TCL B422D User manual
1 1
Hi! Let’s Get Started.
User Manual
B521F
B422D
Beverage Chillers
2
Table of Contents
English
Register and Protect Your Purchase ................................................................................................ 3
Important Safety Information (Please Review Before Use) .................................................... 4
Customer Support Hotline .................................................................................................................... 7
Product Legend ........................................................................................................................................ 9
Installation ................................................................................................................................................... 10
Operating Your Beverage Cooler ...................................................................................................... 13
Troubleshooting ....................................................................................................................................... 14
Warranty Information.............................................................................................................................. 15
Español
Registre y Proteja su Compra ............................................................................................................. 17
Información Importante Sobre Seguridad (Revisar Antes de Usar el Producto) ........... 18
Línea de Atención al Cliente................................................................................................................. 21
Leyenda del Producto ............................................................................................................................ 22
Instalación.................................................................................................................................................... 24
Funcionamiento de su Enfriador de Bebidas ............................................................................... 27
Resolución de Problemas .................................................................................................................... 28
Información Sobre la Garantía............................................................................................................. 29
Français
Enregistrez et Protégez Votre Achat ............................................................................................... 31
Informations Importantes sur la Sécurité (à Lire Avant Utilisation) .................................... 32
Ligne D’assistance à la Clientèle......................................................................................................... 35
Légende du Produit ................................................................................................................................ 36
Installation ................................................................................................................................................... 38
Fonctionnement de votre Refroidisseur de Boissons ............................................................... 41
Dépannage ................................................................................................................................................ 42
Informations sur la Garantie ................................................................................................................ 43
2 3
Product Replacement
Free 1-time replacement if product cannot be fixed.
TCL Parts & Service
Genuine TCL parts & factory certified service.
No Deductible
$0 out of pocket expense.
Priority Service
Free shipping and rapid turn-around time.
Extended Manufacturer Coverage
Extended parts & labor coverage for manufacturer defects.
PROTECT PLUS
Thank you for choosing TCL. We want your ownership experience to bring you as much joy as
the product you purchased does, so we’re oering you a special price on TCL Protection Plans
when you purchase during registration. Add a TCL Protection Plan within your first 30 days of
ownership to receive the best value and we’ll make sure nothing gets in the way of you enjoying
your new product.
Add a TCL Protection Plan when you register your
product and be covered from life’s mishaps
Benefits & Description
Up To 4 Years
3-5 Days3-5 Days
Up To 4 Years
Register easily with your smartphone
Text a photo of the
camera icon to 71403
Or register online at register.tcl.com
Need help? Visit photoregister.com/help or text HELP to 71403
Register and protect your purchase
Accidental Damage Protection
Coverage for drops, breaks and spills starts after 30 days.
ENGLISH
*Extended service plans (i.e., “Protect” and “Plus” plans) are only oered in the United States (US). All TCL
products continue to oer a limited consumer warranty in both the US and Canada. Please refer to the warranty
section in this guide for additional details on warranty information.
TCLREF
4
Safety Information
To reduce the risk of fire, electric shock, or personal injury, thoroughly read the manual
and all instructions completely and carefully.
Store this manual in a safe place for future reference.
All owners, current or future, must have access to this manual.
WARNING
• To avoid accidents or serious injury, all people using this appliance must be familiar with the
contents of this User Manual, including Safety Information. The manufacturer is not responsible
for damages or injury caused using this device outside of normal operations.
• This appliance is not recommended for use by children ages 8 years and under and persons
with reduced physical, sensory, or mental capabilities unless supervised.
• This product is not a toy. Children shall not play with the or inside appliance. Small children and
pets should be supervised when using the fridge.
• Cleaning and maintenance should be conducted by a suitable adult or child ages 8 and above
under supervision.
• When discarding the appliance, make sure to unplug the appliance and wait a while before
cutting the power cable (as close to the appliance as possible) and remove the door to prevent
children from playing with the appliance and, subsequentially, reducing the risk of serious injury
or death from electric shock or suocation.
• If this appliance features a magnetic door seal and is to replace an older appliance with a spring
lock (latch) on the door or lid, be sure to remove, disable, or make the spring lock unusable
before discarding the appliance to prevent serious injury or death.
• CAUTION: Clearance between doors is small and fingers can be pinched. Be careful when
opening and closing the doors, especially if children are in the area.
