C-90656W - SUPER BENCH
ASSEMBLY INSTRUCTIONS:
SLIDE
(1) 5/8” X 6.5” STUD
(2) 5/8” FLAT WASHERS
AND (2) 5/8” LOCK NUTS
(1) 5/8” X 6.5” STUD
(2) 5/8” FLAT WASHERS
AND (2) 5/8” LOCK NUTS
PIVOT POP PIN
HING BOLT:
(1) 3/8” X 7” BOLT,
(2) 3/8” FLAT WASHERS
(1) 3/8” LOCK NUT
FRONT LEG
REAR LEG
5/16” X 2 1/4” BOLT
3/8” NUT
3” DIA PLASTIC
WHEEL
3” FEET (4) PCS
(4) ½”X 4-1/2” BOLTS
(8) ½”FLAT WASHERS
(4) ½” LOCK NUTS
(6) 3/8” X 1” BOLTS
& (6) 3/8” FLAT WASHERS
(2) SETS OF BOLTS AND NUTS
(TO ATTACH FRONT
SEAT TO FRAME IS
NOT VISIBLE)
FRONT SEAT
REAR SEAT
PAGE 1 OF 3
TDS FITNESS EQUIPMENT

HARDWARE LIST
(2) 5/16 X 2 1/4 BOLTS
(4) 5/16 FLAT WASHERS
(2) 5/16 LOCK NUTS
(6) 3/8 X 1 BOLTS
(6) 3/8 FLAT WASHER
(4) 1/2 X 4 1/2 BOLTS
(8) 1/2 FLAT WASHER
(4) 1/2 LOCK NUTS
(1) "L" PIN
(1) TURN POP PIN
(4) FOOT COVERS
(2) 5/8” X 6-1/2” STUDS
(4) 5/8” FLAT WASHERS
(4) 5/8” LOCK NUTS
PAGE 2 OF 3
REAR SEAT FRONT SEAT
FRAME
LEGS
PIVOT
REAR HINGE
SLIDE FRONT HINGE
C-90656W - SUPER BENCH
PARTS LIST

C-90656 - SUPER FLAT/INCLINE BENCH WITH WHEELS
ASSEMBLY INSTRUCTIONS
THIS UNIT REQUIRES (2) 3/4 WRENCHES, (1) 9/16 WRENCH, (2) 1/2 WRENCHES AND 11/16”
WRENCHES FOR ASSEMBLY. DO NOT TIGHTEN HARDWARE BEFORE INSTRUCTED TO.
1- INSTALL (4) 3" RUBBER FEET ON BASES (LEGS)
2- ATTACH (2) WHEELS TO REAR FOOT WITH (2) 5/16 X 2 1/4 BOLTS, (4) 5/16 FLAT
WASHERS, AND (2) 5/16 LOCK NUTS. TIGHTEN HARDWARE. DO NOT OVER TIGHTEN.
WHEELS MUST SPIN FREELY.
3- ATTACH (2) LEGS TO BENCH WITH (4) ½" X 4-1/2" BOLTS, (8) ½” FLAT WASHERS
AND (4) ½” LOCK NUTS
4- STAND BENCH UP, TIGHTEN (4) BOLTS
5- ATTACH SLIDER PIVOT TO BENCH (1) 5/8” X 6-1/2” STUD, (2) 5/8” FLAT WASHERS
AND (2) 5/8” LOCK NUTS. THEN INSTALL POP-PIN
6- ATTACH FRONT AND REAR HINGE WITH (1) 3/8” X 7” BOLT (2) 3/8” FLAT WASHERS &
(1) 3/8” LOCK NUT
7- INSERT SLIDE INTO PIVOT WITH HOLES TO THE OUTSIDE OF BENCH - POP PIN
MUST BE POSITIONED TO THE TOP SIDE
8- ATTACH SLIDE TO REAR HINGE WITH (1) 5/8” X6.5” STUD, (2) 5/8” FLAT WASHERS &
(2) 5/8” LOCK NUTS
9- TIGHTEN BOLTS
10 - ATTACH FRONT AND REAR SEATS TO BENCH WITH (6) 3/8"X1" BOLTS AND (6) 3/8”
FLAT WASHERS
NOTE: TO MOVE BENCH, LIFT FRONT FOOT UNTIL THE WHEELS IN THE BACK
TOUCH THE FLOOR, THEN ROLL.
