TCL P529SBN User manual

TCL Home Appliances (Hefei) Co., Ltd.
Address: No. 10 Yunhu Road, Economic Development Zone,
Hefei City, Anhui Province,China
Two-door Household Refrigerator
Operating Instructions
■Please carefully read the operation instructions before powering on, and keep them safe.
■Product specifications subject to change without notice.
P529SBN
P529SBS
P529SBW

1
Contents
Safety instructions ------------------------------------------------------------------------
Safety information ----------------------------------------------------------------------
Safety information -----------------------------------------------------------------
Product introduction ----------------------------------------------------------------
Handling and placement ----------------------------------------------------------------
Preparations prior to use---------------------------------------
Operation keys --------------------------------------------------------------------------
Ice-making -----------------------------------------------------------------------------
Disassembly and assembly method of accessory ---------------------------
Care and maintenance ------------------------------------------------------------------
Failure analysis ----------------------------------------------------------------------------
Non-failure ----------------------------------------------------------------------------------
P2
P5
P6
P7
P9
P8
P10
P14
P15
P15
P13
P14
P17
Technical parameter-----------------------------------------------------------------------
Packing list-----------------------------------------------------------------------------------
P16
Thank you for buying TCL refrigerator. We hereby express our thanks.
Welcome to use TCL refrigerator. We will do our best to provide you with quality
service.
1.This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.Children should be supervised to ensure that they do not play with the appliance.
2.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
3.This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
4.WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
5.WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
6.WARNING: Do not damage the refrigerant circuit.
7.WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
8.Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
9.This appliance is intended to be used in household and similar applications such as
— Sta ffkitchen areas in shops, offices and other working environments;
— Farm houses and by clients in hotels, motels and other residential type environments;
— Bed and breakfast type environments;
— Catering and similar non-retail applications.

Warning:When positioning the appliance, ensure the supply cord is not trapped or damaged.
Warning: Do not connect multiple portable socket-outlet or portable power supplies.
2
Safety instructions
1.Warning
Warning: No barrier is allowed around the appliance or in the embedded structure in
order to ensure the free ventilation.
Warning: Never damage the refrigerating circuit.
Warning: Never place liquid beverages or food contained in glass containers in the
freezing chamber as the glass container may crack.
Warning: If powered off, the refrigerator shall be powered on 5min later to reduce the
risk of damaging the compressor.
Warning: If any live part, abnormal noise, smell, smoke or other abnormality is found
during use, it is necessary to power o ffthe appliance immediately and contact the after-
sales service department of the Company timely.
Warning: Never place your finger or hand under the refrigerator, especially rear
bottom of refrigerator; otherwise, you may be hurt by sharp edges.
Warning: The children must not play or climb the refrigerator. The operation by the
children must be supervised by their parents for fear of danger.
Warning: Never place your hand between the doors to open or close door for fear of
jamming your finger. The door handle shall be used to open or close the door.
Warning: Under the rated climate types SN, N and ST, the operating ambient range of
the appliance is 10℃~38℃; under the climate types SN, N, ST and T, the operating
ambient range of the appliance is 10℃~43℃. If the appliance operates outside the rated
climate type (ambient temperature range), the appliance may not maintain the satisfying
interior temperature.
Warning:RISK OF CHILD ENTRAPMENT
Child entrapment and suffocation are not problems of the past. Junked orabandoned
refrigeration products are still dangerous – even if they will sit for "just a few days. "
If you are getting rid of your old appliance, please follow these instructions to help prevent
accidents.
Before You Throw Away Your Old Refrigeration Product:
-Take o ffthe doors.
-Leave the shelves in place so that children may not easily climb inside.
Warning:If you wish to dispose of this refrigerator, please contact your local authorities
and ask for the correct method of disposal.
Risk of Fire:The refrigerant of your refr R600a,it's highly igerator is Flamible.