• WARNING: To avoid the danger of suocation, keep plastic packaging away from pets, babies,
and children. Do not use packaging bags in cribs, beds, carriages, or playpens.
• DANGER: Risk of child entrapment. Before you throw away an old refrigerator or freezer:
• Take o the doors
• Leave the shelves in place so that children may not easily climb inside.
4 5
IMPORTANT SAFETY INSTRUCTIONS
• Do not puncture refrigerant tube
• R-600a is used as a refrigerant. This product contains flammable gas (Refrigerant R-600a)
• CAUTION: Risk of fire or explosion. Dispose of refrigerator and refrigerant in accordance with
federal and local regulations.
• When disposing of a refrigerator, remove doors, door seals, and door latches to avoid
entrapment of children and animals.
• In order to avoid the creation of a flammable gas-air mixture in the event that a leak in the
refrigerating circuit occurs, the size of the room in which the appliance may be placed depends
on the mass of the refrigerant loaded in the system. The room must be 35.3 ft3 in size for every
8 grams of R-600a refrigerant inside the appliance. Please refer to the rating label on the back
of the refrigerator to determine the amount of R-600A refrigerant used in this product.
• The installation location should not be exposed to direct sunlight and not placed near any
electrical appliance or heat source, e.g. stove, oven or hob, radiator, etc.
GENERAL SAFETY
• WARNING! Keep the appliance’s ventilation openings clear of obstruction.
• WARNING! Do not damage the refrigerant circuit.
• WARNING! If there is a lightbulb in your unit, do not touch it if it has been on for an
extended period of time as it could be very hot and may result in serious injury.
• WARNING! When positioning the appliance, ensure the supply cord is not trapped or
damaged.
• WARNING! Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.
• WARNING! Do not use extension cords or ungrounded (two-prong) adapters.
NEVER plug multiple appliances into the same outlet.
• Make sure that the power plug is not crushed or damaged by the back of the appliance.
A crushed or damaged power plug may overheat and cause a fire, resulting in injury or death.
Do not bend, twist, pull or place heavy objects on the power cord or supply.
• Do not store explosive substances, such as aerosol cans marked flammable, in this appliance.
• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the appliance,
a natural gas with a high level of environmental compatibility, which is flammable. Be sure to
keep open flames, sources of ignition, and high heat sources away from the unit.
• Ensure that none of the refrigerant circuit components become damaged during transportation
and installation.
• Make sure the room where the unit will be installed has thorough ventilation.
• It is dangerous to alter the specifications or modify this product in any way. Any damage to the
cord may cause a short circuit, fire and/or electric shock.
6
• This appliance is intended to be used in household and similar applications such as:
• Sta kitchen areas in shops, oces, and other working environments
• Farmhouses and by clients in hotels, motels, and other residential-type environments
• Bed and breakfast type environments
• Catering and similar non-retail applications environments
• This appliance is designed for indoor use only.
• WARNING! Any electrical components (plug, power cord, compressor and etc.) must be
replaced by a certified service agent or qualified service personnel. Contact our support team
for help.
• WARNING! The light bulb supplied with this appliance is designed explicitly for this
appliance and should not be used in any other device, lamp, or similar application outside of its
intended use in this machine.
• The refrigerator must be plugged into its own dedicated 115 Volt, 60 Hz., 15 Amp, AC only
electrical outlet. Do not lengthen or shorten the cord. The power cord of the appliance is
equipped with a three-prong grounding plug for your protection against electrical shock
hazards. It must be plugged directly into a properly grounded three prong receptacle. The
receptacle must be installed in accordance with local codes and ordinances.
• Make sure you have quick access to the outlet the appliance is plugged into in case of an
emergency where disconnection is quickly needed.
• Make sure the appliance is plugged into a wall main outlet and not into any power strip or
similar device.
• Do not pull on the main power cable.
• If the power socket is loose, do not use it for the appliance under any circumstance as it may
result in electric shock or fire.
• You must not operate the appliance without the lamp (if applicable to your unit).
• This appliance is heavy. Care should be taken when moving it. Team lift is recommended.
• Avoid prolonged sunlight exposure to the appliance.
DAILY USE
• Do not put hot objects or devices on the plastic parts in the appliance.
• If the appliance is left empty for long periods, switch o, defrost, clean, dry and leave the door
open to prevent mold developing within the appliance.
CARE AND CLEANING
• Before maintenance, switch o the appliance and disconnect the power plug from the main
socket.
• Do not clean the appliance with metal objects.
