TCL L49P3CFS User manual

1:1
A5
80g双胶纸
白底黑字
修改了地址
制作表编号：HZ2017-10-145R
物 料 编 号：72-MT56PS-XAPAB
内 容：说明书
型 号：49P3CFS
日 期：2017-10-20
BOM编号：H7-49P3CGS-URNB1AA
ELQ132176N
牌子名称： TCL L49P3CFS
批 次 号：
机 芯：MT56PS-AP
制作人
PREPARED BY
项目/美工 工程师
ENG.CHECKED BY:
市场业务中心确认
CONFIRM BY：
TCL多媒体科技控股有限公司
运营中心 - 制造中心 - TV一厂
TV工程部产品辅助设计室(外销)
销 往 RUSSIA 地：
：
任晓翠15986513161

Figures and illustrations in this User’s Guide are
provided for reference only and may dier from
actual product appearance. Product design and
specications may be changed without notice.
SMART TV
L49P3CFS L55P3CFS

2
Table of Contents
Chapter 1: Introduction
Precautions ............................................................... 3
Warning ................................................................... 3
Product ................................................................... 3
Power and Plug ....................................................... 3
Power Cord and Signal Cable ................................. 3
Use Environment ..................................................... 3
Cleaning................................................................... 3
Hanging the TV Set on the Wall............................... 3
Sockets...................................................................... 4
Remote Control Functions ...................................... 5
Installing Batteries..................................................... 5
Chapter 2: Getting Started
Switching on ............................................................. 6
Switching off ............................................................. 6
Network Connection................................................. 7
Network Settings ...................................................... 8
TV Controller............................................................. 9
Initial Setup ............................................................... 9
Chapter 3: Basic TV Operations
Accessing Channels .............................................. 10
Watching Connected Devices ............................... 10
Adjusting Volume ................................................... 10
Using Homepage .................................................... 10
Using TV Settings menu ........................................ 10
Selecting menu language ...................................... 10
Instant power on..................................................... 10
Automatic channel search..................................... 10
Chapter 4: Using more of your TV
Using Subtitles ....................................................... 11
Turning on/off subtitles ............................................ 11
Enabling subtitle languages on digital TV channels .. 11
Selecting a subtitle type on digital TV channels...... 11
Using Teletext ......................................................... 11
Selecting decoding page language......................... 11
Digital Teletext language ......................................... 11
Common Interface .................................................. 11
Using the common interface module....................... 11
Accessing common interface services .................... 11
T-Link ....................................................................... 12
Enabling or disabling T-Link .................................... 12
Using Auto Power on............................................... 12
Using Auto standby ................................................. 12
Reset shop ..............................................................
12
Time LED Indicator................................................. 12
Time Shift ................................................................ 12
Quick Access of Time Shift...................................... 12
PVR (Personal Video Recorder)............................... 12
Using EPG (Electronic Program Guide) .................. 13
Password in Parental Control ............................... 13
Software update...................................................... 13
Chapter 5: Other Information
Problems & Solutions ............................................ 14
Troubleshooting .....................................................15
Legal Statement...................................................... 16
Addendum Sheet.....................................................17

3
IntroductionChapter 1
Precautions
Read all of the instructions before operating the set.
Keep these instructions well for future use.
Warning
Never place a television set in an unstable location. A
television set may fall, causing serious personal injury
or death. Many injuries, particularly to children, can be
avoided by taking simple precautions such as:
-Using cabinets or stands recommended by the
manufacturer of the television set.
-Only using furniture that can safely support the
television set.
-Ensuring the television set is not overhanging the
edge of the supporting furniture.
-Not placing the television set on tall furniture
(for example, cupboards or bookcases) without
anchoring both the furniture and the television set to
a suitable support.
-Not placing the television set on cloth or other
materials that may be located between the television
set and supporting furniture.
-Educating children about the dangers of climbing on
furniture to reach the television set or its controls.
If your existing television set is being retained and
relocated, the same considerations as above should be
applied.
Product
• Do not block or cover the ventilation openings on the
back cover.
• Do not push objects of any kind into this unit through
the cabinet slots as they could touch the current
carrying parts or short-circuit parts, resulting in re,
electric shock, or damage to the unit.
• Do not attempt to open the cabinet as this may cause
damage. There are no parts inside you can service by
yourself. Refer all servicing to qualied personnel.
• Do not touch the screen surface with ngers as this
may scratch or mar the TV screen.
• Do not impact the TV screen with hard pressure as
this may damage the TV screen severely.
Power and Plug
• Unplug the set under the following conditions:
-If the set will not be used for a long period of time.
-If the power cord or the power outlet/plug is
damaged.
-Follow the instructions to install and adjust the
product. Adjust those controls that are covered in
these operating instructions as improper adjustment
of other controls may result in damage. If this
happens, unplug the set and refer to the service
personnel.
-If the set is subject to impact or has been dropped
and the cabinet has been damaged.
• Where the mains plug or an appliance coupler is used
as disconnect device, the disconnect device shall
remain readily operable.
(*Where an all-pole mains switch is used as the
disconnect device, the switch shall remain readily
operable.)
Power Cord and Signal Cable
• Do not allow anything to rest on or roll over the power
cord and the signal cable.
• Protect the power cord and the signal cable from
being trampled.
• Do not overload the power cord or the power outlet.
• Do not expose the power cord and the signal cable to
moisture.
Use Environment
• Do not place the set on an unstable cart, stand, or
table.
• Place the set on a place that allows good ventilation.
• Do not use the set near damp, and cold areas.
• Do not expose the set to excessive heat such as direct
sunlight, re, or the like and no naked ame sources,
such as lighted candles, should be placed on the
apparatus.
• Do not expose the set to dripping or splashing and
no objects lled with liquids, such as vases, shall be
placed on the apparatus.
• Do not use the set in dusty environments.
• Operating Temperature: 5°C to 35°C (41°F to 95°F)
Operating Humidity: 20% to 80%, non-condensing
Storage Temperature: -15°C to 45°C (5°F to 113°F)
Storage Humidity: 10% to 90%, non-condensing
Cleaning
• Dust the set by wiping the screen and the cabinet with
a soft, clean cloth or some special liquid cleaner.
• Do not apply excessive force to the screen when
cleaning.
• Do not use water or other chemical cleaner to clean
the screen as this may damage the surface of the TV
screen.
Hanging the TV Set on the Wall
Warning: This operation requires two people.
To ensure a safe installation, observe the following
safety notes:
• Check that the wall can support the weight of the TV
set and wall mount assembly.
• Follow the mounting instructions provided with the
wall mount.
• The TV set must be installed on a vertical wall.
• Make sure to use only screws suitable for the material
of the wall.
• Make sure that the TV set cables are placed so that
there is no danger of tripping over them.
All other safety instructions about our TV sets are
also applicable here. (Note: Certain TV model is not
designed to be mounted to the wall.)

