TCi HarmonicGuard HGL Series User manual

HarmonicGuard®Series Drive-Applied
Harmonic Filter Installation, Operation,
and Maintenance Manual
TCI, LLC
W132 N10611 Grant Drive
Germantown, Wisconsin 53022
Phone: [phone]
Fax: [phone]
Helpline: 800-824-8282
Web Site: www.transcoil.com
© 2019 TCI, LLC All rights reserved
Including information for:
Product No: 30799
Effective: 09/25/19 Version: E

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any
form or by any means, mechanical, electronic, photocopying, recording, or otherwise, without
the prior written permission of TCI, LLC. The information in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual. TCI, LLC
assumes no responsibility for errors or omissions. Neither is any liability assumed for damages
resulting from the use of the information contained in this publication.

Performance Guarantee
Select and install the appropriate HarmonicGuard® Low Capacitance Harmonic Filter in a
variable torque, variable frequency AC drive application, within our published technical
specifications and we guarantee that the input current distortion will be less than or equal to
5% THID for standard HGL Series filters at full load. If a properly sized and installed filter fails
to meet its specified THID level, TCI will provide material for necessary modifications or
replacement filter at no charge.
HG filters can also provide similar performance in other drive applications such as constant
torque, DC drives and other phase-controlled rectifiers, but actual THID levels can vary by
load and/or speed and therefore cannot be guaranteed.
Consult factory for assistance when applying HGL filters on these types of equipment.
MINIMUM SYSTEM REQUIREMENTS:
The guaranteed performance levels of this filter will be achieved when the following
system conditions are met:
Frequency: 60Hz ± 0.75Hz
System Voltage: Nominal System Voltage (line to line) ±10%
Balanced Line Voltage: Within 0.5%
Background Voltage Distortion: < 0.5% THVD
The input VFD current waveform shall be consistent with that of a VFD with 5% AC
line reactance at full load and a 5% source impedance.
NOTE: The presence of background voltage distortion will cause motors and other linear
loads to draw harmonic currents.
Additional harmonic currents may flow into the HGL filter if there is harmonic voltage
distortion already on the system.

Revision
Description
Date
A
Release
10/19/2017
B Added Additional Options
Updated Part Number
11/22/2017
C
Updates to Watts loss table
12/12/2018
D Addition of PQconnect 08/21/2019
E
Addition of PQvision App
09/25/2019

Table of Contents
1.0 Safety.................................................................................................................................................1
Safety Instructions Overview ....................................................................................................................1
Warnings and Cautions ............................................................................................................................1
General Safety Instructions ......................................................................................................................2
2.0 General Information .........................................................................................................................3
Intended Audience....................................................................................................................................3
Receiving Inspection.................................................................................................................................3
Storage Instructions..................................................................................................................................3
TCI Limited Warranty Policy .....................................................................................................................3
3.0 Pre-Installation Planning .................................................................................................................5
Verify the Application ................................................................................................................................5
HGL Drive-Applied Filter...........................................................................................................................5
Nameplate Data........................................................................................................................................5
Part Numbering System............................................................................................................................6
HGL Filter Overview .................................................................................................................................7
4.0 Installation Guidelines.....................................................................................................................9
Installation Checklist .................................................................................................................................9
Select a Suitable Location ........................................................................................................................9
Mounting ...................................................................................................................................................9
Power Wiring ......................................................................................................................................... 10
HGL Filter Operation.............................................................................................................................. 10
Caution................................................................................................................................................... 10
Fuse Specifications................................................................................................................................ 11
SCCR Fusing Requirements ................................................................................................................. 11
5.0 PQconnect Connectivity............................................................................................................... 15
HGL Drive-Applied Filter with PQconnect ............................................................................................. 15
PQvision PC application Screen Elements............................................................................................ 15
Example Application Using “Simply Modbus Master 8.1.0”................................................................... 18
USPTL4 RS485 Converter Dip Switch settings..................................................................................... 19
Example Setup Instructions to Read Data from the PQconnect Unit: ................................................... 19
Example Setup Instructions to Write Data to the PQconnect Unit: ....................................................... 20
PQconnect Quick Start Unit Software Setup ......................................................................................... 21
PQconnect Bluetooth®App Setup ......................................................................................................... 21
PCB Connections .................................................................................................................................. 23
Modbus RTU.......................................................................................................................................... 25
Wiring and Configuration ....................................................................................................................... 25
PQvision Display Connections .............................................................................................................. 26
Register Map ......................................................................................................................................... 28
6.0 PQconnect Troubleshooting........................................................................................................ 38
HarmonicGuard®Low Capacitance Filter Status Warning .................................................................... 38
Receiving Inspection.............................................................................................................................. 38
Connectivity Board Problem .................................................................................................................. 38
Communication Problems...................................................................................................................... 40
Debug Status Conditions ....................................................................................................................... 41
Contactor Problem................................................................................................................................. 42
7.0 Maintenance and Service ............................................................................................................. 45
HGL Filter Reliability and Service Life ................................................................................................... 45
Troubleshooting ..................................................................................................................................... 45
Warning.................................................................................................................................................. 45
Replacement Parts ................................................................................................................................ 45
Factory Contacts and Tech Support...................................................................................................... 45