INSTALLATION
• IMPORTANT! For electrical connection, carefully follow the instructions given in the
following points.
• The refrigerator must be disconnected from the source of electrical supply before attempting
the installation.
• Only use accessories as indicated and not for any other use.
• Remove all protective plastic before using the appliance.
• Unpack the appliance and check if there is any damage to it. Do not connect the appliance if it
is damaged. Report possible damages immediately to the retailer you purchased from. In the
case of any damages, keep the packaging for proof.
• We advise waiting at least four hours before plugging in the appliance to allow the oil to flow
back into the compressor.
6 7
• There should be adequate air circulation around the appliance. Poor air circulation may lead to
overheating. To achieve sucient ventilation, follow the instructions relevant to installation.
• Wherever possible, make sure the product spacers are against a wall to avoid touching or
catching warm parts (compressor, condenser), resulting in possible burning.
• The appliance must not be located adjacent to radiators or cookers.
• Make sure that the power plug is accessible after installing the appliance.
• Allow the refrigerator to stand for 2-3 hours after installation before placing food inside.
SERVICE
• A qualified electrician should carry out any electrical work or service required.
• An authorized Service Center must service this product, and only genuine spare parts must
be used.
ENVIRONMENT PROTECTION
This appliance does not contain gasses that could damage the ozone layer in either its
refrigerant circuit or insulation materials. The appliance should not be discarded in urban refuse
and rubbish. The insulation foam contains flammable gases: the appliance should be disposed of
according to local authorities. Avoid damaging the cooling unit, especially the heat exchanger. The
materials used in this appliance marked by the recycle symbol are recyclable.
This symbol on the product or on its packaging indicates that this product may not be
treated as typical household waste. Instead, it should be taken to the appropriate collection
point for the recycling of electrical and electronic equipment. Ensuring this product is
disposed of correctly will help prevent potential negative environmental and human health
consequences, which could otherwise be caused by inappropriate waste handling of this product.
For more detailed information about the recycling of this product, please contact your local
council, your household waste disposal service or the shop where you purchased the product.
DO NOT RETURN TO STORE
TCL SUPPORT:
support.tcl.com/us
1-877-300-9134
contact us first
with any questions
WE ARE
READY TO
HELP
BE CAREFUL WHEN REMOVING
THE REFRIGERATOR
8
Product Legend : B422D
Note: The above picture is for reference only. The manufacturer reserves the right to change or
alter the product as necessary.
Carbon
Filter
Shelf
Left Door
Handle
Right Door
Handle
Left Glass
Right Glass
Wire
Shelves
Right Fan
Exhaust
Window
Foot
Right Light SwitchLeft Light Switch
Right Temperature SettingLeft Temperature Setting
Right Temperature DisplayLeft Temperature Display
Right Temperature SettingLeft Temperature Setting
Power SwitchPower Switch
Right Upper HingeLeft Upper Hinge
Left Door
Seal
Left Fan
Right Door
Seal
8 9
Product Legend : B521F
Note: The above picture is for reference only. The manufacturer reserves the right to change or
alter the product as necessary.
Shelf
Exhaust
Vent
NTC
Point
Light
Door
Handle
Glass
Exhaust Vent
Foot
Temperature Setting
Temperature Setting
Temperature Display
Temperature Setting
Light Switch
Fan Right Upper HingeCarbon
Filter
Door
Seal
10
Installation
Before using your beverage refrigerator:
• Remove the exterior and interior packaging.
• Before connecting the appliance to the power outlet, let it stand upright for approximately
2 hours. This will reduce the possibility of malfunction in the cooling system from handling
during transportation.
• Clean the interior surface with lukewarm water using a soft cloth.
• Place your appliance on a floor that is strong enough to support the appliance when it is
fully loaded.
• To level your appliance, adjust the front legs at the bottom of the appliance.
To install the door handle:
For shipment, the door handle has been stored inside of the unit binding to the wood shelves.
To install the handle, the door gasket should be gently pulled back where it covers the screw
holes for the handle, then the handle should be attached by screwing into place with the two
screws which are packed in the box with this Instruction Manual and other spare parts.
To reverse the door swing:
As you received your beverage refrigerator, the door swings open at the left. If you wish to
reverse the swing so that the door opens from the right, it is most important to have at least
one other person to help. It is very dangerous to try to reverse the door swing by yourself,
without anybody’s help the door might fall and the glass might be broken, which is terribly
dangerous.
