TE Connectivity 2217480 Series Reference guide

Customer Manual
1 of 9
© 2017 TE Connectivity Ltd. family of companies.
All Rights Reserved.
*Trademark
TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product, and/or company names may be trademarks of their respective owners.
PRODUCT INFORMATION 1-800-522-6752
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.te.com.
409-32031
07 AUG 17 Rev D
SAFETY PRECAUTIONS —READ THIS FIRST! .....................................................................2
SAFETY PRECAUTIONS —AVOID INJURY —READ THIS FIRST!......................................3
1. INTRODUCTION ..................................................................................................................4
2. RECEIVING AND INSPECTION ..........................................................................................5
3. USER INTERFACE INFORMATION (PRE-OPERATION TESTING)..................................5
3.1.LED Indicators................................................................................................................5
3.2.Pressure Sensor ............................................................................................................6
4. OPERATION ........................................................................................................................6
4.1.Battery Installation and Removal ...................................................................................6
4.2.Die Assembly Installation and Removal.........................................................................6
4.3.Crimping.........................................................................................................................7
5. PREVENTIVE MAINTENANCE ...........................................................................................8
5.1.Daily Maintenance..........................................................................................................8
5.2.Yearly Maintenance .......................................................................................................8
5.3.Lubrication......................................................................................................................8
6. TROUBLESHOOTING .........................................................................................................8
6.1.Prior to Beginning Troubleshooting Procedures, Verify Battery is Operational..............8
6.2.Refer to Figure 5 for Problems, Probable Cause(s), and Solution.................................9
7. REPLACEMENT AND REPAIR ...........................................................................................9
8. DECOMMISSIONING...........................................................................................................9
9. RESTRICTION ON HAZARDOUS SUBSTANCES (RoHS) INFORMATION......................9
10. REVISION SUMMARY .........................................................................................................9
Standard Die Envelope (SDE) Lithium-
Ion Battery-Powered Crimping Tool
Kits; PN 2217480-[ ]
ORIGINAL INSTRUCTIONS

409-32031
Rev D
2 of 9
SAFETY PRECAUTIONS —READ THIS FIRST!
IMPORTANT SAFETY INFORMATION
NOTE
Keep all decals clean and legible, and replace them
when necessary.
DANGER
ELECTRIC SHOCK HAZARD
This tool is not insulated. When using this unit near
energized electrical lines, use proper personal protective
equipment.
Failure to observe this warning could result in severe
injury or death.
DANGER
SKIN INJECTION HAZARD
Do not use hands to check for oil leaks. Highly
pressurized oil will puncture the skin causing serious
injury, gangrene, or death. If injured, seek medical help
immediately to remove the oil.
DANGER
FIRE HAZARD
Do not use solvents or flammable liquids to clean the
crimping tool. Solvents or flammable liquids could ignite
and cause serious injury or property damage.
Failure to heed these warnings could result in severe
injury from harmful fumes or burns from flying debris.
DANGER
FIRE HAZARD
Do not dispose of batteries in a fire. They will vent
fumes and will explode. Instead, dispose of batteries in
an environmentally responsible manner or send the
battery back to TE.
DANGER
Inspect the tool and jaws/dies before each use. Replace
any worn or damaged parts. A damaged or improperly
assembled tool can break and strike nearby personnel.
Failure to observe this warning could result in severe
injury or death.
CAUTION
—Do not place the tool in a vise. The crimping tool is
designed for hand-held operation.
—Protect the crimping tool from rain and moisture.
Water will damage the crimping tool and battery.
Failure to observe these precautions may result in injury
or property damage.
CAUTION
—Do not allow anything to contact the battery
terminals.
—Do not immerse the batteries in liquid. Liquid may
create a short circuit and damage the battery. If the
batteries are immersed, contact your service center for
proper handling.
—Do not place the battery into a pocket, tool pouch, or
tool box with conductive objects. Conductive objects
may create a short circuit and damage the battery.
—Do not place a battery on moist ground or grass.
Moisture may create a short circuit and damage the
battery.
Failure to observe these precautions may result in injury
or property damage.
CAUTION
—Do not store the battery at more than 60°C [140°F].
Damage to the battery can result.
—Do not use another manufacturer’s charger.
—Do not attempt to open the battery. It contains no
user-serviceable parts.
Failure to observe these precautions may result in injury
or property damage.
CAUTION
—Do not perform any service or maintenance other
than as described in this manual. Injury or damage to
the tool may result.
Failure to observe these precautions may result in injury
or property damage.