HGL Manual 1.0 Safety
1
1.0 Safety
Safety Instructions Overview
This section provides the safety instructions which must be followed when installing, operating, and
servicing the HarmonicGuard® Low Capacitance (HGL) filter. If neglected, physical injury or death
may follow, or damage may occur to the filter or equipment connected to the HGL filter. The material
in this chapter must be read and understood before attempting any work on, or with, the product.
The HGL filter is intended to be connected to the input terminals of one or more VFDs. Three-phase
power is connected to the input terminals of the HGL and power is supplied to the VFD or VFDs
through the HGL. The instructions, and particularly the safety instructions, for the VFDs, motors,
and any other related equipment must be read, understood, and followed when working on any of
the equipment.
Warnings and Cautions
This manual provides two types of safety instructions. Warnings are used to call attention to
instructions that describe steps that must be taken to avoid conditions that can lead to a serious
fault condition, physical injury, or death.
Cautions are used to call attention to instructions that describe steps that must be taken to avoid
conditions that can lead to a malfunction and possible equipment damage.
Warnings
Readers are informed of situations that can result in serious physical injury and/or serious
damage to equipment with warning statements highlighted by the following symbols:
Warning Dangerous Voltage Warning: warns of situations where
high voltage can cause physical injury and/or damage
equipment. The text next to this symbol describes ways
to avoid the danger.
Warning
General Warning: warns of situations that can cause
physical injury and/or damage equipment by means other
than electrical. The text next to
this symbol describes ways
to avoid the danger.
Warning
Electrostatic Discharge Warning: warns of situations in
which an electrostatic discharge can damage equipment.
The text next to this symbol describes ways to avoid the
danger.
Cautions
Readers are informed of situations that can lead to a malfunction and possible equipment damage
with caution statements:
Caution General Caution: identifies situations that can lead to a
malfunction and possible equipment damage. The text
describes ways to avoid the situation.

HGL Manual 1.0 Safety
2
General Safety Instructions
These safety instructions are intended for all work on the HGL. Additional safety instructions are
provided at appropriate points on other sections of this manual.
Warning
Be sure to read, understand, and follow all safety
instructions.
Warning Only qualified electricians should carry out all
electrical installation and maintenance work on the
HGL filter.
Warning All wiring must be in accordance with the National
Electrical Code (NEC) and/or any other codes that apply
to the installation site.
Warning Disconnect all power before working on the
equipment. Do not attempt any work on a powered
HGL filter.
Warning The HGL filter, drive, motor, and other connected
equipment must be properly grounded.
Warning
After switching off the power, always allow 5 minutes for
the capacitors in the HGL
filter and in the drive to
discharge before working on the HGL, the drive, the motor,
or the connecting wiring. It is a good idea to check with a
voltmeter to make sure that all sources of power have
been disconnected and that all capacitors have
discharged before beginning work.