(For the model B521F) Now, unscrew the upper door hinge while the second person holds the
door. Remove the upper hinge and carefully lift the door o the bottom hinge. Unscrew the
bottom hinge and install it on the left side of the unit. Flip the door around so that the handle
is on the right side and slip the door over the bottom hinge. Reattach the door by screwing the
top hinge into the holes provided on the upper left surface of the unit. Make adjustments as
necessary to be sure the door is aligned properly.
(For the model B422D) Unscrew the lower door hinge while the second person holds the door.
Remove the lower hinge and carefully lift the door o the upper hinge. Unscrew the upper hinge
and install it on the left side of the unit. Flip the door around so that the handle is on the right
side and slip the door over the upper hinge. Reattach the door by screwing the lower hinge into
the holes provided on the lower left surface of the unit. Make adjustments as necessary to be
sure the door is aligned properly.
10 11
Suggested Cabinet Dimensions
B422D
B521F
12
Spare Parts Details
B422D
APPEARANCE PART NAME PART USE
Screw x2 For the handle
installation.
Gasket x2 For the handle
installation.
Round Rubber Plug x1
To cover the holes on
the left front corner of
the body.
B521F
APPEARANCE PART NAME PART USE
Upper Hinge To switch the door
open from right.
Bottom Hinge To switch the door
open from right.
Screw x2 For the handle
installation.
Gasket x2 For the handle
installation.
Round Rubber Plug x2
To cover the holes on
the left front corner of
the body.
12 13
Operating Your Beverage Cooler
The Control Panel
B521F
How to use the press-buttons on the Display Panel:
• To control the temperature, press UP or DOWN button. Each press would adjust the
temperature by 1 °C between 3~10°C or 1 ° F between 38~50° F.
• To turn on or o the internal LED lighting, press LIGHT button on the right side.
• To switch the temperature display from Celsius Degree to be Fahrenheit Degree or vice versa,
press C/F button.
B422D
How to use the press-buttons on the Display Panel:
• To control the temperature, press UP or DOWN button. Each press would adjust the
temperature by 1 °C between 3~10°C or 1 ° F between 38~50° F.
• To turn on or o the internal LED lighting, press LIGHT button on the right side.
• To switch the temperature display from Celsius Degree to be Fahrenheit Degree or vice versa,
press C/F button.
• To shut down inner light and control panel display light (button and display light), please press
and hold both UP and DOWN buttons for 3 seconds, the cooler will restore to its normal status,
with inner light and control panel light on.
Care and Maintenance
Cleaning your beverage chiller
• Unplug the beverage chiller and remove the bottles.
• Wash the inside with warm water or baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
• The outside of wine cooler should be cleaned with mild detergent or warm water.
• Draw out the water box at the bottom, and wash it.
Moving your beverage chiller
• Remove all the bottles.
• Securely tape down all loose items inside your wine cooler.
• Turn the leveling legs up to the base to avoid damage.
• Tape the door.
• Be sure the beverage chiller stays in the upright position during transportation.
14
Troubleshooting
You can solve many common beverage chiller problems easily, saving you the cost of a possible service
call. Try the suggestion below to see if you can solve the problem before calling the service center.
PROBLEM POSSIBLE CAUSES
Beverage Chiller does not operate.
• Not plugged in to power outlet.
• The circuit breaker is tripped or the fuse
is blown.
Beverage Chiller is not cold enough.
• Check the temperature control setting.
• The door is open too often.
• The door is not closed completely.
• The door seal does not seal properly.
• The beverage refrigerator does not have the
correct clearance.
The light does not work.
• Main control board does not work.
• PCB Problem.
• There is some problem with the plug.
Vibrations • Check to assure that the beverage refrigerator
is leveled.
The Beverage Chiller seems to make to much noise • The beverage refrigerator is not leveled.
• Check the fan.
The door will not close properly.
• The wine cooler is not leveled.
• The doors were reversed and not properly
installed.
• The seal is weak.
• The shelves are out of position.
LED could not display.
• Main control board does not work.
• PCB Problem.
• There is some problem with the plug.
Buttons are not functional. Temperature controller panel is damaged.
If problems are recurring, please contact our Service Center for assistance.
14
TTCCLLNNOORRTTHHAAMMEERRIICCAALLIIMMIITTEEDDWWAARRRRAANNTTYY
All New TCL Product Models including LCD/LED Televisions, Sound Bars, and Appliances including Window Air Conditioners, Portable and Through-The-Wall Air
Conditioners, Dehumidifiers, Air Purifiers, and Robot Vacuums (each individually referred to as a “Product” or “Unit”, and together referred to as the “Products”).
