TC Communications TC3005 User manual

TC3005
(LED/ELED/LASER)
User'sManual
Rev. 3.0
−1−
1.1.
1.1.
1. DescriptionDescription
DescriptionDescription
Description
The TC3005 gives users the ability to convert Multimode fiber optic signals to Single Mode format for data
transmission (and vice-versa). These conversions can benefit users by extending transmission distances
and/orenablingdissimilarfiberopticdevicestobeusedwithdifferentfibertypes. Theopticreceiverdetects
the incoming optical signal and regenerates it for transmission through the second optic transmitter. The
TC3005isavailableinmultipleconfigurationsdependingonyourcommunicationrequirements. Whenboth
sides have the same wavelength, the TC3005 works like an optical signal repeater.
2.2.
2.2.
2. Data RatesData Rates
Data RatesData Rates
Data Rates
165Mbps*
*Contact factory for higher data rates.
3.3.
3.3.
3. Optical SpecificationsOptical Specifications
Optical SpecificationsOptical Specifications
Optical Specifications
Transmitter:Transmitter:
Transmitter:Transmitter:
Transmitter: LED; typical Launch Power: -16dBm*(850nm/1310nm,Multimode@62.5/125µm)
ELED;typical Launch Power: -16dBm*(1310nm/1550nm,SingleMode@9/125µm)
LASER; typical Launch Power: -6dBm*(1310nm/1550nm,SingleMode@9/125µm)
Receiver:Receiver:
Receiver:Receiver:
Receiver: PIN DIODE; typical Sensitivity: -33dBm*(850nm/1310nm,Multimode@62.5/125µm)
-33dBm*(1310nm/1550nm,SingleMode@9/125µm)
-36dBm*(1310nm/1550nm,SingleMode@9/125µm)
LossBudget:LossBudget:
LossBudget:LossBudget:
LossBudget: LED;850nm/1310nm,MM@62.5/125µm 16dB
ELED;1310nm/1550nm,SM@9/125µm 16dB
LASER;1310nm/1550nm,SM@9/125µm 25dB
Distance:Distance:
Distance:Distance:
Distance: 850nm,Multimode@62.5/125µm up to 3km*
1310nm,Multimode@62.5/125µm up to 4km*
1310nm,SingleMode@9/125µm up to 40km*
1550nm,SingleMode@9/125µm up to 110km*
Wavelength:Wavelength:
Wavelength:Wavelength:
Wavelength: Note: Any two wavelength combinations are available on each unit.
850nmMultimode(LED)
1310nmMultimode(LED)
1310nmSingleMode(ELED/LASER)
1550nmSingleMode(ELED/LASER)
Connector:Connector:
Connector:Connector:
Connector: ST, FC, or SC
*Launch power, sensitivity and distance are listed for reference only. These numbers may vary. Contact
factory for higher loss budgets.
© COPYRIGHT 1992-2010. ALL RIGHTS RESERVED.
TC Communications, Inc. 17881 Cartwright Road - Irvine, CA 92614
Tel: [phone] Fax: [phone] Web Site: www.tccomm.com Email: [email protected]
4.4.
4.4.
4. Power RequirementsPower Requirements
Power RequirementsPower Requirements
Power Requirements
A. TheTC3005consumesverylow power. The connector is a terminalblock with polarityindicated onthe
rearpaneloftheunit(seeFigure 2). The input voltage is typically 12VDC and current is@600mA. The
unitcanbeorderedwithoptionalpoweroptions: 24 VDC@300mA, 48 VDC@150mA, or 115/230 VAC
with an external power adapter.
B. Should an external power adapter need to be replaced, use one that matches the above specifications.
You may order it from TC Communications.
C. There are two pairs of terminal block connectors on the rear panel (labeled "PWR A" and "PWR B").
Only one pair is required to power the unit. If both pairs are connected, the built-in power redundancy
featurewill beutilized. Whenthisfeature isutilized,both"A" and"B"sharetheload. Ifonepowersource
fails, the other will assume the full load.
165Mbps Fiber Optic Mode Converter/Repeater165Mbps Fiber Optic Mode Converter/Repeater
165Mbps Fiber Optic Mode Converter/Repeater165Mbps Fiber Optic Mode Converter/Repeater
165Mbps Fiber Optic Mode Converter/Repeater
TC3005(LED/ELED/LASER)TC3005(LED/ELED/LASER)
TC3005(LED/ELED/LASER)TC3005(LED/ELED/LASER)
TC3005(LED/ELED/LASER)
User's ManualUser's Manual
User's ManualUser's Manual
User's Manual

TC3005
(LED/ELED/LASER)
User'sManual
Rev. 3.0
−2−
5.5.
5.5.
