentary position and
the switch will return the START position when it is
released. Once the switch has been released from the
START position, it must be turned to OFF before it can
be turned back to the START position.
3) Oil Pressure
This gauge indicates the
engine oil pressure, not the oil
level.However,if yourengine’s
oil level is low, it could affect
the oil pressure.
Typical normal oil pressure
range when engine is hot is 6
to 18 PSI.
With the engine running, the pointer should move into
the NORMAL range. If the pointer drops below the
NORMAL range while the engine is running, you have
lostoilpressureandcontinuedoperationwillcausesevere
engine damage. If the pointer exceeds the NORMAL
range then there may be obstructions in the engine
lubrication system and continued operation will cause
severe engine damage.
If the oil pressure is low, pull to the side of the road and
immediately shut the engine off. Check and add oil as
needed and restart the engine. If the oil pressure is still
low, turn the engine off and have the vehicle towed to a
repairfacility.
If the oil pressure is high, pull to the side of the road and
immediately shut the engine off and have the vehicle
towed to your authorized Tiger Tractor repair facility.
2) Work Lights
Pull the switch out to turn the rear work lights on. Push it
in to turn them off.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 5
9) Horn Switch
The horn switch is locatedon the dash panel to the right
ofthesteeringcolumn.Pushtheswitchto soundthe horn.
6) Battery Volt Meter
This gauge shows you the
batteryvoltagewhenthe ignition
key is in the ON position.
Typical battery voltage when
engine is running should be
between 13 and 15.5 volts. The
battery voltage could exceed
14.5voltsifoperated during cold
weatherordrop below 13 voltsif
there is a heavy demand due to accessories being used
or a moderate demand and the engine is at idle.
If the voltage remains below 13 volts when the engine is
runningand there is a lightloador,if the voltageexceeds
15 volts then the battery charging system should be
inspected.
4) Check Engine Light
When the Check Engine Light is on while the engine is
running, then the ECU has detected conditions that
indicate the engine is not operating correctly.
Ifthe CheckEngine Lightturnson thenthevehicle should
beimmediatelyremoved from service to beinspectedby
a qualified technician.
The Check Engine Light should be on when the ignition
switch is ON but the engine has not yet been started. If
the light does not come on then the vehicle should be
immediately removed from service to be inspected by a
qualifiedtechnician.
5) Coolant Temperature
This gauge indicates the
temperature of the engine
coolant, not the coolant level.
Ifthe coolantisnot atitsproper
level or mixture, the gauge
indication will not be accurate.
Thepointer movesfrom theleft
to the right side of the gauge
as your engine coolant warms
up.
Oncethe engineiswarmed up,the typicalnormalcoolant
temperature range is 180 to 210 degrees (F).
Under normal driving conditions, the pointer should stay
in the NORMAL range. It is acceptable for the pointer to
fluctuate within the NORMAL band under normal driving
conditions,andunder certain driving conditions such as,
heavy stop and go traffic, driving up hills in hot weather,
or towing hevy loads for the pointer to indicate at the top
of the NORMAL band.
If, under any circumstances, the pointer moves above
the NORMAL range, the engine is overheating and
continued operation may cause engine damage.
• Theengine ECU will reducepowerif the temperature
exceeds 220 degrees.
• The engine ECU will shut the engine down if the
temperature exceeds 230 degrees.
If your engine coolant overheats:
1. Pull off the road as soon as safely possible.
2. Turn off the engine.
3.Lettheenginecool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS
COOL.
4. Check the coolant level following the instructions
on checking and adding coolant to your engine.
• If the coolant continues to overheat, have the
coolant system serviced.
7) Fuel Gauge
The fuel gauge displays
approximately how much fuel
isin thefueltankonly whenthe
ignition switch is ON. Do not
refuel any vehicle while the
engine is running.
The fuel gauge indicator may
vary slightly when the vehicle
is in motion. The most accurate reading is obtained with
the vehicle on level ground.
With ignition switch OFF, the fuel gauge indicator may
drift from the ignition switch ON position.
The fuel gauge is not available on LPG fuel systems.
refer to the gauge mounted on your LPG fuel tank.
8) Hour Meter
The hour meterrecords the
number of hours the vehicle
has been in operation.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 6
INSTRUMENT PANEL (CONTINUED)
10) Heater Blower Switch
The blower switch has 4 positions:
OFF:The blower is OFF when the switch indicator is
pointing straight up.
1: Blower low speed.
2: Blower medium speed.
3: Blower full speed.
