TDK piezobrush PZ2 User manual

piezobrush PZ2
Operating Instructions for Handheld Device
Series/Type: PZ2 - Prototypes
Ordering code: Z63000Z2910Z1Z62
Date: 2019-06-12
Version: 2.0
 TDK Electronics AG 2019. Reproduction, publication and dissemination of this publication, enclosures hereto and the
information contained therein without TDK Electronics' prior express consent is prohibited.
Content of header bars 1 and 2 of data sheet will be automatically entered in headers and footers! Please fill in the table and then
change the color to "white". This ensures that the table disappears (invisible) for the customer PDF.
Don't change formatting when entering or pasting text in the table and don't add any cell or line in and to it!
Identification/Classification 1
(header 1 + top left bar):
piezobrush PZ2
Identification/Classification 2
(header 2 + bottom left header bar):
Operating Instructions for Handheld Device
Ordering code: (top right header bar) Z63000Z2910Z1Z62
Series/Type: (bottom right header bar) PZ2 - Prototypes
Preliminary data (optional): Preliminary data
Department:
Date: 2019-06-12
Version: 2.0

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 2 of 17
Important notes at the end of this document.
1 Contents
1Contents........................................................................................................................................................... 2
2Safety ............................................................................................................................................................... 3
2.1Residual risks........................................................................................................................................... 3
2.2Information and obligations for the operator ............................................................................................ 4
2.3Interpermissible operating conditions ...................................................................................................... 4
2.4Emissions ................................................................................................................................................. 5
3Description of device ....................................................................................................................................... 5
3.1Ordering code .......................................................................................................................................... 5
3.2Correct use .............................................................................................................................................. 5
3.3Scope of delivery ..................................................................................................................................... 5
3.4Description of device ............................................................................................................................... 6
4Technical data ................................................................................................................................................. 8
5Transport /storage ........................................................................................................................................... 8
6Installation ........................................................................................................................................................ 8
7Special Note on the operation of the plasma process ..................................................................................... 9
7.1General description .................................................................................................................................. 9
7.2Notes on the correct handling of the substrates to be treated ............................................................... 10
7.3Carrying out surface treatment .............................................................................................................. 10
7.4Measured to take the surface treatment ................................................................................................ 10
8Operation ....................................................................................................................................................... 11
8.1General operating instructions ............................................................................................................... 11
8.2Changing the nozzle .............................................................................................................................. 11
8.3Standard-Nozzle .................................................................................................................................... 12
8.4Nearfield-Nozzle .................................................................................................................................... 12
9Decommissioning .......................................................................................................................................... 13
10Maintenance .................................................................................................................................................. 13
10.1Cleaning ................................................................................................................................................. 13
11Troubleshooting ............................................................................................................................................. 14
12Environment ................................................................................................................................................... 14
12.1Disposal ................................................................................................................................................. 14
13Conformity / standards ................................................................................................................................... 14
13.1CE .......................................................................................................................................................... 14
13.2Product standards .................................................................................................................................. 15
14 Spareparts and optional accessory............................................................................................................... 15
Display of ordering codes for TDK Electronics products ....................................................................................... 15

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 3 of 17
Important notes at the end of this document.
2 Safety
This device is built according to corresponding international standards. Like with every
technical product incorrect or not intended use can however be dangerous.
Follow the instructions in this operating manual in addition to the general safety regulations.
Caution - Danger!
When working with the device, please note and observe the safety instructions and
requirements in these operating instructions because non-compliance may result in
serious or fatal injury.
2.1 Residual risks
This device has been manufactured in accordance with the current state of the art.
However, it is impossible to eliminate residual risks.
Always adhere to the following safety instructions:
Caution – Electrical voltage!
Only use the external power plug provided.
Danger from mains voltage. If the external power plug is visibly damaged:
- Do not use the damaged part.
- Have the damaged parts repaired by a qualified person or replace them.
Attention – Emissions!
Dangerous amounts of the reaction gas ozone (O3) may be produced during device
operation.
- Volumes of ozone in excess of 0.2 mg/m³ may be produced.
- Note that national health and safety measures must be observed when
operating the device.
- Only use the device in well vented areas or in conjunction with a suitable
extraction device