4
Introduction
Sockets
Note: The location and names of the sockets on the TV may vary according to TV model, and not all sockets
available on all models.
LAN
This socket can be used to connect to external modem or network
access equipment.
SPDIF socket (output)
This socket can be used to connect a compatible digital audio
receiver.
HDMI1/HDMI2/HDMI3 socket (input)
The HDMI (High-Denition Multimedia Interface) socket lets you
connect a device, such as a Blu-ray player, with a HDMI output
for best picture quality. It also provides an uncompressed digital
connection that carries both video and audio data by way of an
integrated mini-plug cable.
USB2.0 or USB 2.0/SERVICE socket (input)
These sockets can be used to connect a USB device.
Note: The number of USB sockets on the TV may vary according
to TV model.
ANTENNA/CABLE IN socket (input)
This socket can be used to connect the outside aerial or cable
network.
AV IN adapter socket
The AV IN adapter socket can be used to connect the attached AV
adapter cable with VIDEO and AUDIO L & R IN sockets. The
AV IN sockets can be used to connect a range of equipment,
including video recorders, camcorders, decoders, satellite
receivers, DVD players, or games consoles. The VIDEO IN socket
provides composite video connection.
Headphone socket (output)
This socket can be used to connect headphones or stereo
earphones.
Note: When the Headphone socket is connected, the speakers
will be muted.
Warning: Excessive sound pressure from earphones and
headphones can cause hearing loss.
SATELLITE IN socket (input)
Lets you connect a coaxial cable to receive the signal from your
satellite receiver.
Common Interface socket
This socket can be used to watch encrypted digital TV channels
by in serting a common interface module and a card provided by
a digital TV service operator.
SPDIF
HDMI 1
HDMI 2
or
HDMI 3
or
ANTENNA
/CABLE IN
SATELLITE IN
COMMON INTERFACE
LAN
USB 2.0 or
USB 2.0
/SERVICE
HDD
AV IN
adapter
V L R V L R V L R

5
Remote Control Functions
Most of your television's functions are available via the menus that appear on the screen. The remote control(s)
supplied with your set can be used to navigate through the menus and to congure all the general settings.
Note:Figures and illustrations in this operation manual are provided for reference only and may differ from actual
product appearance. Certain function may not be available for some models, e.g. GUIDE/SUBTITLE/REC functions
are only available under DTV source. And DTV is not availbale for certain model.
Introduction
To switch the sound off and back on.
Standby / quit standby.
Numeric buttons To enter channel numbers or a digit.
PRE-CH To return to the previous channel.
LIST To display the channel list.
/To control the volume.
To display program information, if available.
To display the Settings menu.
P/To change channels.
To access or exit the Smart TV homepage.
To display the Option menu.
▲/▼/◄/►Navigation direction buttons.
OK To conrm an entry or selection.
To return to the previous menu or quit an App.
To select input source.
EXIT To exit the Settings menu.
LANG
To select a sound type available for selected analogue TV program;
to select an audio language available for selected digital TV program.
GUIDE To toggle the Electronic Program Guide on or off (only available for
digital channels).
TEXT To toggle Teletext on or off.
SUBT.
To select a subtitle language available for selected digital TV program.
Color buttons To perform the corresponding function indicated at the bottom of
the screen.
To start fast reverse.
To pause playback.
To start fast forward.
REC To record programs under DTV source.
To start playback.
To stop playback.
NETFLIX To access NETFLIX.
Installing Batteries
1. Push to open the back cover as illustrated.
2. Insert two AAA batteries according to the
polarities marked on the battery case.
3. Replace the back cover as illustrated.