12) Windshield Wiper Switch
Lift the switch handle up to turn on the windshield wiper
and push it down to turn it off.
The wiper motor does not have an automatic park
position.Whenturningthewiperoff,besure thatthewiper
blade in not blocking the drivers view.
11) Heater Water Valve
The heater water valve is used to route the hot engine
coolant through the heater core. Pull the valve out all of
the way for maximum water flow and maximum heat.
The valve can be positioned to control the amount of hat
coolant and heat through the heater core.
14) Warning Light, Hydraulic Pressure
This light will come if the hydraulic system pressure is
too low.
If the light comes on, then the engine should be stopped
and the vehicle should be immediately removed from
service to be inspected by a qualified technician.
13) 12 Volt Electrical Outlet
This outlet can be used to plug in optional electrical
accessories.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 7
2) Foot Brake Pedal
The foot brake pedal, is located to the left of the throttle pedal and
is intended to be operated with the drivers right foot only. It works
similar to the brake in an automobile. Applying pressure to the
brakepedal slows the vehicleaccordingtothe amount of pressure
applied. Relieving pressure from the pedal releases the braking action.
3) Park Brake
The parking brake is actuated with a hand lever, which is located to the right of the driver. To set the parking brake,
push down on the brake pedal and pull the lever up until it locks. To release the park brake, depress the foot brake
pedal, pull up on the park brake handle, push the release button, and lower the handle.
1) Throttle Pedal
The throttle pedal is located on the floorboard and is intended to
be operated by the drivers right foot. It controls the speed of the
vehicleandoperatessimilar to the throttle pedal in an automobile.
Depress the pedal to increase speed and release the pedal to
decrease speed.
Steering
The steering wheel and steering system are similar to an automobile. To
turn right, turn the steering wheel clockwise. To turn left, turn the steering
wheelcounter-clockwise.
4) Transmission Shift Lever
Selects the direction of travel and gear range. Detailed description of operation is in the Vehicle Operation section
later in this chapter.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 8
Starting
For additional information, refer to the engine operator’s
manual included with your vehicle.
Perform all necessary vehicle preparation steps,
inspections,ormaintenancebeforeoperatingthisvehicle.
NOTE: The vehicle may be equipped with a various
startinterlock switches.Allinterlock switches
must be closed to allow the engine to start.
1. Placethe transmissionshiftleverin Parkor neutral.
2. Set the parking brake.
3. Depress the foot brake pedal.
4. Rotate the ignition switch to the start position and
hold (see Cautions above) until the engine starts
and then release the switch.
Do not depress the throttle pedal while starting
the engine. Depressing the pedal while starting
the engine could result in excessive engine RPM
and damage to the engine.
If the engine does not start within 30 seconds,
release the ignition switch and wait a minimum
of 2 minutes before attempting to start the
engine again. Engaging the starter motor for too
long of a time period may overheat and damage
the starter motor
Do not let the engine idle for long periods while
cold. This can result in contaminated engine oil,
carbon build up in cylinders, or valve sticking.
Stopping The Engine
For special instructions regarding stopping a diesel
engine, refer to the engine operator’s manual included
with your vehicle.
VEHICLE OPERATION
Safety Guidelines
•Only qualified and trained operators may drive this
vehicle.
•Driveonlyon level surfaces or on surfaces havingan
incline of no more than 10% (5.6 degrees).
•Drive slowly when making a turn, especially if the
ground is wet or when driving on an incline.
•This vehicle may overturn easily if turned sharply or
when driven at high speeds.
•Observe all traffic regulations and speed limits.
•Keep all body parts (head, arms, legs) inside this
vehicle while it is moving.
•Keep the vehicle under control at all times.
•Yield right of way to pedestrians, ambulances, fire
trucks, or other vehicles in emergencies.
•Donot overtakeanothervehicleat intersections,blind
spots, or other dangerous locations.
•Do not drive over loose objects, holes, or bumps.
•Yield right of way to pedestrians and emergencies
vehicles.
•Stay in your driving lane under normal conditions,
maintaining a safe distance from all objects.
•Keep a clear view ahead at all times.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 9
Towing Loads:
• Donot exceed theDBPtowing capacityofthe tractor.
See vehicle specifications and DBP definition.
• Do not exceed the load capacity of the trailer. Refer
to documentation supplied with your trailer for
information regarding load capacity of the trailer.
• Make sure all loads are securely tied down. Refer to
documentation supplied with your trailer for
information regarding attaching loads to the trailer.
• Do not back up when towing more than one trailer.