HGL Manual 2.0 General Information
3
2.0 General Information
Thank you for selecting the HarmonicGuard® Low Capacitance (HGL) filter. TCI has produced
this filter for use in many variable frequency drive (VFD) applications that require input power line
harmonic current reduction. This manual describes how to install, operate and maintain the HGL
filter.
Intended Audience
This manual is intended for use by all personnel responsible for the installation, operation and
maintenance of the HGL filters. Such personnel are expected to have knowledge of electrical wiring
practices, electronic components and electrical schematic symbols.
Receiving Inspection
The HGL filter has been thoroughly inspected and functionally tested at the factory and carefully
packaged for shipment. When you receive the unit, you should immediately inspect the shipping
container and report any damage to the carrier that delivered the unit. Verify that the part number
of the unit you received is the same as the part number listed on your purchase order.
Storage Instructions
If the HGL filter is to be stored before use, be sure that it is in a location that conforms to published
storage humidity and temperature specifications stated in the HarmonicGuard® Low Capacitance
Filter Technical Specifications. Store the filter in its original packaging.
TCI Limited Warranty Policy
TCI, LLC (“TCI”) warrants to the original purchaser only that its products will be free from defects
in materials and workmanship under normal use and service for a period originating on the date
of shipment from TCI and expiring at the end of the period described below:
Product Family
Warranty Period
KLR, KDR
For the life of the drive with which they are
installed.
HGA, KLC,
KLCUL, KMG,
MSD, V1K
One (1) year of useful service,
not to exceed 18 months from the date of
shipment.
HGP, HGL, KRF
Three (3) years from the date of shipment.
KCAP, KTR
Five (5) years from the date of shipment.
All Other Products
One (1) year of useful service,
not to exceed 18 months from the date of
shipment.
The foregoing limited warranty is TCI’s sole warranty with respect to its products and TCI makes
no other warranty, representation, or promise as to the quality or performance of TCI’s products.
THIS EXPRESS LIMITED WARRANTY IS GIVEN IN LIEU OF AND EXCLUDES ANY AND ALL
EXPRESS OR IMPLIED WARRANTIES INCLUDING, WITHOUT LIMITATION, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
This warranty shall not apply if the product was:
a) Altered or repaired by anyone other than TCI;
b) Applied or used for situations other than those originally specified; or
c) Subjected to negligence, accident, or damage by circumstances beyond TCI’s control,
including but not limited to, improper storage, installation, operation, or maintenance.
If, within the warranty period, any product shall be found in TCI’s reasonable judgment to be

HGL Manual 2.0 General Information
4
defective, TCI’s liability and the Buyer’s exclusive remedy under this warranty is expressly limited,
at TCI’s option, to (i) repair or replacement of that product, or (ii) return of the product and refund
of the purchase price. Such remedy shall be Buyer’s sole and exclusive remedy. TCI SHALL
NOT, IN ANY EVENT, BE LIABLE FOR INCIDENTAL DAMAGES OR FOR CONSEQUENTIAL
DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF INCOME, LOSS OF TIME, LOST
SALES, INJURY TO PERSONAL PROPERTY, LIABILITY BUYER INCURS WITH RESPECT TO
ANY OTHER PERSON, LOSS OF USE OF THE PRODUCT OR FOR ANY OTHER TYPE OR
FORM OF CONSEQUENTIAL DAMAGE OR ECONOMIC LOSS.
The foregoing warranties do not cover reimbursement for removal, transportation, reinstallation,
or any other expenses that may be incurred in connection with the repair or replacement of the
TCI product.
The employees and sales agents of TCI are not authorized to make additional warranties about
TCI’s products. TCI’s employees and sales agent’s oral statements do not constitute warranties;
these shall not be relied upon by the Buyer and are not part of any contract for sale. All warranties
of TCI embodied in this writing and no other warranties are given beyond those set forth herein.
TCI will not accept the return of any product without its prior written approval. Please consult TCI
Customer Service for instructions on the Return Authorization Procedure.

