TCS TCSK-01 User manual

TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Handbook
Service Device
TCSK-01

2 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Table of contents
Table of contents .................................................................................................................2
Scope of delivery .................................................................................................................2
Safety notices ......................................................................................................................3
Terms...................................................................................................................................3
Device overview...................................................................................................................4
Technical data .....................................................................................................................4
Application...........................................................................................................................5
Brief description...................................................................................................................5
Functions .............................................................................................................................5
First commissioning.............................................................................................................5
Send registration fax............................................................................................................5
Determination of the serial number on the Service Device ..................................................6
Clearing the Service Device.................................................................................................6
Cable connection.................................................................................................................6
Changing the display ...........................................................................................................7
Meaning of the protocol digits..............................................................................................8
Readout of the AS address of a front-door station...............................................................9
Programming and cancellation of bell buttons .....................................................................9
Functional check of the system..........................................................................................10
... via function keys ............................................................................................................10
... by entering command sequences..................................................................................11
Functions ...........................................................................................................................11
Cleaning...............................................................................................................................5
Service...............................................................................................................................16
Scope of delivery
1 x Service Device TCSK-01
1 x Adapter board,
1 x Connection cable for UAE box
1 x Connection cable to connecting jack for bell button extension
1 x User manual with registration fax

3 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Safety notices
!
Assembly, installation, and commissioning must only be carried out by a qualified elec-
trician!
For work on systems with 230 V AC mains current the safety requirements of DIN VDE
0100 must be observed.
When installing TCS:BUS systems the general safety rules for telecommunication systems
in accordance with VDE 0800 must be observed.
Terms
AS address
Front door stations have in addition to their own serial number a
sender identity. This is called the AS address. To create a call con-
nection the device being called needs to know from which sender the
call originates. It takes this information from the AS address. The AS
address of a front-door station is not fixed at the time of delivery of
the device. After power is switched on, the front-door stations auto-
matically agree on the AS address. It cannot be predicted which AS
address a front-door station will be assigned.
If the AS is to be fixed, it needs to be entered in the front-door station
using the Service Device TCSK-01. When assigning AS addresses
all front-door stations must be given different AS addresses! Values
from 0 ... 63 are permitted.
The AS block is also automatically set.
AS block
If an AS block has been set it prevents the automatic modification
of the AS address by the front-door station.
Bus protocol
All information transferred via the TCS:BUS is packaged in bus pro-
tocols and displayed in the TCSK-01 display mostly. A bus protocol
consists of three segments:
1. Protocol digit: It explains a specific function of the bus protocol.
2. Serial number: Each device has a serial number. It is used to ad-
dress the selected device. The serial number shows to whom the
respective function from segment A has been allocated.
3. Sender or additional information on the serial number.
Bus protocols may have varying lengths. The description therefore
talks of long (32 bit) and short (16 bit) protocols.
Control protocol
Besides the call of an in-house station by the front-door station there
are further protocols. For control tasks the control protocol is being
used. Control protocols also exist as long and short variants.

4 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Device overview
Technical data
Supply voltage: +24 V ±8 % (via power supply and control unit)
Case: light grey
dimensions (in mm): H 200 mm x W 50 mm x D 50 mm
operating temperature range: 0 °C ... + 40 °C
storage temperature - 10 °C ... + 40 °C
Input current without load (3 wires): I(a) = 0.4 mA, I(P) = 10 mA standby
maximum input current: I(Pmax) = 13 mA
Accuracy: 0.5 V
Measuring range: 0 - 25 V DC
Receiver case
Output of voice
and signal tones
LCD display, 8-digit
(display of bus activity or
entries at the Service Device)
Display in normal state: t.
If no key is pressed for 6 s it returns to
this state.
Call OFF switch
: all in-house stations ring with call
trigger
:all in-house stations do not ring with call trigger
Switch to , if the occupants are not to be dis-
turbed by the ringing of the in-house stations. If
the device is disconnected from the system, the
call suppression continues to be active for up to 2
min. This time period can be bypassed by switch-
ing the system off and back on.
Key F
Changing the display to
the measured bus voltage
Reversing key
Readout of information from
the front-door stations, can-
cellation of the last entered
digit in the display
Microphone
UAE box
for connection to the TCS:BUS using
the supplied UAE connection cable
and the 4-pole Western connector
Numerical
keypad
Entry
Function keys
Door
release
key
Light
key
Quick
program-
ming key
Internal
call key

