Taylor SB25 User manual

SERVICE
MANUAL
Model SB25
Blended Ice Machine
Original Service Instructions
081218-S 8/12/14 (Original Publication)
(Updated 3/26/15)

Table of Contents Model SB25
Table of Contents
Section 1: Introduction 1...............................................
Safety 2.............................................................
SB25 Specifications 4.................................................
General Installation Instructions 6.......................................
Environmental Notices 8...............................................
Section 2: Controls and Systems 9......................................
Control Overview 10....................................................
Keypad 11............................................................
PC Connection 12......................................................
General Repairs 17....................................................
Blender Drive Board 30.................................................
Blender Pitcher Rinse Station 31.........................................
Blender Pitcher Rinse Station Repairs 32.................................
Section 3: Troubleshooting 37...........................................
General Troubleshooting 38.............................................
Rinse Station Troubleshooting 41........................................
Blender Troubleshooting 42.............................................
Section 4: Parts 45......................................................
Warranty Explanation 46................................................
Model SB25 Operator Parts 49..........................................
Model SB25 Internal Service Parts 51....................................
Model SB25 Drain Assembly 53.........................................
Model SB25 Front Panel 55.............................................
Model SB25 Manifold 082222-12 56......................................
Model SB25 Pump-Cane A. - X82356 57..................................
Rinse Station 58.......................................................

Model SB25 Table of Contents
Table of Contents - Page 2
Rinse Station Manifold 082222-05 59.....................................
Parts List 60...........................................................
Wiring Diagram 68.....................................................
CAUTION: Information in this manual is intended to be used by Taylor Authorized
Service Technicians only.
Note: Continuing research results in steady improvements; therefore, information
in this manual is subject to change without notice.
Note: Only instructions originating from the factory or its authorized translation
representative(s) are considered to be the original set of instructions.
E2014 Carrier Commercial Refrigeration, Inc. (Original Publication)
(Updated March, 2015)
081218-S
Any unauthorized reproduction, disclosure, or distribution of copies by any person of any portion of this
work may be a violation of Copyright Law of the United States of America and other countries, could result
in the awarding of Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result
in further civil and criminal penalties. All rights reserved.
Taylor Company
a division of Carrier Commercial Refrigeration, Inc.
750 N. Blackhawk Blvd.
Rockton, IL 61072

1
Model SB25 Introduction
Section 1: Introduction
SSafety
SSpecifications
SGeneral Installation Instructions
SEnvironmental Notices

2
Introduction Model SB25
Safety
______________________________
We at Taylor are committed to manufacturing safe
operating and serviceable equipment. The many
built-in safety features that are part of all Taylor®
equipment are aimed at protecting operators and
trained service technicians alike.
This manual is intended exclusively for
Taylor authorized service personnel.
DO NOT attempt to run the equipment
unless you have been properly trained to do so.
CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! Do not operate this unit
unless it is properly grounded and all service panels
and access doors are restrained with screws. Failure
to do so can result in severe personal injury from
electrical shock!
SDO NOT attempt any repairs unless the
main power supply to the unit has been
disconnected.
SDO NOT operate the unit with larger fuses
than specified on the data label.
SStationary appliances which are not
equipped with a power cord and a plug or
other device to disconnect the appliance
from the power source must have an all-pole
disconnecting device with a contact gap of
at least 3 mm installed in the external
installation.
SAppliances that are permanently connected
to fixed wiring and for which leakage
currents may exceed 10 mA, particularly
when disconnected, not used for long
periods, or during initial installation, shall
have protective devices such as a GFI to
protect against the leakage of current,
installed by authorized personnel to the local
codes.
SSupply cords used with this unit shall be
oil-resistant, sheathed flexible cable, not
lighter than ordinary polychloroprene or
other equivalent synthetic
elastomer-sheathed cord (Code designation
60245 IEC 57) installed with the proper cord
anchorage to relieve conductors from strain,
including twisting, at the terminals and
protect the insulation of the conductors from
abrasion.
If the supply cord is damaged, it must be
replaced by an authorized Taylor service
technician in order to avoid a hazard.
Failure to follow these instructions may result in
electrocution or damage to the unit.
DO NOT partially remove the ice hopper
cover. Complete removal of the hopper cover is
required when accessing the ice bin. Failure to
follow this instruction may result in personal injury.
DO NOT remove any internal operating
parts unless all control switches are in the OFF
position. Failure to follow these instructions may
result in severe personal injury from hazardous
moving parts.