What your warranty covers: Defects in materials or workmanship to the original owner of this TCL Product when purchased as new from an Authorized Dealer of TCL
brand Products in the United States and packaged with this warranty statement.
New Products (Non-Commercial Use)
For how long after your purchase: One (1) year from date of purchase for parts and labor for non-commercial use.
New Products (Commercial Use)
For how long after your purchase: Six (6) months from date of purchase for parts and labor for commercial use.
Commercial use includes, but is not limited to, the use of this Product in a commercial or business environment, the use of this Product in an institution or for
institutional purposes, or other commercial purposes including rental purposes.
What we will do
At TCL’s discretion, (1) pay an Authorized TCL Service Center for both labor charges and parts to repair your Product, or (2) replace your Product with a new or
refurbished/remanufactured equivalent value Product. The decision to repair or replace will be made solely by TCL. See section entitled “How to get service.”
How to get service
• Before submitting a request for warranty service, please visit
support.tcl.com for helpful FAQs and additional troubleshooting
suggestions.
• To get warranty service, contact TCL Customer Support by visiting
support.tcl.com/contact-us. Please have your Product type, model
number, serial number, and ZIP code ready. Troubleshooting and prior
approval from a TCL representative MUST occur before sending in your
Product to a TCL Service Center.
• A representative must troubleshoot your problem over the telephone,
via chat, or through e-mail before receiving service. If it is determined
that your Unit requires service, the service location will be at the sole
discretion of TCL based upon the Limited Warranty Statement.
• At the sole discretion of TCL, television screen sizes 43-inches and
smaller will either be repaired at an Authorized TCL Service Center or
directly exchanged for a new or refurbished/re-certified Unit. At the
sole discretion of TCL, television screen sizes 44-inches or larger will
either be repaired or directly exchanged for a new or refurbished/re-
certified Unit at an Authorized TCL Service Center or in-home. At the
sole discretion of TCL, Sound Bars, and Appliances including Window
Air Conditioners, Portable and Through-The-Wall Air Conditioners,
Dehumidifiers, Air Purifiers, and Robot Vacuums will either be repaired
or directly exchanged for a new or refurbished/re-certified Unit at an
Authorized TCL Service Center or in-home. In the event of a service visit
where the on-site technician, in his-her sole discretion, deems the home
or property conditions to be hazardous and/or unsafe, TCL reserves the
right to cancel or re-schedule the service visit, or opt for an exchange of
the in-warranty Unit for a refurbished/re-certified Unit in lieu of the in-
home service visit.
• TCL is not responsible for transportation costs for warranty coverage,
including but not limited to Unit repair or replacement, to the
Authorized TCL Service Center or TCL-designated address. However,
TCL will pay for return shipping to a United States address only. TCL
will provide instructions for packaging and shipping the Unit to the
Authorized TCL Service Center or TCL-designated address. Units that
are improperly packed and damaged during shipping are not covered
under your limited Product warranty.
• Proof of purchase in the form of a bill of sale or receipted invoice from
an Authorized Dealer which is evidence that the Product is within the
warranty period must be presented to obtain warranty service.
• In the event that a Unit is to be replaced, a picture of the back of the
Unit showing the model and serial number and picture of the Product
issue itself may be required.
• PRE-AUTHORIZATION MUST BE OBTAINED BEFORE (1) SENDING ANY
PRODUCT TO AN AUTHORIZED TCL SERVICE CENTER, OR (2)
OBTAINING ANY IN-HOME REPAIR/REPLACEMENT/RENTAL
SERVICES.
What your warranty does not cover
• A Unit sold in “As-Is”, “Used”, “Factory Reconditioned”, “Factory Re-
Certified”, or “Refurbished”, condition or with faults.
• Damage caused by transportation or handling, including damage during
shipment from a Retailer (please contact your Retailer for assistance).
• Extended Service Plans purchased from Retailers. Please contact your
Retailer for assistance.
• Customer instruction. (Your Owner’s Manual describes how to install,
adjust, and operate your Unit. Any additional information should be
obtained from your Authorized Dealer).
• Service calls to your home for delivery or pick-up, installation,
instruction, replacement of house fuses, connection of house wiring or
plumbing, or to correct unauthorized repairs.