HGL Manual 3.0 Pre-Installation Planning
5
3.0 Pre-Installation Planning
Verify the Application
Make sure that the HGL filter is correct for the application. The voltage rating of the filter must
match the input voltage rating of the connected drive. The horsepower and current ratings of the
filter must be appropriate for the connected load.
HGL Drive-Applied Filter
The HGL is a drive-applied harmonic filter designed and developed by TCI to reduce the harmonic
currents drawn from the power source by VFDs. The published HGL voltage, Power (Hp or kW)
and current ratings apply to matching power (Hp or kW) rated standard VFDs with six-pulse diode
bridge rectifiers. The HGL may also be sized to filter other loads such as SCR six-step drives,
SCR Direct Current (DC) motor drives, thyristor furnaces, battery chargers, electroplating supplies
or other types of non-linear loads. In many cases, the filter power rating (Hp or kW) will differ from
load power rating (Hp or kW). Please contact TCI Technical Support for additional information
and support on sizing HGL harmonic filters for your non-six-pulse diode front end VFD
applications.
The HGL is a passive filter connected in series with the input terminals of a VFD or several VFDs
that operate as a group. It is designed to provide a low impedance path for the major harmonic
currents demanded by the drive. The filter is a stand-alone device that can be furnished in its own
enclosure and mounted adjacent to the drive. It is also available on an open panel for mounting
within an enclosure with the drive or other equipment.
The HGL filters consist minimally of the following features and components:
•A KDR tuned series reactor to prevent system interaction and improve filter
performance
•An L-C-L filter circuit with:
•A TCI 3-phase tuning reactor specifically designed for the HGL filter
•High-endurance, harmonic-rated capacitors
•Larger filters may have multiple tuned circuits. Consult fuse tables to determine if the
filter in question has “parallel” branches.
•Bleeder resistors to ensure safe capacitor discharge upon filter shutdown
•Cooling fans (on select models) to ensure adequate cooling and safe
operating temperatures
•Compression terminals for ease and integrity of all power and control wiring
•Fuses sized to protect the capacitor wiring
Nameplate Data
The following information is marked on the nameplate:
•Part number: encoding is explained on the following page
•FLA: the rated continuous operating current (RMS amps)
•System Voltage: the rated 3-phase line voltage (RMS volts)
•Hz: the rated frequency
•Phase: 3 – The HGL filter is designed for use only with 3-phase power.
•Drawing #: outline and mounting dimension drawing number
•Schematic #: schematic diagram drawing number
•Manufacturing #: for TCI internal use
•Enclosure Type: UL designation or "Open" panel construction

HGL Manual 3.0 Pre-Installation Planning
6
Part Numbering System
Figure 1 identifies the significance of each character in the HGL part number. The example part
number, HGL0150AW1S0000 designates an HGL filter that is rated 150 HP, 480 volts, 60 Hz. It
includes a line reactor, tuning reactor, and capacitors in a UL Type 1 enclosure. It is designed for
use with a 150 HP drive.
Figure 1: HGL Part Number Encoding

HGL Manual 3.0 Pre-Installation Planning
7
Table 1: HGL Technical Specifications
Electrical Characteristics
Voltage ratings
60 Hz, 3 Phase: 480 V/600 VAC
kVar rating
0.15 kVAR/HP
Load types
3-phase diode bridge rectifier loads such as PWM AC drives
Load power range 20-900HP for 480 V/600 V units. Power range varies
depending on system voltage
Current ratings The included series reactors can tolerate 200% of rated
current for no more than 3 minutes.
SCCR (short circuit current
rating)
Standard rating is 100kA.
Environmental Conditions
Maximum elevation
6,500 feet (2,000 meters) as standard.
Maximum ambient operating
temperature
50°C (122°F) – Open Panel; 40°C (104°F) –
Enclosed Panel.
Product must be equipped with special cooling
provisions for operation above this temperature.
Maximum ambient storage
temperature
60°C (140°F)
Maximum humidity,
operating or storage
95%, non-condensing.
Agency approvals or
certifications UL and cUL Listed to UL508A
Insertion Impedance
10% at full load current
Fusing and protection All units have internal fuse protection for the capacitor
branch circuit
Performance Guarantee
To meet the requirements for the Performance Guarantee the minimum system
conditions must conform to the following:
•At least a 5% Source inductance
•The input VFD current waveform shall be consistent with that of a VFD with
5% AC line reactance at full load
HGL Filter Overview
The HarmonicGuard®Low Capacitance (HGL) Filter provides a low impedance path for the major
harmonic currents demanded by Variable Frequency Drives (VFDs). This greatly reduces the
amount of harmonic currents flowing through the electrical power distribution system, bringing
those harmonic currents in line with the IEEE-519 standard for harmonic distortion mandated by
an increasing number of utilities.
The HGL Filter includes branch fuses on the harmonic trap circuit capacitors. These fuses are
included in the design to prevent damage to the capacitors in the event of excessive harmonic
trap current if the filter is misapplied.