3
Model SB25 Introduction
THIS UNIT HAS MANY SHARP EDGES
THAT CAN CAUSE SEVERE INJURIES.
This unit must be installed on a level
surface to avoid the hazard of tipping. Extreme care
should be taken in moving this equipment for any
reason.
Two or more people are required to safely move this
unit. Failure to comply may result in personal injury
or equipment damage.
This appliance is only intended to be
installed in a location where its use and maintenance
is restricted to trained personnel.
This unit must NOT be installed in an area
where a water jet or hose can be used. NEVER use
a water jet or hose to rinse or clean this unit. Using a
water jet or hose on or around this equipment may
result in the electrocution of the user or damage to
the equipment.
Cleaning and sanitizing schedules are
governed by your state or local regulatory agencies
and must be followed accordingly. Please refer to
the cleaning section of the Operator Manual for the
proper procedure to clean this unit.
Some consumers are highly allergic to
strawberries. In some severe cases, allergic
reactions to strawberries can cause death.
When blending natural strawberry
products, make sure excess product is
removed from the pitcher to eliminate
product carryover.
WARNING!

4
Introduction Model SB25
SB25 Specifications
The Model SB25 is a combination unit consisting of
the Model SB24 commercial ice shaver/blender unit
and a rinse station.
The Model SB24 shaver/blender unit has the option
of metered water and liquid sugar cane dispensing.
The rinse station is a timer controlled, automatic
system that rinses the interior of the blender
pitchers.
Ice Hopper
The standard frosted ice hopper holds approximately
28 lbs (13 kg) of ice. An optional clear ice hopper is
available which holds approximately 15 lbs (7 kg) of
ice.
Blender Pitcher
The maximum fill capacity of the blender pitcher is
48 fl oz (1.4 liters).
Electrical
Two dedicated electrical connection are required for
the SB24 and X81173-12. See the electrical chart
for proper electrical requirements. Manufactured to
be cord connected. Cord length is 9 ft. (274 mm)
external to unit.
Blender Station
Electrical Total Amps Supplied with
NEMA Cord
115/60/1 10.0A 5-15P
Rinse Station
Electrical Total Amps Power Supply
24 VAC 0.63A 115V
This unit may be manufactured with other electrical
characteristics. Refer to the local Taylor Distributor
for availability. (For exact electrical information,
always refer to the data label of the unit.)
Water
A 3/8” (9.5 mm) water line with minimum 55 PSI
(380 kPa) is required.
INSTALL POTABLE WATER CONNECTION
WITH ADEQUATE BACK-FLOW
PROTECTION TO COMPLY WITH
APPLICABLE NATIONAL, STATE AND
LOCAL CODES. WATER TEMPERATURE IS
NOT TO EXCEED 125°F (51°C).
Drain
A drain is required. The drain must be able to
accommodate a 1-1/8” (29 mm) diameter drain tube.
A minimum of 1” (25 mm) air gap is required
between the end of the drain tube and the drain to
ensure proper flow.
IMPORTANT: The unit must be installed on a level
surface for proper drainage.
Accessories include 10 ft. (3050 mm) of 7/8” (222
mm) ID drain hose.
Air Cooled
No additional clearance is required on either side of
the unit for air inlet or discharge.
2” (50 mm) of clearance is required behind the unit
to allow for proper routing of the drainage hardware.
12” (304 mm) of air clearance is required above the
unit to allow for proper loading of ice into the ice
hopper.
Dimensions
Width: 12-1/4” (311 mm)
Depth: 18” (457 mm)
Height:23-1/2” (597 mm)
Approximate Weights
Net: 35 lb (15.9 kgs)
Crated: Carton #1 35 lbs. (15.9 kgs)
Carton #2 11 lbs. (5 kgs)
Water Pressure
55 PSI (380 kPa) minimum incoming
100 PSI (690 kPa) maximum incoming

5
Model SB25 Introduction
SB25 Specifications (Continued)

6
Introduction Model SB25
General Installation Instructions
CAUTION: Only trained, authorized service
technicians should install the Blended Ice Machine.
Failure to comply will void the factory warranty.
The following are general installation instructions.
For complete installation instructions, please see the
Installation Checklist.
ALL WIRING AND PLUMBING MUST
CONFORM TO NATIONAL AND LOCAL CODES.
INSTALL POTABLE WATER CONNECTION
WITH ADEQUATE BACK-FLOW
PROTECTION TO COMPLY WITH
APPLICABLE NATIONAL, STATE AND
LOCAL CODES.
Site Preparation
Review the area where the unit will be installed
before uncrating the unit. Make sure that all possible
hazards to the installer, user, and the unit have been
addressed.
For Indoor Use Only: This unit is designed to
operate indoors, under normal ambient
temperatures of 70° - 75°F (21° - 24°C). The unit
has successfully performed in high ambient
temperatures of 104°(40°C) at reduced capacities.
This unit must NOT beinstalledinanarea
where a water jet or hose can be used. NEVER use
a water jet or hose to rinse or clean this unit. Using a
water jet or hose on or around this equipment may
result in the electrocution of the user or damage to
the equipment.
This unit must be installed on a level
surface to avoid the hazard of tipping. Extreme care
should be taken in moving this equipment for any
reason.
Two or more people are required to safely move this
unit. Failure to comply may result in personal injury
or equipment damage.
Uncrate the unit. Inspect the unit for damage. Report
any damage to the Taylor Factory immediately.
This unit is made using USA sizes of hardware. All
metric conversions are approximate.
Air Clearance:
No additional clearance is required on either side of
the unit for air inlet or discharge.
2” (50 mm) of clearance is required behind the unit
to allow for proper routing of the drainage hardware.
12” (304 mm) of air clearance is required above the
unit to allow for proper loading of ice into the ice
hopper.
Unit Preparation: Freezing Conditions
Storage
In order to prevent the freezing of water lines in the
unit, the drinking and rinse water lines shall be
drained prior to storage of the unit in a location
below freezing. If freezing of water in these lines
does occur, thaw the lines in normal ambient
conditions and check the water lines for signs of
damage before and after supplying water to the unit.

7
Model SB25 Introduction
Installer Safety
In all areas of the world, equipment should
be installed in accordance with existing local codes.
Please contact your local authorities if you have any
questions.
Care should be taken to ensure that all basic safety
practices are followed during the installation and
servicing activities related to the installation and
service of Taylor® equipment.
SOnly authorized Taylor service personnel
should perform installation, maintenance,
and repairs on Taylor equipment.
SAuthorized service personnel should consult
OSHA Standard 29CFRI910.147 or the
applicable code of the local area for the
industry standards on lockout/tagout
procedures before beginning any installation
or repairs.
SAuthorized service personnel must ensure
that the proper personal protective
equipment (PPE) is available and worn
when required during installation and
service.
SAuthorized service personnel must remove
all metal jewelry, rings, and watches before
working on electrical equipment.
The main power supply(s) to the units must
be disconnected prior to performing any installation,
maintenance, or repairs. Failure to follow this
instruction may result in personal injury or death
from electrical shock or hazardous moving parts as
well as poor performance or damage to the unit.
This unit has many sharp edges that can
cause severe injuries.
Water Connection
New hose sets supplied with the appliance are to be
used and old hose sets should not be re-used.
Electrical Connections
In the United States, this equipment is
intended to be installed in accordance with the
National Electrical Code (NEC), ANSI/NFPA
70-1987. The purpose of the NEC code is the
practical safeguarding of persons and property from
hazards arising from the use of electricity. This code
contains provisions considered necessary for safety.
In all other areas of the world, equipment should be
installed in accordance with the existing local codes.
Please contact your local authorities.
Each unit requires one power supply. Check the
data label on the unit for fuse, circuit ampacity and
other electrical specifications. Refer to the wiring
diagram provided inside the control box for proper
power connections.
Refer to the Electrical Specifications on page 4 for
proper field wire connection.
It is recommended that the unit be plugged into an
electrical surge protector for added protection
against power surges, which could damage an
electrical/electronics component. An electrical surge
event may cause the unit to shut down. Such an
event would require service by a qualified service
technician if the unit was not adequately protected.
A good surge protector, as would normally be used
on a home computer, should be adequate and is
available at most computer retail outlets or electrical
supply stores.
FOLLOW YOUR LOCAL ELECTRICAL CODES!
CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! FAILURE TO DO SO
CAN RESULT IN SEVERE PERSONAL INJURY
FROM ELECTRICAL SHOCK!

8
Introduction Model SB25
SDO NOT operate the unit with larger fuses
than specified on the data label.
SStationary appliances which are not
equipped with a power cord and a plug or
another device to disconnect the appliance
from the power source must have an all-pole
disconnecting device with a contact gap of
at least 3 mm installed in the external
installation.
SAppliances that are permanently connected
to fixed wiring and for which leakage
currents may exceed 10 mA, particularly
when disconnected, not used for long
periods, or during initial installation, shall
have protective devices such as a GFI to
protect against the leakage of current,
installed by authorized personnel to the local
codes.
SSupply cords used with this unit shall be
oil-resistant, sheathed flexible cable, not
lighter than ordinary polychloroprene or
other equivalent synthetic
elastomer-sheathed cord (Code designation
60245 IEC 57) installed with the proper cord
anchorage to relieve conductors from strain,
including twisting, at the terminals and
protect the insulation of the conductors from
abrasion.
If the supply cord is damaged, it must be
replaced by an authorized Taylor service
technician in order to avoid a hazard.
Failure to follow these instructions may result in
electrocution or damage to the unit.
Environmental Notices
______________________________
If the crossed out wheeled bin symbol is
affixed to this product, it signifies that this product is
compliant with the EU Directive as well as other
similar legislation in effect after August 13, 2005.
Therefore, it must be collected separately after its
use is completed, and cannot be disposed as
unsorted municipal waste.
The user is responsible for returning the product to
the appropriate collection facility, as specified by
your local code.
For additional information regarding applicable local
laws, please contact the municipal facility and/or
local distributor.
NOISE LEVEL: Airborne noise emission does not
exceed 89 dB(A) when measured at a distance of
1.0 meter from the surface of the unit and at a
height of 1.6 meters from the floor.

9
Model SB25 Controls and Systems
Section 2: Controls and Systems
SControl Overview
SKeypad
SPC Connection
SGeneral Repairs
SBlender Drive Board
SBlender Pitcher Rinse Station

10
Controls and Systems Model SB25
Control Overview
Figure 1

11
Model SB25 Controls and Systems
Keypad
The keypad allows the operator to control the
functions of the unit. It is located in the front face of
the blender. (See Figure 2.)
Figure 2
Stop/Cancel Key
Pressing this key will shut down the unit and cancel
the drink cycle.
Recipe Keys
Selects pre-programmed flavor/recipes.
NO SUGAR Key
Removes cane sugar from the drink recipe currently
being dispensed.
Drink Size Keys
Selects the drink size.
Single/Double Quantity Keys
Allows the operator to make a single or double
serving of K, S, and M drink sizes. It will not make a
double L drink.
GO Key
The GO key starts the selected drink cycle.
Shaver Key and Blender Key
These keys are used to manually shave ice and
blend product.

12
Controls and Systems Model SB25
PC Connection
The SB25 can be connected to a PC in order to
manage recipes and system calibration, using the
supplied software. A PC running Windows XP or
greater with a USB port is required.
1. Remove the cover from the upper USB port on
the left side of the system by unscrewing the
cap counter-clockwise.
2. Connect the USB cable from the PC to the
USB-B connector on the unit.
3. Switch the main power ON.
4. The first time you connect to the unit and start
the PC software, you may be prompted to
install the proper drivers on your PC. Follow the
on screen instructions to install the proper
drivers. Note: This requires an Internet
connection.
5. Open the programming software:
“OTGConfig Rels Rev A.exe”
6. Refresh the Port List and select the proper
COM Port from the list of Available Ports. This
is usually the highest numbered port in the list.
(See Figure 3.)
Figure 3
7. To reset the connection select “Close Port” and
reselect.
Customer Numbers
Two customer numbers can be stored in the
shaver/blender controller PCA memory, containing
separate recipe and calibration settings. These are
selected by a DIP switch setting inside the system,
located on the top edge of the dispense PCA
assembly. Position 5 is used to select the customer
number. (Position 6 is used to enable or disable the
cane pump option on the SB25, if it is functioning.)
SCustomer 1 - Switch Position 5 OFF
SCustomer 2 - Switch Position 5 ON
When you power up the system, the customer
selected number is displayed briefly (one second)
before showing the default menu settings.
SIf recipe key 1 is on briefly at power up, the
DIP switch is set to customer 1.
SIf recipe key 2 is on briefly at power up, the
DIP switch is set to customer 2.
Customer configurations are generated in the
supplied PC software. The main page of the
supplied software will indicate the current DIP switch
setting. Any combination of customer configurations
can be loaded into the system. If you select a
configuration that hasn't been downloaded, the
default values in the software will be used.

13
Model SB25 Controls and Systems
Calibration
______________________________
The SB25 unit can be calibrated using the supplied
PC software or by using the manual calibration
method through the main keypad.
Target Calibration Settings
SShaved Ice: 10 oz. (by weight)
SWater Dispense: 4 oz (by volume)
SCane Dispense: 4 oz (by volume)
PC Calibration
Step 1
Refer to PC Connection on page 12.
Step 2
Select “System Calibration” from the supplied
software. (See Figure 4.)
Step 3
The current system Calibration Factor values for
Shave, Blend, Water and Cane dispense times are
displayed.
Step 4
Use the +/- buttons next to each Calibration Factor
to increase or decrease calibration settings to
achieve desired results. Note that this changes the
Calibration Factor on the shaver/blender system
immediately.
Step 5
Select the Run Cycle button next to each Calibration
Factor to run that particular function with the
Calibration Factor applied.
Step 6
Select “Reset Calibration Factors” to return all
values to 1.0.
Step 7
Select “Main Menu”, select recipe settings, and
select save to unit.
Figure 4

14
Controls and Systems Model SB25
Keypad Calibration
Step 1
Enter the keypad calibration mode by holding the
Stop button until all recipe key LED's blink.
SPress recipe 1 key to change the Shave
calibration value.
SPress recipe 3 key to change the Water
calibration value.
SPress recipe 4 key to change the Cane
calibration value (Model SB25, only).
When the value to be changed has been selected, it
will blink at a slow rate, along with the recipe1 & 2
serving size LED's.
Note: The serving size LED's blink to indicate that
the calibration value can now be changed.
Step 2
Use the +/- buttons to increase or decrease the
calibration settings to achieve the desired results.
Step 3
Press the STOP/CANCEL button to cancel any
unsaved changes and exit the calibration mode.
Step 4
Press the NO SUGAR button to save the current
calibration value and run a test cycle of the item
being calibrated:
SShave – dispense 10 oz of ice with the
current calibration value applied.
SBlend – run blender for “2 seconds” with the
current calibration value applied.
SWater - dispense 4 oz of water with the
current calibration value applied.
SCane - dispense 4 oz of cane with the
current calibration value applied.
SPress “GO” to save the changes.
Test Mode
______________________________
The Test Mode within the Calibration Mode allows
all motors, valves, and pumps to be run manually.
This can be useful in diagnosing motor or dispensing
issues.
Step 1
Enter the calibration mode by holding the
button for 3 seconds.
Step 2
Press and hold the manual blend button for
3 seconds.
Step 3
Press the single serving button for shaver or
blender motor testing:
SPress and hold the manual shave button
to run the shaver motor.
SPress and hold the manual blend button
to run the blender motor.
Step 4
Press the double serving button for water
dispense testing:
SPress and hold the manual shave button
to run the cane pump.
SPress and hold the manual blend button
to activate the water valve.
Step 5
Press the STOP/CANCEL button to exit the Test
Mode.

15
Model SB25 Controls and Systems
Programming & Recipe Storage
______________________________
The customer recipe information is held in the
microprocessor memory. Recipes distributed on
USB memory sticks can be uploaded to the system
automatically. Note: When new recipes are
uploaded, any recipes currently on the system
will be overwritten.
Programming Using USB Stick
Note: Do not plug in a thumb drive and the PC
USB cable at the same time.
Step 1
Switch the main power OFF.
Step 2
Remove the cover from the lower USB port on the
left side of the system by unscrewing the cap
counter-clockwise. (See Figure 5.)
Figure 5
Step 3
Insert the USB stick.
Step 4
Switch the main power ON.
Step 5
The SB25 will automatically download and save the
recipe information to the unit.
Step 6
Place the main power switch in the OFF position.
Step 7
Remove the USB stick and reinstall the USB port
cover.
Step 8
Place the main power switch in the ON position.
PC Recipe Management
The supplied software can be used to transfer drink
recipe information back and forth from a PC to the
shaver/blender. It can also be used to create USB
flash drives in order to distribute recipes to customer
sites.
Recipe Programming
Step 1
Refer to PC Connection on page 12.
Step 2
Select “Recipe Programming” from the supplied
software. (See Figure 6.)
Figure 6

16
Controls and Systems Model SB25
Step 3
To load an existing recipe file, select “Load from
File” and browse to the folder. Select the file name
and select “Open.” This will overwrite the recipe set
shown in the table.
Step 4
To load recipes from the shaver/blender, select
“Load from Machine.” This will overwrite the recipe
set shown in the table.
Step 5
The recipe table is used to display and edit a set of
drink recipes.
a. Use the left/right arrow keys to select drink
numbers.
b. Enter the Drink Flavor - This is descriptive text to
identify the drink, e.g. “Strawberry Banana.”
c. Drink size – Corresponds to the drink sizes on
the system (Note that “O” on the PC stands for
“K” on the keypad).
d. Water Volume (oz.) – Amount of water dispensed
for each drink size.
e. Ice (oz.) – Amount of ice dispensed for each
drink size.
f. Base Volume (oz.) – Amount of flavor base that
needs to be manually added before shaving/
blending. This parameter is for reference and is
not used by the unit.
g. Liquid Cane Volume (oz.) – Amount of liquid
cane dispensed for each drink size.
h. Blend Time (sec.) – Duration of blend cycle for
each drink size.
Step 6
To store the recipe set to the PC, select “Save to
File,” browse to a folder, enter the file name, and
select “Save.”
Select “Save to Machine” to store the recipes on the
unit. This will overwrite the recipe set stored on the
system.
Step 7
TostorearecipesettoaUSBflashdrive,plugthe
drive into the PC’s USB port and select “Export to
Flash.” Select the USB device from the browser and
select “Save” (file will be named CUST1.txt,
CUST2.txt depending on the DIP switch customer
number system setting).
Step 8
Select “Main Menu” when done.
