TCL L32P60-MT10L-L User manual

4#,
3%26)#%-!.5!,
















L32P60-MT10L-LA
 #AUTION
………………… ………………… …………………… ………………

 SPECIFICATION
………………… …………………… ………………… …………

  !LIGNMENT0ROCEDURE
……… ………………… ………………… ……………


ˊ
"LOCKDIAGRAM
……… ………………… …………………… …………………


ˊ
3CHEME$IAGRAM
……………… ………………… …………………… ……

 4ROUBLESHOOTING
………………… ………………… …………………… ……

 0#",AYOUT 
…………… …………………… ………………… ……………




4HISM ANUALI ST HEL ATESTAT T HET IMEOF PR INTING ANDDOE S NOT
INCLUDETHEMODIFICATIONWHICHMAYBEMADEAFTERTHEPRINTINGBY
THECONSTANTIMPROVEMENTOFPRODUCT

CA UTION: TO RE DUCE THE RIS K OF
ELECTR ICA L SHOCK, DO NOT RE MOVE
COVER (OR BACK). NO USER SERVIC EABLE
PAR TS INS IDE . RE FER SER VIC ING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CA U T ION
RISK
RISK OF
ELECTRI
ELECTRIC
SHOCK
SHOCK DO
NOT
NOT
OPEN.
OPEN.
2
dangerous
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SCHNEIDER ELECTRONICS GMBH-GERMANY
1. CAUTION
2

1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Sa ve these instructions for later use . Follo w all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
3
SCHNEIDER ELECTRONICS GMBH-GERMANY
IMPORTANT SAFETY INSTRUCTIONS
FOR YOUR PERSONAL SAFETY
3

11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s
4
SCHNEIDER ELECTRONICS GMBH-GERMANY
PROTECTION AND LOCATION OF YOUR SET
PROTECTION AND LOCATION OF YOUR SET
4

18. This television set should be operated only from the type of power source indicated on the marking label.If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
21. If you are unable to restorenormal operation by followingthe detailedprocedurein your operatinginstructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
24. Do not use attachments not recommendedby the television set manufacturer as they may cause hazards.
25. When replacementparts are required, be sure the service technicianhas used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
off
5
SCHNEIDER ELECTRONICS GMBH-GERMANY
OPERATION OF YOUR SET
IF THE SET DOES NOT OPERATE PROPERLY
FOR SERVICE AND MODIFICATION
5

EM BUSINESS CENTER
FTV PRODUCT MANAGEMENT DEPT.
SPECIFICATION RELEASE
Version: V0.1 Issued Date: 2011.05.08
Panel Size (inch) 32''
Category LCD TV
Aspect Ratio 16:9
Color Temperature Warm / Normal / Cool SIGNAL FORMAT CAPABILITY
Backlight Adjustable Yes Component Video Format Y, Pb/Cb, Pr/Cr; Up to 1080P.
Scaler Mode Auto,Full Screen,NormalˈZoom DVI Video Format Yes
Picture Effect UserˈCinemaˈSportˈVividˈHi-Bright HDMI Video Format Up to 1080P
Picture Enhancement PC Compatibility Up to UXGA@60Hz
Comb Filter 3D TERMINALS
Core Technology High-quality scaling engine & 3-D video de-interlacer Audio/CVBS Input (Composite) 1 R/L+2 Video: AV1(side), AV2
CCS -- S-Video Input --
DCDi
TM
-- Audio Input for S-Video --
Blue Stretch Yes YPbPr Input 1
Black Stretch Yes Audio Input for YPbPr 1
Motion Compensation Yes YCbCr Input Share with "YPbPr"
DLTI Yes Audio Input for YCbCr Share with Audio for "YPbPr"
DCTI Yes VGA Input(RGB) 1 (D-Sub,15 Pins)
Dynamic Skin Correction Yes Audio Input for RGB ĭPP
DNR Yes DVI Share with "HDMI"
Other features Dynamic Back Light, Noise Reduction. Audio Input for DVI Share with Audio for "VGA"
Panel Specification HDMI 3; HDMI1, HDMI2,HDMI3
Panel supplier SAMSUNG Audio/CVBS Output (Composite) 1 (R/L+CVBS) (RCA)
Viewing Technology -- SPDIF Output 1 (RCA)
Display Resolution 1366*768 Headphone Output ĭPP
Brightness (cd/m2) 450 RF Input 2 (Antenna, Cable)
Contrast Ratio 4000:1 USB 2;USB1,USB2
Response Time 9ms BASIC INFO.
Viewing Angle (H/V) 89°/89° TV System (Analog) NTSC-M, PAL-M/N
Life Time 50,000 hrs (min) TV System (Digital) ISDB-T
Color 16.7M (8 bit) AV System PAL, NTSC
SOUND TV Channels (Analog) Cable (1125), Antenna (269)
Speakers Integrated speakers TV Channels (Digital) Antenna (769)
Audio Power Output 8W+8W Chassis MT10L-LA
Sound Processing BTSC (SAP, Stereo, Mono) Certification CB
DVSS (Dolby Virtual Surround) -- Power Supply AC 100V-240V 50/60Hz
DDAS (Digital Dynimic Audio System) -- Power Consumption (TV on) 170W
Smart Volume -- Power Consumption (Standby) İ1W
BBE -- Default Color of Front Cabinet Black
SRS -- Keyboard Position Side
Base Stand Detachable Yes
Unpackaged Dimension for Main Body (L*H*D) (mm)
With Base Stand (mm) 790(L)*574(W)*243.7(H)
Without Base Stand (mm) 790(L)*531.4(W)*86(H)
FUNCTION Packaged Dimension (L*H*D)
V-Chip -- Main Body (mm) 868(L)*178(W)*610(H)
CCD (Closed Caption) Yes Speaker Box --
Teletext -- Base Stand --
PIP/POP -- Net Weight (Kg) 8.8kg
Macro Vision -- Gross Weight (Kg) 11.5kg
Calendar -- Container Loading
Clock/Timers Yes 20 feet 315
Lock Yes(Channal Block,Program Block,Front Panel Lock,Installation L
o
40 feet 660
OSD Language English/Spanish/Portuguese 40 feet high 745
OSD Features -- ACCESSORIES
Card Reader -- Operation Manual English (Default)
DVD Combo -- Remote Control For TV Control (With Two Batteries)
USB Connection Yes Base Stand Integrated Packaging
Game -- Speaker Box Integrated
Screen Saver -- Wall Mount 400*400
Demo Function -- Others --
HDMI CEC Yes
Picture Freeze Yes
Other Functions --
Design and specifications are subject to change without notice! Page 1 of 1
Model: L32P60/MT10L-LA/SS8P
MTS, AVC, Equalizer, Surround
Approved by:
Sound Control
Sound Features
Drafted by:
䚱亲亲
Volume, Balance, Bass Boost

