TCL X10 Series User manual

X10 series
Hi!Let’s get started.
Quick start guide
Like us on Facebook
www.tcl.com/au
Customer Support:1300 738 149

Remove your TV from the box
Be careful, it’s heavy!
What’s in the box
Stand parts Stand Screws
(for 65X10)
Stand Screws
(for 75X10)
AV IN adapter cable
Power cable
Clips
Wall Screw
Remote Control
Batteries
* The remote control type may be changed without notice.
VESA Adapter Screws
Warranty Card
User manual
Quick Start Guide

SomeTV’s may besupplied without the table stand attached. This will give you the choice to either mount your TV to the supplied table stand;or to a wall using an appropriate wall
mount bracket (wall mount bracket sold separately). If you do decide to mount your TV on the supplied table stand, carefully follow the instructions supplied. (Note: For certain
models, the table stand may need to be secured to the table or hard surface using a screw (s) inserted in the specified hole in the table stand).
Keep the screws and plastic parts away from grease and organic solvents to avoid damage, especially during the assembly process
Mount the stand
12
Remove the stand cover from the TV rear cabinet. Assemble the stand bar and neck with 3 screws.
4
Put the stand cover back into place.
3
Screw the table stands tightly.

Fix the TV to the wall or pillar
To avoid Toppling
* Screw off the two upper VESA screws on the back of the TV.
* Pass the two VESA screws through the two clips and then attach them to the VESA holes on the upper middle of the rear cover.
* Pass the wall screw through the third clip and then attach them to the wall. Make sure the wall screw is attached to a stud, and properly anchored. Do not simply screw into plaster.
* Pass a string (commercially available) through the three clips.
* Tie the string tightly.
* Make sure that you use a suitable string, wire or chain that has a breaking weight that exceeds the total weight of the television. If you are unsure, please contact
TCL Customer Support who can assist.
* In order to reduce harm or injury due to falls in such situations as an earthquake or accidentally knocking the TV, please conduct the following fall prevention measures.
* Depending on the strength of the cabinet or wall where the anchoring solution is attached, the level of protection may be greatly reduced. If this is the case, please arrange adequate reinforcement.
* Fall prevention measures described below are intended to reduce harm or injury, but do not guarantee its effectiveness against all earthquakes.
* To avoid the TV from toppling, please fix the TV to a wall or pillar. Install the TV close to a wall to avoid falling backwards.
Rear Cover
Sturdy string/Chain/Wire (not included)
VESA Screw
(On the VESA Hole)
Clip
(Accessories)
Wall Screw
(Accessories)
Fixed to a wall
or a solid pillar
VESA
Screw Hole
<20cm
* Figures and illustrations in this manual are for reference only and may differ from actual product appearance.

Wall mounting
300mm
300mm

Wall mounting
1
* If you want to mount the TV to the wall, please purchase an appropriate wall mount bracket.
* Refer to the instructions of the wall mount bracket to hang the TV on the wall.
2
Screw off the four screws on the back of the TV. Screw the four VESA adapter screws into the holes.
1 2
Screw the VESA bracket tightly onto the back cover. Ready to be mounted to the wall.

Connect
ANTENNA IN
AV IN
adapter
HDMI 3
LAN HDMI 2
(SERVICE)
HDMI 1
(ARC)
DIGITAL
AUDIO OUT
(OPTICAL)
USB 2.0
5V 0.5A
USB 2.0
5V 0.5A
or
ON
OFF

HDMI
HDMI(ARC)
AV IN adapter
V
V
DIGITAL
AUDIO OUT
(OPTICAL)
LAN

HDMI
HDD
USB 2.0

Connect Smart TV
LAN
802.11
NETWORK

Initial setup
Follow the on screen instructions to finish the initial setup, then you're all set and ready to go!
*Figures and illustrations in this manual are for reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice.
2
1
2
1
Sold Separately

70-RT51AU-X101A