409-32031
Rev D
3 of 9
SAFETY PRECAUTIONS —AVOID INJURY —READ THIS FIRST!
Safeguards are designed into this application equipment to protect operators and maintenance personnel from
most hazards during equipment operation. However, certain safety precautions must be taken by the operator
and repair personnel to avoid personal injury, as well as damage to the equipment. For best results, application
equipment must be operated in a dry, dust-free environment. Do not operate equipment in a gaseous or
hazardous environment.
Carefully observe the following safety precautions before and during operation of the equipment:
Always wear approved eye protection while operating
equipment.
Always wear appropriate ear protection while using
equipment.
Moving parts can crush and cut. Always keep guard(s)
in place during normal operation.
Electrical shock hazard.
Always turn off the main power switch and disconnect
the electrical cord from the power source when
performing repair or maintenance on the equipment.
Never insert hands into installed equipment.
Never wear loose clothing or jewelry that may catch in
moving parts of the equipment.
Never alter, modify, or misuse the equipment.
Do not operate equipment if the guards are removed.
Read and understand this entire document before
using equipment.
SUPPORT CENTER
CALL TOLL FREE 1-800-522-6752 (CONTINENTAL UNITED STATES AND PUERTO RICO ONLY)
The Support Center offers a means of providing technical assistance when required. In addition, Field Service
Specialists are available to provide assistance in the adjustment or repair of the application equipment when
problems arise which your maintenance personnel are unable to correct.
INFORMATION REQUIRED WHEN CONTACTING THE SUPPORT CENTER
When calling the Support Center regarding service to equipment, it is suggested that a person familiar with the
device be present with a copy of the manual (and drawings) to receive instructions. Many difficulties can be
avoided in this manner.
When calling the Support Center, be ready with the following information:
1.
Customer Name
6.
Product part number (and serial number
if applicable)
2.
Customer Address
7.
Urgency of request
3.
Person to contact (name, title,
telephone number, and extension)
8.
Nature of problem
4.
Person Calling
9.
Description of inoperative component(s)
5.
Equipment number (and serial number
if applicable)
10.
Additional information/comments that
may be helpful

409-32031
Rev D
4 of 9
Length
336.5 mm [13.25 in.]
Width
72.9 mm [2.87 in.]
Depth
114 mm [4.5 in.]
Mass/Weight (with Battery)
1.88 kg [4.2 lbs]
Sound Level
70 dBA at 1 Meter
Vibration
< 2.5 m/s2
Hydraulic Oil
Shell Tellus T15 or RIVOLTA S.B.H. 11
Maximum Crimping Force
15.6 kN [1.75 tons]
Average Crimping Time
2-4 seconds
Average Crimps per Charge
85-170 (Approx.)
Charging Voltage
18 V
Charging Time
15 Min. –1.3 AH/22 Min. –3.0 AH
Figure 1
INTRODUCTION
SDE lithium-ion battery-powered crimping tool kits 2217480-[ ] each consist of a battery crimping tool (with an
SDE crimping head installed), as well as two rechargeable battery cartridges used to power the tool. See
Figure 1.
Each kit has a battery charger. The battery charger part number, its voltage, and the kit region of use are listed
in Figure 2. The battery-powered crimping tool may or may not have a release switch to retract the ram.
When reading this manual, pay particular attention to DANGER, CAUTION, and NOTE statements.
DANGER
Denotes an imminent hazard that may result in moderate or severe injury.
CAUTION
Denotes a condition that may result in product or equipment damage.
NOTE
Highlights special or important information.
NOTE
Dimensions in this customer manual are in metric units [with U.S. customary units in brackets]. Figures are not drawn to scale.
Crimping Tool Kit with Battery Cartridge Installed
Battery Lock
Battery Cartridge
2217332-1
Release Switch
(Kits 2217480-1
and -2 Only)
Light-Emitting Diode
(LED) Indicator Light
Trigger
Stationary
Jaw
SDE Crimping Head
Movable
Jaw
Shell and RIVOLTA are trademarks of their respective owners.

