TCL RF436GM1110 User manual
RF436GM1110
RF436GM1110UK
■ Please carefully read the operation instructions before power on, and keep it properly.
■ The products may subject to changes without notice.
Two-Door Household Refrigerator
Operating Instructions
TCL Home Appliances (Hefei) Co., Ltd.
Address: No. 10 Yunhu Road, Economic Development Zone,
Hefei City, Anhui Province, China
1. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
3. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
4. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
5. WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
6. WARNING: Do not damage the refrigerant circuit.
7. WARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
8. Do not store explosive substances such as aerosol cans with a flammable propellant in
this appliance.
9. This appliance is intended to be used in household and similar applications such as
–Staff kitchen areas in shops, offices and other working environments;
–Farm houses and by clients in hotels, motels and other residential type environments;
–Bed and breakfast type environments;
–Catering and similar non-retail applications.
P5
P6
P7
P8
P8
P11
P11
P12
P12
P13
P13
P14
P14
P2
Contents
Thank you for buying TCL refrigerator. We hereby express our thanks. Welcome
to use TCL refrigerator. We will do our best to provide you with quality service.
Safety instructions ........................................................
Product introduction .................................................................................................................
Handling and placement ........................................................................................................
Preparations prior to use .......................................................................................................
Operation notes .........................................................................................................................
Illustration and operation of display panel ..............................................................
Food storage .......................................................................................................................
Ice-making...........................................................................................................
Disassembly and assembly method of accessory ...............................................
Maintenance ...............................................................................................................................
Failure analysis .........................................................................................................................
Non-failure ..................................................................................................................................
Technical parameter ................................................................................................................
Packing list ...................................................................................................................................
EN
Safety instructions
1. Warning
Warning: No barrier is allowed around the appliance or in the embedded
structure in order to ensure the free ventilation.
Warning: it is forbidden to speed up the defrosting process with any
mechanical equipment or by other method except for the method recommended
by the manufacturer.
Warning: Never damage the refrigerating circuit.
Warning: Never use any electric apparatus in the food chamber of the
appliance except for the type recommended by the manufacturer.
Warning: Never place the liquid beverage or food contained with glass
container in the freezing chamber for fear of cracking.
Warning: If powered off, the refrigerator shall be powered on 5min later for
fear of damaging the compressor.
Warning: If any live part, abnormal noise, smell, smoke or other abnormality
is found during use. It is necessary to power off the appliance immediately and
contact the aftersales service department of the Company timely.
Warning: Never place your finger or hand under the refrigerator, especially
rear bottom of refrigerator; otherwise, you may be hurt by the sharp matter.
Warning: The children must not play or climb the refrigerator. The operation
by the children must be supervised by their parents for fear of danger.
Warning: Never place your hand between the doors to open or close door for
fear of jamming your finger. The door handle shall be used to open or close the
door.
Warning: Under the rated climate types SN, N and ST, the operating ambient
range of the appliance is 10°C~38°C; under the climate types SN, N, ST and T,
the operating ambient range of the appliance is 10°C~43°C. If the appliance
operates outside the rated climate type (ambient temperature range), the
appliance may not maintain the satisfying interior temperature.
EN
ar: Rs of re / aae ateras
ar: e osto te aae, esre te s or s ot
trae or aae.
ar: o ot oate te ortae soet-otets or ortae oer
ses at te rear of te aae.
Cre ae fro 3 to 8 ears are aoe to oa a oa refrerat
aaes
Oe te oor for o eros a ase a sat rease of te
teeratre te oartets of te aae.
Cea rear srfaes tat a oe otat t foo a aesse
raae sstes.
Cea ater tas f te ae ot ee se for 48 ; s te ater sste
oete to a ater s f ater as ot ee ra for 5 as.
Store ra eat a s stae otaers te refrerator, so tat t s ot
otat t or r oto oter foo.