6
Chapter 2 Getting Started
Switching on
Follow the instructions on this page on how to switch on your TV set
and the remote control before going on to following pages describing
how to use the channel set-up procedure.
1. Insert two AAA batteries in the remote control.
Precautions on using batteries:
- Only use the battery types specied.
- Make sure you use the correct polarity.
- Do not mix new and used batteries.
- Do not use rechargeable batteries.
- Do not expose batteries to excessive heat such as sunshine,
re or the like, throw them in a re, recharge them or try to open
them, as this could cause them to leak or explode.
- Remove the batteries from the remote control if you are not using
it for a long period of time.
- Attention should be drawn to the environmental aspects of battery
disposal.
2. Connect the power cable FIRST to the television, THEN to a mains
socket. (Note: If the power cable is connected to the television,
please only connect the power cable to the mains socket.)
Your TV set should only be connected to an AC supply. It must
not be connected to a DC supply. If the plug is detached from the
cable, do not, under any circumstances, connect it to a mains
socket, as there is a risk of electric shock.
Note: The gures are for representation only, the location of power
socket of the television may differ depending on the model.
3. Connect an outside aerial to the ANTENNA IN socket at the back
of the TV set.
The aerial socket (75 OHM - VHF / UHF / cable) can be used for
connecting an external aerial or other equipment tted.
Note: If you want to receive the signal from your cable or cable
box, please connect a coaxial cable to the CABLE IN socket at the
back of the TV set.
4. When powered on, the TV will be turned on directly or be in
standby mode.
If the power indicator lights up, the TV set is in standby mode.
Press the button on the remote control or on the TV set to turn
on the TV.
Switching off
• To put the TV set into standby mode, press the button on the
remote control. The TV set remains powered up, but with low
energy consumption.
• To switch off the TV set, unplug the mains socket from the mains
outlet.

7
Getting Started
Network Connection
Your TV will require an internet connection to operate all functions. Data usage charges may apply.
Please refer to your Internet Service Provider (ISP) for additional information.
To access the Internet, you must subscribe to high speed broadband Internet service with your Internet service
provider (ISP).
Your TV can be connected to your home network in two ways:
• Wired, using the RJ45 (LAN) connector on the back panel.
• Wireless, using the internal wireless and your home wireless network.
Note:Instructions below are just the usual ways to connect your TV to the wired or wireless network. The connection
method may be different depending on your actual network conguration. If you have any questions about your home
network, please refer to your ISP.
Connecting to a wired network
To connect to a wired network:
1. Ensure you have:
• An Ethernet cable long enough to reach your TV
• A router or modem with an available Ethernet
port
• A high-speed Internet connection
• An Ethernet (LAN) port on the back of the TV
2. Connect your Ethernet cable to the router and to
the Ethernet port on the back of the TV.
3. Use the Network menu to configure the TV.
Connecting to a wireless network
To connect to a wireless network:
1. Ensure you have:
• A router broadcasting a high-speed wireless
signal
• A high-speed Internet connection
2. Use the Network menu to configure the TV.
ModemInternet
TV Set
Router
Ethernet
Port on the
back panel
Wireless Router
Modem
TV Set
Built-in wireless
connection

