TCL DFL Series User manual

1
Hi! Let’s Get Started.
DFL -Series Dehumidifier
English / Spanish / French

2
Table of Contents
English
Register and Protect Your Purchase ................................................................................................. 3
Important Safety Instructions.............................................................................................................. 4
What’s in the Box...................................................................................................................................... 7
Let’s Get Started!...................................................................................................................................... 8
How to Control Your Dehumidifier..................................................................................................... 9
Troubleshooting ........................................................................................................................................ 12
WiFi App Installation (WiFi Modules Only).................................................................................... 13
Warranty Information.............................................................................................................................. 16
Spanish
Registre y proteja su compra............................................................................................................... 16
Instrucciones Importantes De Seguridad........................................................................................ 17
Contenidos de la Caja ............................................................................................................................. 22
¡Comencemos!............................................................................................................................................ 23
Cómo Manejar su deshumidificador.................................................................................................. 24
Solución de Problemas........................................................................................................................... 27
Instrucciones de la aplicación WiFi (Solo modelos con WiFi)................................................ 28
Información de garantía ........................................................................................................................ 30
French
Enregistrez et prot gez votre achat.................................................................................................. 33
Consignes De Sécurité Importantes.................................................................................................. 34
Contenu de la boîte.................................................................................................................................. 37
C’est parti!.................................................................................................................................................... 38
Comment régler votre déshumidificateur....................................................................................... 39
Conseils de dépannage .......................................................................................................................... 42
Installation de l’application WiFi (Modèles WiFi seulement) .................................................. 43
Informations de garantie........................................................................................................................ 46

3
Product Replacement
Free 1-time replacement if product cannot be fixed.
TCL Parts & Service
Genuine TCL parts & factory certified service.
No Deductible
$0 out of pocket expense.
Priority Service
Free shipping and rapid turn-around time.
Extended Manufacturer Coverage
Extended parts & labor coverage for manufacturer defects.
PROTECT PLUS
Thank you for choosing TCL. We want your ownership experience to bring you as much joy as
the product you purchased does, so we’re oering you a special price on TCL Protection Plans
when you purchase during registration. Add a TCL Protection Plan within your first 30 days of
ownership to receive the best value and we’ll make sure nothing gets in the way of you enjoying
your new product.
Add a TCL Protection Plan when you register your
product and be covered from life’s mishaps
Benefits & Description
Up To 4 Years
3-5 Days3-5 Days
Up To 4 Years
Register easily with your smartphone
Scan or text a photo of
the camera icon to 71403
Or register online at register.tcl.com
Need help? Visit photoregister.com/help or text HELP to 71403
Register and protect your purchase
Accidental Damage Protection
Coverage for drops, breaks and spills starts after 30 days.
ENGLISH
*Extended service plans (i.e., “Protect” and “Plus” plans) are only oered in the United States (US). All TCL
products continue to oer a limited consumer warranty in both the US and Canada. Please refer to the warranty
section in this guide for additional details on warranty information.
TCL-DHM

IMPORTANT SAFETY INSTRUCTIONS
Before installing and using your dehumidifier, please read this owner’s manual carefully.
Store this manual in a safe place for future reference. Your safety and the safety of others is very important to us.
Please pay attention to all safety messages outlined in this owner’s manual.
WARNING: To reduce the risk of fire, electrical shock or injury when using your dehumidifier, follow the following basic precautions:
ELECTRICAL REQUIREMENTS
The electrical ratings for your dehumidifier are listed on the model and serial number label located on the on the back side
(when facing the front).
REGISTER YOUR APPLIANCE
You can register your appliance online by going to register.tcl.com
Be sure to retain your original sales receipt. A valid proof of purchase is required for all warranty claims.
Document your model and serial numbers here:
Model #___________________________________ Serial #___________________________________
You can locate your 20 digit serial number underneath the bar code (on the back side)
WARNING
Specific electrical requirements are shown in the diagram
below. Follow the requirements below for the type of plug on
the power supply cord.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or
electrical shock.
Wiring Requirements Power Supply Cord
60Hz, 115V AC outlet protected
by a 15 amp time delay fuse
or circuit breaker.
RECOMMENDED GROUND METHOD
For your personal safety, this air conditioner must be grounded. This dehumidifer is equipped with a 3 prong power supply cord with
a grounded plug. To minimize the possibility of electrical shock, the cord must be plugged into a 3 prong outlet and grounded in
accordance with all local codes and ordinances. If a 3 prong outlet is not available, it is the customer’s responsibility to have a properly
grounded 3 prong outlet installed by a qualified electrician.
FCC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help. The distance between user and device should be no less than 20cm.
PREFERRED
GROUNDING METHO D
Ensure prope r
ground exist s
before use.
DO NOT RETURN TO STORE
TCL SUPPORT:
support.tcl.com
1-800-825-6747
contact us first
with any questions
WE ARE
READY TO
HELP
TAKE CARE WHEN REMOVING
THE DEHUMIDIFIER UNIT

5
INSTALLATION MANUAL---Important considerations
When compared with other refrigerants, R32 is more environmentally friendly. Please use this product
as instructed. This refrigerant is flammable and may combust under certain conditions, however when
this product is used as directed these risks are significantly reduced. Always consult with a trained
professional when maintaining or repairing an air conditioner.
Important Considerations
• The air conditioner you buy must be installed by professional personnel and
the “Installation manual” is used only for the professional installation personnel!
• The installation specifications should be subject to our after-sale service regulations.
• When filling the flammable refrigerant, please use caution to avoid serious injury.
• A leak test must be done after the installation is completed.
• It is a must to perform the safety inspection before maintaining or repairing an air conditioner
using flammable refrigerant in order to ensure that the fire risk is reduced to a minimum.
• Requirements for the total weight of filled refrigerant and the area of a room to be equipped
with an air conditioner (are shown as in the following Tables GG.1 and GG.2)
The maximum charge and the required minimum floor area
m1 = (4 m3) x LFL , m2 = (26 m3)) x LFL, m3 = (130 m3 )x LFL
Where LFL is the lower flammable limit in kg/ m3,R290 LFL is 0.038 kg/ m3,R32 LFL is 0.038 kg/ m3.
For the appliances with a charge amount m1 < M = m2:
The maximum charge in a room shall be in accordance with the following:mmax= 2.5 x (LFL)(5/4) x h0 x (A)1/2
The required minimum floor area Amin to install an appliance with refrigerant charge M (kg) shall be in accordance with
following: Amin = (M/ (2.5 x (LFL)(5/4) x h0)) 2
Where:
mmax is the allowable maximum charge in a room, in kg;
M is the refrigerant charge amount in appliance, in kg;
Amin is the required minimum room area, in m2;
A is the room area, in m2;
LFL is the lower flammable limit, in kg/m3;
h0 is the installation height of the appliance,in meters for calculating mmax or Amin, 1.8 m for wall mounted;
Warning
• Please read the manual before installing, using, or conducting maintenance.
• Do not use means to accelerate the defrosting process or to clean, other than those recommended by
the manufacturer.
• Be aware that refrigerants may not contain an odor.
• Do not pierce or burn the appliance.
• The appliance shall be stored in a room without continuously operating sources (for example: open flames, an
operating ignition gas appliance or an operating electric heater).
• Please contact the nearest after-sale service center when maintenance is necessary. At the time of maintenance,
the maintenance personnel must strictly comply with the Operation
• Manual provided by the corresponding manufacturer and any non-professional is prohibited to maintain the
air conditioner.
• It is necessary to comply with the provisions of gas-related federal, state, and local laws and regulations.
• It is necessary to clear away the refrigerant in the system when maintaining or recycling an air conditioner by a
trained professional.
Warning: flammable
& Dangerous
Read the user manual Read the installation
manual
Read the
service manual

6
Table GG.1 - Maximum charge (kg)
Category LFL
(kg/m3)
h 0
(m)
Floor area (m2)
4 7 10 15 20 30 50
R32 0,306
0,6 0,68 0,9 1,08 0,32 1,53 1,87 2,41
1 1,14 1,51 1,8 2,2 2,54 3,12 4,02
1,8 2,05 2,71 3,24 3,97 4,58 5,61 7,254
2,2 2,5 3,31 3,96 4,85 5,6 6,86 8,85
Table GG.2 - Minimum room area (m2)
Category LFL
(kg/m3)
h 0
(m)
Charge amount (M) (kg)
Minimum room area (m2)
1,224 kg 1,836 kg 2,448 kg 3,672 kg 4,896 kg 6,12 kg 7,956 kg
R32 0,306
0,6 29 51 116 206 321 543
1 10 19 42 74 116 196
1,8 3 6 13 23 36 60
2,2 2 4 0 15 24 40
Installation Safety Principles
1. Site Safety
Open Flames Prohibited Ventilation Necessary
2. Operation Safety
Open Flames Prohibited
3. Installation Safety
• Refrigerant Leak Detector
• Appropriate Installation Location
The left picture is the schematic diagram of a refrigerant
leak detector.
Please note that:
1. The installation site should be in a well-ventilated area.
2. The sites for installing and maintaining an air conditioner using Refrigerant R32 should be free from open fire or welding, smoking, drying
oven or any other heat source higher than 548°C which easily produces open fire.
3. When installing an air conditioner, it is necessary to take appropriate anti-static measures such as wear anti-static clothing and/or gloves.
4. Installation or maintenance location should not be surrounded by obstacles or close to any heat source, flammable, and/or explosive
areas or objects.
5. If the product suers refrigerant leak during the installation, all personnel should go out till the refrigerant leaks completely for 15 minutes.
If the product is damaged, a professional must carry such damages product back to the maintenance station. It is prohibited to weld the
refrigerant pipe or conduct other operations on the contaminated site.
6. The air conditioner unit needs to sit on a flat even surface.
7. It is necessary to avoid the places where there are other electrical products, power switch plugs and sockets, kitchen cabinet, bed, sofa
and other valuables directly under the lines on two sides of the indoor unit.
8. Any ventilation openings of unit should be free from obstructions.
Mind Static Electricity Must wear protective clothing and
anti-static gloves
Don`t use mobile phone

7
What’s in the Box
Note: Some accessories are not in bucket, please find it in packaging.
NO. APPEARANCE PART NAME QUANTITY
1Pump Drain Hose
(about 5m, 16.4ft)
(PUMP MODEL ONLY)
1 set
NO. COMPONENT DESCRIPTION
1Control Panel
2Air Outlet
3Bucket
4Water Level View Window
5Handle
6Castor
7Air Intake Grill
8Power Cord
9Drain Port
10 Holes of Hooks
11 Pump Connector
(Only on models with a pump)
Note: Illustrations in this manual are for
explanatory purposes only. Product
design and aesthetics may vary.
1
2
3
4
5
6
7
9
11
8
10

8
Let’s Get Started!
Installation & Assembly Instructions
Step 1: Installation
Note: Do not place your dehumidifier in any location that features permanent, intermittent, or risk
of standing water to prevent damage to the unit and/or any persons.
Preparation
1. Remove the budget from the unit.
2. Remove the bucket’s tank cover and take out the included accessories.
3. Put the bucket’s tank cover back on.
4. Install the bucket into the main unit.
Accessories Included
Hook Assembly
Insert the hooks as illustrated below and turn them clockwise approximately 45-degrees.
Step 2: Testing
• Do not use outdoors.
• Place the unit on a smooth level surface.
• Allow at least 12 -18 inches of clearance on all sides of the unit.
• Place the unit in a space where the temperature will not fall below 41 degrees Fahrenheit.
• The dehumidifier must be operated in an enclosed area to be most eective, such as a basement.
• Close all doors, windows, and other outside openings to the room.
NO. APPEARANCE PART NAME QUANTITY
1Drain Pipe
(Pump Model Only) x1
2Hooks x2

9
How to Control Your Dehumidifier
All the basics you need to know!
Disclaimer: Pump and Wi-Fi features are only available on select models. It is normal for the letters
“CF” to be displayed for several seconds on Wi-Fi models as the dehumidifier powers on.
It is recommended to run the dehumidifier in Contentious mode for 24 hours for the first time. This
will stabilize the humidity and ensure that the compressor will function properly.
1. Power On and O - Press the once to turn on the appliance, push again to power o.
2. Comfort Mode - Hold the for 3 seconds and the “Comfort” or “Comf.” symbol will turn
on. In this setting, the humidity level will automatically be set according to the ambient
temperature and cannot be changed. Please note - the unit’s fan speed will default to Low
and cannot be adjusted.
To exit Comfort mode, press the or hold the for 3 seconds.
3. Timer - The timer can be used to delay the appliance start-up or shutdown.
Start-up - With the appliance o, press the to enable this feature.
Then press the or buttons to increase or decrease the timer in 30 minute increments.
After 5 seconds of inactivity, the Timer symbol will light up and this feature will be active.
Shutdown - With the appliance on, press the to enable this feature.
Then press the or buttons to increase or decrease the timer in 30 minute increments.
After 5 seconds of inactivity, the Timer symbol will light up and this feature will be active
4. Filter - Remove the filter from the back of the unit by using your thumbs to press down on
the filter tabs directly above the filter. Clean the filter with warm, soapy water. Dry thoroughly
before replacing the filter. Once the filter is completely dry, place the filter back in the unit.
The bigger cabinet:
FFAABB
88
CCEEDD
44665511223377
CC
EEDD
AA
BB
11~~334455
6688
The smaller cabinet:
A.On / Off butto n
B.Fan speed butto n
C.Decreas e butto n
D.Increas e butto n
E.Timer butto n
1.High speed symbol
2.Me d spee d symbol
3.Lo w spee d symbol
4.Comfor t symbo l
5.Tank full symbo l
6.Timer symbol
7.Wi-F i symbol *
A.On / Off butto n
B.Fan speed butto n
C.Decreas e butto n
D.Increas e butto n
E.Timer butto n
F.Pump butto n
1.High speed symbol
2.Me d spee d symbol
3.Lo w spee d symbol
4.Comfor t symbo l
5.Tank full symbo l
6.Timer symbol
7.Wi-F i symbol *
8.Pump symbol**

10
Avoid contacting metal parts of the appliance to avoid possible cuts or risk of personal injury.
5. Tank Full - When the water bucket is full, the Tank Full symbol will light up and the
compressor will turn o. The fan may continue to run for a few more minutes. Remove the
bucket with both hands and empty. Do not place the bucket on the floor when it is full
because the bottom is not flat.
Cleaning the water tank - It is recommended to clean the bucket the with a mild detergent every
week to prevent the growth of mold, mildew, and bacteria. Once clean, completely dry the bucket
and, using two hands, place it back inside the appliance.
Continuous Drain -
A standard garden hose can be used for continuous gravity flow into a floor drain.
1. Unscrew the cap on the back of the unit.
2. Install a standard garden hose to the back of the unit, ensuring there are no kinks in the hose.
3. Ensure that the dehumidifier is level, even a slight tilt can cause the water to drip down into
the drain bucket and not through the garden hose.
For Model(s) with PUMP
1. PUMP - Enable this function for use with a drain hose. Connect the pump drain tube and
adapter to the back of the unit. Press the PUMP button and verify the light next to the Pump
symbol turns on.
Note: Water will still drain into the bucket but the pump will engage when the bucket is almost full.
Note: You must place
the end of the drain
hose down a drain or
someplace where it
can freely drain
(bowls, buckets, etc.
are not recommended
as they can overflow).
Drai n Hose

11
Attaching Pump Drain Tube -
1. Push in on the outer ring of the pump connector on the back of the dehumidifier (See photo).
2. Slide the drain adapter into the opening and then release the outer ring of the pump connect.
3. Gently pull the drain adapter to ensure it is locked into place.
4. To remove the drain hose push in on the outer ring of the pump connector and pull on the
drain tube connector.
NOTE:
After the pump has been activated, the pump will not begin removing water until the internal
bucket is almost full and will continue removing water after this point until the pump mode is
turned o.
Makes sure there are not kinks or knots in the hose.
If there is a full tank alarm, please clean the tank first before activating the pump.
WARNING:
Before the ambient temperature drops to 32-degrees F (0-degrees C), condensate remaining in
the appliance must be emptied to avoid damage to the machine.
Make sure to clean the condensate channel every month to avoid damage to the pump by
unplugging the device, emptying the bucket and ensuring no blockage in the pump drain port.
Automatic Defrost - When frost builds up on the evaporator coils, the compressor will stop and
the fan will continue to run until the frost disappears. When the coils are completely defrosted, the
compressor will automatically restart and dehumidify will resume. If the frost does not completely
melt on its own, unplug the appliance overnight. Be sure to confirm the filter is clean before
running again.

12
Troubleshooting
Having trouble completing installation? Don’t worry, it’s usually an easy fix.
PROBLEM POSSIBLE CAUSES SOLUTIONS
Dehumidifier does
not start
The dehumidifier is unplugged. • Make sure the dehumidifier plug is pushed
completely into the outlet.
The fuse is blown/circuit breaker
is tripped
• Check the house fuse/circuit breaker box
and replace the fuse or reset the breaker.
Dehumidifier has reached its
pre-set level or the bucket is full
• The dehumidifier automatically turns o
when either condition occurs. Change to
a lower setting or empty the water bucket.
The bucket must be replaced properly for
the dehumidifier to operate.
Bucket is not in the proper position • The bucket must be in place and securely
inserted for the dehumidifier to operate.
Power failure
• There is a protective time delay (up to 3
min.) to prevent tripping of the compressor
overload. For this reason, the unit may not
start normal dehumidification for 3 min.
after it is powered back on.
Dehumidifier does not dry the
air as it should
Not enough time allowed for unit to
remove moisture
• When first installed, allow at least 24 hours
to reach the desired dryness/humidity level.
Airflow is restricted
• Make sure there are no curtains,
blinds , or furniture blocking the front
or back of the dehumidifier.
Dirty filter • Clean the filter. See the Cleaning
and Care Section of the manual.
The Humidity Control may not be set
low enough
• For drier air, press the v button to lower
the humidity setting percentage in the room
set the dehumidifier to CO for maximum
dehumidification.
Doors and windows may not be closed
tightly
• Check that all doors, windows, and other
openings are securely closed.
Clothes dryer may be blowing moist
air into the room
• Install the dehumidifier away from the
dryer. The dryer should be vented outside.
Room temperature is too low
• Moisture removal is best at higher room
temperatures. Lower room temperatures
will reduce the moisture removal rate.
This model is designed to operate at
temperatures above 41° F (5°C).

13
WiFi App Installation
(for WiFi models only)
Step 1: Download and Install the TCL Home App
Using the camera function on your smartphone, please scan the QR code below to be
directed to the TCL Home page. If your phone does not have a QR scanner, download one
from the app store or manually type in the URL below in your smartphone’s web browser.
Then, download and launch the app.
https://tcl.link/homeplusapp
Note: The App only supports the 2.4 GHz WiFi channel (all routers have a 2.4 GHz band).
Please connect to the 2.4 GHz band before you begin the app setup process.
Step 2: Create an Account
Once you have opened the app, select “Create account.” You will then be sent a verification code
to your email. Input the code and continue.

14
Step 3: Add Your Device
Select the “Add Devices” button and follow the in-app instructions to complete the setup.

15
Troubleshooting
Having trouble completing installation? Don’t worry, it’s usually an easy fix.
PROBLEM POSSIBLE CAUSES SOLUTIONS
TCL Home App
loses connectivity to AC
during setup
Wireless router may be too far
from AC • Relocate wireless router closer to AC.
Network error • Restart wireless router, AC, and mobile device
TCL Home App cannot
find AC
Network error • Restart wireless router, AC, and mobile device
App & AC are not on the same 2.4GHz
channel
• Confirm your device is connected to the
2.4GHz channel.
Router blocking TCL Home App • Verify App is not being blocked by the
router’s firewall.
Incorrect WiFi Password • Reinput and verify WiFi password.
Unable to find or connect
to Wireless Network App may need permission to location • Give TCL Home App permission to Location
in phone settings.

16
TCL NORTH AMERICA
LIMITED PRODUCT WARRANTY
What your warranty covers: Defects in materials or workmanship to the original owner of this TCL product when purchased as new from an Authorized Dealer of TCL
brand products and packaged with this warranty statement.
WARRANTY PERIOD (NON-COMMERCIAL USE):
Labor: Twelve (12) Months from the original date of purchase.
Parts: Twelve (12) Months from the original date of purchase.
WARRANTY PERIOD (COMMERCIAL USE):
Labor: Six (6) Months from the original date of purchase.
Parts: Six (6) Months from the original date of purchase.
Commercial Use includes, but is not limited to, the use of this product in a commercial or business environment, the use of this product in an institution or for
institutional purposes, or for other commercial purposes including rental purposes.
Should your TCL device prove to be defective in material or workmanship under normal use during the warranty period listed above, effective from the date of original
consumer purchase of the product, TCL North America at its sole discretion will, (1) pay an Authorized TCL Service Center for both labor charges and parts to repair your
device, or (2) replace your device with a new or refurbished/recertified equivalent product. If repaired at an Authorized TCL Service Center, TCL is not responsible for the
transportation costs to the Authorized TCL Service Center. However, TCL will pay for the return shipping. TCL will provide instructions for the packaging and shipping of
the unit. Units that are improperly packed and damaged during shipping are not covered under this limited product warranty. This limited product warranty is good only
to the original purchaser of the product and effective only when used in North America. You must have your original purchase receipt or proof of purchase (bill of sale or
receipted invoice) which states the condition of the unit (new, used), the unit’s date of purchase, place of purchase, and model/serial number.
HOW SERVICE IS HANDLED: Call 1-800-825-6747 and choose the appropriate prompt. Please have product type, model number, serial number, and ZIP code ready.
Troubleshooting and prior approval from a TCL representative MUST occur before sending in your product for repair.
Product Registration Information
You can find the model number and serial number on a label on the back or side of the product. Register your product online at register.tcl.com.
NO OTHER WARRANTY IS APPLICABLE TO THIS PRODUCT. THIS LIMITED WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS
LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS DISTRIBUTOR SHALL BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE
WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. SOME STATES AND/OR TERRITORIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LIMITATIONS ON THE LENGTH OF TIME AN IMPLIED WARRANTY LASTS, SO THE ABOVE EXCLUSION OR LIMITATION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU, THE ORIGINAL PURCHASER, SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE OR
TERRITORY TO TERRITORY. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT NOTICE. PLEASE VISIT WWW.TCL.COM/US TO VIEW THE MOST CURRENT VERSION.
THIS LIMITED PRODUCT WARRANTY DOES NOT APPLY TO:
1. Service calls to your home for delivery or pick-up, installation, instruction,
replacement of house fuses, connection of house wiring or plumbing, or to
correct unauthorized repairs.
2. Failure of the product to perform due to wireless signal reception
problems not caused by your unit, or due to power failures or
interruptions or inadequate electrical service.
3. Damage caused by transportation or handling, including damage during
shipment from a Retailer (please contact your Retailer
for assistance).
4. Damage caused to the product by accident, vermin, lightning, wind(s), fire,
flood(s), or act(s) of God.
5. Damage caused by operating the product in a corrosive or
wet atmosphere.
6. Repairs when your TCL product is used in other-than-normal, single-family
household use, or contrary to the instructions described in the product
User’s Guide.
7. Damage resulting from accident, alteration, misuse, abuse, neglect,
insects, normal wear-and-tear, cosmetic damage, mishandling, power line
surges, improper or faulty installation, or improper repair or maintenance.
Improper repair includes the use of parts not approved or specified by TCL.
8. Markings or images on the product’s display panel.
9. Normal maintenance as described in the User’s Guide (including but not
limited to cleaning or replacing filters, cleaning coils, or other normal
maintenance).
10. Use of accessories or components that are not compatible with
this product.
11. Products with altered, missing, defaced, unreadable, or removed
serial numbers.
12. Changes in the appearance of the product that do not affect
product performance.
13. Increases in utility costs and/or additional utility expenses.
14. Products purchased from non-authorized TCL resellers.
15. Products sold in any condition other than new from the original
manufacturer or sold outside of North America.
The cost of repair or replacement under these excluded circumstances shall be borne by the consumer.
CONTACT INFORMATION:
TCL North America
1860 Compton Ave
Corona, California 92881
1-800-825-6747
www.tcl.com/us

17
¡Hola! Comencemos.
Deshumidificador - Serie DFL

18
Reemplazo del producto
1 reemplazo gratuito si el producto no se puede reparar.
Piezas y servicio TCL
Piezas TCL originales y servicio certificado de fábrica.
No deducible
$0 de gastos de bolsillo.
Servicio prioritario
Envío gratuito y tiempo de respuesta rápido.
Cobertura extendida del fabricante
Cobertura ampliada de piezas y mano de obra por defectos
de fabricación.
PROTECT PLUS
Gracias por elegir TCL. Queremos que disfrute de la experiencia de propiedad tanto como disfruta
del producto adquirido, por lo que, cuando realice la compra, le ofreceremos un precio especial en
planes de protección de TCL durante el registro. Agregue un Plan de protección TCL dentro de los
primeros 30días de ser propietario para recibir el mejor valor y nos aseguraremos de que nada se
interponga en el camino para que disfrute de su nuevo producto.
Agregue un Plan de protección de TCL cuando registre
el producto, a fin de contar con cobertura contra los
contratiempos que la vida presenta.
Beneficios y descripción
Hasta 4años
De 3 a 5días De 3 a 5días
Hasta 4años
Regístrese fácilmente con su teléfono inteligente
Escanee o envíe un mensaje de texto con una
foto del icono de la cámara al 71403
O regístrese en línea en register.tcl.com
¿Necesita ayuda? Visite photoregister.com/help o envíe un
mensaje de texto que diga HELP al 71403
Registre y proteja su compra
Protección contra daños accidentales
La cobertura para caídas, roturas y derrames comienza después
de 30días.
*Los planes de servicio extendido (es decir, los planes “Protect" y “Plus") solo se ofrecen en los Estados Unidos
(EE. UU.). " Todos los productos de TCL continúan ofreciendo una garantía limitada al consumidor tanto en los EE.
UU. como en Canadá. Consulte la sección de garantía de esta guía para obtener más información sobre la garantía.
TCL-DHM
NO LO DEVUELVA A LA TIENDA
ASISTENCIA TCL:
support.tcl.com/us
1-800-825-6747
Contáctenos primero
con cualquier pregunta
ESTAMOS
LISTOS PARA
AYUDAR
CUIDADO CUANDO RETIRE
LA UNIDAD DEL DESHUMIDIFICADOR

19
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Antes de instalar y usar su deshumidificador, lea atentamente este manual del usuario. Guarde este manual
en un lugar seguro para futuras consultas. Su seguridad y la seguridad de los demás es muy importante para
nosotros. Preste atención a todos los mensajes de seguridad que se describen en este manual del usuario.
ADVERTENCIA: Para reducir el riesgo de incendio, descarga eléctrica o lesiones al usar el deshumidificador,
siga las siguientes precauciones básicas:
REQUERIMIENTOS ELÉCTRICOS
Las clasificaciones eléctricas de su deshumidificador se encuentran en la etiqueta del modelo y del número
de serie que se encuentra en la parte posterior (cuando está mirando hacia el frente).
REGISTRE SU APARATO
Puede registrar su aparato en línea yendo a register.tcl.com
Asegúrese de conservar su recibo de venta original. Se requiere una prueba de compra válida para todas las
reclamaciones de garantía.
Documente aquí sus números de modelo y de serie:
N° de modelo______________________________ N° de serie ______________________________
Puede localizar su número de serie de 20 dígitos debajo del código de barras (en la parte posterior)
ADVERTENCIA Los requisitos eléctricos específicos se muestran en el siguiente
diagrama. Siga los siguientes requisitos para el tipo de enchufe
del cable de alimentación.
Enchufe de Peligro de Choque Eléctrico en un
tomacorriente de 3 control remoto de conexión a tierra.
No retire la clavija de tierra.
No utilice un adaptador.
No utilice un cable de extensión.
El incumplimiento de estas instrucciones puede acarrear la
muerte, un incendio o una descarga eléctrica.
Requisitos de cableado Cable de alimentación
Salida de 5=60 Hz, 115 V AC
protegida por un fusible o
disyuntor de 12 amperios de retardo.
MÉTODO RECOMENDADO DE CONEXIÓN A TIERRA
Para su seguridad personal, este aire acondicionado debe estar conectado a tierra. Este acondicionador de
aire está equipado con un cable de alimentación de 3 puntas con un enchufe con conexión a tierra. Para
minimizar la posibilidad de una descarga eléctrica, el cable debe conectarse a una toma de corriente de 3
control remoto y conectarse a tierra de acuerdo con todos los códigos y requerimientos legales locales. Si
no hay disponible un tomacorriente de 3 puntas, es responsabilidad del cliente que un electricista calificado
instale un tomacorriente de 3 espigas debidamente conectado a tierra.
NO LO DEVUELVA A LA TIENDA
ASISTENCIA TCL:
support.tcl.com/us
1-800-825-6747
Contáctenos primero
con cualquier pregunta
ESTAMOS
LISTOS PARA
AYUDAR
CUIDADO CUANDO RETIRE
LA UNIDAD DEL DESHUMIDIFICADOR

20
MANUAL DE INSTALACIÓN: consideraciones importantes
En comparación con otros refrigerantes, el R32 es más ecológico. Utilice este producto según las instrucciones. Este
refrigerante es inflamable y puede hacer combustión en ciertas circunstancias; sin embargo, cuando se utiliza este
producto como se indica, estos riesgos se reducen significativamente. Consulte siempre con un profesional capacitado
cuando realice el mantenimiento o la reparación de un aire acondicionado.
Consideraciones importantes
• El aire acondicionado que compre debe ser instalado por personal profesional y el “Manual
de instalación” está destinado solo al personal de instalación profesional. Las especificaciones
de instalación deben estar sujetas a nuestras normas de servicio posventa.
• Cuando llene el aire acondicionado con el refrigerante inflamable, tenga cuidado para evitar
lesiones graves.
• Se debe realizar una prueba de fugas después de que se complete la instalación.
• Es imprescindible realizar una inspección de seguridad antes de realizar el mantenimiento o la
reparación de un
aire acondicionado que utilice refrigerante inflamable para garantizar que el riesgo de incendio
se reduzca al mínimo.
• Requisitos según el peso total del refrigerante lleno y la superficie del cuarto que se equipará
con un aire acondicionado (se muestran en las siguientes tablas GG.1 y GG.2)
Carga máxima y superficie mínima de suelo requerida
m1 = (4 m3) x LFL, m2 = (26 m3) x LFL, m3 = (130 m3 )x LFL
Donde LFL es el límite inferior de inflamabilidad en kg/m3, de modo que el LFL del R290 es 0,038 kg/m3, y el LFL del R32
es 0,038 kg/m3.
Para aparatos con una cantidad de carga de m1 < M = m2:
La carga máxima en un cuarto debe corresponderse con lo siguiente: mmáx.= 2,5 x (LFL)(5/4)xh0x (A)1/2
La superficie de suelo mínima requerida (Amin) para instalar un aparato con carga de refrigerante M (kg) debe
corresponderse con lo siguiente: Amín.= (M / [2,5 x (LFL)(5/4)xh0])2
Donde:
mmáx. es la carga máxima permitida en un cuarto, en kg; M es la cantidad de carga de refrigerante en el aparato, en kg;
Amin es la superficie mínima requerida del cuarto, en m2; A es la superficie del cuarto, en m2;
LFL es el límite inferior de inflamabilidad, en kg/m3;
h0 es la altura de instalación del aparato, en metros, para calcular mmáx. o Amín. (1,8 m para el montaje en paredes).
Advertencia
• Lea el manual antes de instalar o usar el aire acondicionado, o antes de llevar a cabo el mantenimiento.
• No acelere el proceso de descongelación ni lleve a cabo la limpieza con métodos distintos de los recomendados
por el fabricante.
• Tenga en cuenta que los refrigerantes pueden ser inodoros.
• No perfore ni queme el aparato.
• El aparato debe almacenarse en un ambiente libre de fuentes en funcionamiento continuo (por ejemplo: llamas
abiertas, un aparato de encendido a gas en funcionamiento o un calentador eléctrico en funcionamiento).
• Póngase en contacto con el centro de servicio posventa más cercano cuando sea necesario realizar un
mantenimiento. Cuando se realice el mantenimiento, el personal de mantenimiento debe cumplir rigurosamente
con el manual de operación proporcionado por el fabricante correspondiente; queda prohibido que personas no
profesionales realicen el mantenimiento del aire acondicionado.
• Es necesario cumplir con las disposiciones de las leyes y normas federales, estatales y locales relativas al gas.
• Es necesario que un profesional capacitado elimine el refrigerante del sistema cuando realice el mantenimiento de
un aire acondicionado.
Advertencia: inflamable
y peligroso
Lea el manual de usuario Lea el manual de
mantenimiento
Lea el manual de
mantenimiento
