TCL RT545GM1220 User manual
RT545GM1220
RT545GM1220GR
Operating Instructions
Air-cooled & Frost-free Household Refrigerator
■Please carefully read the operation instructions before power on, and keep it properly.
■The products may subject to changes without notice.
1.This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.Children should be supervised to ensure that they do not play with the appliance.
2.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
3.This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
4.WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
5.WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
6.WARNING: Do not damage the refrigerant circuit.
7.WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
8.Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
9.This appliance is intended to be used in household and similar applications such as
— Staff kitchen areas in shops, offices and other working environments;
— Farm houses and by clients in hotels, motels and other residential type environments;
— Bed and breakfast type environments;
— Catering and similar non-retail applications.
Safety instructions ------------------------------------------------------------------------ P2
Product introduction ---------------------------------------------------------------------- P5
Handling and placement -----------------------------------------------------------------
P6
Preparations prior to use ----------------------------------------------------------------
P7
Operation and diagram of display board --------------------------------------- P8
Operation keys ---------------------------------------------------------------------------- P8
Food storage --------------------------------------------------------------------------
P11
Failure analysis ---------------------------------------------------------------------------- P14
Non-failure ---------------------------------------------------------------------------------- P14
Care and maintenance ------------------------------------------------------------------ P13
P11
Circuit drawing
P15
Technical parameter
P16
----------------------------------------------------------------------
Packing list
P16
-----------------------------------------------------------------------------------
Thank you for buying TCL refrigerator. We hereby express our thanks.
Welcome to use TCL refrigerator. We will do our best to provide you with quality service.
EN
1.Warning
Warning: No barrier is allowed around the appliance or in the embedded structure in
order to ensure the free ventilation.
Warning: It is forbidden to speed up the defrosting process with any mechanical
equipment or by other method except for the method recommended by the manufacturer.
Warning: Never damage the refrigerating circuit.
Warning: Never use any electric apparatus in the food chamber of the appliance
except for the type recommended by the manufacturer.
Warning: Never place the liquid beverage or food contained with glass container in
the freezing chamber for fear of cracking.
Warning: If powered off, the refrigerator shall be powered on 5min later for fear of
damaging the compressor.
Warning: If any live part, abnormal noise, smell, smoke or other abnormality is found
during use, it is necessary to power off the appliance immediately and contact the after-
sales service department of the Company timely.
Warning: Never place your finger or hand under the refrigerator, especially rear
bottom of refrigerator; otherwise, you may be hurt by the sharp matter.
Warning: The children must not play or climb the refrigerator. The operation by the
children must be supervised by their parents for fear of danger.
Warning: Never place your hand between the doors to open or close door for fear of
jamming your finger. The door handle shall be used to open or close the door.
Warning: Under the rated climate types SN, N and ST, the operating ambient range of
the appliance is 10℃~38℃; under the climate types SN, N, ST and T, the operating
ambient range of the appliance is 10℃~43℃. If the appliance operates outside the rated
climate type (ambient temperature range), the appliance may not maintain the satisfying
interior temperature.
EN
3
Safety instructions
Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances
Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
Clean regularly surfaces that can come in contact with food and accessible drainage systems.
Clean water tanks if they have not been used for 48 h; flush the water system connected to a
water supply if water has not been drawn for 5 days.
Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact
with or drip onto other food.
Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making ice-cream and making ice cubes.
One-, two- and three-star compartments are not suitable for the freezing of fresh food.
If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould developing within the appliance.
Warning: When positioning the appliance, ensure the supply cord is not trapped or
damaged.
Warning Risk of fire / flammable materials:
Warning: Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.
2. Cautions
Cautions: The power supply of this product must be uniform with the power supply
mentioned on the nameplate, and the standard independent 3-hole socket shall be used
(above 10A, and reliably grounded). One socket must not be shared by more than one
appliance; otherwise, fire may be caused due to overheat.
Cautions: Never pull the power wire by hand. It is necessary to hold and unplug the
power connector from the socket to disconnect the power supply. The power wire or
connector must not be touched by the wet hand for fear of electric shock.
Cautions: The power wire must not be squeezed by the refrigerator or any heavy
load, and the power wire shall not be bent extremely. The damage or peeling of power
wire may result in fire or electric shock. If the power wire is broken or cut, please contact
the after-sales service department immediately.