5. LEDs, DIP Switches and ConnectorsLEDs, DIP Switches and Connectors
LEDs, DIP Switches and ConnectorsLEDs, DIP Switches and Connectors
LEDs, DIP Switches and Connectors
Figure 2. TC3005's Rear PanelFigure 2. TC3005's Rear Panel
Figure 2. TC3005's Rear PanelFigure 2. TC3005's Rear Panel
Figure 2. TC3005's Rear Panel
Figure 1. TC3005's Front PanelFigure 1. TC3005's Front Panel
Figure 1. TC3005's Front PanelFigure 1. TC3005's Front Panel
Figure 1. TC3005's Front Panel
LEDs FunctionsLEDs Functions
LEDs FunctionsLEDs Functions
LEDs Functions
ALARM StatusIndicator-
Alarm Buzzer & ALM LED Flashing - Indicates that the optical signal is not present or lost at the Multimode and/or
Dry contact Relay: Singlemodereceiver(s)andthealarmwillbetriggered.
ALM LED Off - Indicates the unit is under normal working condition (receiving good optical signals).
AlarmCondition:
When the Alarm is triggered, the alarm buzzer will sound & the dry contact relay will close. (see section 6 on next page).
Power Supply Status Indicators-
PWRA/B: When lit, these LEDs indicate which power source on the rear panel the unit is drawing from. If power
redundancyisutilized,both LEDswillbe lit.
Vcc: +5V Voltage indicator. The Vcc LED should light solidly whenever power is connected to the unit.
It indicates the correct operating voltage is being derived from the power source.
Multimode Optic Signal Status Indicators-
MMRX: Solidly lit, indicates a valid optical signal is received at the MM receiver & it is above sensitivity threshold.
Off, indicates the optical signal at the MM RX is not present, lost, bursty or questionable (not valid).
- Verify that the user’s Multimode device optical wavelength matches that of the TC3005 units.
- Verify the integrity of the Multimode fiber cables and connections.
Single Mode Optic Signal Status Indicators-
SMRx: Solidly lit, indicates optical signal at the SM optic receiver is received & it is above sensitivity threshold.
Off, indicates the single mode optical signal at the SM optic receiver is not present or it is lost.
Optical ConnectorsOptical Connectors
Optical ConnectorsOptical Connectors
Optical Connectors
MMTx: MultimodeTransmitter(Tx).-Connecttolocalequipment'sMMreceiver(Rx).
MMRx: MultimodeReceiver(Rx).-Connecttolocalequipment'sMMtransmitter(Tx).
SMTx: SinglemodeTransmitter(Tx).-Connecttoremoteunit'sSMreceiver(Rx).
SMRx: SinglemodeReceiver(Rx).-Connecttoremoteunit'sSMtransmitter(Tx).
DIP Switch FunctionsDIP Switch Functions
DIP Switch FunctionsDIP Switch Functions
DIP Switch Functions
SW1,2,3: Not used; reserved for future functions.
SW4: DISALM - Down (or Right) disables the audio buzzer and dry contact relay alarm switch.
Note:Keep the "DISALM" dip switch in the Off or "up position" under normal condition.
ALARM
PWR
APWR B
+ -
(12-14 VDC)
@600mA
+ -
1234
ON
Made in U.S.A.
Vcc
SM RX
B
A
MM RX
TCCOMM.COM
ALM
PWR
FIBEROPTIC
MODECONVERTER
Rx Tx Rx Tx
SMMM
Multimode Transmitter
& Receiver (Tx & Rx)
Not Used. Reserved
for future functions. Not Used. Reserved for future functions.
Single mode Transmitter
& Receiver (Tx & Rx)

TC3005
(LED/ELED/LASER)
User'sManual
Rev. 3.0
−3−
7.7.
7.7.
7. InstallationInstallation
InstallationInstallation
Installation
Figure 3. Installation Diagram for Dual TC3005 ApplicationFigure 3. Installation Diagram for Dual TC3005 Application
Figure 3. Installation Diagram for Dual TC3005 ApplicationFigure 3. Installation Diagram for Dual TC3005 Application
Figure 3. Installation Diagram for Dual TC3005 Application
Figure 4. Installation Diagram for Single TC3005 ApplicationFigure 4. Installation Diagram for Single TC3005 Application
Figure 4. Installation Diagram for Single TC3005 ApplicationFigure 4. Installation Diagram for Single TC3005 Application
Figure 4. Installation Diagram for Single TC3005 Application
6.6.
6.6.
6. Dry Contact Relay AlarmDry Contact Relay Alarm
Dry Contact Relay AlarmDry Contact Relay Alarm
Dry Contact Relay Alarm
A terminal block connector on the rear panel (labeled
"ALARM")providesforthedrycontactrelay alarm (see Figure
2). NormallyintheOPENposition, thelossofeither opticsignal
will trigger an alarm condition and force the switch to the
CLOSED position. This relay can be used in conjunction with
an external device to monitor the condition of the fiber optic
links. Note:If SW4(DISALM)onthefrontpanel is intheDown
position, the audio buzzer will not sound and the dry contact
relay will not activate.
SM Tx
SM Rx
Single Mode
fiber optic cable
TC3005
Fiber Optic Mode Converter
Multimode
850nm/1300nm
TRANSCEIVER
RxTx
MM Tx
MM Rx
Multimode
fiber optic
cable
MM Rx
MM Tx
TC3005
Fiber O
p
tic Mode Converter
Multimode
850nm/1300nm
TRANSCEIVER
Rx Tx
SM Rx
SM Tx
Multimode
fiber optic
cable
SM Tx
SM Rx
Single Mode
fiber optic
cable
TC3005
Fiber Optic Mode Converter
Multimode
850nm/1300nm
TRANSCEIVER
RxTx
MM Tx
MM Rx
Multimode
fiber optic
cable
Single Mode
1300nm/1550nm
TRANSCEIVER
Tx Rx
Dr
y
Contact Rela
y
Alarm Switch To remote alarm status indicator
Max switch voltage: 100VDC
Switch current:0.5Amp
Max carry current: 1.2Amp
Contact resistance: 0.2Ohm
Reply switch specifications

TC3005
(LED/ELED/LASER)
User'sManual
Rev. 3.0
−4−
8.8.
8.8.
8. TroubleshootingTroubleshooting
TroubleshootingTroubleshooting
Troubleshooting
Typically, most problems encountered with the TC3005 are related to optic receiver overdrive. The
maximumopticpowerthatcanbereceivedwithoutdistortion is referred to as the optic receiver's "saturation
level." When the incoming optic power is greater than the saturation level of the receiver, optic "overdrive"
can occur.
The TC3005's optic receivers have a typical saturation level of -14 dBm. If the user's equipment's launch
power is higher than -14dBm (i.e. -13dBm or greater) and the fiber run is very short and has low signal loss,
it is likely to overdrive the TC3005's Multimode receiver. The consequences of overdrive can be high error
rates or the device's failure to recognize the incoming optic signal at all.
TheTC3005has been adjusted at the factory so that the Single ModetransmitterwillnotoverdrivetheSingle
Mode receiver even when short cables are used to connect them; hence, the overdrive condition happens
most frequently at the Multimode receiver optic.
If you suspect the Multimode receiver has an optic overdrive condition, a simple test will help verify it. At
thereceivingopticinquestion,simplydisconnecttheopticconnectorandbackitout of the receptacle (about
1/8 of an inch), creating a gap between the fiber connector and the receiver. Verify that the equipment is
still in "sync" with the optic signal and that the overdrive condition has been corrected. To resolve the
overdrive condition permanently, insert a 5dB or 10dB in-line attenuator into the problem link. In-line
attenuators can be purchased from Metrotek* at [phone]. The part numbers are:
Description:Description:
Description:Description:
Description: ST@5dBST@5dB
ST@5dBST@5dB
ST@5dB ST@10dBST@10dB
ST@10dBST@10dB
ST@10dB FC@5dBFC@5dB
FC@5dBFC@5dB
FC@5dB FC@10dBFC@10dB
FC@10dBFC@10dB
FC@10dB
PartNumber:PartNumber:
PartNumber:PartNumber:
PartNumber: 68-JJ-7-051368-JJ-7-0513
68-JJ-7-051368-JJ-7-0513
68-JJ-7-0513 68-JJ-7-101368-JJ-7-1013
68-JJ-7-101368-JJ-7-1013
68-JJ-7-1013 68-FF-051368-FF-0513
68-FF-051368-FF-0513
68-FF-0513 68-FF-101368-FF-1013
68-FF-101368-FF-1013
68-FF-1013
Thefollowingdiagramillustrates a TC3005 Mode Converter usedto converta 1300nmSingle Mode optical
signalfrom an OC3(155 Mbps) ATMSWITCH into a 1300nmMultimode optic signalto be receivedbythe
HP7000.* Inthereversedirection,theHP7000'sMultimodeopticsignalisconvertedtoSingleModeformat
tobereceived by theOC3 ATMSWITCH. In-lineattenuators are used tocorrect opticoverdriveconditions
that exist on either side of the TC3005.
Figure 5. In-line Attenuator Placement DiagramFigure 5. In-line Attenuator Placement Diagram
Figure 5. In-line Attenuator Placement DiagramFigure 5. In-line Attenuator Placement Diagram
Figure 5. In-line Attenuator Placement Diagram
*HP (Hewlett Packard) and Metrotek are corporate names and are not affiliated with TC Communications, Inc.
Note: Launch power measurements are taken at 155Mbps and may vary due to the actual signal's duty cycle.
OC3
ATM
SWITCH
TxRx
Rx RxTx
Tx
ATTN
10 dB
launch power:
-10 dBm
MMSM
Receiving power:
-20 dBm
1300nm SM
HP7000
Tx
Rx
ATTN
15 dB
3005
launch power:
-7 dBm
receiving power:
-22 dBm
1300nm MM
1300nm MM

TC3005
(LED/ELED/LASER)
User'sManual
Rev. 3.0
−5−
10. Return Policy & Warranty10. Return Policy & Warranty
10. Return Policy & Warranty10. Return Policy & Warranty
10. Return Policy & Warranty
Return PolicyReturn Policy
Return PolicyReturn Policy
Return Policy
To return a product, you must first obtain a Return Material Authorization number from the Customer
Service Department. If the product’s warranty has expired, you will need to provide a purchase order to
authorize the repair. When returning a product for a suspected failure, please provide a description of the
problem and any results of diagnostic tests that have been conducted.
WarrantyWarranty
WarrantyWarranty
Warranty
Damages by lightning or power surges are not covered under this warranty.
All products manufactured by TC Communications, Inc. come with a five year (beginning 1-1-02)
warranty. TC Communications, Inc. warrants to the Buyer that all goods sold will perform in accordance
with the applicable data sheets, drawings or written specifications. It also warrants that, at the time of sale,
the goods will be free from defects in material or workmanship. This warranty shall apply for a period of
fiveyearsfromthe date of shipment, unless goodshave beensubject tomisuse, neglect, alteredor destroyed
serialnumberlabels,accidents(damages causedinwhole orinparttoaccident,lightning,power surge,floods,
fires, earthquakes, natural disasters, or Acts of God.), improper installation or maintenance, or alteration or
repair by anyone other than Seller or its authorized representative.
Buyershould notifyTCCommunications,Inc.promptly inwritingofanyclaim based uponwarranty,and
TC Communications, Inc., at its option, may first inspect such goods at the premises of the Buyer, or may
give written authorization to Buyer to return the goods to TC Communications, Inc., transportation charges
prepaid, for examination by TC Communications, Inc. Buyer shall bear the risk of loss until all goods
authorized to be returned are delivered to TC Communications, Inc. TC Communications, Inc. shall not be
liable for any inspection, packing or labor costs in connection with the return of goods.
In the event that TC Communications, Inc. breaches its obligation of warranty, the sole and exclusive
remedyoftheBuyerislimitedto replacement, repair or credit of thepurchase price, at TCCommunications,
Inc.’s option.
Toreturn aproduct,youmustfirstobtain aReturnMaterialAuthorization(RMA)number andRMAform
from the Customer Service Department. If the product’s warranty has expired, you will need to provide a
purchaseordertoauthorizetherepair. Whenreturning a product for a suspected failure,please fill out RMA
form provided with a description of the problem(s) and any results of diagnostic tests that have been
conducted. Theshipping expense to TC Communicationsshouldbeprepaid. Theproductshouldbeproperly
packaged and insured. After the product is repaired, TC Communications will ship the product back to the
shipperatTC'scostto U.S. domestic destinations. (Foreigncustomers are responsiblefor all shippingcosts,
duties and taxes [both ways]. We will reject any packages with airway bill indicating TC communications
is responsible for Duties and Taxes. To avoid Customs Duties and Taxes, please include proper documents
indicating the product(s) are returned for repair/retest).
9.9.
9.9.
9. Physical CharacteristicsPhysical Characteristics
Physical CharacteristicsPhysical Characteristics
Physical Characteristics
RackMountableCardRackMountableCard
RackMountableCardRackMountableCard
RackMountableCard Stand Alone UnitStand Alone Unit
Stand Alone UnitStand Alone Unit
Stand Alone Unit
Height:Height:
Height:Height:
Height: 7.0"(17.7cm) Height:Height:
Height:Height:
Height: 1.4"(3.5 cm)
Width:Width:
Width:Width:
Width: 1.2"(3.1 cm) Width:Width:
Width:Width:
Width: 7.1"(18cm)
Depth:Depth:
Depth:Depth:
Depth: 5.8"(14.8cm) Depth:Depth:
Depth:Depth:
Depth: 6.6"(16.6cm)
Weight:Weight:
Weight:Weight:
Weight: 8.5 oz. (188 gm) Weight:Weight:
Weight:Weight:
Weight: 1.5 lbs. (512 gm)
