UV100A Ultraviolet
Air Treatment System
OWNER’S GUIDE

UV100A ULTRAVIOLET AIR TREATMENT SYSTEM
69-1659 2
HOW YOUR ULTRAVIOLET
AIR TREATMENT SYSTEM WORKS
When installed in forced air heating and cooling systems, your UV100A Ultraviolet Air
Treatment System kills a high percentage of micro-organism contaminants in the air
passing over it. Individual results depend on how carefully all installation and
maintenance requirements are followed and on the actual amount of time your air
delivery fan operates.
You can capture and minimize micro-organism pass-through in your heating,
ventilation and air conditioning (HVAC) system when you combine your Ultraviolet Air
Treatment System with a high-efficiency air filtration system that includes an electronic
air cleaner. Talk to your installer about adding an electronic air cleaner to complement
your air treatment system and provide added protection for you and your family.
Your UV100A Ultraviolet Air Treatment System unit is one of these three models: a
single-lamp, medium-efficiency return air unit; a dual-lamp high-efficiency return air
unit; or an air conditioner coil irradiation unit.
• The UV100A coil irradiation unit is mounted in your supply side air duct or
downstream from the air conditioner cooling coils in your HVAC system. The single
lamp reduces mold and spores on duct surfaces, coils and drain pans.

UV100A ULTRAVIOLET AIR TREATMENT SYSTEM
3 69-1659
HOW YOU CAN CHECK YOUR ULTRAVIOLET
AIR TREATMENT SYSTEM OPERATION
WARNING
UV Light Hazard.
Harmful to bare skin and eyes.
Can cause temporary or permanent loss of vision.
Never look at the lamps while illuminated.
Only view illumination by way of the light indicator located on the lamp knob.
To prevent exposure to ultraviolet light, disconnect power to the ultraviolet air
treatment system before servicing any part of the heating/air conditioning
system.
Do not mount device in location that allows ultraviolet light to be seen after
installation.
Do not attempt to bypass the duct mount switch.
Do not attempt to open housing; unit is sealed to prevent ultraviolet light
exposure.
Your Ultraviolet Air Treatment System has a power cord that plugs into a 120 Vac
electrical outlet. Your unit is designed to prevent accidental contact with the voltage
and with the ultraviolet rays in the sealed unitthe ultraviolet lamps do not illuminate
unless the base is mounted on the HVAC duct.
It is recommended that every month you verify that your ultraviolet lamp(s) are
operating only by viewing through the lamp light indicator on the lamp knob. Do not
attempt to look into the duct at the illuminated lamp(s).

UV100A ULTRAVIOLET AIR TREATMENT SYSTEM
69-1659 4
HOW YOU CAN MAINTAIN YOUR ULTRAVIOLET
AIR TREATMENT SYSTEM
Your should regularly clean your ultraviolet lamps to maintain your air treatment
system. And once every year, you must remember to replace your ultraviolet lamps.
CAUTION
Personal Injury Hazard.
Power supply can cause electrical shock.
Disconnect power supply before cleaning or replacing ultraviolet lamp(s).
Do not open base unit or lamp knob; there are no user-serviceable
components inside.
CAUTION
Breakable Glass Hazard.
Can cause personal injury.
Be careful when inserting lamp(s) into lamp base.
Wear protective gloves when handling lamp(s).
Cleaning Your Lamps Every Three Months (Quarterly)
MERCURY NOTICE
This device contains mercury in the sealed ultraviolet lamp(s). Do not place
your used lamp(s) in the trash. Dispose of properly.
Broken Lamp Cleanup.
Do not use a household vacuum.
Sweep debris (phosphor/glass) into a plastic bag and dispose of properly.
Contact your local waste management authority for instructions regarding
recycling and the proper disposal of old lamp(s). If you have questions, call
Honeywell Customer Relations at 1-800-468-1502.
Lamp cleaning is recommended as routine maintenance four times a year or every
three months (quarterly). Use the Ultraviolet Lamp Cleaning Reminder Schedule,
Fig. 1, to help you establish and track your regular cleaning schedule.

UV100A ULTRAVIOLET AIR TREATMENT SYSTEM
5 69-1659
Fig. 1. Ultraviolet lamp cleaning reminder schedule.
CAUTION
UV Lamp Burn Hazard.
Harmful to bare skin.
Can cause severe burns.
Disconnect power 15 minutes before removing the ultraviolet lamp(s)
IMPORTANT
If the lamps in your model have external wires running along the glass sur-
face, be sure to avoid pulling on those wires.
To clean your lamps:
1. Disconnect the power to your HVAC system.
2. Unplug your ultraviolet air treatment system cord from the electrical outlet and
allow the lamps to cool for at least 15 minutes.
3. Rotate your lamp knob counterclockwise and gently pull the lamp knob to
remove the lamp(s).
4. Holding only the lamp knob, wipe the lamp glass using a soft cloth with window
cleaner applied to it. Do not touch the lamp surface with your hands. Use only
the cloth.
5. To ensure that the lamp indicator continues to function, use a moistened cotton
swab to gently remove any dust that may have collected between the lamp light
indicator on the base and the black lamp base.
YEAR
UV LAMP CLEANING REMINDER SCHEDULE
, (year)
M13516
JFMAMJJASOND
INSTALLATION DATE: (month)

UV100A ULTRAVIOLET AIR TREATMENT SYSTEM
69-1659 6
6. Wipe your lamps with a clean, dry cloth.
7. Put your clean lamps back into the unit base by following Replacing Your Lamps
(Annually) section steps 5, 6, and 7.
WARNING
UV Light Hazard.
Harmful to bare skin and eyes.
Can cause temporary or permanent loss of vision.
Never look at the lamps while illuminated.
Only view illumination by way of the light indicator located on the lamp knob.
To prevent exposure to ultraviolet light, disconnect power to the ultraviolet air
treatment system before servicing any part of the heating/air conditioning
system.
8. Plug the cord into the nearby 120 Vac electrical outlet.
9. Verify that the ultraviolet lamp(s) are operating only by viewing through the lamp
light indicator on the lamp knob. Never look directly at your lamps while illumi-
nated.
10. Reconnect the power to your HVAC system.
CAUTION
UV Lamp Burn Hazard.
Harmful to bare skin.
Can cause severe burns.
Disconnect power 15 minutes before removing the ultraviolet lamp(s).
IMPORTANT
If the lamps in your model have external wires running along the glass sur-
face, be sure to avoid pulling on those wires.
Replacing Your Lamps (Annually)
Annual replacement of your lamps is required. To replace your lamps:
1. Select and obtain the correct replacement lamp for your unit. See Table 1.
2. Disconnect the power to your HVAC system.
3. Unplug your ultraviolet air treatment system cord from the electrical outlet and
allow the lamps to cool for at least 15 minutes.
4. Rotate the lamp knob counterclockwise and gently pull the lamp knob to remove
the lamp(s).
5. Insert the lamp into the base unit with the lamp light indicator at the eleven
o’clock position (left of the raised button on the unit cover). Do not touch the
lamp surface with your hands.

UV100A ULTRAVIOLET AIR TREATMENT SYSTEM
7 69-1659
6. Continue lightly pushing in on the lamp while rotating it slowly counterclockwise.
This should cause the lamp to drop into the bottom of the lamp well.
7. Rotate the lamp clockwise until it snaps into place with the lamp light indicator
aligned with the raised button on the unit cover.
WARNING
UV Light Hazard.
Harmful to bare skin and eyes.
Can cause temporary or permanent loss of vision.
Never look at the lamps while illuminated.
Only view illumination by way of the light indicator located on the lamp knob.
To prevent exposure to ultraviolet light, disconnect power to the ultraviolet air
treatment system before servicing any part of the heating/air conditioning
system.
8. Plug your ultraviolet air treatment system cord into the nearby 120 Vac electrical
outlet.
9. Verify that your ultraviolet lamp(s) are operating only by viewing through the
lamp light indicator on the lamp knob. Never look directly at your lamp(s) while
illuminated.
10. Reconnect the power to your HVAC system.
Table 1. Replacing Your Lamp(s).
Unit Description Replacement Lamps Wattage
UV100A1085 Coil Irradiation Unit UC100A1054 36W

69-1659 G.H. 10-02 www.honeywell.com/yourhome
Automation and Control Solutions
Honeywell Honeywell Limited-Honeywell Limitée
1985 Douglas Drive North 35 Dynamic Drive
Golden Valley, MN 55422 Scarborough, Ontario
M1V 4Z9
Printed in U.S.A. on recycled
paper containing at least 10%
post-consumer paper fibers.
Limited Warranty
York International, Unitary Products Group (UPG) warrants this product, excluding lamps, to be free from defects
in the workmanship or materials, under normal use and service, for a period of one (1) year from the date of
purchase by the consumer. If, at any time during the warranty period, the product is defective or malfunctions,
UPG shall repair or replace it (at UPG’s option) within a reasonable period of time.
This warranty does not cover removal or reinstallation costs.This warranty shall not apply if it is shown by UPG
that the defect or malfunction was caused by damage which occurred while the product was in the possession
of a consumer.
UPG’s sole responsibility shall be to repair or replace the product within the terms stated above. UPG SHALL
NOT BE LIABLE FOR ANY LOSS OR DAMAGE OF ANY KIND, INCLUDING ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING, DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF ANY
WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF THIS PRODUCT. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so this limitation may not apply to you.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY UPG MAKES ON THIS PRODUCT. THE DURATION
OF ANY IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED TO THE ONE YEAR DURATION OF THIS
WARRANTY. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
If you have any questions concerning this warranty, please write Unitary Products Group Consumer Relations,
5005 York Drive, Norman, OK 73069 or call 1-877-874-7378.