5 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Application
The Service Device TCSK-01 is used for system programming and analysis.
Brief description
Functions
Display of BUS protocols via number codes
Evaluation and control of :BUS protocols
Modification of parameters for front-door and in-house stations
Execution of basic functions on the TCS:BUS
Activation and Deactivation of call suppression
Display of the current :BUS voltage
Programming and cancellation of bell buttons
Testing of voice connections from Service Device to front-door station and from Service
Device to in-house station
Checking of the :BUS installation in service mode
Activation and deactivation of an programming block
Cleaning
!
Avoid water entering the device!
Do not use any aggressive or abrasive cleaning agents!
Clean the device using a dry or slightly moist cloth.
More persistent dirt can be removed using a mild household cleaner.
First commissioning
!
Only applies once for the first commissioning.
During software updates the device does not need to be cleared again.
Send registration fax
!
The use of the Service Device TCSK-01 is only possible after entry of a release code.
After initial release the Service Device can be used without restrictions.
Please remove the registration fax from the manual.
Enter your complete address into the field provided.

6 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Enter the 4-digit number of your Service Device TCSK-01, which is printed on a sticker
on the device packaging, into the field serial number.
Complete the registration fax and send it to us.
You will receive the release code from us by return fax within one working day from Mon-
day to Friday.
Determination of the serial number on the Service Device
If the number printed on the packaging is not available, the
not yet cleared device is able to display the serial number:
Connect the Service Device to a system
(see sectionCable connection).
The display briefly shows P and the serial number:
Clearing the Service Device
As soon as you have received the release code you can
clear the Service Device.
Connect the Service Device to a system
(see section Cable connection).
The display shows:
Enter the allocated release code via the keypad of the
Service Device.
The number has a maximum of 6 digits.
Confirm the entry by pressing the hash key.
Cable connection of the device
Connect the adapter board as shown in the illustration below.
If a front-door station (without bell button extension) is not fitted with a connecting jack for
a Service Device, the connection from the 3-pole connection terminal of the adapter board
to the front-door station can be made using any 3-wire connection cable.
!
Notes:
Do not connect any adapter cable to front-door stations with 3-pole connector!
Always connect the TSCK-01 to the P conductor to ensure proper functioning!
(e. g. via wire to BVS)
Serial number

7 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Changing the display
The display of the Service Device allows for various indications. With two display states a
change to the other display is possible by pressing a key.
The change between the protocol displays is always accompanied by a brief acknowledg-
ment tone
3-pole terminal
for any cable
Jack for PES/TCU
UAE connection cable *
Connection cable to
connecting jack for bell
button extension.
Jacket for PET/TCKE
* included in scope of delivery
Adapter board*
Connection cable
to connecting jack
for bell button
extension
F
F key
BUS idle voltage
(e. g. 228 corresponds to 22.8 V)
Display normal state (t)
Connect Service
Device
Software state (e. g. 1.9)
after approx. 6 s
automatic
* If no command is entered, the dis-
play automatically returns to the
normal display after 6 s.
*

8 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
From the normal state bus protocols can be displayed: If an action is executed at the sys-
tem (e. g. lifting a telephone handset), this is displayed at the Service Device. If the serial
number of a front-door station is displayed, it is possible to change from the long protocol
display to the short protocol display.
Meaning of the protocol digits
Protocol
digit
Action
0
Call from front-door station to in-house station with display of serial number called
0t
Call from front-door station to in-house station with display of AS address
1
Long door release protocol with display of the corresponding serial number
1t
Short door release protocol with display of the AS address
2t
Light switch protocol with display of the AS address
3
Call commencement by the in-house station with display of the serial number of the in-
house station
3t
Call termination by the in-house station with display of the AS address
4
Flat-door call with display of the serial number of the ringing device
6
Long control protocol with display of the serial number of the device
6t
Long control protocol with display of the control function number
9
Internal call with display of the serial number of the called device
Press a function key at the service
device or enter a command sequence
or action at the system
Reversing key
Protocol digit Serial number
Long protocol display
protocol digit with
special sign t
AS address
Short protocol display
*

9 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Readout of the AS address of a front-door station
Connect the Service Device to a system (see page 6).
Press a bell button at the front-door station.
If the bell button is programmed the protocol digit 0 and the serial number of the called in-
house station appear in the display. By pressing the reversing key on the Service Device
its AS address it shown in the right portion of the number field (e. g. 23)
If the bell button is not programmed the protocol digit 2t (light switch protocol) appears in
the display when pressing the bell button together with the AS address (e. g. 0)
Programming and cancellation of bell buttons
Tone legend
Signal tone legend TCSK
Acknowledgement tone positive (function was executed correctly)
Acknowledgement tone negative (function could not be executed)
Confirmation signal for key press
!
Note: The programming mode of the system must not be switched on at the supply
and control device for this!
Programming of the first serial number
Response
1. Connect the Service Device to the front-door station.
2. Enter the serial number of an in-house station (tele-
phone) via the keypad.
3. Press the quick programming key .
Wait until a P appears on the display.
The serial number of the in-house station is
transferred to the front-door station.
4. Briefly press the bell button on the front-door station
which is to be allocated to this in-house station.
A positive acknowledgement tone TCSK con-
firms the successful programming.
Delation tone
Ring tone
NoProg tone
Prog2 tone
BlockProg tone