8
Getting Started
7. If you want to check the Internet connectivity,
press ▲/▼to select Connection test and press
OK/►.
Connecting to a wireless network
Your TV is equipped to be connected to your home
network wirelessly. To do that you need a wireless
router or modem.
1. Press on the remote control, select Network >
Internet connection and press OK/► to enter.
2. Press ▲/▼to select On and press OK to
conrm.
3. Press ▲/▼to select Interface and press OK/►
to enter.
4. Press ▲/▼to select Wireless and press OK to
conrm.
5. Press ▲/▼to select Wireless settings and
press OK/► to enter. You can set the wireless
network connection in 3 ways:
-a) Scan
• Press ▲/▼to select Scan and press OK/►
to enter. The TV will search all access points
within range. Access points found by the TV
will be displayed.
• Press ▲/▼to select an available access
point, then press OK/►to connect.
• Press to return to the Wireless settings
menu.
Note: If you select a protected access point,
you will have to enter the corresponding
password. Press OK on the remote control
to display the virtual keyboard to enable
you to enter the password.
- b) Manual
Press ▲/▼to select Manual and press OK/►
to enter. You will be prompted to enter the
correct SSID of an available wireless router to
set up the connection. Press to return to the
Wireless settings menu.
- c) Auto
If your AP (Access Point) supports WPS
(Wi-Fi Protected Setup), you can connect to
the network via PIN (Personal Identication
Number) or PBC (Push Button Conguration).
WPS will automatically congure the SSID and
WPA key in either mode.
Press ▲/▼to select Auto and press OK/►to
enter.
• PIN: Select PIN and press OK/►to enter.
Choose a random PIN code. Make sure
this code is installed on the AP. (For the
procedures, refer to your router manual.)
Network Settings
You can set up your TV so that it can access the
Internet through your local area network (LAN) using
a wired or wireless connection.
Connecting to a wired network
You can connect your TV to your LAN using cable in
three ways:
• You can connect your TV to your LAN by
connecting the LAN port on your TV to an external
modem using a Cat 5 cable.
• You can connect your TV to your LAN by
connecting the LAN port on your TV to an IP
sharer, which is connected to an external modem.
Use Cat 5 cable for the connection.
• Depending on how your network is congured, you
may be able to connect your TV to your LAN by
connecting the LAN port on your TV directly to a
network wall outlet using a Cat 5 cable. Note that
the wall outlet is connected to a modem or router
elsewhere in your house.
1. Press on the remote control, select Network >
Internet connection and press OK/► to enter.
2. Press ▲/▼to select On and press OK to
conrm.
3. Press ▲/▼to select Interface and press OK/►
to enter.
4. Press ▲/▼to select Ethernet and press OK to
conrm.
5. Press ▲/▼to select IP settings and press
OK/► to enter. You can set Address type to
Auto or Manual.
- Select Auto if you want the TV to acquire and
enter the needed IP address automatically.
- Select Manual if you want to enter your IP
address manually, then:
• Press ▼ to go to the rst entry eld.
• Enter the IP address, Subnet mask, Default
gateway, Primary DNS and Secondary DNS
values. Use the numeric buttons to enter
numbers and the ▲/▼/◄/►buttons to move
from one entry eld to another.
- Once IP setting is completed, press ▲/▼/◄/►
to select OK and press OK to conrm. The set
will try to connect to the network and inform
you about the result. Press to return to the
Network menu.
6. If you want to check the information on current
connection, such as Interface, Address type, IP
address, etc., press ▲/▼to select Information
and press OK/► to enter. Press to return to
the Network menu.

9
Getting Started
TV Controller
If the batteries in your remote control are run down, you can use the buttons on your TV set. They have the
following functions:
For models with below buttons on the set: For models with below buttons on the set:
/◄TV mode In menus
P▲
/►P▼
►
Features (Short press)
(Long press)
◄
Features (Long press)
OK (Short press)
Features (Long press)
OK (Short press)
Note:
Figures and illustrations are provided for reference only and may vary depending on the model.
Initial Setup
The rst time you switch the set on, the initial setup wizard appears, which guides you through the initial setup
process. Follow the on-screen instructions to nish the initial setup process such as selecting the language,
connecting to the network, and more. During each step, either make a choice or skip the step. If you skip a step, you
can perform the setup later from the settings menu.
Note: If the channel search retrieved only the analogue channels it could be caused by poor broadcasting and
therefore is not covered by manufacturer warranty. Manufacturers cannot be held responsible for lack of or
poor broadcasting in some areas.
Select OK and press OK to set up the connection.
• PBC: If your router has a PBC push button, select PBC and press OK/►to enter. Press the PBC
push button on your router within 2 minutes before you select OK and press OK again. Your TV will
automatically acquire all the network setting values it needs and connect to your network.
• Press to return to the Wireless settings menu.
- Press to return to the Network menu.
6. If you want to check the information on current connection, such as Interface, Address type, IP address,
etc., press ▲/▼to select Information and press OK/► to enter. Press to return to the Network menu.
7. If you want to check the Internet connectivity, press ▲/▼to select Connection test and press OK/►.