• Drive slowly when towing loads with a high center of
gravity.
• When turning, be sure to allow for “corner cutting” of
the trailer.
• Allow for longer stopping distances when towing
heavyloads.
• Allowforlongerstoppingdistanceswhendrivingdown
a grade.
Towing This Vehicle
Totowthis vehicle, attachatow strap to the frontbumper
tow-bar.
Use another driver to steer this vehicle while it is being
towed. Be sure the driver uses the brakes when the
towing vehicle slows or stops. Do not tow the vehicle
faster than 5 m.p.h. or its maximum designed speed,
whichever is lower.
Ifat allpossible, thisvehicle shouldbeplacedona carrier,
rather than towing.
This vehicle is equipped with a power assist
braking system. The power assist system only
functions when the engine is running. The effort
required to activate the brakes will be
significantly increased when the engine is off
and will require a longer stopping distance.
Parking
Before leaving the vehicle:
•After coming to a complete stop, move the shift lever
to the Park position.
•Set the parking brake.
•Rotate the ignition switch to the “OFF” position.
In addition:
•If parking this vehicle on an incline, turn the steer
wheels to the curb, or block the wheels.
•Do not block fire aisles, emergency equipment,
stairways, or exits.
Driving
•Slow down and sound the horn to warn pedestrians
or when approaching a corner or other intersection.
•No reckless driving.
•Do not drive this vehicle on steep inclines or where
prohibited.
•Immediatelyreport anyaccidentsorvehicle problems
to a supervisor.
Depress the foot brake pedal.
Release the parking brake.
Movethetransmissionshiftleverintothedesireddirection
of travel and then depress the throttle pedal.
Hydraulics
Thehydraulic pressureisdependant ontheengine RPM.
The pressure may not be high enough to operate the
hydraulics when the engine is at idle.
Your vehicle is equipped with a hand operated throttle to
beused when operatingthehydraulics.The hand throttle
lever is located on the transmission shift assembly. It is
the lever closest to the driver.
Thethrottlelever cannot be operated while the vehicle is
in gear.
To operate the lever:
Park the vehicle, place the shift lever in neutral and set
the parking brake.
Pushthethrottlelever outof theslot onthe shifterhousing
and pull back to set the desired engine RPM.

SAFETY RULES AND OPERATING INSTRUCTIONS
Safety Rules and Operating Instructions: MT-030-60-C
Page 10
Draw Bar Pull (DBP), definition
DBP is a measure of pulling force required to move a
load. The load may be a trailing load or a pushed load. It
is normally expressed in pounds or Newtons.
The DBP of a tow tractor is the horizontal force exerted
on a load at its coupler while towing or pushing a load.
To measure the DBP, a scale would be connected in line
with the tractor coupler and the load. The scale will
directly read the DBP as the tractor tows the load.
Tow tractor DBP specifications, definition:
Normal DBP: Highest DBP that can be sustained for a
given duty cycle.
Ultimate DBP:Alsoreferred to aMaximum DBP.Highest
DBP achieved while travailing at a minimum speed of
approximately 0.5 mph (0.8 kph)for a minimum of 30
seconds. This specification is used in calculations for
getting a load moving.
Notes:
Tow tractor DBP specifications are based on:
•Road surface consisting of level dry clean asphalt,
brushed concrete or equivalent.
•Maximum battery weight installed per tow tractor
battery specification.
Towing a load up any grade will significantly affect the
DBP required.
Mostpavedroads andparkinglotshavea drainagegrade
to allow water to run off. When operating a tow tractor at
or near its maximum capacity, this drainage grade will
greatly affect DBP required to pull the load and may
exceed the tractor specifications.
Loading and Unloading
•Do not carry more than the maximum number of
passengers allowed for this vehicle.
•Do not exceed the cargo load capacity.
•Do not load cargo that can fall off.
•Be careful when handling cargo that is longer, wider,
orhigher than this vehicle, besureto properly secure
all loads.
Refueling
The fuel system may be under pressure. If the
fuel cap or fuel line is venting vapor or if you
hear a hissing sound while disengaging the fuel
cap or fuel line, wait until it stops before
completely removing the cap or line. Otherwise,
fuel may spray out and injure you or others.
Refertotheengineoperationmanualfordetailsregarding
approved fuel types.
The following guidelines should be followed regardless
of engine fuel type.
•Turn the engine off before refueling.
•No smoking or open flames.
•Only refuel in an area with adequate ventalation.
•If using LPG, turn LPG tank valve off before
disconnecting the fuel line.
