EMC Filters for AC Power Line
For Single-phase, Small-size Box Cased ZMG-11, ZMG-M Series
FEATURES
• The ZMG series EMC filters exhibit outstanding attenuation
characteristics with respect to both differential mode and com-
mon mode noise components in the MF and HF bands.
• Small, high performance, this series demonstrates superior
attenuation effects for low frequency band noise components
under 1MHz. It is therefore suitable for conform to FCC and VDE
standards relating to switching power supply use devices.
• Current leakage is maintained at less than 0.5mA.
• Efficient manufacturing makes these filters highly cost-effective.
• ZMG-M series is compact on-board type.
• It is a product conforming to RoHS directive.
APPLICATIONS
Computer terminals, office automation equipment, digital applied
devices (ECRs, electronic calculators, electronic scales, etc.), con-
trol devices, measurement devices, and any other devices that
require a miniaturized filter.
SAFETY STANDARDS
SHAPES AND DIMENSIONS
Dimensions in mm
• Case: plastic, terminal: pin
Conformity to RoHS Directive
Part No.
Standard and standard No.
U.S.A. Canada Europe
UL1283 CSA C22.2 No.8 EN60939
ZMG22R5-11 1052559 LR76849C P08209004
ZMG2202-11 1052559 LR76849C P08209004
ZMG2203-11 1052559 LR76849C P08209004
ZMG2206-11 1052559 LR76849C P08209004
ZMG2201-M 1052555 LR76849C P08209004
ZMG2203-M 1052555 LR76849C P08209004
ZMG2206-M 1052555 LR76849C P08209004
UL(NRTL) CSA NEMKO
Series ABCDEFøG
ZMG-11 31 44.5 22 3.5 10 35 1
ZMG-M 2525263.510201
B
A
CD
øG
EE
F
Ground
terminal
14
23
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.

(2/3)
003-01 / 20080818 / e9145_zmg.fm
• All specifications are subject to change without notice.
ELECTRICAL CHARACTERISTICS
Part No. ZMG22R5-11 ZMG2202-11 ZMG2203-11 ZMG2206-11
Rated voltage Eac(V) 250 250 250 250
Rated current(A) 0.5 2 3 6
Test voltage Eac(V)[Between terminal and ground terminal] 1500 1500 1500 1500
Insulation resistance(MΩ)
[DC. 500V, 1min/between terminal and ground terminal] 100min. 100min. 100min. 100min.
Leakage current(mA)[250V • 60Hz] 0.5max. 0.5max. 0.5max. 0.5max.
DC resistance(mΩ) 450max. 350max. 230max. 60max.
Operating temperature range(°C)[Including self-temperature rise] –25 to +85 –25 to +85 –25 to +85 –25 to +85
Withderatingover(°C) 55555555
Temperature rise(°C) 30max. 30max. 30max. 30max.
Attenuation frequency range
(MHz)[+5 to +35°C]
Differential mode at 30dB 0.45 to 10 0.7 to 10 0.8 to 10 2 to 10
Common mode at 30dB 0.1 to 10 0.2 to 10 0.3 to 10 1 to 10
Weight(g) 36363640
Part No. ZMG2201-M ZMG2203-M ZMG2206-M
Rated voltage Eac(V) 250 250 250
Rated current(A) 1 3 6
Test voltage Eac(V)[Between terminal and ground terminal] 1500 1500 1500
Insulation resistance(MΩ)
[DC. 500V, 1min/between terminal and ground terminal] 100min. 100min. 100min.
Leakage current(mA)[250V • 60Hz] 0.5max. 0.5max. 0.5max.
DC resistance(mΩ) 140max. 120max. 60max.
Operating temperature range(°C)[Including self-temperature rise] –25 to +85 –25 to +85 –25 to +85
With derating over(°C) 55 55 55
Temperature rise(°C) 30max. 30max. 30max.
Attenuation frequency range
(MHz)[+5 to +35°C]
Differential mode at 25dB 0.8 to 10 0.8 to 10 1.5 to 20
Common mode at 25dB 0.6 to 10 0.6 to 10 3 to 10
Weight(g) 242424

(3/3)
003-01 / 20080818 / e9145_zmg.fm
• All specifications are subject to change without notice.
TYPICAL ELECTRICAL CHARACTERISTICS
ATTENUATION vs. FREQUENCY CHARACTERISTICS
ZMG22R5-11 ZMG2202-11
ZMG2203-11 ZMG2206-11
ZMG2201-M ZMG2203-M
ZMG2206-M CIRCUIT DIAGRAM
RECOMMENDED SOLDERING CONDITIONS
• Dip time : Within 5 seconds at 240±10°C
• Soldering iron : Within 5seconds at 400°C max.