10
Selecting menu language
You can choose your preferred menu language
following the instructions below.
1. Press on the remote control, select System >
Menu language > Language and press OK/► to
enter.
2. Press ▲/▼to select your desired language to
display the menus and press OK to conrm.
3. Press EXIT or to close the menu.
Instant power on
This function enables you to turn on your TV quickly.
1. Press on the remote control, select System >
Instant power on and press OK/► to enter.
2. Press ▲/▼to select On and press OK to
conrm.
3. Press EXIT or to close the menu.
Automatic channel search
This section describes how to search and store
channels automatically. This may be done in any of
the cases below:
- you have selected “I don't want to install
channels" in the initial setup;
- you see “No program info now, please search
channels rst!” in TV mode;
- you want to update your channels.
1. In TV mode, press on the remote control and
select Channel > Channel scan. Press OK/►to
enter.
2. The TV installs and arranges channels according
to your country. Press ▲/▼to select Country,
and press OK/►to enter. Enter the default
password 1234 or your own password in case
you have changed the password in the System >
Lock menu. Press ▲/▼to select your country
and press OK/► to conrm.
3. Press ▲/▼to select Tuner mode>Antenna,
then press OK/►to enter. Press ▲/▼to select
Automatic search, then press OK/►to enter.
4. Press ▲/▼to select Channel type (Digital &
Analogue, Digital or Analogue), then press OK
to start the automatic search for all digital and/
or analogue channels. The search may take a few
minutes. During the process, you can press OK to
abort halfway.
5. The channel search may take a few minutes.
During the process, you can press OK to stop the
search halfway.
6. After the automatic search, channels are
arranged in a preset order. If you wish to skip
channels, modify the preset order, rename or
delete channels, press on the remote control,
select Channel > Organiser and press OK/► to
enter.
Chapter 3 Basic TV Operations
Accessing Channels
Using the numeric buttons: press the corresponding
numeric buttons on the remote control to access the
channels.
Using the P / buttons: press the P / buttons
on the remote control or the corresponding buttons on
the TV set to scroll through the channels.
Using the LIST button: press the LIST button on the
remote control to display the channel list and press
▲/▼/◄/►and OK to select channels.
Watching Connected Devices
Press on the remote control to display the source
list. Press ▲/▼to select TV or other input sources and
press OK to conrm.
You can also press on the remote control to display
the homepage, press ◄/►to select TV and move to
the source area, then press ▲/▼/◄/►to select your
desired source and press OK to conrm.
Adjusting Volume
Volume control: press the /buttons on the
remote control or the corresponding buttons on the TV
set to increase or decrease the volume.
Sound mute: press the button to temporarily mute
the sound. Press this button again or the button to
restore the sound.
Using Homepage
This section explores the most commonly used menu of
your TV.
Press on the remote control to display the
homepage. Press ▲/▼/◄/► to enter the Home page
and select icons from the screen list. Press OK to enter
each option. To exit the menu, press .
Homepage contains 4 parts: Home, Videos, TV, and
Apps. Use ◄/► to switch among them.
Using TV Settings menu
Allows you to adjust TV settings, such as picture and
sound.
1. Press on the remote control to display the Settings
menu.
2. Press ▲/▼to select the desired item, then press
OK/ ►to enter the corresponding sub-menu.
3. In sub-menu, press ▲/▼to select menu options,
then press OK/► to enter the option list, the
adjustment interface, or the corresponding sub-
menu.
4. Press to return to the previous menu.
5. Press EXIT or to close the menu.
Note: You can also press on the remote control,
select Settings (if available) and press OK to
enter the Settings menu. Some options may
not be available for certain signal sources.

11
Digital Teletext language
On digital TV channels, depending on the broadcaster,
you may be able to enjoy a service with multiple initial
Teletext pages in different languages. This function
allows you to select an available language as primary
language, which relates to different initial Teletext
pages.
1. Press on the remote control, select Channel >
Teletext > Digital teletext language and press
OK/► to enter.
2. Press ▲/▼to select a language and press OK to
conrm.
3. Press EXIT or to close the menu.
Common Interface
(* not available for some models)
Encrypted digital TV channels can be decoded with a
common interface module and a card provided by a
digital TV service operator.
The common interface module may enable several
digital services, depending on the operator and services
you choose (for example, pay TV). Contact your digital
TV service operator for more information about services
and terms.
Using the common interface module
WARNING: Switch off your TV before inserting a
common interface module. Be sure to follow the
instructions described below. Wrong insertion of
a common interface module may damage both the
module and your TV.
1. Following the directions printed on the common
interface module, gently insert the module into the
common interface slot on the TV.
2. Push the module in as far as it will go.
3. Turn on the TV and wait for the common interface
function to be activated. This may take several
minutes.
Note: Do not remove the common interface module
from the slot. Removing the module will
deactivate the digital services.
Accessing common interface services
After inserting and activating the common interface
module, press on the remote control, select
System > Common interface and press OK/►to
enter.
This menu option is only available if the common
interface module is correctly inserted and activated. On-
screen applications and content are provided by your
digital TV service operator.
Notes: This feature is only available under DTV source.
Using Subtitles
You can enable subtitles for each TV channel.
Subtitles are broadcast via Teletext or DVB-T/DVB-C
digital broadcasts. With digital broadcasts, you have
the additional option of selecting a preferred subtitle
language.
Turning on/off subtitles
1. Press on the remote control, select Channel >
Subtitle and press OK/► to enter.
2. Select the Subtitle option, press OK/► to enter,
press ▲/▼to select On or Off and press OK to
conrm.
3. Press EXIT or to close the menu.
Enabling subtitle languages on digital TV
channels
1. Press on the remote control, select Channel >
Subtitle > Digital subtitle language and press
OK/► to enter.
2. Press ▲/▼to select a subtitle language as your
preferred language and press OK to conrm.
3. Press ▲/▼to select Digital subtitle language 2nd
and press OK/► to enter.
4. Press ▲/▼to select a secondary subtitle language
and press OK to conrm.
5. Press EXIT or to close the menu.
Shortcut operation: Press SUBT. on the remote
control to directly select a subtitle language available for
the selected digital TV program.
Selecting a subtitle type on digital TV
channels
1. Press on the remote control, select Channel >
Subtitle > Subtitle type and press OK/► to enter.
2. Press ▲/▼ to select a subtitle type and press OK to
conrm. You can select Hearing impaired to display
the hearing impaired subtitles with your selected
language.
3. Press EXIT or to close the menu.
Using Teletext
Selecting decoding page language
1. Press on the remote control, select Channel >
Teletext > Decoding page language and press
OK/► to enter.
2. Press ▲/▼to select a proper type of language in
which Teletext will display and press OK to conrm.
3. Press EXIT or to close the menu.
Chapter 4 Using more of your TV