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 4 of 17
Important notes at the end of this document.
Attention – Damage to device!
Under no circumstances may the fan cover on the rear side of the device be closed.
This would interrupt the supply of cooling medium required in operation.
Never touch the piezo component at the front of the device with sharp-edged objects.
This component may be damaged by improper handling.
Protect the plasma generator from falls or other hard impacts which may damage the
electronics or piezo component.
2.2 Information and obligations for the operator
 The system may emit interference.
- The system has been tested in accordance with EMC legislation.
- The operator must verify and assure electromagnetic compatibility with other
electrical and electronic equipment in the immediate vicinity of the system.
 Ensure that:
- Operating personnel have read and understood these operating instructions.
- Anyone working near the device is made aware of the dangers and is provided with
the necessary protective equipment.
- Repairs are only carried out by qualified persons.
 In particular, make operating personnel aware of the safety instructions in this document.
 Always keep the system in fully functional condition.
 Any modifications made to the device will invalidate the operating license and the
warranty. The only exceptions are modifications which are expressly authorized by the
manufacturer.
2.3 Interpermissible operating conditions
The device must not be operated under the following conditions:
 In explosive (Ex) zones
 In areas with severe build-up of dust
 In environments where the humidity is too high (see technical data)
 At altitudes of more than 2000 m above sea level
 In areas with strong vibrations

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 5 of 17
Important notes at the end of this document.
2.4 Emissions
The connected plasma generator produces certain amounts of zone (O3), which may exceed
the workplace limits
Plasma Gas Gas flow Ozone
Air Ca 20 l/min < 0.12 g/h
Note!
As a precautionary measure, we recommend an extraction system with about 10 times the amount
of gas flow through the device in the direct vicinity of the plasma outlet.
3 Description of device
3.1 Ordering code
The piezobrush ®PZ2 handheld device can be ordered by using ordering code: Z63000Z2910Z1Z62.
3.2 Correct use
The piezobrush PZ2 is a handheld device for generating technical plasma. It is used to pretreat a wide range of
material surfaces before processes such as gluing or printing. It is also possible to use the cleaning effect of the
plasma.
Only use the device for the intended purposes. Failure to do so may restrict product liability.
3.3 Scope of delivery
The scope of delivery includes the following components:
Plasma generator
Standard nozzle (already mounted)
Nearfield nozzle
Power plug (length 1.5m)
Changeable plugs for EU, US and UK
Operating instruction
Not included:
Multigas nozzle (see chapter 14)
Additional information can be found on the website www.relyon-plasma.com.

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 6 of 17
Important notes at the end of this document.
3.4 Description of device
The individual parts of the generator are shown and named in the diagram below. These terms are used
throughout the operating instructions.
No. Component description
1 Piezo component (internal)
2 Nozzle insert
3 Catch button for nozzle insert (on both sides)
4 On/Off button
5 Nameplate
6 Fan grille
7 Socket for external power plug
1
2 3
4
7
6
5

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 7 of 17
Important notes at the end of this document.
No. Component description
8 External power plug (with changeable plugs for EU, US and UK)
9 Nearfield nozzle in socket for spare nozzle-inserts
10 Foam inlay
8 9 10

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 8 of 17
Important notes at the end of this document.
4 Technical data
Electrical data
Supply voltage 15 V DC
Power consumption max. 30 W
Model Handheld device with external power plug
Dimensions
Weight 170 g (not including external power plug)
Length 215 mm
Diameter max. 36 mm
Diameter min. 27 mm
Cable length 1500 mm
Typical application parameters
Plasma temperature < 50 °C
Distance for treatment 5 … 10 mm
Width of treatment 5 … 20 mm depending on process parameters (see chapter 7)
Treatment speed 10 … 20 mm/s
Operating conditions
Air humidity < 80% rel. (non-condensing)
Temperature 10 … 40 °C; 50 … 104 °F
Storage conditions
Air humidity < 80% rel. (non-condensing)
Temperature 0 … 60 °C; 32 … 140 °F
5 Transport /storage
 Store the plasma generator in a dry place. This will prevent corrosion of the electrical contacts.
It is best to use the provided case for storage and transport.
 Protect the plasma generator from dirt and foreign bodies.
 Protect the plasma generator from falls or other hard impacts.
6 Installation
 Remove the plasma generator from the packaging.
 Use the external power plug to establish the power supply.
 Ensure that the workplace is well vented.
Attention - Damage to device
In order to prevent damage to the device, please ensure that you follow the advice in
chapter 8 Operation.