• Installation and related adjustments, or damage resulting from
installation.
• Damage resulting from non-approved installation or repair methods.
• Failure of the Product to perform due to signal reception problems not
caused by your Unit, or due to power failures or interruptions, or
inadequate electrical service.
• Damage from misuse, abuse, neglect, insects, normal wear and tear,
cosmetic damage, mishandling, faulty installation, inadequate electrical
wiring, or power line surges.
• Damage caused by operating the Product in a corrosive or wet
atmosphere.
• Markings or images on the television’s panel resulting from viewing
fixed images (including but not limited to certain 4:3 images on wide
screen televisions, or data or images in fixed screen locations from
banners, video games, or certain broadcast networks).
• Units that have original factory serial numbers that are unreadable or
missing, or that have been changed, defaced, or altered in any manner.
• Batteries.
• A television that has been modified or incorporated into other Products,
or that has had the serial number removed or altered.
• Use of accessories or components that are not compatible with this
Product.
• A Unit purchased or serviced outside of the United States.
• Costs of shipping the Unit to the Authorized TCL Service Center or TCL-
designated address. TCL will pay for return shipping to the customer to
a United States address only.
• Acts of nature or God (as illustrative examples and for the avoidance of
doubt, such acts of nature or God include but are not limited to damage
caused by earthquakes, fires, lightning, or flood whether caused by
nature or humans).
• Special, incidental, or consequential damages.
LIMITATION OF WARRANTY
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO VERBAL OR
• WRITTEN INFORMATION GIVEN BY TTE TECHNOLOGY, INC. DBA TCL NORTH AMERICA, ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN
ANY WAY INCREASE OR MODIFY THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. TTE TECHNOLOGY, INC. DBA TCL
NORTH AMERICA SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR
ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED
WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF CALIFORNIA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY AND
WARRANTY PERIOD SET FORTH ABOVE. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT NOTICE. PLEASE VISIT WWW.TCL.COM TO VIEW THE MOST
CURRENT VERSION.
How State Law relates to this warranty
• Some states may not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other rights that vary from state to state.
If you purchased your Unit outside of the United States or seek warranty service coverage outside of the United States, this warranty does not apply. Contact your
dealer for warranty information. Service calls which do not involve defective materials or workmanship are not covered by this limited warranty. Costs of such service
calls are the sole responsibility of the purchaser.
16
¡Hola! Comencemos.
Manual de Usuario
Refrigerador de Bebidas
B521F
B422D
16 17
Reemplazo del producto
1 reemplazo gratuito si el producto no se puede reparar.
Piezas y servicio TCL
Piezas TCL originales y servicio certificado de fábrica.
No deducible
$0 de gastos de bolsillo.
Servicio prioritario
Envío gratuito y tiempo de respuesta rápido.
Cobertura extendida del fabricante
Cobertura ampliada de piezas y mano de obra por defectos
de fabricación.
PROTECT PLUS
Gracias por elegir TCL. Queremos que disfrute de la experiencia de propiedad tanto como disfruta
del producto adquirido, por lo que, cuando realice la compra, le ofreceremos un precio especial en
planes de protección de TCL durante el registro. Agregue un Plan de protección TCL dentro de los
primeros 30días de ser propietario para recibir el mejor valor y nos aseguraremos de que nada se
interponga en el camino para que disfrute de su nuevo producto.
Agregue un Plan de protección de TCL cuando registre
el producto, a fin de contar con cobertura contra los
contratiempos que la vida presenta.
Beneficios y descripción
Hasta 4años
De 3 a 5días De 3 a 5días
Hasta 4años
Regístrese fácilmente con su teléfono inteligente
Envíe un mensaje de texto con una foto del
icono de la cámara al 71403
O regístrese en línea en register.tcl.com
¿Necesita ayuda? Visite photoregister.com/help o envíe un
mensaje de texto que diga HELP al 71403
Registre y proteja su compra
Protección contra daños accidentales
La cobertura para caídas, roturas y derrames comienza después
de 30días.
*Los planes de servicio extendido (es decir, los planes “Protect" y “Plus") solo se ofrecen en los Estados Unidos
(EE. UU.). " Todos los productos de TCL continúan ofreciendo una garantía limitada al consumidor tanto en los EE.
UU. como en Canadá. Consulte la sección de garantía de esta guía para obtener más información sobre la garantía.