12
Using more of your TV
3. Press EXIT or to close the menu.
Time Shift
Note: This Option is only available when Time Shift is
set to On: Select Settings> Channel> Time shift, press
OK/► to enter and use ▲/▼ to set Time Shift to On or
Off.
Allows you to pause, fast forward and rewind live TV,
so you don’t have to miss any part of your favourite
programs. Before you use the function, connect a
USB drive to the TV rst. For the rst time, you should
complete the disk setup for the USB drive.
1. Press on the remote control and select Channel
and then press ▲/▼to select Time Shift, then
press OK/► to confirm.
2. Follow the directions on the screen to do the disk
setup if you use time shift for the first time.
3. After the disk setup is done, time shift will start, and
the time shift menu displays on the screen.
4. For later use, press and select Time Shift. press
OK/► to display the time shift menu and operate
according to the on-screen prompt.
5. Pressing Stop button stops the time shift and exits.
-When the time shift menu disappears and only the
timing of the time shift remains on the screen, you
can press OK to call out the time shift menu.
Notes:
- This feature is available only for digital channels.
- Before you plug the USB drive to TV, make sure
you have backed up the data on the drive to avoid
unforeseen malfunction and data loss.
- We recommend that you use a USB drive with at
least 1GB free space and a disk speed faster than
5.0MB/sec.
- The bigger the USB drive free space for time shift,
the bigger the recording length.
Quick Access of Time Shift: Insert a USB disk, press
PLAY(►) on the remote control, it will access Time Shift
automatically.
PVR (Personal Video Recorder)
Allows you to record your favourite TV programs. Before
you use the function, connect a USB drive to the TV
rst.
Note: The feature is available only in selected products
and, due to specic TV network limitations and country
technical requirements, might not be available in
product or place of installation. Feature might also be
blocked by TV network due to copyright protection (HD
content, recording protection). Please use on the
remote control to check if the feature is available in your
T-Link
Use this function to search for CEC devices
connected to the HDMI sockets in your TV and
enable one-touch play and one-touch standby
between CEC devices.(T-Link may not be available
for some models)
Enabling or disabling T-Link
1. Press on the remote control, press ▲/▼to
select T-Link and press OK/► to enter.
2. Press ◄/►to select On or Off and press OK to
conrm.
3. Press EXIT to close the menu.
Using Auto Power on
Enables the TV to automatically power on when you
power on a CEC device (e.g. DVD) with the device’s
remote. Select On to enable this function.
Using Auto Standby
Enables all CEC devices to automatically go to the
standby mode when you turn off the TV with the TV
remote. Select On to enable this function.
Note: The CEC functions depend on the devices
connected and it is possible that some
devices may not interoperate correctly when
connected to this TV. The user manual or
the manufacturer of the problematic devices
should be consulted for further information..
Reset shop
Allows you to reset the TV to factory default settings.
1. Press on the remote control, select System >
Reset shop and press OK/► to enter.
2. Use the numeric buttons to enter the password.
3. Press ◄/►to select OK and press OK to
conrm.
4. The Initial setup menu appears. Follow the
instructions in the section Initial setup.
LED Indicator
Allows you to select the LED indicator on the TV
front panel to ash or not.
1. Press on the remote control, select System >
LED Indicator and press OK/► to enter.
2. Press ▲/▼to select Flashing, Normal or Off
and press OK to conrm.