HGL Manual 3.0 Pre-Installation Planning
8
No Contactor Option (S)
The No Contactor (Standard) Option includes high quality harmonic-grade capacitors and line
reactors. This filter will meet most application requirements found today. This cost-effective
product is available as an open panel version, in a UL Type 1, UL Type 12, or in an UL Type 3R
enclosure. The open panel is perfect for inclusion in a MCC section or easy installation into
industry standard enclosures. The UL Type 1 enclosed units maintain the same vertical profile as
the open panel design. This design is perfect for applications where floor space is at a premium.
The UL Type 3R enclosure protects the filter from harsh conditions.
Contactor Option (C)
The contactor option shall allow the user to open and close a contact that will remove the
capacitors from the circuit. Operation shall be controlled through a contact input on the customer’s
equipment.
The Contactor Option includes a contactor, control power transformer and connection terminals
in the filter circuit which allows the VFD user to control the insertion of this circuit using a relay
contact in the VFD. It is recommended that the VFD contact be programmed to open the contactor
below 33% motor power. For variable torque (fan) loads this will be approximately below 70%
speed, so the at-speed contact may be used. This reduces the possibility of leading power factor
interacting with other devices on the power system. Contactor logic should also maintain the
contactor closed in cases where the VFD is bypassed and the filter is not bypassed.
Vibration Pad Option (V)
The Vibration Pad Option is intended for use in applications which require environmental noise
protection. The resilient mounting material is placed between the reactor and the interior of the
enclosure and dampens noise produced by the reactor.
The Vibration Pad option is available for all enclosure types.
Floor Stand Option (F)
The Floor Stand Option is intended for use in applications which require the HGL enclosure to be
elevated from the floor. The Floor Stand option consists of 12” steel feet available for Type 3R
enclosures 125hp and below.
Oilfield Duty Option (P)
The Oilfield Duty Option features components designed specifically for oil and gas field applications
to handle the additional electrical stress. Designed for cyclical loads these units will be available in
Type 3R enclosures and will be for use with HP ranges from 40 to 200HP.
Heater Option (H)
The Heater Option is intended for use in applications which require the environmental protection of
a NEMA 3R enclosure. The heater is mounted to the interior of the enclosure and protects sensitive
electronic equipment from the harmful effects of corrosion and condensation. When using a Type
12 or Type 3R Enclosure and in a high humidity environment, set thermostat to 37°C (100°F) or
max temperature below 37°C (100°F).
The Heater option is available for all 3R enclosures.

HGL Manual 4.0 Installation Guidelines
9
4.0 Installation Guidelines
Installation Checklist
The following are the key points to be followed for a successful installation. These points
are explained in detail in the following sections of this manual.
Make sure that the installation location will not be exposed to direct sunlight,
corrosive or combustible airborne contaminants, excessive dirt or liquids.
Select a mounting area that will allow adequate cooling air and maintenance access.
Make sure that all wiring conforms to the requirements of the National Electrical Code
(NEC) and/or other applicable electrical codes.
Connect the HGL equipment-grounding lug to the system ground of the premises
wiring system.
Use a properly sized grounding conductor.
Connect three-phase power to the input terminals of the HGL, L1, L2 & L3.
Connect the output power terminals, of the HGL, T1, T2 & T3, to the input power terminals
of the VFD.
Select a Suitable Location
Environment
Locating the HGL in a suitable environment will help ensure proper performance and a normal
operating life. Refer to the environmental specifications listed in Table 2 and/or noted on the
drawings furnished with the unit.
Warning Unless specifically labeled as approved for such use, this equipment is not
suitable for use in an explosive atmosphere or in a "Hazardous (Classified)
Location" as defined in article 500 of the National Electrical Code (NEC).
The unit must be installed in an area where it will not be exposed to:
•Direct sunlight
•Rain or dripping liquids (unless filter is in a Type 3R enclosure)
•Corrosive liquids or gasses
•Explosive or combustible gases or dust
•Excessive airborne dirt and dust
•Excessive vibration
Working Space
Provide enough access and working space around the unit to permit ready and safe installation,
operation and maintenance. Make sure that the installation conforms to all working space and
clearance requirements of the National Electrical Code (NEC) and/or any other applicable codes.
Provide enough unobstructed space to allow cooling air to flow through the unit. Keep the widest
or deepest portion of the unit enclosure having ventilation openings a minimum of six inches from
adjacent walls or other equipment. The unit enclosure sides that do not have ventilation openings
should be kept a minimum of three inches from adjacent walls or other equipment.
Mounting
The HGL must be mounted vertically on a smooth, solid surface, free from heat, dampness, and
condensation.
If you are mounting an open panel unit in your own enclosure, you must provide an enclosure
that is adequately sized and ventilated sufficiently to prevent overheating. The rating and
dimension tables for open panel units list the watts of heat loss dissipated by the HGL filter. The
maximum temperature of the air around the HGL filter capacitors, line reactor, and tuning reactor
should not exceed 50°C (122°F).