TCLREF
18
Información Sobre Seguridad
Para reducir el riesgo de incendio, descarga eléctrica o lesiones personales, lea detenidamente
el manual y todas las instrucciones de forma completa y cuidadosa.
Guarde este manual en un lugar seguro para hacer futuras consultas. Todos los propietarios,
actuales o futuros, deben tener acceso a este manual.
ADVERTENCIA
• Para evitar los accidentes o las lesiones graves, todas las personas que utilicen este aparato
deben estar familiarizadas con el contenido de este Manual del usuario, incluida la información
de seguridad. El fabricante no es responsable de los daños o las lesiones causados por el uso
de este dispositivo fuera de las operaciones normales.
• No se recomienda que niños menores de 8años ni que las personas con discapacidades físicas,
sensoriales o mentales usen este aparato sin la supervisión de un adulto.
• Este producto no es un juguete. Los niños no deben jugar con el aparato ni dentro de él. Los
niños pequeños y las mascotas deben ser supervisados al usar el refrigerador.
• La limpieza y el mantenimiento los debe realizar un adulto responsable o un niño de 8 años o
más bajo supervisión.
• Al desechar el aparato, asegúrese de desenchufar el aparato y esperar un rato antes de cortar
el cable de alimentación (lo más cerca posible del aparato) y retire la puerta para evitar que los
niños jueguen con el aparato y, en consecuencia, reducir el riesgo de lesiones graves o muerte
por descarga eléctrica o asfixia.
• Si este aparato tiene un sello magnético en la puerta y va a sustituir un aparato más antiguo
por un cierre de resorte (parche) en la puerta o tapa, asegúrese de quitar, desactivar o hacer
que el cierre de resorte sea inutilizable antes de desechar el aparato para evitar lesiones graves
o la muerte.
• PRECAUCIÓN: La separación entre las puertas es pequeña y los dedos pueden quedar
atrapados. Tenga cuidado al abrir y cerrar las puertas, especialmente si hay niños en el área.
• Advertencia: Para evitar el peligro de asfixia, mantenga los empaques de plástico alejados de
mascotas, bebés y niños. No utilice bolsas de embalaje en cunas, camas, coches ni corralitos.
• PELIGRO: Riesgo de atrapamiento de niños.
Antes de desechar un refrigerador o congelador antiguo:
• Retire las puertas.
• Deje los estantes en su lugar para que los niños no suban y se metan fácilmente.
18 19
IMPORTANT SAFETY INSTRUCTIONS
• No perfore el tubo de refrigerante
• R-600a se utiliza como refrigerante. Este producto contiene gas inflamable (refrigerante
R-600a)
• PRECAUCIÓN: Riesgo de incendio o explosión. Deseche el refrigerador y el refrigerante de
acuerdo con las normas federales y locales.
• Cuando deseche un refrigerador, retire las puertas, los sellos de las puertas y los bloqueos de
las puertas para evitar que los niños y animales queden atrapados.
• Para evitar que se cree una mezcla de gases inflamables en caso de que se produzca una fuga
en el circuito de refrigeración, el tamaño de la habitación en la que se puede colocar el aparato
dependerá de la masa del refrigerante suministrado al sistema. La habitación debe medir 35.3
pies3 por cada 8 gramos de refrigerante R-600a dentro del dispositivo. Consulte la etiqueta de
valores nominales ubicada en la parte trasera del refrigerador para determinar la cantidad de
refrigerante R-600A que este producto debe utilizar.
• La ubicación de instalación no estar expuesta a la luz solar directa ni estar cerca de ningún
aparato eléctrico o fuente de calor, por ejemplo, estufa, horno o cocina, radiador, etc.
SEGURIDAD GENERAL
• ¡ADVERTENCIA! No debe haber ninguna obstrucción en las aberturas de ventilación del
aparato.
• ¡ADVERTENCIA! No dañe el circuito del refrigerante.
• ¡ADVERTENCIA! Si hay una bombilla en su unidad, no la toque si ha estado encendida
durante un período prolongado, pues podría estar muy caliente y puede causar lesiones graves.
• ¡ADVERTENCIA! Al colocar el aparato, asegúrese de que el cable de alimentación no quede
atrapado ni esté dañado.
• ¡ADVERTENCIA! No ubique múltiples tomacorrientes portátiles ni fuentes de alimentación
portátiles en la parte posterior del aparato.
• ¡ADVERTENCIA! No utilice cables de extensión ni adaptadores sin conexión a
tierra (dos clavijas). Nunca conecte varios aparatos a la misma toma de corriente.
