TCL L39E5390F-MS63F-LA User manual

4#,
3%26)#%-!.5!,
















/39E5390F-MS63F-LA
 #AUTION…………………………………………………………………………
 SPECIFICATION……………………………………………………………………………
  !LIGNMENT0ROCEDURE…………………………………………………………

ˊ
"LOCKDIAGRAM
…………………………………………………………………


ˊ
3CHEME$IAGRAM
……………………………………………………………
 4ROUBLESHOOTING
………………………………………………………………
 0#",AYOUT 
…………………………………………………………………




4HISM ANUALI ST HEL ATESTAT T HET IMEOF PR INTING ANDDOE S NOT
INCLUDETHEMODIFICATIONWHICHMAYBEMADEAFTERTHEPRINTINGBY
THECONSTANTIMPROVEMENTOFPRODUCT

CA UTION: TO RE DUCE THE RIS K OF
ELECTR ICA L SHOCK, DO NOT RE MOVE
COVER (OR BACK). NO USER SERVICEABLE
PAR TS INS IDE . RE FE R SER VIC ING TO
QUALIFIE D SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CA U T ION
RISK
RISK OF
ELECTR I
ELECTR IC
SHOCK
SHOCK DO
NOT
NOT
OPEN.
OPEN.
2
dangerous
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SCHNEIDER ELECTRONICS GMBH-GERMANY
1. CAUTION
2

1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and
Instructions marked on the audio equipment.
1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
3
SCHNEIDER ELECTRONICS GMBH-GERMANY
IMPORTANT SAFETY INSTRUCTIONS
FOR YOUR PERSONAL SAFETY
3

11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s
4
SCHNEIDER ELECTRONICS GMBH-GERMANY
PROTECTION AND LOCATION OF YOUR SET
PROTECTION AND LOCATION OF YOUR SET
4

18. This television set should be operated only from the type of power source indicated on the marking label.If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
21. If you are unable to restore normal operationby following the detailedprocedurein your operatinginstructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
24. Do not use attachments not recommendedby the television set manufacturer as they may cause hazards.
25. When replacement parts are required,be sure the service technicianhas used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
off
5
SCHNEIDER ELECTRONICS GMBH-GERMANY
OPERATION OF YOUR SET
IF THE SET DOES NOT OPERATE PROPERLY
FOR SERVICE AND MODIFICATION
5

EM BUSINESS CENTER
FTV PRODUCT PLANNING DEPT.
SPECIFICATION RELEASE
Version: V1.0 Issued Date: 2013.4.22
Panel Size (inch) 39'
Category LED TV(LED BACK LIGHT)
Aspect Ratio 16:9 Component Video Format Y,Pb/Cb,Pr/Cr:up to 720p,1080i,1080p @50Hz/60Hz
Color Temperature Warm / Standard / Cold DVI Video Format Up to XGA for HDMI-PC
Backlight Adjustable Yes HDMI Video Format Up to 720p,1080i,1080P
Scaler Mode Auto, 4:3, Cineme,Subtitle,Full Screen PC Compatibility VGA: up to UXGA@60Hz
Picture Effect StandardˈVividˈsoftˈUserˈ
Picture Enhancement Audio/CVBS Input (Composite) 2 R/L+2 Video: AV1, AV2(Bottom)
Comb Filter 3D YPbPr Input 1
Core Technology High-quality scaling engine & 3-D video de-interlacer Audio Input for YPbPr 1˄Share with AV1˅
MstarACE Yes YCbCr Input Share with "YPbPr"
Motion Compensation Yes Audio Input for YCbCr Share with Audio for "YPbPr"
DLTI Yes VGA Input(RGB) 1 (D-Sub,15 Pins)
DCTI Yes Audio Input for RGB 1˄Share with AV2˅
Dynamic Skin Tone Correction Yes Headphone 1
DNR Yes DVI share with “HDMI” port
Panel Specification HDMI 1.3+CEC 3
Panel supplier TCL Audio/CVBS Output (Composite) 1(R/L+CVBS)
Display Resolution 1920*1080 SPDIF 1 (Coaxial)
Brightness (cd/m2) 320 RF Input 2 (Antenna, Cable)
Contrast Ratio 3000:1 USB 2.0 2
Response Time 6.5ms (G to G) LAN 1
Viewing Angle (H/V) 160°/140°
Life Time 30,000hrs TV System ATV:NTSC PAL/M PAL/N DTV:ISDB-T
Color 8 bit AV System PAL,NTSC
SOUND TV Channels (Analog) Cable (1125), Antenna (269)
Speakers Integrated speakers (Bottom side) TV Channels (Digital) Antenna (769)
Audio Power Output 8W*2 Chassis MS63F-LA
Sound Processing BTSC (SAP, Stereo, Mono) Certification CB
Dolby Virtual Surround MS10(DD+,DP) Power Supply AC 100V-240V 50/60Hz
Model: L39E5390F/MS63F-LA/AJLW01 V3
AVC (Auto Volume Control) Yes Power Consumption-TV on 90W
SRS Yes Power Consumption-Standby Less than 0.5W
Sound Features MTS, AVC, Equalizer, Surround Default Color of Front Cabinet Silver
Sound Control Volume, Balance, Keyboard Position Side
Function Base Stand Detachable Yes
subtitle Yes Unpackaged Dimension for Main Body (L*H*D) (mm)
Clock/Timers Yes With Base Stand (mm) 891.6*587.5*226
Lock Yes Without Base Stand (mm) 891.6*534.2*70.2
OSD Language English/Spanish/Portuguese Packaged Dimension (L*H*D)
OSD Features Semi-transparent Main Body (mm) 1195*133*690
HDMI CEC Yes Base Stand Packaged with Main Body
USB Connection Yes Net Weight (Kg) 12
Demo Function Yes Gross Weight (Kg) 15
Picture Freeze Yes Container Loading
IPTV FEATURE 20 feet 228
Browser Opera 2.0 40 feet 510
NETFLIX NETFLIX3.1.4 40 feet high 628
YouTube V3
Terra TV Yes Operation Manual English(Default)
FILE SHARE Yes Remote Control For TV control (with two batteries)
Wi-Fi IEEE Standards 802.11 g/n Base Stand Packaged with Main Body
Software Upgrade HUAN Speaker Box Integrated
Social Network Facebook & Twitter Wall Mount WMB331˄400*400*M6)
Online Picture/Album Picasa USB Dongle Yes(TP-LINK)
Others AC Power cord,AV Adapter cable
Design and specifications are subject to change without notice! Page 1 of 1
HW Drafted by: Huashan-Chen 2013-04-21
MD Drafted by:
Approved by:

Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 1 of 18
TCL World-Wide R&D
FPD CENTER
Factory Test & Alignment Specification
(FTAS)
for MS63F-LA Series
Version 0.10
PREPARED BY : Jianwei Li DATE : 2012-09-12
APPROVED BY : _____ DATE:

Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 2 of 18
Disclosure
The information contained in this document is proprietary to TCL SZ FPD lab and shall
not be disclosed by the recipient to third persons without the written permission of the
team leader or GM of R&D.
Revision History
Version Issue Date Description of changes
v0.10 2012-8-12 This is the draft version of normal SIACP
·HDMI as the main absolute input
·The password of factory menu is 9735

Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 3 of 18
These chassis are designed for Latin America(LA) markets Ready for IPTV. The main chip is from
Mstar and supports below features matrix:
Class Item MS63F-LA
Inputs
&
Outputs
ATV
( PAL M/PAN N/ NTSC) CABLE&ANTENNA
DTV
(ISDB-T) ANTENNA
HDMI
(480i/p, 576i/p, 720p up to 1080i/p, compliant v1.4
with HDCP)
3
VGA 1
VGA/DVI audio 1
CMP
(YPrPb can support from 480i up to 1080p,audio) 1
AV 1
(CVBS ,audio) 1
Side AV
(CVBS,audio) 1
AV O U T 1
USB thumb drive 2
- Picture,Video,Audio Playback
- Hub, Mouse, Keyboard rd
Headphone output 1
SPDIF output Optical
Functions
OAD •
WIFI Ready USB Dongle accessory
(IEEE 802.11 b/g/n)
DIVX •
DLNA (DMP) •
Internet Opera
3D (auto, top & bottom, side by side, frame
sequencing, …)
1920x2205@24Hz (1920x1080p x2)
1280x1470@50Hz (1280x720p x2)
1280x1470@60Hz (1280x720p x2)
Passive Glasses
Audio Return Channel (ARC) •
Serial connector N/A
Others
VGA connector P508
I2C connector of MEMC module N/A
Main SW Serial NAND Flash
BIN image
U301
V8-6328L01-LF1Rxxx
IC Details
&
Position
Main EEPROM
U302
VGA connector pinout:
VGA/P508 Pin4:RXD VGA Pin11:TXD

Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 4 of 18
INFO:
ªAll tests and measurements mentioned hereafter have to be carried out at a normal mains voltage
(220 ~ 240 VAC)
ªAll voltages have to be measured with respect to ground, unless otherwise stated
ªAll final tests have to be done on a complete set including LCD panel in a room with temperature of
25+/-7°C
ªThe Picture Performance assessment such as White Balance (luminance and color temperature)
has to be performed into subdued lighted room after at least 45min of warm-up in order to avoid any
temperature drift influence (colorimetry vs time)
1. PCB/SKD Assembly: Test & Alignment
1.1. Pre-Conditions and DC/DC Check
Before power-on, please check the board according to the relevant block diagram and circuit
diagram, and make sure that no serious issue or mistake can destroy the board. For example, the
output of DC/DC and LDO should not be shorted to ground.
Supply a suited voltage and power-on, then check the voltage according to the relevant block
diagram, circuit diagram and voltage spec . the error should less than 5% .For example, the voltage
for main chip(+3V3, AV3.3, +1V2, CORE1V2, etc.), the voltage for DDR (DDRV) , the voltage for
amplifier (AMP_VCC), etc...
Position Value Remark
U200(U200A) 3.3V ±5% 3V3
U201 2.5V ±5% 2V5
U202 1.5V ±5% 1V5
U203 1.2V ±5% 1V2
U204 5V ±5% 5V
U205 12V ±5% 12V
U208 1.2V ±5% DEMO_1V2
U209 3.3V ±5% TU_3V3
Here enclosed circuit diagram:
'?⭥䐟മ?06?
06/$0$&+*
1.2. SW Image download
Download the latest release SW from below FTP server:
- Link: http://sw.tcl-cctv.com
- Username: TCL_HW_MS6328
- Password: to be requested!