Factory Alignment Specification of normal SIACP
Page 1 of 12
TCL WW R&D
FPD CENTER
Factory Alignment Specification of normal SIACP
For MT10-LA
Version 1.0
PREPARED BY : ∳䰇 DATE : 2011-4-22
APPROVEDBY: DATE:

Factory Alignment Specification of normal SIACP
Page 2 of 12
TableofContents
Feature Specification ........................................................................................................................................... 4
INFO.................................................................................................................................................................... 5
1.Electrical Assembly Alignment ........................................................................................................................ 5
1.1 Preconditions – DC/DC Check...................................................................................................................... 5
1.2 SW download ................................................................................................................................................ 5
1.3 Panel ID check and modify ........................................................................................................................... 6
1.4 Functional Test .............................................................................................................................................. 6
1.5 DDC & EDID Test......................................................................................................................................... 6
1.6 HDCP Test ..................................................................................................................................................... 7
2.Final Assembly Alignment ............................................................................................................................... 7
2.1 FactoryMenu.................................................................................................................................................. 7
2.2 Entering to “P” Mode .................................................................................................................................... 7
2.3 White Balance Alignment.............................................................................................................................. 7
2.4 High Pot. and Insulating Resistance Tests ..................................................................................................... 8
3.Factory default settings..................................................................................................................................... 8
Appendix
n
“How to download FLASH SW”................................................................................................ 11
Appendix
o
“How to upgrade FLASH SW from USB”.................................................................................... 11
Appendix
p
“Modify panel ID with RC” ......................................................................................................... 12

Factory Alignment Specification of normal SIACP
Page 3 of 12
$ISCLOSURE
The information contained in this document is proprietary to TCL SZ FPD lab and shall not be
disclosed by the recipient to third persons without the written permission of the team leader or
GM of R&D.
2EVISION(ISTORY
3TATUS6ER $ATE$RAFTER $ESCRIPTIONOFCHANGES
V1.0 2011-4-22 This is the draft version of normal SIACP
gHDMI as the main absolute input
gThe password of factory menu is 9735
gUse RC to change project ID
gWhite Balance

Factory Alignment Specification of normal SIACP
Page 4 of 12
FeatureSpecification
These chassises are designed for South America LCD TV. The main chip is from Mediatec
(MT5310 series) and supports below inputs and outputs:
class item Status MT10B-LA MT10L-LA
ATV
( PAL- M/N, NTSC-M)
¥Cable&Antenna Cable&Antenna
DTV
(SBTVD-T)
¥Antenna Antenna
HDMI
(480i/p, 576i/p, 720p up to
1080i/p, compliant v1.2. with
HDCP)
3 P300
P301
P302
P301
P302
P303
VGA 1 P406 P406
VGA/DVI audio 1 P400 P400
CMP
(YPrPb can support from 480i
up to 1080p,audio)
1P1
P455 (Audio)
P404
Side AV or back AV
(CVBS,audio)
2 P304
P404
P423
P421
USB player
(picture,video,audio)
2 P303
P401
P401
P427
Headphone output ¥P800 P800
SPDIF output Optical P405 P405
AV out 1 P498 P407
P424
P425
Input
&
Output
function
Others
VGA connector of MT5310B definition:
VGA: Pin4:RXD VGA Pin11:TXD