3
Safety instructions
Cautions: The power cord must not be squeezed by the refrigerator or any heavy
load, and the power cord shall not be bent in an extreme position. Damaged or peeling
of the power cord may result in fire or electric shock. If the power cord is broken or cut,
please contact the after-sales service department immediately.
Cautions: No flammable or explosive matter or corrosive acid or alkaline matter is
allowed in the refrigerator.
Cautions: The refrigerator must not be used in the rain or in direct sunlight.
Cautions: It is forbidden to place the containers with fluid on top of the refrigerator
because breakage or tipping of the container may affect the electrical insulation of
refrigerator and result in electric shock or fire.
Cautions: The refrigerator must not be disassembled or modified without
permission. The repair of refrigerator must be performed by an authorized service agent
Cautions: In case of leakage of any flammable gas such as natural gas, it is
necessary to close the leaking valve first and then open the window for ventilation. Do
not unplug the refrigerator connector immediately to prevent the risk of of fire or
explosion due to an electric spark.
Cautions: Effervescent drinks should not be stored in the freezer compartments or
cabinets.
Cautions: Do not exceed the storage time(s) recommended by the food
manufacturers for any kind of food.
Cautions: Be mindful of frozen food in storage in the event of an extended non
running of the refrigerating appliance (interruption of power supply or failure of the
refrigerating system).
Cautions:Preparations need to be taken when the refrigerating appliance is
switched o ffand taken out of service temporarily or for an extended period (e.g. emptied,
cleaned and dried, and the door(s) or lid(s) propped ajar).
or qualified technician .
2.. Caution
Cautions: The power supply of this product must be uniform with the power supply
mentioned on the nameplate, and the standard independent 3-hole socket shall be used
(above 10A, and reliably grounded). One socket must not be shared by more than one
appliance; otherwise, fire may be caused due to overheating.
Cautions: Never pull the power cord by hand. It is necessary to hold and unplug the
power connector from the socket to disconnect the power supply. The power cord or
connector must not be touched by wet hands for fear of electric shock.

4
Do not place any hot items in the fridge as it may cause damage to the
plastic or operation.

5
Recycling

6
The LED Lamp is not user replaceable. Contact your service agent for more details.

7
Product introduction
Warm prompt:
Product specifications subject to change.
The pictures are for reference only. Please refer to the object
Refrigerating chamber door
Upper refrigerator glass shelf
Refrigerator bottle holder
Lower refrigerator glass shelf
Lower refrigerator drawer
Refrigerator air duct
Freezer chamber door
Upper freezer glass shelf
Freezer bottle holder
Lower freezer glass shelf
Lower freezer drawer
7

Handling and placement
The refrigerator shall be
placed in an environment
which is dry, has good
ventilation, far from direct
sunshine and heat source.
8
>30cm
>10cm >10cm
T he refrigerator shall be
placed on a flat and firm
surface. If the ground is not
flat, adjust the adjusting leg
to keep it level.
Never place the refrigerator
into a very cold environment
that may get frozen.
Do not operate the refrigerator on the foam
base it was shipped on. This will help heat
dissipation and reduce the risk of fire.
8

P529SBN
P529SBS
P529SBW
630 920 >L1+380 >W1+600
This refrigerating appliance is not intended to be used as a built-in appliance
The appliance should be located in the coolest area of the room, away from heat producing appliances or
heating ducts, and out of the direct sunlight.
Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the
compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts down
on frost build-up inside the appliance.
Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with
cold air circulation, making the appliance less efficient.
Organize and label food to reduce door openings and extended searches. Remove as many items as needed
at one time, and close the door as soon as possible.
Please refer to the product introduction picture on page 5 for the placement of accessories.
9
Preparations prior to use
1. Remove fixing tape 2. Connect to power 3. Store food after
connecting to power
for 2-3 hours
Wipe with
warm and
wet cloth
In hot summer, 24 hours are
needed to fully freeze the food.
Check the refrigerating condition
on the second day.
Do not open the
doors frequently
to save electricity.
The plastics deodorant will disappear
automatically after freezing for a while.
1.Remove all packing materials such as adhesive tape, plastic bags, etc., especially the foam base.
2.Use a warm wet cloth to clean both interior and exterior of the refrigerator, (neutral detergent
can be added to warm water).
3. After leveling and cleaning the refrigerator, keep it upright for about 2 hours before plugging in
the power for the first time.Let the refrigerator run for 2 to 3 hours before storing foods.
9

10
Operation keys
The above is the computer control board of the product
Operation and diagram of the electronic control board
10

11
Operation keys
Powered on for the first time
When it is powered on for the first time, the refrigerator will start the intelligent mode and run
at 5 °C for the refrigerator chamber and -18 °C for the freezer chamber.
Child lock function
In the unlocked state, enter the "child lock" function:
Manual temperature adjustment
When there is no key operation on the display within 30 seconds, the display will go out
Automatically turn on the child lock function: There is no key operation on the
display; after 30 seconds, the child lock function will be automatically turned on;
Exit the child lock function: When the child lock icon " ” is lit, press and hold the "long press for
3 seconds to unlock" button for 3 seconds to unlock.
the child lock icon “ ”will be lit; the keyboard will be locked;
automatically, and the keyboard will be automatically locked. When the display is o f,
press the
f
button for the first time to wake up the display; press and hold the "long press for 3
seconds to unlock" button for 3 seconds to unlock, and then press the button again to make the
button function e f
f ective.
Refrigerator chamber temperature adjustment (2°C ~ 8°C)
In the unlocked state, repeatedly press the “temperature area” button until the refrigerated
storage temperature area is lit, and then presses the "temperature" button to adjust the
temperature of the refrigerator chamber. The temperature of the refrigerator chamber should be set
between "02" - "03" - "04" - "05" - "06" - "07" - "08" - "OF" - "02". Select the appropriate
temperature which will be set after releasing the button.
Freezer chamber temperature adjustment (-24°C ~-15°C)
In the unlocked state, repeatedly press the “temperature area” button until the freeze storage
temperature area is lit, and then presses the "temperature" button to adjust the temperature of the
freezer chamber. The temperature of the freezer chamber should be set between “-24” - “-23” -“-22” - “-21”
- “-20” - “-19” - “-18” - “-17” - “-16” - “-15” - “-24”. Select the appropriate
temperature which will be set after releasing the button.
Power Cool function
When the refrigerator is under unlock state, press “function” button repeatedly till the “Power
Cool” icon blinks, after that, stop the key operation and wait for 3 seconds to enter refri gerator
chamber power cool function. You can quit the power cool function with the same operation.
The Refrigerator will automatically quit the power cool function after entering it for 2 hours.
Under “Power Cool” state, the setting temperature for the refrigerator chamber is displayed by
2°C till quitting the function. Under “Power Cool” state, when setting other functions, you may
automatically quit the power cool function. Under “Power Cool” state, you will automatically
quit the power cool function when the refrigerating door is opened over 3 minutes. (Under
“Power Cool” state, when setting other functions, you may automatically quit the power cool
function.)
Power Freezing function
When the refrigerator is under unlock state, press “function” button repeatedly till the “Power
Freezing” icon blinks, after that, stop the key operation and wait for 3 seconds to enter freezer
chamber power freezing function. You can quit the power freezing function with the same
11

12
Operation keys
operation. Once entering “Power Freezing”, the refrigerator will automatically quit the power
freezing function after it is under “Power Freezing” for 4 hours.
Under “Power Freezing” state, the setting temperature for the freezer chamber is displayed by
-32°C till quitting the function. U nder “ Power Freezing”
state, when setting other functions, you
may automatically quit the power freezing func.t i o n Under “Power Freezing” state, you will
automatically quit the power freezing function when the freezing door is opened over 3 minutes.
(Under “Power Freezing” state, when setting other functions, you may automatically quit the
power freezing function.)
Smart function
When the refrigerator is under unlock state, press “function” button repeatedly till the “smart”
icon blinks, after that, stop the key operation and wait for 3 seconds to enter intelligent function.
You can quit the smart function with the same operation. When the smart function is enabled,
the refrigerator will realize self-monitor for the state of each chamber, so as to run with the most
effective way. Under the smart state, the refrigerator many automatically enter “Power Cool” or
“Power Freeze” function according to the temperature rise in the refrigerator and freezer
chamber. (Under smart state, when setting other functions, you may automatically quit the
smart function.)
Refrigeration shutdown function
In the unlocked state, repeatedly press the “temperature area” button until the refrigerated
storage temperature zone is lit, and then presses the "temperature" button to adjust the
temperature of the refrigerator chamber. When the temperature range of the refrigerator chamber
is selected to "OF", stop the key operation, and then enter the refrigeration shutdown function.
Set the set temperature of the refrigerator chamber to non-"OF" to exit the refrigeration
shutdown function. (Under the refrigeration shutdown function, when other functions are set,
the refrigeration shutdown function may be automatically exited. Note: Before the refrigeration
shutdown function is activated, please take the food out of the refrigerator chamber.)
When the "refrigeration shutdown" function is turned on, the refrigerator chamber will enter the of f state.
Power off memory
When power goes off, the instantaneous working state at the time of power off will be locked.
After power on, it will still work according to the setting before power off.
Door alarm
If the refrigerator or freezer door is not closed tightly or stays open for more than 1 minute, beep
issue “Didi, Didi”. Press any key to pause the alarm; send an alarm again after 1 minute; close
the refrigerator or freezer door tightly to stop the alarm.
Over temperature warning of freezer chamber
When the power is switched on and the temperature in the freezer chamber is higher than -12°C, the
freezer zone indication is visible, and the display flashes. This is an indication to show that the
freezer temperature is still high, and it may be worthwhile to wait to put in frozen food to allow time for
the freezer to get cold. Press any key to display the temperature of the freezer chamber when
powered on. Press the key again, or 10 seconds later, it will return to the normal display state.
mode, press any key to exit the display protection func.tion
If there is no any key operation within 30 seconds, the refrigerator will enter the display protection function, and
the keyboard will be automatically locked. In the display protection.
Display protection function
12

13
Operation keys
Foods storage
Refrigerating chamber (2℃~8℃)
--The refrigerating chamber is mainly used for storing short-term foods, like milk, eggs and bottled
drink . s
--Vegetables, melons and fruits shall be put into the fruit and vegetable box to prevent water loss.
--The cooked foods shall be put into the refrigerator after packaging with the preservative bags, to
prevent power from increasing.
Freezing chamber (-24℃~-15℃)
--The freezing chamber is used for the foods to be stored for long-term.
--Fish and meat to be frozen shall be cut into small pieces, packaged with preservative bags
separately and then put into the frozen drawer.
--Glass containers or the sealed containers filled with liquid shall not be stored in the freezing
chamber, to prevent the risk of bursting due to freezing.
--The fresh foods shall not be stored together with the frozen foods.
--Do not place food close to inside wall in freezer lest food and wall should be frozen together.
Fill the ice tray with water , then place it in the freezer. When
the water in the ice try turns to ice, twist the ice tray and drop
the ice into a container.
13

14
It is suggested to maintain the refrigerator once per month;
--Unplug the power plug to prevent from electric shock;
--Use wet cloth or neutral detergent (cleanser essence to wipe off
the oil contamination and other dirt. Then completely wipe off the
detergent.
--Do not use alkaline detergent, soap powder, gasoline and
alcohol, talcum powder etc.; otherwise the coats or plastics may
be damaged;
--Regularly clean the refrigerator body and clear the ground dust
to keep the refrigerator clean.
Inspections after maintenance:
1. Whether there are damages to the power line and plug; 2.
Whether he power plug; 3. Whether there is there is dust on t
abnormal heat on the plug; 4. Whether the socket is loose; 5.
Whether the plug is totally inserted.
Note:
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
Care and maintenance
Please use neutral
detergent
Neut ral detergent
To remove, gently squeeze from both sides at the same
time and make sure the clips are dislodged, and then slowly lift out.
shelf

Failure analysis
15
The following items shall be inspected before occurring failures which require maintenance:
Failures:Refrigerator does not work,The refrigeration effect is poor
Causes:1. Check the connection of power supply. 2. Check whether the refrigerator is exposed to
direct sunlight or whether there is heat source nearby. 3. Check whether there is heat dissipation
space around refrigerator.
Remedies:1. Connect the power supply. 2. Move the refrigerator to a place without direct sunlight
and heat source. 3. Leave sufficient space between refrigerator and wall.
Failures:Foods in refrigerating chamber are frozen
Causes:1. Check whether the setting temperature is too low. 2. Check whether foods with too
much water are too close to the rear wall.
Remedies:1. Adequately increase the temperature. 2. Move the foods with too much water to the
door side of glass shelf
Failures:There is abnormal sound in refrigerator
Causes:1. Check whether the bottom of refrigerator is stable. 2. Check whether the refrigerator is
too close to the wall. 3. Check whether the refrigerator touches other objects.
Remedies:1. Adjust the bottom adjusting leg to stabilize the refrigerator. 2. Leave sufficient space
around refrigerator. 3. Remove the obstacles.
Failures:There is abnormal odor in refrigerator
Causes:1. Check whether the foods are sealed for storage. 2. Check whether the refrigerator is
clean. 3. Check whether the foods are stored for too long time.
Remedies:1. Sealed foods for storage. 2. Regularly clean the refrigerator. 3.Do not store foods
for too long time.
Non-failures
Phenomenon:Fever or hot on two sides and spacing part surface between refrigerating
chamber and freezing chamber.
Cause:Refrigerator pipes (condenser, anti-fog pipes) are on two sides and front part of refrigerator
for heat dissipation and to prevent from condensation.
Phenomenon:The door is too tight and not easy to open
Cause:Reopening of the door immediately after closing it is hard because hot air enters the
refrigerator and contracts to produce pressure It is easy to open the door after a while. difference.
Phenomenon:There is water ripple in refrigerator
Cause:When starting or stopping the compressor, the refrigerant will make such sound;
Water produced after defrosting will also make such sound.
Phenomenon:There is “Click” sound or tick sound in refrigerator
Cause:Shrinkage and swelling of case will make such sound;When the case is cold or the door is
opened, this sound will occur;Phenomenon:There is hum sound in refrigerator
Cause:Running of compressor will make such sound (if the refrigerator is not leveled, this sound
will be louder)
Phenomenon:There is condensation or frosting freezing chamber door surface or food
surface
Cause:Temperature or humidity around the refrigerator is high;The door is opened for too long
time;The foods with too much water are not sealed or tightly wrapped
Phenomenon:There is condensation on the built-in light surface
Cause:Light will produce heat after being lit, and the door is opened for too long time. So there is
temperature di erence, and thus the light case will have condensation.
Phenomenon:There is condensation and water mist on body
Cause:Humidity around refrigerator is high, and the moisture in the air will gather in the case to
form condensation

Technical prameter
Technical parameter
16
Model
Climate type
Electric shock resistance
Star sign
Power type
Rated current
Power consumption
Lamp power
Weight
Refrigerant and charge amount
Noise Volume
Fresh food compartment
Total Volume
Volume of Two-star Section
Dimension
T
I
3W
R600a,75g
83kg
41dB(A)
324L
181L
1.7A
220-240V〜/50Hz
399 kWh/a
505L
/
920x630x1768mm
Volume of Freezer
P529SBN
T
I
3W
R600a,75g
83kg
41dB(A)
324L
181L
1.7A
220-240V〜/50Hz
399 kWh/a
505L
/
920x630x1768mm
T
I
3W
R600a,75g
83kg
41dB(A)
324L
181L
1.7A
220-240V〜/50Hz
399 kWh/a
505L
/
920x630x1768mm
P529SBS
P529SBW

Packing list
17
4
P529SBN
4
Egg Tray
Ice Tray
P529SBS
P529SBW
4
4
4
4

Symbol Ambient temperature ranges℃
+ 16 to + 43
T
Class
Tropical
Table 1 Climate classes
Extended temperate:‘this refrigerating appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C’;
temperate:‘this refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C’;
Subtropical:‘thisrefrigeratingapplianceisintendedtobeusedatambienttemperatures
rangingfrom16°Cto38°C’;
Tropical:‘thisrefrigeratingapplianceisintendedtobeusedatambienttemperatures
rangingfrom16°Cto43°C’;
Dear customer
if you need customer service, please check warranty card for further information.
Disposal
Old appliances still have some surplus value. An environmentally friendly approach will ensure
that valuable raw materials are recycled.
The refrigerants used in your equipment and insulation materials require special handling
procedures. Make sure there is no pipe damage on the back of the equipment before handling.
Up-to-date information on the options for disposing of old equipment and packaging from old
equipment can be obtained from the local municipal office.
Correct Disposal of this product.
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To retum your
used device, please use the return and ollection systems or contact the retailer
where the product was purchased. They can take this product for environmental
safe recycing.
Safe recovery instructions
18