To-star froe-foo oartets are stae for stor re-froe foo,
stor or a e-rea a a e es.
Oe-, to- a tree-star oartets are ot stae for te free of fres
foo. If te refrerat aae s eft et for o eros, st off,
efrost, ea, r, a eae te oor oe to reet o eeo t
te aae.
Catos: Te oer s of ts rot st e for t te oer
s etoe o te aeate, a te staar eeet 3-oe
soet sa e se (aoe 10, a rea roe). Oe soet st ot
e sare ore ta oe aae; oterse, re a e ase e to
oereat.
Catos: Neer te oer re a. It s eessar to o a
te oer oetor fro te soet to soet te oer s. Te
oer re or oetor st ot e toe te et a for fear of eetr
so.
Catos: Te oer re st ot e seee te refrerator or a
ea oa, a te oer re sa ot e et etree. Te aae or
ee of oer re a rest re or eetr so. If te oer re s
roe or t, ease otat te after-saes sere eartet eate.
Catos: No aae or eose atter or orrose a or aae
atter s aoe te refrerator.
3
EN
4
Safety instructions
Cautions: The refrigerator must not be used in the rain or under the
sunshine.
Cautions: It is forbidden to place the container with fluid on the refrigerator
because the breakage or turnover of the container may affect the electrical
insulation of refrigerator and result in electric shock or fire.
Cautions: The refrigerator must not be disassembled or modified without
permission. The repair of refrigerator must be performed by the specialist.
Cautions: In case of leakage of any flammable gas such as coal gas, it is
necessary to close the leaking valve first and then open the window for
ventilation, and forbidden to unplug the refrigerator connector immediately for
fear of fire or explosion due to electric spark.
Cautions: Refrigerating appliances - in particular a refrigerator-freezer Type
I - might not operate consistently (possibility of defrosting of contents or
temperature becoming too warm in the frozen food compartment) when sited for
an extended period of time below the cold end of the range of temperatures for
which the refrigerating appliance is designed;
Cautions: The fact that effervescent drinks should not be stored in food
freezer compartments or cabinets or in low-temperature compartments or
cabinets, and that some products such as water ices should not be consumed
too cold.
Cautions: The need to not exceed the storage time(s) recommended by the
food manufacturers for any kind of food.
Cautions: The precautions necessary to prevent an undue rise in the
temperature of the frozen food while defrosting the refrigerating appliance,
such as wrapping the frozen food in several layers of newspaper.
Cautions: The fact that a rise in temperature of the frozen food during
manual defrosting, maintenance or cleaning could shorten the storage life.
Cautions: The care required with regard to frozen food in storage in the
event of an extended non-running of the refrigerating appliance (interruption of
power supply or failure of the refrigerating system).
Cautions: The action to be taken when the refrigerating appliance is
switched off and taken out of service temporarily or for an extended period (e.g.
emptied, cleaned and dried, and the door(s) or lid(s) propped ajar).
EN
The pictures are for reference only. Please refer to the object
5
Refrigerator room door
Freezer room door
Bottle holder
Freezer room door
Freezer drawer
Freezer upper drawer
Fruit and
vegetable box
Product introduction
Refrigerating Light
Flip Beam
Refrigerating Shelf
Cover
Features
--Computer intelligent temperature control; air cooling and frost free.
--Environmental-friendly refrigerant, it applies materials without CFC, R600a
environmental- friendly materials. 80% of the main materials can be recycled;
--Transparent drawers with novel appearances and their internal foods can be clear at
a glance;
--The tempered glass refrigeration shelves are height adjustable, wear proof, heat-
proof and practical;
--The concealed condenser applies flat back design. It has perfect and coordinated
style which is simple, easy to clean and high utility rate of space;
--This product adopts the efficient mute compressor of international brand and special
case foaming technology, and features low noise, low energy consumption, and is
more suitable for family and commercial purposes.