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 9 of 17
Important notes at the end of this document.
7 Special Note on the operation of the plasma process
7.1 General description
Treating surfaces with atmospheric plasma has several advantages. Examples include the increase of surface
energy resulting in improved surface wetting.
Optimal surface wetting is the first and often decisive step to get a good imprint, a uniform coating, a consistent
coat of varnish or an integrally-bonded application of adhesive. The bond at this boundary layer often
determines the longevity and adhesive strength of this material pairing.
Atmospheric-pressure plasma increases throughput in many industrial processes, while at the same time saving
costs for solvents or chemical primers. We have successfully integrated our plasma products into the following
application fields:
 Cleaning of metal, glass and plastics
 Surface activation and surface functionalization for optimized wettability
 Plasma-assisted laminating process
 Plasma-assisted adhesive bonded joints
 Plugging and sealing
 Plasma induced reduction of metal surfaces
 Chemical-free bleaching of textiles
 Plasma decontamination of fabric
 Handling of food products for quality and shelf life
 Decontamination of thermally-unstable plastics
 Air purification and odour reduction
 Multi-component injection moulding
Practically all technical material classes can be efficiently processed under atmospheric pressure:
 Metals, metal alloys
 Plastics and composite materials
 Glass, ceramics, inorganic composites, natural stone
 Real leather, imitation leather
 Natural fibres, wood, paper
Since the plasma treatment is always just one part of the entire process, it is important to know the overall
influences on the surface properties in order to achieve an optimal result.
Typical influencing factors could be:
 Plasma process: Distance to the substrate, speed, nozzle geometry
 Substrate/ workpiece: Material composition, contamination, electrical conductivity, thermal conductivity,
moisture content
 Workpiece treatment: Contamination before or after the plasma process, the time duration between the
plasma process and the follow-up process
Treatment examples can be requested directly from Relyon Plasma GmbH.
Additional information on applications, as well as publications, can be found on the website
www.relyon-plasma.com.

piezobrush PZ2 Z63000Z2910Z1Z62
Operating Instructions for Handheld Device PZ2 - Prototypes
Preliminary data
2019-06-12
Please read Cautions and warnings and Page 10 of 17
Important notes at the end of this document.
7.2 Notes on the correct handling of the substrates to be treated
Caution – Electrical voltage!
• Danger from electrical voltage
- Never direct the plasma beam at people or animals.
- Never touch the plasma nozzle or the plasma jet when the device is in operation.
- Never touch the workpiece to be treated or its holder during plasma generation.
- Make sure that no third party comes into contact with the workpiece to be treated
or its holder.
- If electrically conductive materials touch the workpiece to be worked on, these
materials must be grounded.
This applies not only to direct handling of the device, but also to the workpiece to be handled and its holder.
A functional grounding connection is provided on the device for a special form of plasma treatment involving
transferred electric arcs. If you want to use this special application, please contact Relyon Plasma GmbH
directly.
7.3 Carrying out surface treatment
Depending on the type and condition of your substrate, pre-cleaning before the plasma process can improve the
overall outcome.
The effect of the treatment depends on the working distance, treatment time, speed and consistency of
movement as well as the material to be treated.
Ensure that the substrate is not thermally damaged due to movement that is too slow or a working distance that
is too low.
Treatment examples can be requested directly from Relyon Plasma GmbH.
7.4 Measured to take the surface treatment
To achieve an optimal result, it is important that as little time as possible elapse after the plasma treatment and
that the treated surface is not touched or contaminated. Cleaning the surface AFTER the plasma treatment is
not recommended. Since the workpiece can heat up depending on the type and duration of the plasma process,
it may be necessary to allow the workpiece to first cool down first before the next process step is executed in
order to not negatively affect the follow-up process through the introduction of heat (e.g. certain bonding
processes).
Caution – Hot surface!
The workpiece to be treated can become heated up by the plasma process depending on
the process parameters. If necessary, allow the workpiece to cool down before handling it.