Cautions: No flammable or explosive matter or corrosive acid or alkaline matter is
allowed in the refrigerator.
EN
Cautions: The refrigerator must not be used in the rain or under the sunshine.
Cautions: It is forbidden to place the container with fluid on the refrigerator because
the breakage or turnover of the container may affect the electrical insulation of
refrigerator and result in electric shock or fire.
Cautions: The refrigerator must not be disassembled or modified without
permission. The repair of refrigerator must be performed by the specialist.
Cautions: In case of leakage of any flammable gas such as coal gas, it is necessary
to close the leaking valve first and then open the window for ventilation, and forbidden to
unplug the refrigerator connector immediately for fear of fire or explosion due to electric
spark.
Cautions: Refrigerating appliances – in particular a refrigerator-freezer Type I –
might not operate consistently (possibility of defrosting of contents or temperature
becoming too warm in the frozen food compartment) when sited for an extended period
of time below the cold end of the range of temperatures for which the refrigerating
appliance is designed;
Cautions: The fact that effervescent drinks should not be stored in food freezer
compartments or cabinets or in low-temperature compartments or cabinets, and that
some products such as water ices should not be consumed too cold.
Cautions: The need to not exceed the storage time(s) recommended by the food
manufacturers for any kind of food.
Cautions: The precautions necessary to prevent an undue rise in the temperature of
the frozen food while defrosting the refrigerating appliance, such as wrapping the frozen
food in several layers of newspaper.
Cautions: The fact that a rise in temperature of the frozen food during manual
defrosting, maintenance or cleaning could shorten the storage life.
Cautions: The care required with regard to frozen food in storage in the event of an
extended non-running of the refrigerating appliance (interruption of power supply or
failure of the refrigerating system).
Cautions: The action to be taken when the refrigerating appliance is switched off
and taken out of service temporarily or for an extended period (e.g. emptied, cleaned
and dried, and the door(s) or lid(s) propped ajar).
4
EN
Refrigerating door bottle
bracket
5
EN
6
EN
7
RT545GM1220
EN
RT545GM1220GR
8
EN
9
EN
10
EN
11
EN
12
EN
13
EN
Failure analysis
The following items shall be inspected before occurring failures which require maintenance:
Failures:Refrigerator does not work,The refrigeration effect is poor
Causes:1. Check the connection of power supply. 2. Check whether the refrigerator is exposed to
direct sunlight or whether there is heat source nearby. 3. Check whether there is heat dissipation
space around refrigerator.
Remedies:1. Connect the power supply. 2. Move the refrigerator to a place without direct sunlight
and heat source. 3. Leave sufficient space between refrigerator and wall.
Failures:Foods in refrigerating chamber are frozen
Causes:1. Check whether the setting temperature is too low. 2. Check whether foods with too
much water are too close to the rear wall.
Remedies:1. Adequately increase the temperature. 2. Move the foods with too much water to the
door side of glass shelf
Failures:There is abnormal sound in refrigerator
Causes:1. Check whether the bottom of refrigerator is stable. 2. Check whether the refrigerator is
too close to the wall. 3. Check whether the refrigerator touches other objects.
Remedies:1. Adjust the bottom adjusting leg to stabilize the refrigerator. 2. Leave sufficient space
around refrigerator. 3. Remove the obstacles.
Failures:There is abnormal odor in refrigerator
Causes:1. Check whether the foods are sealed for storage. 2. Check whether the refrigerator is
clean. 3. Check whether the foods are stored for too long time.
Remedies:1. Sealed foods for storage. 2. Regularly clean the refrigerator. 3.Do not store foods
for too long time.
Non-failures
Phenomenon:Fever or hot on two sides and spacing part surface between refrigerating
chamber and freezing chamber.
Cause:Refrigerator pipes (condenser, anti-fog pipes) are on two sides and front part of refrigerator
for heat dissipation and to prevent from condensation.
Phenomenon:The door is too tight and not easy to open
Cause:Reopening of the door immediately after closing it is hard because hot air enters the
refrigerator and contracts to produce pressure difference. It is easy to open the door after a while.
Phenomenon:There is water ripple in refrigerator
Cause:When starting or stopping the compressor, the refrigerant will make such sound;
Water produced after defrosting will also make such sound.