Warm prompt:
If your product is improved product, it may not be totally same as that in the
instructions. But it will not change the performance and method of application.
Please feel relieved about usage.
EN
6
Handling and placement
During handling, the door
side of the refrigerator shall
not contact with the handling
tools
Removing the foam base is
beneficial for bottom heat
dissipation and can avoid fire.
The refrigerator shall be
placed in an environment
which is dry, has good
ventilation, far from direct
sunshine and heat source.
The refrigerator shall be
placed on the flat and firm
surface. If the ground is not
flat, adjust the adjusting leg to
keep it level.
Never place the refrigerator
into a too cold environment
that may get frozen.
Warm prompt:
--When handling the refrigerator, at least two persons are required - one lifts the
top of rear part, the other one handles the bottom (if one part is clamped, it is quite
dangerous and may cause accident).
--When moving the refrigerator, the lower runner may damage and scratch the
floor. If you need to move the refrigerator for a long distance, the internal
accessories shall be fixed using adhesive tape. Otherwise, the accessories may
get damaged due to crashing each other.
--Please place the refrigerator in the position with small vibration or little exposed
to vibration. For users in the area where earthquake often occurs, please fix the
refrigerator against the wall or pole. Otherwise, the falling of refrigerator will cause
accident.
--Sufficient clearance shall be left around. If the clearance is too small or place
goods on the top or close to the side, or paste on the sides, the heat dissipation of
refrigerator will be affected, and thus to cause unnecessary electric energy waste
as well as burn out of the wall and other goods; the contact between the back and
wall will cause vibration and noise;
--Adjust the front part and adjusting leg of the refrigerator to level it. Unlevel of the
refrigerator will cause vibration and noise.
Certain space shall be left
around the refrigerator,
shown in the figure.
>30cm
>10cm >10cm
EN
7
Preparations prior to use
1. Remove all packing assemblies such as case fixing tape etc., especially the foam base.
2. Use warm wet cloth to clean both interior and exterior of the refrigerator, (neutral
detergent can be added in warm water).
3. After leveling and cleaning the refrigerator, stand it for about 5 hours before plugging
the power plug for powering on, and cool the refrigerator for 2 to 3 hours before storing
foods.
1. Remove fixing tape 2. Connect to power 3. Store food after
connecting to power for
2-3 hours
Wipe with warm
and wet cloth
In hot summer, 24 hours are needed to
fully freeze the food. Check the
refrigerating condition on the second
day.
Do not open the
doors frequently to
save electricity.
The plastics deodorant will disappear
automatically after freezing for a while.
677 703 >L1+300 >W1+500
L 3
W 3
Handling and placement
The outline dimension of the product and the space needed by the
use of product are shown in the following pictures:
Space needed by the free ventilation
Outline dimension of
product
Space needed by the
use of product
Unit: mm
Total space nee ded by
the use of product
Outline dimension
of product
Space needed by the use
of product Total space needed by the use
of product
EN
8
The above is the computer control board of the product
Operation and diagram of display board
Refrigerator room
Freezer room
Temperature display
Quick freezing mode icon
Quick freezing mode icon
Energy saving mode icon
Temperature zone / function button
Press the button for
3 seconds to unlock
Temperature adjustment button
Set/Function
Power
Freeze
Power
Cool
ECO
Regulate
3"Unlock
Operation notes
EN
9
Power on for the first time
The first time the power is turned on, the refrigerator operates according to the refrigerator
room at 5°C, and in the freezer at -18°C.
Child lock function
On: When there is no key operation in the display within 30 seconds, the child lock icon on
the display lights up, and the remaining characters go out, and the child lock function is
entered immediately. After 5 minutes, the child lock icon goes out and enters the display
protection function. In the screen saver mode, Press any key to exit the screen saver
mode.
Close: When the child lock of the display is turned on, press and hold the "Unlock for 3
seconds" button for 3 seconds to unlock, that is, the child lock function is turned off.