HGL Manual 4.0 Installation Guidelines
10
Power Wiring
When selecting a mounting location for the HGL filter, plan for the routing of the power wiring. Route
the conduit and wiring from the power source to the filter and then to the VFD. The HGL is provided
with internal fuses.
Cable Entry Locations
The enclosed HGL filters are not provided with enclosure wiring knockouts. A location can be
selected at the time of installation. Typical or recommended cable entry locations are shown in
the drawings section of this manual.
Field Wiring Connection Terminals
Compression type terminals are provided for all field wiring connections. The wire size capacity
range and tightening torque for all field wiring connections are listed in the drawings and other
information shipped with the unit.
Grounding
The HGL panel equipment-grounding lug must be connected to the ground of the wiring system.
The equipment-grounding connection must conform to the requirements of the National Electrical
Code (NEC) and/or any other codes that apply to the installation site. The ground connection
must be made using a wire conductor. Metallic conduit is not a suitable grounding conductor. The
integrity of all ground connections should be periodically checked.
Caution Use copper wire that is appropriate for the voltage and current rating of the
equipment. The wire selection must conform to the requirements of the
National Electrical Code (NEC) and/or other applicable electrical codes.
For units rated less than 100 amps, use wire with an insulation temperature
rating of 60°C or higher.
For units rated 100 amps or more, use wire with an insulation temperature
rating of 75°C or higher.
Connect three-phase power of the appropriate voltage and current capacity to the circuit protective
device to the HGL input power terminals.
Note: In large units, the input power conductors are connected directly to the input terminals on
the line reactors.
Connect the output terminals of the HGL to the input power terminals of the VFD.
Note: In large units, the output power conductors are connected directly to the output terminals on
the line reactors. Refer to the VFD installation instructions for additional information.
HGL Filter Operation
Caution
Thoroughly check the installation before applying power and operating the
equipment for the first time.
Before Applying Power for the First Time
Inspect the installation to make sure that all equipment has been completely and correctly installed
in accordance with the Installation Guidelines section of this manual.
•Check to see that the cooling fan(s) are operating in units so equipped.
•Check to make sure power connections are torqued to recommended torque value.

HGL Manual 4.0 Installation Guidelines
11
Since the HGL is a passive filter, it is always operating whenever the drive is operating.
Fuse Specifications
Always refer to the drawings and other information shipped with your unit. Consult applicable wiring
codes, UL and NEC, for current limiting and disconnect requirements.
SCCR Fusing Requirements
See the table below for line fusing requirements that must be supplied to comply with the
100kA SCCR.
Table 2: Customer Installed Line Fuse Requirements to comply with the 100kA SCCR
Provisional 480 V Fuse Table
The fuse tables provided below show the fuse ratings of the included branch circuit fuse internal
to the HGL unit as a fuse replacement reference.
The fuse tables also show a typical line fuse or circuit breaker current rating for overcurrent
protection, given the unit’s nameplate power rating, if necessary, based on the installation. The
line current fuses listed below are typical values given the unit power rating, not required values.
Line fusing ratings are determined by the installer, based on input conductor sizing and
protection required for downstream equipment. Any drawings or documentation included with
the unit literature kit take precedence over the fuse tables below.
Note that to achieve a 100kA SCCR, the customer provided line fuse must be installed as per
the requirements in Table 2 and sized following NEC (National Electrical Code) guidelines for
the source conductors selected by the installer. The branch fuses are required to be installed at
the shown ratings.
Warning
Only qualified electricians should carry out all electrical installation and maintenance work on the
HGL filter. Disconnect all sources of power to the drive and HGL before working on the equipment.
Do not attempt any work on a powered HGL filter.
The harmonic filter contains high voltages and capacitors. Wait at l
east five minutes after
disconnecting power from the filter before you attempt to service the harmonic filter. Check for
zero voltage between all terminals on the capacitors. Also, check for zero voltage between all
phases of the line side of the fuses, Fu1(a)–Fu2(a)–Fu3(a), and all input terminals L1, L2 and L3
of the line reactor (KDR). All setup, maintenance, and troubleshooting must be done by a qualified
electrician. Failure to follow standard safety procedures may result in death or serious injury.
Voltage Size Customer Installed Line Fuse Requirements
to Comply with the 100 kA SCCR
600
≤ 40
Use appropriately rated Class J, T, or L fuse less than or equal to 60 A
600
> 40
No requirement for SCCR
480
≤30
Use appropriately rated Class J, T, or L fuse less than or equal to 60 A
480
> 30
No requirement for SCCR

HGL Manual 4.0 Installation Guidelines
12
Table 3: Fuse Table for HGL 480 Volt, 60Hz Models
HGL
Rating
(HP)
Branch Circuit Fuse Current Rating
(Included Internal to HGL Unit)
Typical Line Current Fuse
or Circuit Breaker Rating
(Customer Supplied)
(J or T)
20
20
60
25
20
60
30
20
60
40
20
60
50
25
80
60
30
90
75
30
125
100
45
150
125
60
200
150
70
225
200
90
300
250
125
350
300
150
450
350
175
500
400
175
600
450
200
600
500
225
750
600
250
800
700
300
1000
800
350
1200
900
400
1300
Table 4: Fuse Table for HGL 600 Volt, 60Hz Models
HGL
Rating
(HP)
Branch Circuit Fuse Current Rating
(Included Internal to HGL Unit)
Typical Line Current Fuse or
Circuit Breaker Rating
(Customer Supplied)
(J or T)
20
20
30
25
20
60
30
20
60
40
20
60
50
20
70
60
30
80
75
40
100
100
40
125
125
50
175
150
60
200
200
70
250
250
90
300
300
110
350
350
125
400
400
150
450
450
175
500
500
175
550
600
200
650
700
250
750
800
300
900
900
300
1000

HGL Manual 4.0 Installation Guidelines
13
Table 5: 480 V HGL Watts loss
HP
Open
Type 1
Type 3R
20
205
208
208
25
341
346
346
30
239
242
242
40
447
54
454
50
518
525
525
60
608
617
617
75
560
569
569
100
760
771
771
125
871
884
884
150
1046
1062
1062
200
907
921
921
250
1217
1235
1235
300
1454
1476
1476
350
1411
1432
1432
400
1548
1571
1571
450
1842
1869
1869
500
2053
2083
2083
600
1976
2005
2005
700
2225
2258
2258
800
2419
2455
2455
900
2577
2616
2616

HGL Manual 4.0 Installation Guidelines
14
Table 6: 600 V HGL Watts loss
HP
Open
Type 1
Type 3R
20
338
343
343
25
304
309
309
30
293
297
297
40
341
346
346
50
511
519
519
60
600
609
609
75
734
745
745
100
736
747
747
125
920
934
934
150
1182
1200
1200
200
976
991
991
250
1306
1325
1325
300
1452
1474
1474
350
1766
1792
1792
400
1566
1589
1589
450
2079
2110
2110
500
1984
2014
2014
600
2034
2064
2064
700
2341
2376
2376
800
2726
2766
2766
900
3080
3126
3126
