TCL RP470CSF0 User manual

RP470CSF0
No-frost Cross Door Refrigerator

EN
10.This product contains a light source of energy efficiency class F for light source ERP,
test with(without) light cover.
Safe recovery instructions
Description of climate types
P2
P5
P6
P7
P8
P8
P11
P12
P13
P14
P14
P13
P15
P15

EN

EN

EN

EN
5

EN
6

EN
678 833
＞L1+100 ＞W1+200 ＞L1+450 ＞W1+450
This refrigerating appliance is not intended to be used as a built-in
appliance
7
Preparations prior to use
1. Remove all packing assemblies such as case fixing tape etc., especially the foam base.
2. Use warm wet cloth to clean both interior and exterior of the refrigerator, (neutral detergent can
be added in warm water).
3. After leveling and cleaning the refrigerator, stand it for about 2 hours before plugging the power
plug for powering on, and cool the refrigerator for 2 to 3 hours before storing foods.
1. Remove fixing tape 2. Connect to power 3. Store food after
connecting to power
for 2-3 hours
Wipe with
warm and
wet cloth
In hot summer, 24 hours are
needed to fully freeze the food.
Check the refrigerating condition
on the second day.
Do not open the
doors frequently
to save electricity.
The plastics deodorant will disappear
automatically after freezing for a while.

EN
The appliance should be located in the coolest area of the room, away from heat producing appliances or
heating ducts, and out of the direct sunlight.
Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the
compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts down
on frost build-up inside the appliance.
Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with
cold air circulation, making the appliance less efficient.
Organize and label food to reduce door openings and extended searches. Remove as many items as needed
at one time, and close the door as soon as possible.
Please refer to the product introduction picture on page 5 for the placement of accessories.
8
Refrigerating Chamber
Freezing Chamber
Temperature Display
Temperature Down Button
Fast Cooling Mode
Smart Mode
Child Lock Mode
Function Selection
Temperature Up Button
Fast Freezing Mode
Holiday Mode
Energy Saving Mode
Fridge/Freezer Temperature
Zone Choose Button

EN
9
First power-on
After first power-on, the refrigerator shall operate with the cold chamber set at 5℃and the
freezing chamber set at -18℃.
Hand temperature regulating function
When no button on the display panel is operated within 30s, the display panel will go out, and
the keyboard will be locked automatically. When the display panel is off, first press the button
to awake the display, press the zone button for 3s for unlocking, and then press the button to
activate the button function.
Temperature regulation of cold chamber (2℃~8℃)
When the display panel is unlocked, press the zone button repeatedly until the cold chamber
icon flashes, and then press or button to regulate the temperature of cold chamber.
Afterwards, every pressing the button can increase the temperature by 1℃; or every pressing
the button can decrease the temperature by 1℃. The cold chamber temperature circulates
as per "02"- "03" -"04" - "05" - "06" - "07" - "08" - "02". After the suitable temperature is selected,
and the button is not operated any more, the set temperature will be confirmed 5s later.
Temperature regulation of freezing chamber (-22℃~ -15℃)
When the display panel is unlocked, press the zone button repeatedly until the freezing chamber
icon flashes, and then press or button to regulate the temperature of freezing chamber.
Afterwards, every pressing the button can increase the temperature by 1℃; or every pressing
the button can decrease the temperature by 1℃. The freezing chamber temperature circulates
as per “-22” - “-21” - “-20” - “-19” - “-18” - “-17” - “-16” - “-15”- “-22”. After the suitable temperature
is selected, and the button is not operated any more, the set temperature will be confirmed 5s later.
Fast cooling function
When the display panel is unlocked, press the Function button repeatedly until the “ "
icon flashes, and then stop operating any button and wait for 5s to activate the fast
cooling function of cold chamber. Such operation can quit the fast cooling function by hand.
The fast cooling function operates for 2h, and then stops automatically.
When the “Fast cooling” function is active, the cold chamber temperature is controlled at 2℃;
during this period, the temperature setting of cold chamber cannot be selected or amended
until the fast cooling function is deactivated. (Under the fast cooling mode, the setting of
other function may quit the fast cooling function automatically; the fast cooling function is
deactivated automatically after the cold chamber door is opened for more than 3min.)
Fast freezing function
When the display panel is unlocked, press the Function button repeatedly until the “ ”
icon flashes, and then stop operating any button and wait for 5s to activate the fast
freezing function of freezing chamber. Such operation can quit the fast freezing function by
hand. After the fast freezing function is activated, the refrigerator will start the strong freezing
for 4h, and then stop the fast freezing automatically.
When the “Fast freezing” function is active, the temperature setting of freezing chamber
cannot be selected or amended, and the shown temperature is -24℃until the fast freezing
function is deactivated. (Under the fast freezing mode, the setting of other function may quit
the fast freezing function automatically; the fast freezing function is deactivated
automatically after the freezing chamber door is opened for more than 3min.)