Refrigerator temperature adjustment
In the unlocked state, press the "Temperature Zone / Function" button repeatedly until the
refrigeration temperature zone lights up, and then press the "Temperature Adjustment"
button to refrigerate the room temperature Degree adjustment. The shift of refrigerator
compartment stalls recycles around "08"-"07"-"06"-"05"-"04"-"03"-"02"-"OF"-"08". Select
the appropriate temperature to stop the key operation and wait for 5 seconds, then set the
temperature to confirm.
(The set temperature of the refrigerator compartment is "of", which is the refrigeration
shutdown function. After the refrigeration shutdown function is turned on, the refrigeration
compartment stops cold.)
Freezer temperature adjustment
In the unlocked state, repeatedly press the "temperature zone / function" key until the
freezing temperature zone lights up, and then press the "temperature adjustment" button
to freeze the room temperature.
The temperature is adjusted. The set temperature of the freezer is "-15"-"-16"-"-17"-"-18"-
"-19"-"-20"-"-21 "-"-22 "-"-23 "-"-24 "-"-15 ". Choose the right temperature to stop the key
operation and wait 5 seconds, the set temperature is confirmed.
Operation notes
EN
Quick cooling function
In the unlocked state, repeatedly press the "temperature zone / function" button until the
"quick cooling" icon flashes, stop the button operation and wait for 5 seconds, Then enter
the quick cooling function of the refrigerator. The same operation can exit the quick
cooling function. After entering the "quick cooling" 2 hours, it will automatically exit.
In the "quick cooling" state, the set temperature of the refrigerator compartment is
displayed as 2°C until the function is exited. In the "quick cooling" state, when other
functions are set, the quick cooling function may be automatically exited. In the "quick
cooling" state, the refrigerator The door will automatically exit the quick cooling function
after being opened for more than 3 minutes.
Quick freeze function
In the unlocked state, press the "Temperature Zone / Function" button repeatedly until the
"Quick Freeze" icon flashes. Stop the key operation and wait for 5 seconds to enter the
quick freeze function of the freezer. The same operation can exit the quick freeze
function. After entering the "Quick Freeze" After 4 hours of entering the cold state, it will
automatically exit.
In the "Quick Freeze" state, the setting value of the freezer is displayed at -32°C until the
function is exited. In the "Quick Freeze" state, when other function settings are made, the
quick freeze function may be automatically exited. In the "Quick Freeze" state, the freezer
door is opened for more than 3 minutes Automatically exit the quick freeze function.
Energy saving function
In the unlocked state, repeatedly press the "temperature zone / function" key until the
"energy saving" icon flashes, stop the key operation and wait for 5 seconds, Then enter
the "energy saving" function. The same operation can exit the energy saving function.
After the "energy saving" function is turned on for 10 seconds, the display The remaining
characters are automatically extinguished, after which the refrigerator automatically
enters a low energy consumption state.
Power-off memory
When the power is cut off, the instantaneous working state of blackout will be locked and
resume the state after power on.
10
Operation notes
EN
Door alarm
When the refrigerator or freezer door is not well closed or open for over 1 minute, the buzzer siren will
send off sound. Press down any key to stop alarming and the siren sounds “beep, beep, beep" again
after 1 minute; close refrigerator or freezer door to stop alarming.
Freezer compartment temperature reminder
When the temperature of freezer compartment is higher than -12°C, the corresponding temperature
area is lit, the digital area flashes. Press down any key to display temperature of freezer compartment
when the power is on, press again or wait for 10 seconds to restore normal display state.
Display protection function
The refrigerator will enter display protection function without any key operation for 30 seconds, and the
key board is locked automatically. Under display protection mode, press any key to exit display
protection function.
11
Operation notes
Operation keys
Foods storage
Refrigerating chamber (2 -8 )°C °C
--The refrigerating chamber is mainly used for storing short-term foods, like milk, eggs and bottled
drink.
--Vegetables, melons and fruits shall be put into the fruit and vegetable box to prevent water loss.
--The cooked foods shall be put into the refrigerator after packaging with the preservative bags, to
prevent the back from frosting and the power from increasing.
Freezing chamber (-22 -15 )°C °C
--The freezing chamber is used for the foods to be stored for long-term.
--Fish and meat to be frozen shall be cut into small pieces, packaged with preservative bags
separately and then put into the frozen drawer.
--The glass container or the sealed container filled with liquid shall not be stored in the freezing
chamber, to prevent the risk of burst due to freezing.
--The fresh foods shall not be stored together with the frozen foods.
--Do not place food close to inside wall in freezer lest food and wall should be frozen together.
★★ Warm tips:
The stored food, if any, shall not block the air duct outlet and return port for fear of affecting the
refrigerating effect.
Before being stored in the refrigerator, the overheated water and food shall be cooled to the room
temperature.
Ice-making (If the appliance has it)
Fill the Ice-making box with 4/5 water and put the box
into the freezing chamber. After the water in the box
turns into ice, twist the box slightly to separate the ice
from the box. However, don’t bend the box. When
separating the ice, wrap the box with dry box to avoid
finger frostbite.
EN
12
Operation notes
Disassembly and assembly method of accessory
--Glass shelf in the refrigerating chamber: the height of the shelf is
adjustable, which facilitates the storage of articles with different
volumes. Pull the shelf outwardly and upwardly in a slight way to
take out.
--Fruit and vegetable box: for storing vegetables and fruits. It can
be taken out by pulling outwardly.
--Drawer in the freezing chamber: storing foods to be preserved for
long-term, such as meat and fish. It can be taken out by pulling
outwardly and lifting upwardly. Kindly tips: It is recommended to put
into the large piece of meat after being cut into small pieces, to
avoid difficult cutting after being frozen. The quick-freezing foods
shall be distributed uniformly and stored together after being
frozen.
--Bottle pedestal at the refrigerating door: storing eggs, various
bottled drinks and other sundries. It can be taken out by being lifted
up slightly.
Note: Don’t pull out the bottle pedestal at the refrigerating door
forcibly during disassembly, to avoid damaging the refrigerator.
Maintenance
It is suggested to maintain the refrigerator once per month;
--Unplug the power plug to prevent from electric shock;
--Use wet cloth or neutral detergent (cleanser essence) to wipe off
the oil contamination and other dirt. Then completely wipe off the
detergent.
--Do not use alkaline detergent, soap powder, gasoline and alcohol,
talcum powder etc.; otherwise the coats or plastics may be damaged;
--Regularly clean the refrigerator body and clear the ground dusts to
keep the refrigerator clean.
Inspections after maintenance:
1. Whether there are damages to the power line and plug;
2. Whether there are dusts on the power plug;
3. Whether there is abnormal heat on the plug;
4. Whether the socket is loose;
5. Whether the plug is totally inserted.
Note:
If the power line and plug is damaged and there exist dusts, electric
shock or fire may occur;
After unplugging the plug, 5 minutes must pass before re-plugging it;
Do not put your hands under the refrigerator to avoid getting hurt.
Take out by pulling
upwardly and outwardly
in a slight way
Take out by pulling
outwardly and upwardly
in a slight way
Unplug the
refrigerator plug
before cleaning
Please use neutral
detergent
EN
The following items shall be inspected before occurring failures which require
maintenance:
Failures: Refrigerator does not work, the refrigeration effect is poor
Causes: 1. Check the connection of power supply. 2. Check whether the refrigerator is
exposed to direct sunlight or whether there is heat source nearby. 3. Check whether there
is heat dissipation space around refrigerator.
Remedies: 1. Connect the power supply. 2. Move the refrigerator to a place without direct
sunlight and heat source. 3. Leave sufficient space between refrigerator and wall.
Failures: Foods in refrigerating chamber are frozen
Causes: 1. Check whether the setting temperature is too low. 2. Check whether foods with
too much water are too close to the rear wall.
Remedies: 1. Adequately increase the temperature. 2. Move the foods with too much water
to the door side of glass shelf
Failures: There is abnormal sound in refrigerator
Causes: 1. Check whether the bottom of refrigerator is stable. 2. Check whether the
refrigerator is too close to the wall. 3. Check whether the refrigerator touches other
objects.
Remedies: 1. Adjust the bottom adjusting leg to stabilize the refrigerator. 2. Leave
sufficient space around refrigerator. 3. Remove the obstacles.
Failures: There is abnormal odor in refrigerator
Causes: 1. Check whether the foods are sealed for storage. 2. Check whether the
refrigerator is clean. 3. Check whether the foods are stored for too long time.Remedies:1.
Sealed foods for storage. 2. Regularly clean the refrigerator. 3. Do not store foods for too
long time.
Non-failures
Phenomenon: Fever or hot on two sides and spacing part surface between
refrigerating chamber and freezing chamber.
Cause: Refrigerator pipes (condenser, anti-fog pipes) are on two sides and front part of
refrigerator for heat dissipation and to prevent from condensation.
Phenomenon: The door is too tight and not easy to open
Cause: Reopening of the door immediately after closing it is hard because hot air enters
the refrigerator and contracts to produce pressure difference. It is easy to open the door
after a while.
Phenomenon: There is water ripple in refrigerator
Cause: When starting or stopping the compressor, the refrigerant will make such sound;
Water produced after defrosting will also make such sound.
Phenomenon: There is “Click" sound or tick sound in refrigerator
Cause: Shrinkage and swelling of case will make such sound; When the case is cold or the
door is opened, this sound will occur; Phenomenon: There is hum sound in refrigerator
Cause: Running of compressor will make such sound (if the refrigerator is not leveled, this
sound will be louder)
Phenomenon: There is condensation or frosting freezing chamber door surface or
food surface
Cause: Temperature or humidity around the refrigerator is high; The door is opened for too
long time; The foods with too much water are not sealed or tightly wrapped
Phenomenon: There is condensation on the built-in light surface
Cause: Light will produce heat after being lit, and the door is opened for too long time. So
there is temperature difference, and thus the light case will have condensation.
Phenomenon: There is condensation and water mist on body
Cause: Humidity around refrigerator is high, and the moisture in the air will gather in the
case to form condensation
13
Failure analysis
EN
83
390
RF436GM1110
Weight
Dimension
703x677x1890
90L
68
1.95A
0.88kW•h/24h
3W
14
Refrigerating shelf
Annex
3
1
Model
Freezer drawer
1
Fruit and vegetable box
1
Operating instruction
1
Freezer upper drawer
RF436GM1110
Cover
Egg box
1
1
Bottle bracket
6
Ice-making box
1
Model
Climate type
Electric shock resistance
Star sign
Total Storage Volume
Storage Volume of Freezer
Power type
Rated current
Power consumption
Lamp power
Refrigerant and charge amount
Noise Volume
Technical parameter
Packing list
EN
8
3
390
RF436GM1110UK
703
x677x1890
90L
68
1.95A
0.88kW•h/24h
3W
3
1
1
1
1
RF436GM1110UK
1
1
6
1
Material number: 8B110-000807
Edition: 202007-B.1
EN
RF436GM1110
RF436GM1110UK
■ Veuillez lire attentivement le mode d’emploi avant la mise en marche, et conservez-le bien.
■ Les produits peuvent être sujets à modification sans préavis.
Réfrigérateur domestique à 2 portes
Mode d’emploi
TCL Home Appliances (Hefei) Co., Ltd.
Adresse: 10 rue Yunhu, zone de développement économique,
ville de Hefei, province d’Anhui, Chine
FR
1. et appareil n’est pas destiné à être utilisé par des personnes (incluant les enfants) à C
capacités physiques, sensorielles ou mentales réduites, ou manquant d’expériences et de
connaissances, à moins d’être surveillé ou avoir reçu des instructions concernant l’utilisation de
l’appareil par une personne responsable de leur sécurité. Les enfants doivent être surveillés afin
de s’assurer qu’ils ne s’amusent pas avec l’appareil.
2. i le cordon d’alimentation est endommagé, il doit être remplacé par le fabricant, son agent deS
service ou tout autre personne qualifiée similaire dans le but d’éviter tout danger.
3. et appareil peut être utilisé par des enfants âgés de 8 ans et plus ainsi que par les personnesC
à capacités physiques, sensorielles ou mentales réduits ou manquant d’expériences et de
connaissances étant surveillées ou ayant reçu des instructions concernant l’utilisation de
l’appareil de manière sûre et comprenant les dangers impliqués. Les enfants ne doivent pas
s’amuser avec l’appareil. Le nettoyage et l’entretien par l’utilisateur ne doivent pas être faits par
un enfant sans surveillance.
4. VERTISSEMENT: veuillez garder les ventilations de l’appareil se trouvant dans le boîtier deA
l’appareil ou dans la structure intégrée libres de toute obstruction.
5. VERTISSEMENT: N’utilisez aucun appareil mécanique ou aucun autre moyen afinA
d’accélérer le processus de dégivrage autres que ceux recommandés par le fabricant.
6. VERTISSEMENT: N’endommagez pas le circuit réfrigérant.A
7. VERTISSEMENT: N’utilisez pas d’appareils électriques à l’intérieur des compartiments deA
stockage des aliments de l’appareil à moins qu’ils soient du type recommandé par le fabricant.
8. e stockez aucune substance explosive telle que des bombes aérosols avec un propulseurN
inflammable dans cet appareil.
9. et appareil est destiné à être utilisé dans une maison ou pour des applications similairesC
telles que:
– ones de cuisine du personnel de magasins, de bureaux et autres environnements de travail;Z
– ermes et par les clients d’hôtels, de motels et autres environnement de type résidentiel;F
– nvironnements de type gîte touristique;E
– estauration et applications similaires non commerciales.R
P5
P6
P7
P8
P8
P11
P11
P12
P12
P13
P13
P14
P14
P2
Sommaire
Merci d’avoir acheté un réfrigérateur TCL. Nous exprimons par la présente nos
remerciements. N’hésitez pas à utiliser notre réfrigérateur TCL. Nous ferons de
notre mieux pour vous fournir un service de qualité.
Consignes de sécurité......................................................................................................................
Présentation du produit ...................................................................................................................
Manipulation et placement ...........................................................................................................
Préparations avant utilisation .....................................................................................................
Indications de fonctionnement ...................................................................................................
Illustration et fonctionnement du panneau d’affichage ......................................
Conservation de l'aliment .....................................................................................................
Fabrication de glaçons ...........................................................................................................
Méthode de montage et démontage des accessoires .........................................
Entretien ..................................................................................................................................................
Échec de l’analyse .............................................................................................................................
Aucun échec ..........................................................................................................................................
Paramètres techniques ..................................................................................................................
Liste de colisage ..................................................................................................................................
FR
Consignes de sécurité
1. Avertissement
Avertissement: Aucune barrière ne doit être installée autour de l’appareil ou dans la
structure afin d’assurer une bonne ventilation.
Avertissement: Il est interdit d’accélérer le processus de dégivrage avec un équipement
mécanique ou une autre méthode autre que la méthode recommandée par le fabricant.
Avertissement: N’endommagez jamais le circuit réfrigérant.
Avertissement: N’utilisez jamais d’appareils électriques dans le compartiment à aliments
de l’appareil à l’exception de ceux du type recommandé par le fabricant.
Avertissement: Ne placez jamais de boisson liquide ou de nourriture contenue dans un
récipient en verre dans la partie du congélateur par crainte de fissuration.
Avertissement: Si le réfrigérateur se retrouve hors tension, il doit être redémarré 5 minutes
plus tard pour éviter d’endommager le compresseur.
Avertissement: Si une pièce sous tension, un bruit anormal, une odeur, une fumée ou autre
anormalité est trouvée pendant l’utilisation de l’appareil. Il est nécessaire de le mettre
immédiatement hors tension et de contacter le département du service après-vente de la
compagnie en temps voulu.
Avertissement: Ne placez jamais votre doigt ou votre main sous le réfrigérateur,
spécialement vers la partie arrière; Dans le cas contraire, vous risquez de vous blesser avec la
partie tranchante.
Avertissement: Les enfants ne doivent pas s’amuser ou grimper sur le réfrigérateur.
L’emploi de l’appareil doit se faire sous la surveillance de leurs parents pour éviter tout danger.
Avertissement: Ne placez jamais votre main entre les portes que ce soit pour ouvrir ou
fermer la porte pour éviter de coincer votre doigt. La poignée de la porte doit être utilisée pour
ouvrir et fermer la porte.
Avertissement: Sous les types de climat SN, N et ST, la plage ambiante d’utilisation de
l’appareil est de 10°C~38°C; sous les types de climat SN, N, ST et T, la plage ambiante
d’utilisation de l’appareil est de 10°C~43°C. Si l’appareil fonctionne en dehors des plages de
température ambiante des types de climat concerné, l’appareil pourrait ne pas maintenir la
température intérieure souhaitée.
FR
ertsseet: Rse ee/atre aae
ertsseet: orse os ae aare, assre-os e e oro aetato
est as o o eoa.
ertsseet: Ne ae as e t-rses o e os aetato ortae arrre
e aare.
es efats s e 3 8 as sot atorss rer et er es aares e rfrrato.
oertre e a orte eat e oes roes et aser e aetato ortate
e a teratre as es oartets e aare.
Nettoe rreet es srfaes eet tre e otat ae a orrtre as e es
sstes e raae aesses.
Nettoe es rserors ea ss ot as t tss eat 48 eres; re e sste e
strto ea oet e sore ea s ea a as t tse eat 5 ors.
Stoe a ae frae et e osso as es oteats arors as e rfrrater e
fao e s etret as e otat o sottet sr atres aets.
es oartets or aets sres 2 toes oeet a stoae e a orrtre
r-sree, a stoae o a farato e aes et a farato e aos.
es oartets 1, 2 et 3 toes e oeet as or a oato aets fras.
S aare e rfrrato est ass e eat e oes roes, ette-e ors
teso, re-e, ettoe-e, se et asse a orte oerte a ter e
eoeet e osssres trer e aare.
tteto: aetato e e rot ot tre ofore aetato etoe sr a
ae sate, et e rse eate 3 tros ot tre tse (srere 10, et
se terre orreteet). e rse e ot as tre arta ar s se aare; as
e as otrare, ee orrat tre roo ar e sraffe.
tteto : Ne tre aas e e aetato a a. I est essare e ter et e
raer e oeter aetato e a rse or oeter aetato. e oro
aetato o e oeter e oet as tre tos ar e a oe or ter
tote etroto.
tteto : e oro aetato e ot as tre o ar e rfrrater o tote atre
are ore, et e oro aetato e ot as tre te a a.
eoaeet o e eet oro aetato et etraer ee o
e etroto. S e oro aetato est ass o o, ee otater e
arteet sere ars-ete ateet.
tteto : e atre aae, eose, orrose o e atre aae est
atorse trer rfrrater.
3
FR
This manual suits for next models
1
Table of contents
Languages:
Other TCL Refrigerator manuals