Phenomenon:There is “Click” sound or tick sound in refrigerator
Cause:Shrinkage and swelling of case will make such sound;When the case is cold or the door is
opened, this sound will occur;Phenomenon:There is hum sound in refrigerator
Cause:Running of compressor will make such sound (if the refrigerator is not leveled, this sound
will be louder)
Phenomenon:There is condensation or frosting freezing chamber door surface or food
surface
Cause:Temperature or humidity around the refrigerator is high;The door is opened for too long
time;The foods with too much water are not sealed or tightly wrapped
Phenomenon:There is condensation on the built-in light surface
Cause:Light will produce heat after being lit, and the door is opened for too long time. So there is
temperature difference, and thus the light case will have condensation.
Phenomenon:There is condensation and water mist on body
Cause:Humidity around refrigerator is high, and the moisture in the air will gather in the case to
form condensation
14
EN
15
TemperatureCompensated Heater
The power plug
PTC Relay
Overloading Protector
Operating
Capacitor
Compressor
Control Line
Null Line
Display panel
Temperature Fuse
Defrost Heater
Master
Control
Board
Temperature Fuse
Freezing Fan
Electrical Damper
Refrigerating Door Switch
Temperature Sensor
Refrigerating Led
Freezing Led
Freezing Door Switch
Damper Heater
MMM
Air Swing Motor
Atmosphere Led
Refrigerating chamber door Led
EN
16
RT545GM1220
RT545GM1220
EN
RT545GM1220GR
RT545GM1220GR
0DWHULDOQXPEHU%781
(GLWLRQ$
EN
0RGHG¶HPSORL
5pIULJpUDWHXUGRPHVWLTXHDYHFUHIURLGLVVHPHQW
SDUDLUHWVDQVJLYUH
Ŷ9HXLOOH]OLUHDWWHQWLYHPHQWOHPRGHG¶HPSORLDYDQWODPLVHHQPDUFKHHWFRQVHUYH]OHELHQ
Ŷ/HVSURGXLWVSHXYHQWrWUHVXMHWVjPRGL¿FDWLRQVDQVSUpDYLV
7&/+RPH$SSOLDQFHV+HIHL&R/WG
$GUHVVHUXH<XQKX]RQHGHGpYHORSSHPHQWpFRQRPLTXH
YLOOHGH+HIHLSURYLQFHG¶$QKXL&KLQH
FR
RT545GM1220
RT545GM1220GR
&HWDSSDUHLOQ¶HVWSDVGHVWLQpjrWUHXWLOLVpSDUGHVSHUVRQQHVLQFOXDQWOHVHQIDQWVj
FDSDFLWpVSK\VLTXHVVHQVRULHOOHVRXPHQWDOHVUpGXLWHVRXPDQTXDQWG¶H[SpULHQFHVHWGH
FRQQDLVVDQFHVjPRLQVG¶rWUHVXUYHLOOpRXDYRLUUHoXGHVLQVWUXFWLRQVFRQFHUQDQWO¶XWLOLVDWLRQGH
O¶DSSDUHLOSDUXQHSHUVRQQHUHVSRQVDEOHGHOHXUVpFXULWp/HVHQIDQWVGRLYHQWrWUHVXUYHLOOpV
D¿QGHV¶DVVXUHUTX¶LOVQHV¶DPXVHQWSDVDYHFO¶DSSDUHLO
6LOHFRUGRQG¶DOLPHQWDWLRQHVWHQGRPPDJpLOGRLWrWUHUHPSODFpSDUOHIDEULFDQWVRQDJHQW
GHVHUYLFHRXWRXWDXWUHSHUVRQQHTXDOL¿pHVLPLODLUHGDQVOHEXWG¶pYLWHUWRXWGDQJHU
&HWDSSDUHLOSHXWrWUHXWLOLVpSDUGHVHQIDQWVkJpGHDQVHWSOXVDLQVLTXHSDUOHVSHUVRQQHV
jFDSDFLWpVSK\VLTXHVVHQVRULHOOHVRXPHQWDOHVUpGXLWVRXPDQTXDQWG¶H[SpULHQFHVHWGH
FRQQDLVVDQFHVpWDQWVXUYHLOOpHVRXD\DQWUHoXGHVLQVWUXFWLRQVFRQFHUQDQWO¶XWLOLVDWLRQGH
O¶DSSDUHLOGHPDQLqUHVUHHWFRPSUHQDQWOHVGDQJHUVLPSOLTXpV/HVHQIDQWVQHGRLYHQWSDV
V¶DPXVHUDYHFO¶DSSDUHLO/HQHWWR\DJHHWO¶HQWUHWLHQSDUO¶XWLOLVDWHXUQHGRLWSDVrWUHIDLWSDUXQ
HQIDQWVDQVVXUYHLOODQFH
$9(57,66(0(17YHXLOOH]JDUGHUOHVYHQWLODWLRQVGHO¶DSSDUHLOVHWURXYDQWGDQVOHERvWLHU
GHO¶DSSDUHLORXGDQVODVWUXFWXUHLQWpJUpHOLEUHVGHWRXWHREVWUXFWLRQ
$9(57,66(0(171¶XWLOLVH]DXFXQDSSDUHLOPpFDQLTXHRXDXFXQDXWUHPR\HQD¿Q
G¶DFFpOpUHUOHSURFHVVXVGHGpJLYUDJHDXWUHVTXHFHX[UHFRPPDQGpVSDUOHIDEULFDQW
$9(57,66(0(171¶HQGRPPDJH]SDVOHFLUFXLWUpIULJpUDQW
$9(57,66(0(171¶XWLOLVH]SDVG¶DSSDUHLOVpOHFWULTXHVjO¶LQWpULHXUGHVFRPSDUWLPHQWVGH
VWRFNDJHGHVDOLPHQWVGHO¶DSSDUHLOjPRLQVTX¶LOVVRLHQWGXW\SHUHFRPPDQGpSDUOHIDEULFDQW
1HVWRFNH]DXFXQHVVXEVWDQFHVH[SORVLYHVWHOVTXHGHVERPEHVDpURVROVDYHFXQ
SURSXOVHXULQÀDPPDEOHGDQVFHWDSSDUHLO
&HWDSSDUHLOHVWGHVWLQpjrWUHXWLOLVpGDQVXQHPDLVRQRXSRXUGHVDSSOLFDWLRQVVLPLODLUHV
WHOOHVTXH
±=RQHVGHFXLVLQHGXSHUVRQQHOGHPDJDVLQVGHEXUHDX[HWDXWUHVHQYLURQQHPHQWVGHWUDYDLO
±)HUPHVHWSDUOHVFOLHQWVG¶K{WHOVGHPRWHOVHWDXWUHVHQYLURQQHPHQWGHW\SHUpVLGHQWLHO
±(QYLURQQHPHQWVGHW\SHJvWHWRXULVWLTXH
±5HVWDXUDWLRQHWDSSOLFDWLRQVVLPLODLUHVQRQFRPPHUFLDOHV
&RQVLJQHVGHVpFXULWp 3
3UpVHQWDWLRQGXSURGXLW
3
0DQLSXODWLRQHWSODFHPHQW
3
3UpSDUDWLRQVDYDQWXWLOLVDWLRQ
3
)RQFWLRQQHPHQWHWVFKpPDGXSDQQHDXG¶DffiFKDJH 3
7RXFKHVG¶RSpUDWLRQ 3
&RQVHUYDWLRQGHVDOLPHQWV
3
eFKHFGHO¶DQDO\VH3
$XFXQpFKHF
3
(QWUHWLHQHWPDLQWHQDQFH
3
3
6FKpPDGXFLUFXLW
3
3DUDPqWUHVWHFKQLTXHV
3
/LVWHGHFROLVDJH
3
0HUFLG¶DYRLUDFKHWpXQUpIULJpUDWHXU7&/1RXVH[SULPRQVSDUODSUpVHQWHQRVUHPHUFLHPHQWV
1¶KpVLWH]SDVjXWLOLVHUQRWUHUpIULJpUDWHXU7&/1RXVIHURQVGHQRWUHPLHX[SRXUYRXVIRXUQLUXQVHUYLFHGHTXDOLWp
Sommaire
)DEULFDWLRQGHJODoRQV
FR
This manual suits for next models
1
Table of contents
Languages:
Other TCL Refrigerator manuals