• Asegúrese de que el enchufe de alimentación no esté aplastado ni sufra daños por la
parte posterior del aparato. Si el enchufe de alimentación está aplastado o dañado puede
sobrecalentarse y provocar un incendio, lo que puede causar lesiones o la muerte.
No doble, tuerza ni jale el cable de alimentación ni coloque objetos pesados en él ni en la
fuente de alimentación.
• No almacene sustancias explosivas, como latas de aerosol marcadas como inflamables,
en este aparato.
• Dentro del circuito refrigerante del aparato hay isobutano refrigerante (R600a), un gas natural
con un alto nivel de compatibilidad ambiental, que es inflamable. Asegúrese de mantener las
llamas abiertas, las fuentes de ignición y las fuentes de calor alto lejos de la unidad.
• Asegúrese de que ninguno de los componentes del circuito refrigerante se dañe durante el
transporte y la instalación.
Advertencia: Riesgo de incendio / Materiales inflamables
ADVERTENCIA
20
• Asegúrese de que la habitación donde se instalará la unidad tenga una ventilación completa.
• Es peligroso alterar las especificaciones o modificar este producto de alguna manera. Cualquier
daño al cable puede causar un cortocircuito, incendio o descarga eléctrica.
• Este aparato está destinado a ser utilizado en aplicaciones domésticas y similares como:
• Áreas de cocina del personal en tiendas, oficinas y otros entornos de trabajo
• Casas rurales y por clientes en hoteles, moteles y otros entornos de tipo residencial
• Ambientes tipo bed and breakfast
• Entornos de catering y aplicaciones similares no comerciales
• Este aparato está diseñado solo para usarse en interiores.
• ¡ADVERTENCIA! Cualquier componente eléctrico (enchufe, cable de alimentación,
compresor, etc.) lo debe reemplazar un agente de servicio certificado o personal de servicio
calificado. Póngase en contacto con nuestro equipo de soporte para obtener ayuda.
• ¡ADVERTENCIA! La bombilla suministrada con este aparato está diseñada explícitamente
para este aparato y no se debe utilizar en ningún otro dispositivo, lámpara o aplicación similar
fuera del uso previsto en esta máquina.
• El refrigerador debe estar conectado a su propio tomacorriente dedicado de 115voltios,
60Hz., 15A, solo tomacorriente CA. No alargue ni acorte el cable. El cable de alimentación del
aparato está equipado con un enchufe de conexión a tierra de tres clavijas para su protección
contra los peligros de descarga eléctrica. Se debe conectar directamente a un receptáculo de
tres clavijas debidamente conectado a tierra. El receptáculo debe instalarse de acuerdo con los
códigos locales y las ordenanzas.
• Asegúrese de tener acceso rápido a la toma de corriente en la que está enchufado el aparato
en el caso de una emergencia donde sea necesario desconectarlo rápidamente.
• Asegúrese de que el aparato esté enchufado a un tomacorriente de pared y no a una regleta o
un dispositivo similar.
• No tire del cable de alimentación principal.
• Si el tomacorriente está suelto, no lo utilice para el aparato bajo ninguna circunstancia, ya que
puede provocar descargas eléctricas o incendios.
• No debe hacer funcionar el aparato sin la lámpara (si aplica para su unidad).
• Este aparato es pesado. Debe tener cuidado al moverlo. Se recomienda levantar en equipo.
• Evite la exposición prolongada a la luz solar del aparato.
USO DIARIO
• No coloque objetos ni dispositivos calientes en las piezas de plástico del aparato.
• Si el aparato permanece vacío durante períodos prolongados, apáguelo, descongele, límpielo,
séquelo y deje la puerta abierta para evitar que se desarrolle el montaje dentro del aparato.
CUIDADO Y LIMPIEZA
• Antes de realizar el mantenimiento, apague el aparato y desconecte el enchufe de alimentación
del tomacorriente.
• No limpie el aparato con objetos metálicos.
INSTALACIÓN
• ¡Importante! Para la conexión eléctrica, siga cuidadosamente las instrucciones que se indican
en los siguientes puntos.
• El refrigerador debe estar desconectado de la fuente de alimentación eléctrica antes de
intentar instalarlo.
• Solo use los accesorios como se indica y no para ningún otro uso.
• Retire todo el plástico protector antes de usar el dispositivo.
This manual suits for next models
1
Table of contents
Languages:
