TC Communications TC3006 User manual

Notice!
Althougheveryefforthasbeenmadetoinsurethatthismanualiscurrent
and accurate as of date of publication, no guarantee is given or implied
that this document is error free or accurate with regard to any specifica-
tion. TC Communications, Inc. reserves the right to change or modify
the contents of this manual at any time without prior notification.
TC3006
GIGABIT ETHERNET
FIBER OPTIC MODE CONVERTER
User's Manual
© COPYRIGHT 1992-2009. ALL RIGHTS RESERVED.
MODEL:
S/N:
DATE:
TC Communications, Inc. 17881 Cartwright Road - Irvine, CA 92614
Tel: [phone] Fax: [phone] Web Site: www.tccomm.com Email: [email protected]

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-2-
Table Of Contents
Chapter 1 - Overview ...................................................................................................3
Description.......................................................................................................................................... 3
Data Rates........................................................................................................................................... 3
Optical Specifications ....................................................................................................................... 4
Transmission Distances (typical) .............................................................................................. 4
Launch Power & Sensitivity ....................................................................................................... 4
Front Panel LEDs, DIP Switches, and Connectors ....................................................................... 6
Rear Panel Connectors..................................................................................................................... 6
Chapter 2 - Installation ................................................................................................7
Unpacking the Unit ............................................................................................................................ 7
Equipment Location .......................................................................................................................... 7
Power Supply...................................................................................................................................... 7
Dry Contact Alarm Relay................................................................................................................... 7
Installation Diagrams......................................................................................................................... 8
Chapter 3 - Troubleshooting ........................................................................................9
Chapter 4 - Specifications.......................................................................................... 10
Appendix A................................................................................................................ 11
Return Policy ....................................................................................................................................11
Warranty ............................................................................................................................................11

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-3-
Chapter 1 - Overview
Description
The TC3006 gives users the ability to convert Multimode fiber optic signals to Single Mode format for data
transmission (and vice-versa). These conversions can benefit users by extending transmission distances and/
or enabling dissimilar fiber optic devices to be used with different fiber types. The optic receiver detects the
incoming optical signal and regenerates it for transmission through the second optic transmitter. The TC3006
isavailableinmultiple configurationsdepending onyour communicationrequirements. When bothsides have
the same wavelength, the TC3006 works like an optical signal repeater.
Data Rates
1000Mbps

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-4-
*Launch power, sensitivity and distance are listed for reference only. These numbers may vary. Contact factory for
higher loss budgets and ST & FC fiber connector types (SC fiber connectors are standard).
Optical Specifications
Multimode 850nm, 275/550 Meter Option
Transmitter: FP LASER; typical Launch Power: -10.0 dBm @850nm
Receiver: PIN Diode; typical Sensitivity: -18.0 dBm @850nm
Optic saturation level: 0 dBm @850nm
Loss Budget: Multimode (50/125µm)@850nm: 8 dB
Multimode (62.5/125µm)@850nm: 8 dB
Distance: Multimode (50/125µm)@850nm: up to 550 Meter distance*
Multimode (62.5/125µm)@850nm: up to 275 Meter distance*
Wavelength: Multimode 850nm:
Connector*:ST
FC
SC
Multimode 1310nm, 2km Option
Transmitter: FP LASER; typical Launch Power: -6.0 dBm @1310nm
Receiver: PIN Diode; typical Sensitivity: -16.0 dBm @1310nm
Optic saturation level: 0 dBm @1310nm
Loss Budget: Multimode (50 or 62.5/125µm)@1310nm: 10 dB
Distance: Multimode (50 or 62.5/125µm)@1310nm: up to 2km distance*
Wavelength: Multimode 1310nm:
Connector*:ST
FC
SC
Single Mode 1310nm, 20km Option
Transmitter: FP Laser; typical Launch Power: -10 dBm @1310nm
Receiver: PIN Diode; typical Sensitivity: -20.0 dBm @1310nm
Optic saturation level: -3 dBm @1310nm
Loss Budget: Single Mode (9/125µm)@1310nm: 10 dB
Distance: Single Mode (9/125µm)@1310nm: up to 20 km distance*
Wavelength: Single Mode 1310nm (LASER):
Connector*:ST
FC
SC
Single Mode 1550nm, 50km Option
Transmitter: FP Laser; typical Launch Power: -4dBm @1310nm
Receiver: PIN Diode; typical Sensitivity: -23.0 dBm @1310nm
Optic saturation level: -3 dBm @1310nm
Loss Budget: Single Mode (9/125µm)@1310nm: 19dB
Distance: Single Mode (9/125µm)@1310nm: up to 50km distance*
Wavelength: Single Mode 1310nm (LASER)
Connector*:ST
FC
SC

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-5-
Single Mode 1550nm, 80km Option
Transmitter: Typical Launch Power: 0 dBm @1550nm
Receiver: PIN Diode; typical Sensitivity: -24.0 dBm @1550nm
Optic saturation level: 0 dBm @1550nm
Loss Budget: Single Mode (9/125µm)@1550nm: 24 dB
Distance: Single Mode (9/125µm)@1550nm: up to 80km distance*
Wavelength: Single Mode 1550nm :
Connector*: ST
FC
SC
Single Mode 1550nm, 120km Option
Transmitter: DFB Laser; typical Launch Power: 0dBm @1550nm
Receiver: PIN Diode; typical Sensitivity: -32.0 dBm @1550nm
Optic saturation level: -9dBm @1550nm
Loss Budget: Single Mode (9/125µm)@1550nm: 32dB
Distance: Single Mode (9/125µm)@1550nm: up to 120km distance*
Wavelength: Single Mode 1550nm (LASER)
Connector*:ST
FC
SC
Single (One) Fiber, 40km Model
Transmitter: Typical Launch Power -3 to + 2 dBm* (1310nm/1550nm, @9/125µm)
Receiver: PIN Diode; typical Sensitivity -23 dBm* (1310nm/1550nm, @9/125µm)
Optic saturation level -3 dBm*
Loss Budget: 1310nm/1550nm Single Mode, @9/125µm 20 dB
Distance: 1310nm/1550nm Single Mode, @9/125µm up to 40km distance*
Wavelength: 1310nm/1550nm Single Mode
Connector: SC Only*
*Launch power, sensitivity and distance are listed for reference only. These numbers may vary. Contact factory for
higher loss budgets and ST & FC fiber connector types (SC fiber connectors are standard).

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-6-
Front Panel LEDs, DIP Switches and Connectors
Figure 2. TC3006's Rear Panel
Figure 1. TC3006's Front Panel
Rear Panel Connectors
+ - + -
12VDC
48VDC 24VDC 125VDC
ALARM
PWR
APWR B
Terminal Block Connectors
for Power Supply "A" & "B" Dry Contact Alarm
Relay Connector
1 2 3 4
ON
Single Mode
Transmitter (Tx):
Connect to remote
unit's SM Receiver (Rx).
Note: The MM RX/SM RX or (SM RX/SM RX - on repeater models) LEDs may be arbitrarily Lit or Off on initial power up
(or if power is cycled). This is normal.
Once a valid optical signal is received, the will be solidly lit.
If the optical signal is then removed the LEDs mentioned will turn Off. (Normal condition)
MM RX/SM RX or (SM RX/SM RX) LEDs
Multimode Transmitter
(Tx): Connect to local
equipment's MM
Receiver (Rx).
Not Used.
Reserved
for future
functions.
Not Used.
Reserved
for future
functions.
Single Mode
Receiver (Rx):
Connect to
remote unit's SM
Transmitter (Tx).
Multimode
Receiver (Rx):
Connect to local
equipment's MM
Transmitter (Tx).
Multimode optic receive
status: MM received optic
power is above sensitivity
threshold when lit.
Single Mode optic receive
status: SM received optic
power is above sensitivity
threshold when lit.
Alarm: When lit, it indicates
a broken fiber condition and
closure of alarm dry contact
relay (buzzer will sound).
Buzzer can be disabled by
"DISALM” switch.
DIP Switch Functions
SW1,2,3 - Not Used; reserved for future functions.
SW4 - Down (or Right) Disables the audio buzzer
and Dry Contact Relay Alarm.
Vcc: +5 VDC
operating voltage
derived from either
PWR A or PWR B
Made
i
n
U
.
S
.
A
.
V
c
c
S
M
R
X
B
A
MM RX
TCCOMM.COM
ALM
PWR
G
I
G
A
B
I
T
E
T
H
E
R
N
E
T
F
I
B
E
R
O
P
T
I
C
M
O
D
E
C
O
N
V
E
R
T
E
R
Rx Tx
R
x
T
x
S
M
M
M
DC Power Input Status for
PWR A and/or PWR B: Lit when
power supply is connected to
either PWR A or PWR B
connector on the rear panel

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-7-
Chapter 2 - Installation
Unpacking the Unit
Before unpacking any equipment, inspect all shipping containers for evidence of external damage caused
during transportation. The equipment should also be inspected for damage after it is removed from the
container(s).Claims concerningshippingdamage shouldbe madedirectly to thepertinentshipping agencies.
Any discrepancies should be reported immediately to the Customer Service Department at TC Communi-
cations, Inc.
Equipment Location
The TC3006 should be located in an area that provides adequate light, work space, and ventilation. Avoid
locating it next to any equipment that may produce electrical interference or strong magnetic fields, such as
elevator shafts or heavy duty power supplies. As with any electronic equipment, keep the unit from excessive
moisture, heat, vibration, and freezing temperatures.
Power Supply
Standard input power to the TC3006 is 12VDC @600mA. There are two pairs of terminal block connectors
on the rear panel (labeled "PWR A" and "PWR B"). Only one pair is required to power the unit. Polarity
is indicated on each connector block. If both pairs are connected, the built-in power redundancy feature will
beutilized. When this feature is utilized,both "A"and "B"share theload. If onepower sourcefails, theother
willassume thefull load. Polarity isindicated oneachconnector block.Alternate power sourcesare available
as an option (see Chapter 4 - Specifications).
Dry Contact Relay Alarm
A terminal block connector on the rear panel (labeled
"ALARM") provides for the dry contact relay alarm (see Figure
2). Normallyin theOPEN position,theloss ofeither opticsignal
will trigger an alarm condition and force the switch to the
CLOSED position. This relay can be used in conjunction with
an external device to monitor the condition of the fiber optic
links. Note: If SW4 (DISALM) on the front panel is in the
Down position, the audio buzzer will not sound and the dry
contact relay will not activate.
Dry Contact Relay
Alarm Switch
To remote alarm status indicator
Max switch voltage: 100VDC
Switchcurrent: 0.5Amp
Max carry current: 1.2Amp
Contactresistance: 0.2Ohm
Reply switch specifications

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-8-
Installation Diagrams
Figure 3. Installation Diagram for Dual TC3006 Application
Figure 4. Installation Diagram for Single TC3006 Application
SM Tx
SM Rx
Single Mode
fiber optic
cable
TC3006
Gigabit Mode Converter
Multimode
850nm/1300nm
GIGABIT
TRANSCEIVER
RxTx
MM Tx
MM Rx
Multimode
fiber optic
cable
Single Mode
1300nm/1550nm
GIGABIT
TRANSCEIVER
Tx Rx
SM Tx
SM Rx
Single Mode
fiber optic cable
TC3006
Gigabit Mode Converter
Multimode
850nm/1300nm
GIGABIT
TRANSCEIVER
RxTx
MM Tx
MM Rx
Multimode
fiber optic
cable
MM Rx
MM Tx
TC3006
Gigabit Mode Converter
Multimode
850nm/1300nm
GIGABIT
TRANSCEIVER
Rx Tx
SM Rx
SM Tx
Multimode
fiber optic
cable

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-9-
Chapter 3 - Troubleshooting
Typically, most problems encountered with the TC3006 are related to optic receiver overdrive. The
maximum optic power that can be received without distortion is referred to as the optic receiver's "saturation
level." When the incoming optic power is greater than the saturation level of the receiver, optic "overdrive"
can occur.
Forexample,theTC3006's(SingleMode1310nm,20kmmodel) opticreceivershaveatypical saturation level
of -3dBm. If the user's equipment's launch power is higher than -3dBm (i.e. -2dBm or greater) and the fiber
run is very short and has low signal loss, it is likely to overdrive the TC3006's Multimode receiver. The
consequences of overdrive can be high error rates or the device's failure to recognize the incoming optic
signal at all.
TheTC3006has beenadjusted atthe factorysothatthe SingleMode transmitterwill notoverdrive theSingle
Mode receiver even when short cables are used to connect them; hence, the overdrive condition happens
most frequently at the Multimode receiver optic.
If you suspect the Multimode receiver has an optic overdrive condition, a simple test will help verify it. At
the receiving optic in question, simply disconnect the optic connector and back it out of the receptacle (about
1/8 of an inch), creating a gap between the fiber connector and the receiver. Verify that the equipment is
still in "sync" with the optic signal and that the overdrive condition has been corrected. To resolve the
overdrive condition permanently, insert a 5dB or 10dB in-line attenuator into the problem link. In-line
attenuators can be purchased from Metrotek* at [phone]. The part numbers are:
Description: ST@5dB ST@10dB FC@5dB FC@10dB
Part Number: 68-JJ-7-0513 68-JJ-7-1013 68-FF-0513 68-FF-1013
The following diagram illustrates a TC3006 Mode Converter used to convert a 1310nm Single Mode optical
signal from a Gigabit Switch #1 into an 850nm Multimode optic signal to be received by a second Gigabit
Switch #2. In the reverse direction, the Gigabit Switch #2's Multimode optic signal is converted to Single
Mode format to be received by the Gigabit Switch #1. In-line attenuators are used to correct optic overdrive
conditions that exist on either side of the TC3006.
Figure 5. In-line Attenuator Placement Diagram
Note: Launch power measurements are taken at 1000Mbps and may vary due to the actual signal's duty cycle.
GIGABIT
SWITCH#1
TxRx
Rx RxTx
Tx
ATTN
10 dB
launch power:
5 dBm+
MMSM
receiving power:
-5 dBm
1310nmSM
GIGABIT
SWITCH#2
Tx
Rx
ATTN
10 dB
3006
launch power:
+3 dBm
receiving power:
-7 dBm
850nm MM
850nm MM

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-10-
Chapter 4 - Specifications
Data Rates
.........................................................................................................................1000Mbps
Optical
See pages 4 and 5
Indicators
System status ......................................................................ALARM, PWR A, PWR B, Vcc
Optic Signal Status .................................................................................. MM RX, SM RX
Power Source
Standard ....................................................................................12VDC @600mA (typical)
Optional .................24VDC, 48VDC, 125VDC, or 115/230VAC with an external power cube
Temperature
Operating.....................................................................................................-10oC to 50oC
........................................................................Hi-Temp Version (Optional) -20oC to 70oC
Storage ........................................................................................................-40oC to 90oC
Humidity ..........................................................................................95% non-condensing
Physical Characteristics
Rack Mountable Card Stand Alone Unit
Height: 7.0" (17.7 cm) Height: 1.4" (3.5 cm)
Width: 1.2" (3.1 cm) Width: 7.1" (18 cm)
Depth: 5.8" (14.8 cm) Depth: 6.6" (16.6 cm)
Weight: 8.5 oz. (188 gm) Weight: 1.5 lbs. (512 gm)

TC3006
(LED/ELED/LASER)
User's Manual
Rev. 1.8
-11-
Appendix A
Return Policy
To return a product, you must first obtain a Return Material Authorization number from the Customer
Service Department. If the product’s warranty has expired, you will need to provide a purchase order to
authorize the repair. When returning a product for a suspected failure, please provide a description of the
problem and any results of diagnostic tests that have been conducted.
Warranty
Damages by lightning or power surges are not covered under this warranty.
All products manufactured by TC Communications, Inc. come with a five year (beginning 1-1-02)
warranty. TC Communications, Inc. warrants to the Buyer that all goods sold will perform in accordance
with the applicable data sheets, drawings or written specifications. It also warrants that, at the time of sale,
the goods will be free from defects in material or workmanship. This warranty shall apply for a period of
five years from the date of shipment, unless goods have been subject to misuse, neglect, altered or destroyed
serialnumberlabels, accidents(damages causedinwholeor inpart toaccident,lightning,power surge,floods,
fires, earthquakes, natural disasters, or Acts of God.), improper installation or maintenance, or alteration or
repair by anyone other than Seller or its authorized representative.
Buyer should notify TC Communications, Inc. promptly in writing of any claim based upon warranty, and
TC Communications, Inc., at its option, may first inspect such goods at the premises of the Buyer, or may
give written authorization to Buyer to return the goods to TC Communications, Inc., transportation charges
prepaid, for examination by TC Communications, Inc. Buyer shall bear the risk of loss until all goods
authorized to be returned are delivered to TC Communications, Inc. TC Communications, Inc. shall not be
liable for any inspection, packing or labor costs in connection with the return of goods.
In the event that TC Communications, Inc. breaches its obligation of warranty, the sole and exclusive
remedy of the Buyer is limited to replacement, repair or credit of the purchase price, at TC Communications,
Inc.’s option.
To return a product, you must first obtain a Return Material Authorization (RMA) number and RMA form
from the Customer Service Department. If the product’s warranty has expired, you will need to provide a
purchaseorder toauthorize therepair. Whenreturning aproductfor asuspectedfailure, pleasefillout RMA
form provided with a description of the problem(s) and any results of diagnostic tests that have been
conducted. The shipping expense to TC Communications should be prepaid. The product should be properly
packaged and insured. After the product is repaired, TC Communications will ship the product back to the
shipper at TC's cost to U.S. domestic destinations. (Foreign customers are responsible for all shipping costs,
duties and taxes [both ways]. We will reject any packages with airway bill indicating TC communications
is responsible for Duties and Taxes. To avoid Customs Duties and Taxes, please include proper documents
indicating the product(s) are returned for repair/retest).