13
Using more of your TV
• Press the blue button to display the type list of
the program.
• Navigate through the different types using the
▲/▼/◄/► buttons on the remote control.
• Select one or more types, which you want to
highlight from the type list, press OK to select or
deselect. A checkmark will appear to the right of
the type when selected. When you select a type,
all its subtypes (if available) will be selected
accordingly.
• Also, you can select some desired subtypes (if
available) without selecting any type rst.
• Press the blue button to exit the type list.
• After ltering, all your desired digital TV
programs will be highlighted.
- Detail: Press the yellow button to bring out more
details about the selected program in the case that
the details are not shown completely.
- Add schedule: Press to add a schedule into
your schedule list.
3. Press GUIDE or EXIT to exit EPG.
Password in Parental Control
-The default password is 1234. You can change it to a
new one.
-The super password is 0423. If you forget your code,
enter the super password to override any existing
codes.
Software update
Note: Do not switch off or unplug the TV until the
upgrade is completed.
Press on the remote control, select Support >
Software update and press OK/►to enter. You
have the following options to update the software.
-By USB: Enables you to install a new version
software from a USB stick. Insert the USB stick
in which a new version software is stored into a
USB socket of the set. Select By USB and press
OK/►to enter. Follow the on-screen instructions
to complete the process.
-By network: Enables you to download and install
the latest version software from the Internet.
Make sure to set up a wired or wireless network
connection rst then select By network and press
OK/►to enter. Follow the on-screen instructions
to complete the process.
Note: Keep successful network connection during
upgrade.
-By channel: Enables you to install the latest
version software if available from the broadcast.
Select By channel and press OK/►to enter.
Follow the on-screen instructions to complete the
process.
product.
1. Press on the remote control and select PVR.
2. Press OK/► to enter. It starts to record
automatically..
3. Press button on the remote control and use
▲/▼/◄/► to adjust the recording duration.
4. Press OK to stop recording manually, the recorded
file will be saved. In normal operation, the recording
will stop automatically when the recording duration
expires.
5. In recording, the PVR mini panel will also show on
the screen to indicate the recording progress.
6. To watch the recorded program, exit PVR mode first
and go to > TV > Media > All. Select the folder
PVR, then select the related record file. Press OK
to play. (It is the same if you record a digital radio
program).
Notes:
- This feature is available only for digital non-
encrypted channels. Even when CICAM (CI or CI+)
is inserted, this feature is not available on encrypted
channels.
- Before you connect the USB drive to the TV, make
sure you have backed up the data in the drive
to avoid the loss of your important data due to
unforeseen malfunction.
- The bigger the USB drive free memory for the PVR
function, the bigger the recording length.
- If you want to change channel or signal source
during recording, store the recording data before
changing the channel or source.
- The TV cannot play files normally if the parameters
of the file exceed the limitations of the system, the
file format is not supported, the file is damaged, or
the file cannot be decoded.
- Do not disconnect the USB drive when the system
is reading a file or transmitting data, otherwise the
system or the drive may be damaged.
Using EPG (Electronic Program Guide)
EPG is an on-screen guide that displays scheduled
digital TV programs. You can navigate, select and view
programs.
1. Press GUIDE on the remote control, the Program
Guide menu will appear, which allows you to get
information about the current or next program
playing on each channel. Navigate through the
different programs using the ▲/▼/◄/► buttons on
the remote control.
2. Use the related buttons shown at the bottom of the
screen to view EPG.
- Page -/+: Press the red or green button to toggle
among the different program guide pages.
- Filter: Program guide lter for digital TV programs.

14
Chapter 5 Other Information
6. Video stops playing midway.
-Mistakes may occur when videos are copied or
compressed, so they may automatically stop playing
during playback.
7. What should I pay attention to, when I do SW
updating?
-No power cuts when SW updating;
-Avoid any operations with your remote control when
SW updating;
-Depending on your internet connection speed, the
software updating process may take some time.
8. There are no distinct changes of TV interface
after SW updating.
-Under certain conditions, SW updating may not only
update or add new functions but also improve the
performance of the TV set, without distinct changes
to the user interface. Also, there may be no changes
to the user interface at all.
9. External device cannot be recognized.
-Some external devices (e.g. webcam, smart phone,
tablet, game handle, and external wireless adapter)
may not be compatible with the TV and cannot be
supported for certain functions (nScreen, wireless
display, gesture control, face recognition, if any).
Please try a similar device. If it does not work,
contact your local dealer.
1. Fail to link to the network.
-Check if your TV is connected with the network;
-Reboot your TV;
-Consult your internet service provider, to conrm
if access of your router is supported. Refer to the
operation manual of your router.
-Make sure your TV is connected to a router, and
make sure your router is powered on. Check that
your router/modem has an internet connection, and
that your Ethernet cables/wireless connection is OK.
Test your connection with a computer to make sure it
is OK. Should the problem persist, contact customer
service.
2. The video could not be played smoothly.
-Videos from your USB ash drive --- It may result
from data transmission, or its code ow is far beyond
the supported formats of this TV set.
-Videos downloaded from internet, or online videos.
a. It may be caused by the lower bandwidth of your
network. A high network speed is required to
handle online videos.
b. Peak internet usage times may affect the
bandwidth.
c. Check if any other computers on the same
network are also operating, as they may be using
up bandwidth. Especially if they are downloading
or playing on-line videos.
d. The video may not be smooth itself, it is not the
problem of your TV or network.
3. When two mobile hard disks are connected
with the TV at the same time, they will not be
recognized some times.
-All mobile hard disks consume a lot of power,
which may result in power supply problems. We
recommend inserting only one hard disk, or a low
power consumption mobile hard disk.
4. The video from a mobile hard disk (USB) is
playing with no sound.
-The audio format of the video in your mobile hard
disk is not supported by the TV player.
5. Some videos fail to play.
-The formats of the videos may not be supported
by the TV, especially videos shot by certain kinds
of cameras, generally with their private protocol of
formats, which are not compatible with your TV.
Problems & Solutions
Note:Problems & solutions 1 to 2 are for the TV models which have network functions, so users of non-connected
TV models can disregard them.