EN
10
Smart function
When the display panel is unlocked, press the Function button repeatedly until the “ ”
icon flashes, and then stop operating any button and wait for 5s to activate the smart function.
Such operation can quit the smart function by hand. After the smart function is activated, the
refrigerator can monitor the state of each chamber and operate with the highest efficiency.
Under the smart mode, the refrigerator can activate the fast cooling or freezing function
automatically in accordance with the temperature rise of cold or freezing chamber. (Under the
smart mode, the setting of other function may quit the smart function automatically.)
Holiday function
When the display panel is unlocked, press the Function button repeatedly until the “ ”
icon flashes, and then stop operating any button and wait for 5s to activate the holiday
function. Such operation can quit the holiday function by hand. (Under the holiday mode, the
setting of other function may quit the holiday function automatically.) (Notice: Please take the
food out from the cold chamber before the holiday function is activated.)
When the “Holiday” function is active, the cold chamber is turned off, and the temperature
setting of cold chamber is OF.
Child lock function
When the display panel is unlocked, activate the “ ”function.
” icon flashes; 5s Manual start: press the Function button repeatedly until the “
later, the “ ” icon light goes on and the keyboard is locked;
Automatic start: If no button on the display panel is operated in 30s, the child lock function is
activated automatically, the “ ” icon goes on, and the keyboard is locked.
” icon light goes on, pressing the zone button for Quit the child lock: When the “
3s will unlock the child lock.
Energy saving function
” When the display panel is unlocked, press the Function button repeatedly until the “
icon flashes, and then stop operating any button and wait for 5s to activate the energy
saving function. Such operation can quit the energy saving function by hand. When the
“Energy saving” function is active, the residual words on the display panel are off.
Power-off memory
In case of power failure, the operating state at the moment of power failure will be locked; after
the power supply recovers, the refrigerator will operate under the settings before power
failure.
Door-open warning
If the door of cold or freezing chamber is not closed tightly or is opened for more than 1min, the
“beeping” warning will appear, be halted by operating any button, but recovered 1min later, or
be eliminated by closing the door of cold or freezing chamber tightly.
Over-temperature hint of freezing chamber
If the temperature of freezing chamber is above -12℃ when the refrigerator is powered on, the
corresponding temperature zone indicating box of freezing chamber will light on, and the
digital zone will flash. When any button is pressed, the temperature of freezing chamber at the
moment of power on will be shown; if the button is pressed again or 10s later, the normal
display will recover.

EN
11

EN
12
Changing the Light
Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its
service agent or similar qualified person.

EN
13

EN
RP470CSF0
SN/N/ST/T
I
301L
3W
1.25A
R600a,68g
220-240V〜/50Hz
8kg/24h
95kg
833x678x1860mm
470L
169L
368 kWh/a
Energy consumption E16
Energy consumption E32
Auxiliary energy consumption
14
40dB(A)
0.487 kWh/24h
1.400 kWh/24h
23.468 kWh/a
RP470CSF0

Symbol
ST
N
SN
Ambient temperature ranges℃
+ 10 to + 32
+ 16 to + 32
+ 16 to + 38
+ 16 to + 43T
Class
Extended temperate
Temperate
Subtropical
Tropical
Table 1 Climate classes
Extended temperate:‘this refrigerating appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C’;
temperate:‘this refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C’;
Subtropical:‘thisrefrigeratingapplianceisintendedtobeusedatambienttemperatures
rangingfrom16°Cto38°C’;
Tropical:‘thisrefrigeratingapplianceisintendedtobeusedatambienttemperatures
rangingfrom16°Cto43°C’;
Dear customer
if you need customer service, please check warranty card for further information.
Disposal
Old appliances still have some surplus value. An environmentally friendly approach will ensure
that valuable raw materials are recycled.
The refrigerants used in your equipment and insulation materials require special handling
procedures. Make sure there is no pipe damage on the back of the equipment before handling.
Up-to-date information on the options for disposing of old equipment and packaging from old
equipment can be obtained from the local municipal office.
Correct Disposal of this product.
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To retum your
used device, please use the return and ollection systems or contact the retailer
where the product was purchased. They can take this product for environmental
safe recycing.
Safe recovery instructions
15
Description of climate types
EN

FR
RP470CSF0

1. Cet appareil n’est pas destiné à être utilisé par des personnes (incluant les enfants) à
capacités physiques, sensorielles ou mentales réduites, ou manquant d’expériences et de
connaissances, à moins d’être surveillé ou avoir reçu des instructions concernant l’utilisation de
l’appareil par une personne responsable de leur sécurité. Les enfants doivent être surveillés afin
de s’assurer qu’ils ne s’amusent pas avec l’appareil.
2. Si le cordon d’alimentation est endommagé, il doit être remplacé par le fabricant, son agent
de service ou tout autre personne qualifiée similaire dans le but d’éviter tout danger.
3. Cet appareil peut être utilisé par des enfants âgé de 8 ans et plus ainsi que par les personnes
à capacités physiques, sensorielles ou mentales réduits ou manquant d’expériences et de
connaissances étant surveillées ou ayant reçu des instructions concernant l’utilisation de
l’appareil de manière sûre et comprenant les dangers impliqués. Les enfants ne doivent pas
s’amuser avec l’appareil. Le nettoyage et l’entretien par l’utilisateur ne doit pas être fait par un
enfant sans surveillance.
4. AVERTISSEMENT: veuillez garder les ventilations de l’appareil se trouvant dans le boîtier de
l’appareil ou dans la structure intégrée libres de toute obstruction.
5. AVERTISSEMENT: N’utilisez aucun appareil mécanique ou aucun autre moyen afin
d’accélérer le processus de dégivrage autres que ceux recommandés par le fabricant.
6. AVERTISSEMENT: N’endommagez pas le circuit réfrigérant.
7. AVERTISSEMENT: N’utilisez pas d’appareils électriques à l’intérieur des compartiments de
stockage des aliments de l’appareil à moins qu’ils soient du type recommandé par le fabricant.
8. Ne stockez aucunes substances explosives tels que des bombes aérosols avec un
propulseur inflammable dans cet appareil.
9. Cet appareil est destiné à être utilisé dans une maison ou pour des applications similaires
telles que:
–Zones de cuisine du personnel de magasins, de bureaux et autres environnements de travail;
–Fermes et par les clients d’hôtels, de motels et autres environnement de type résidentiel;
–Environnements de type gîte touristique;
–Restauration et applications similaires non commerciales.
Sommaire
M
erci d’avoir acheté un réfrigérateur TCL. Nous exprimons par la
présente nos remerciements.

N’hésitez pas à utiliser notre réfrigérateur TCL. Nous ferons de notre
mieux pour vous fournir un service de qualité.
FR
10.Ce produit contient une source lumineuse de classe d'efficacité énergétique F.Pour la source
lumineuse ERP, il est testé avec (sans) couvercle de lumière.
Directive sur le recyclage sûr
Description du type de climat
P2
P5
P6
P7
P8
P8
P11
P12
P13
P14
P14
P13
P15
P15