10 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Programming of a second serial number for the same
bell button (not for PAK before version 2.23 and TCKE)
Response
1. Repeat the steps 2. and 3.
2. Keep the the bell button to be programmed pressed on
the front-door station (for 12 s) until …
Note: The programming is automatically terminated by the Ser-
vice Device if no bell button is pressed after 14 s.
… always after 6 s you will hear: Prog2 tone,
NoProg tone, ring tone (both devices will ring).
A negative acknowledgement tone TCSK can be
heard if the programming attempt failes.
Cancellation of a bell button
1. Switch the programming mode on.
2. Press the desired bell button and keep it pressed until a cancel-
lation tone can be heard.
Repeat step 2for other buttons to be cancelled.
3. Switch the programming mode off.
Functional check of the system
... via function keys
Function
Key
Process
Door release function
trigger
Enter AS address of the opening front-door station
(with more than one front-door station)
Press door release key
Light switch function
trigger
Press light key
Voice connection
to front-door station
Enter AS address of front-station
(value 0 ... 63 permitted)
Press internal call key
speaking
Termination of the voice connection:
Press internal call key again.
Voice connection
to in-house station
Enter serial number of in-house station*
Press internal call key
speaking
Termination of the voice connection:
Press internal call key again.
* serial number has at least 3 digits, if necessary complete number with leading zeros (e. g. 1 001)

11 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
... by entering command sequences
Command sequences are activated by pressing the * key.
Principally a command entry is terminated by pressing the # key.
The reversing key functions as correction key in this mode.
Successfully executed commands are confirmed with an acknowledgment tone.
!
Note:
If no key has been pressed the Service Device returns to the normal state after 6 s.
The key sequences must therefore be entered without delay.
Determine the serial numbers of the devices prior to starting and familiarise your-
self with the key sequences to be entered.
Functions
Command group and sequences
switching the programming mode of the system on / off
switch on
switch off
Program VSW camera input
2
Ser.-Nr. M = serial number of master VSW04 (*see fig. below)
Ser.-Nr. S = serial no. of slave VSW04
K = number of camera input at VSW04 (value 1 ... 15)
AS = AS address of front-door station for this camera input (value 0 ... 63)
ADR = slave address at VSW04 (value 1 ... 4)
NOTE: The AS address of the video front-door station must first be set with TCSK-01 (see p. 14: * 76 #).
Connect camera input with video front-door station
Connect camera input with camera without front-door station
Cancel camera input *
NOTE: Camera input 1 cannot be cancelled.
Set VSW slave address
Load VSW factory setting
* Fig.: Cascading of video reversing switch VSW04
Camera
Camera
Camera
Camera
Camera
Video in-
house
station

12 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Program FVU1210
2
AS = AS address of the video front-door station
Ser.-Nr.VU = serial no. of the FVU1210
K = no. of the video input at theFVU1210 (value 1 or 2)
NOTE: The AS address of the video front-door station must first be set with TCSK-01 (see p. 14: * 76 #).
Connect FVU1210 video input Kwith the video front-door station
Cancel FVU1210 to AS allocation to the video input
Load FVU1210 factory setting
Trigger control function
3
Ser.-Nr. = serial no. of end device
StF = number of control function to be sent
Configure signal devices
4
Ser.-Nr. = the serial number of the newly to be configured signal device
ParSNr. = the serial number for the device to which the newly to be configured signal device
will be allocated.
parallel call 1
parallel call 2
VU
VU
VU

13 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
to the first
serial number
Search for BUS devices
5
The TCSK-01 can detect all devices connected to the BUS (max. 80) of a special device type and display
their serial numbers. After entering the respective command all devices of the type searched for will be
acquired. The number of the devices found will be briefly shown. Then the first found serial number ap-
pears in the display.
Search telephones
Search simplex communication devices
Search sensors and combining devices
Search front-door stations
Search bells and signal units
After the acknowledgement tone scrolling through the list of serial numbers is possible using the function
keys:
Configure relay TRE2, TOER2 and FVU1200
6
Ser.-Nr. = the serial number of TRE2 / TOER2 or FVU1200
ParSNr. = the serial number for the device to which the newly to be configured relay
will be allocated.
AS = AS address of the front-door station (value 0 ... 63).
For FVU1200: AS address of the flat-door video front-door station
TelSnr. = the serial number of the telephone sending the control function (video in-house station for *63)
StF = number of control function to be sent (0 ... 11)
Activation of the TRE2 or TOER2 for front-door call, internal call
to parallel serial number and operation of the flat-door button at
the device with the corresponding serial number
TOER2 as door release relay
Evaluate control functions (control functions 0 ... 11)
(TRE2, TOER2)
Configure FVU1200
Set relay switching time
(time: value between 1 and 255; 1 s steps) (TRE2, TOER2)
to
the previous
to
the next
search
mode end
to the last serial
number

14 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Configure front-door station
7
Some functional features of the front-stations can be modified with the TCSK-01. Each front-door station
has a serial number. For the settings to be applied to the desired front-end station the serial number of the
front-end station must be included in all command sequences of group 7.
Ser.-N. = the serial number of the newly to be configured front-end station.
(see label in the front-end station)
AS = AS address (value 0 ... 63)
Cancel programming block, light switch function and speaking
with active door readiness,
loading the normal state for acknowledgement tones
Activate programming block
NOTE: With the programming block set no key programming
is possible. If programming is attempted the programming
block tone will sound at the front-door station.
Set speaking time speaking time = (1 to 5) 8 s
0 = unlimited
Activate speaking only with active door readiness
Select front-station acknowledgement tones
Fct. = 0- acknowledgement tone for front-door call (ring
tone)
1- acknowledgement tone when a voice connection
has been established
2 - brief acknowledgement tone for front-door call
3- no acknowledgement tone for front-door call
(except P mode)
Set and block AS address
NOTE: The programming and AS block and the speaking with
active door readiness can be set separately, but can only be
removed jointly.
Activate Light switch function TTS1 / TTS10 and TTS25
Select alert contact function
(only TCU2 and PDS, PES)
Fct. = 0- door alert
1- light switch function
2- door release function
3- control function 3 with SN of the front-door station

15 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Configure in-house stations telephones
8
Ser.-Nr. = the serial number of the newly to be configured telephone
ZielSNr. = the serial number of the target telephone in call redirection
IntSNr. = the serial number of the internal telephone
ParSNr. = the serial number for the device to which the newly to configured telephone
will be allocated.
Set functions for key : IMM1xxx, IVW3010
key :VMH30, VML30, VMH30C, VMH30
Call redirection
Automatic door release
Internal call 1
Control function 8
Set functions for key : VMH30, VML30, VMH30C, VMH30, VMF30
Internal call 2
Control function 9
Light switching
Set functions for key : VMH30, VML30, VMH30C, VMH30, VMF30
Internal call 3 *
control function 10
Switch on parallel call *
Switch off parallel call
*Note for VMH30, VML30, VMH30C, VMH30C:
Parallel allocation deactivates the internal call 3 for key .

16 06/2010
TCS TürControlSysteme AG, TCS Hotline Germany: +49 41 94/ 9 88 11 88 Subject to change without notice.
FAX: [phone] www.tcs-germany.com HB_GB_TCSK01_Art0015720_1v1.doc mi
Configure in-house stations hands free
9
Programming the commands “9” has to be initiated with command *95#Ser.-Nr.#.
Then the programming of the function key has to be carried out with the service device
(not for ISW4100, IMM2xxx).
Ser.-Nr. = the serial number of the newly to be configured in-house station
ZielSNr. = the serial number of the target in-house station in call redirection
IntSNr. = the serial number of the in-house station to be called internal
ParSNr. = the serial number for the in-house station to which the newly to be configured
in-house station will be allocated
Function key: ISW42x0, ISW4100, IVW2210. IVW2220, IVW3011, IMM2xxx
Einleitung (not for ISW4100, IMM2xxx)
Call redirection
Automatic door release
Internal call
Control function 8
Light switch function (not for ISW4100, IMM2xxx)
Parallel allocation: ISW3030, ISW4000, ISW42x0, ISW4100, IVW2210. IVW2220, IVW3011, IMM2xxx
Switch on parallel call *
Switch off parallel call
Service
Contact your local sales representative or
www.tcs-germany.com
Headquarters
TCS TürControlSysteme AG,
Geschwister-Scholl-Str. 7, 39307 Genthin, Germany
Phone: [phone],
FAX: [phone]
www.tcsag.de
0