15
Troubleshooting
Most problems you encounter with your TV can be corrected by consulting the following troubleshooting list.
Snowy dots and interference
If the antenna is located in the fringe area of a television
signal where the signal is weak, the picture may be
marred by dots. When the signal is extremely weak,
it may be necessary to install a special antenna to
improve the reception.
1. Adjust the position and orientation of the indoor/
outdoor antenna.
2. Check the connection of antenna.
3. Fine tune the channel.
4. Try another channel. Broadcasting failure may
happen.
Ignition
Black spots or horizontal streaks appear, or the picture
utters or drifts. This is usually caused by interference
from car ignition system, neon lamps, electric drills, or
other electrical appliance.
Ghost
Ghosts are caused by the television signal following
two paths. One is the direct path, the other is reected
from tall buildings, hills, or other objects. Changing the
direction or position of the antenna may improve the
reception.
Radio frequency interference
This interference produces moving ripples or diagonal
streaks, and in some case, loss of contrast in the
picture. Find out and remove the radio interference
source.
* To bring you better visual experience, please remove
all labels from TV front panel and screen before use.
No picture, no sound
1. Check if the fuse or circuit breaker is working.
2. Plug another electrical device into the outlet to make
sure it is working or turned on.
3. Power plug is in a bad contact with the outlet.
4. Check the signal source.
No color
1. Change the color system.
2. Adjust the saturation.
3. Try another channel. Black-white program may be
received.
Remote control does not work
1. Change the batteries.
2. Batteries are not installed correctly.
No picture, normal sound
1. Adjust the brightness and contrast.
2. Broadcasting failure may happen.
Normal picture, no sound
1. Press the VOLUME UP button to increase volume.
2. Volume is set to mute, press the MUTE button to
restore sound.
3. Change the sound system.
4. Broadcasting failure may happen.
Unorderly ripples on the picture
It is usually caused by local interference, such as cars,
daylight lamps and hair driers. Adjust the antenna to
minimize the interference.
Other Information

16
Other Information
Legal Statement
[Legal Statement] of TCL - manufacturer of this TV set
Due to the various capabilities of products featuring
the SmartTV - Services, as well as limitations in the
available content, certain features, applications, and
services may not be available on all devices or in all
territories. Some features on SmartTV may also require
additional peripheral devices or membership fees that
are sold separately. Please visit our website for more
information on specic device information and content
availability. The services and availability of content
through SmartTV are subject to change from time to
time without prior notice.
All content and services accessible through this device
belong to third parties and are protected by copyright,
patent, trademark and/or other intellectual property
laws. Such content and services are provided solely
for your personal noncommercial use. You may not
use any content or services in a manner that has
not been authorized by the content owner or service
provider. Without limiting the foregoing, unless expressly
authorized by the applicable content owner or service
provider, you may not modify, copy, republish, upload,
post, transmit, translate, sell, create derivative works,
exploit, or distribute in any manner or medium any
content or services displayed through this device.
You expressly acknowledge and agree that use of the
device is at your sole risk and that the entire risk as to
satisfactory quality, performance and accuracy is with
you. The device and all third party content and services
are provided “as is” without warranty of any kind,
either express or implied. TCL expressly disclaims all
warranties and conditions with respect to the device and
any content and services, either express or, implied,
including but not limited to, warranties of merchantability,
of satisfactory quality, tness for a particular purpose, of
accuracy, of quiet enjoyment, and non-infringement of
third party rights. TCL does not guarantee the accuracy,
validity, timeliness, legality, or completeness of any
content or service made available through this device
and does not warrant that the device, content or services
will meet your requirements, or that operation of the
device or services will be uninterrupted or error-free.
Under no circumstances, including negligence, shall
TCL be liable, whether in contract or tort, for any direct,
indirect, incidental, special or consequential damages,
attorney fees, expenses, or any other damages arising
out of, or in connection with, any information contained
in, or as a result of the use of the device, or any content
or service accessed by you or any third party, even if
advised of the possibility of such damages.
Third party services may be changed, suspended,
removed, terminated or interrupted, or access may be
disabled at any time, without notice, and TCL makes no
representation or warranty that any content or service
will remain available for any period of time. Content
and services are transmitted by third parties by means
of networks and transmission facilities over which TCL
has no control. Without limiting the generality of this
disclaimer, TCL expressly disclaims any responsibility or
liability for any change, interruption, disabling, removal
of or suspension of any content or service made
available through this device. TCL may impose limits
on the use of or access to certain services or content,
in any case and without notice or liability. TCL is neither
responsible nor liable for customer service related to
the content and services. Any question or request for
service relating to the content or services should be
made directly to the respective content and service
providers.

17
Notes:• If the table stand has been assembled, just ignore the following instructions.
• Follow the instructions accordingly based on the table stand supplied to you.
• Graphics contained within this publication are for representation only.
• Keep the screws and plastic parts away from grease and organic solvents to
avoid damage, especially during the assembly process.
• When the TV faced down, do not impact the screen with sharp edges to avoid
scratching the screen.
• If you want to mount the TV to the wall, please purchase an appropriate one
in the case that no wall mount bracket is supplied along with the TV.
Addendum Sheet
Mount the Stand
1
2

* Figures and illustrations in this User Manual are provided for reference only and may differ from actual product
appearance. Product design and specications may be changed without notice.