409-32031
Rev D
5 of 9
CRIMPING TOOL KIT
REGION OF USE
BATTERY CHARGER
BATTERY CHARGER VOLTAGE
RAM RETRACT SWITCH
2217480-1
North America
2217331-1
110 V
Yes
2217480-2
Europe
2217331-2
220 V
2217480-3
North America
2217331-1
110 V
No
Figure 2
Each kit is designed to accept interchangeable die assemblies used in PRO-CRIMPER* hand tools, which
crimp various types of product.
NOTE
This crimp tool accepts TE shoulder mounted die sets. Tool does not accept pin mounted die sets.
RECEIVING AND INSPECTION
Each kit is thoroughly inspected during and after assembly. Prior to packaging and shipping a final series of
tests and inspections is made to ensure proper function of the tool. The following inspection should be
performed as a safeguard against potential problems generated in transit.
1. In a well-lighted area, carefully uncrate the kit and inspect each component as it is removed from the
crate.
2. Thoroughly inspect each component for evidence of damage that may have occurred in transit. If any
of the components are damaged, file a claim against the carrier and notify TE Connectivity
immediately.
3. Keep this manual and all drawings and product samples with the kit for the benefit of operation and
maintenance personnel.
The crimping tool should be inspected at regularly scheduled intervals, depending on care, degree of operator
skill, the type and size of the product to be crimped, and environmental conditions. At a minimum, the tool
should be inspected after every 40 hours of use.
USER INTERFACE INFORMATION (PRE-OPERATION TESTING)
LED Indicators
White LED Work Light
This LED automatically turns on when the trigger is pulled. The indicator remains lit for ten seconds after
the trigger is released.
Red LED Indicator
The tool is equipped with a special circuit board incorporating several important features. These features
inform the user of the current status of the tool. The red LED will signal in the cases given in Figure 3.
WHAT HAPPENS
WHAT IT MEANS
Red LED flashes for two seconds
The battery has been inserted in the tool
Red LED is lit constantly for 20 seconds at the end of the cycle
Battery charge is below 17 volts at the beginning of the cycle
Tool will not start. Red LED light remains lit for 20 seconds after trigger
is released
Battery charge is below 16 volts at the beginning of the cycle
Tool will stop. Red LED light remains lit for 20 seconds after the trigger
is released
Battery voltage drops below 13 volts during the cycle
Tool will stop. The LED will flash for 20 seconds after the trigger is
released
Motor current exceeds 20 A during the cycle
Circuit has become hot
Figure 3

409-32031
Rev D
6 of 9
Pressure Sensor
The tool is equipped with a pressure sensor that alerts the user of an incomplete crimp.
If the tool is manually retracted before completion of a crimp, the red LED will flash for two seconds
and an audible alarm will sound for two seconds.
If the tool is unable to reach the required crimp force, the red LED will flash for two seconds and an
audible alarm will sound until after the trigger is released.
NOTE
The tool has an on-board memory of previous crimp cycles and the cycle count. This information can be accessed and
downloaded onto a computer using USB Adapter Module 2217896-1.
OPERATION
Battery Installation and Removal
NOTE
The batteries Directive 2006/66/EC introduces new requirements from September 2008 on removability of batteries from
waste equipment in EU Member States. To comply with this Directive, this device is designed to allow the rechargeable
battery pack to be easily removed by the end-user when it needs to be replaced.
To install the battery, slide the battery into the bottom of the crimping tool until it can go no further. There will be
an audible “click” from the battery lock to indicate that the battery has been properly installed.
To remove the battery, disengage the battery lock by applying pressure on the lock toward the bottom of the
crimping tool and slide the battery away from the tool.
DANGER
Always dispose of the old battery pack in an environmentally-responsible way, in accordance with local waste regulations.
Where possible, please recycle the battery cartridge. Contact your local authority for details of battery recycling locations in
your area.
Die Assembly Installation and Removal
DANGER
To avoid personal injury, be sure to exercise extreme caution when handling the crimping tool. Remove the battery before
installing or removing the die assembly.
Each kit is supplied with an SDE crimping head installed on the battery-powered crimping tool. The only
installation required is the die assembly.
CAUTION
Do not operate the tool without the SDE crimping head installed. Damage to the ram or seals can result.
CAUTION
Do not operate the tool without the die assembly installed. Damage to the crimping head can result.
The following instructions are specific to the use of TE SDE die assemblies. Make sure to use only TE SDE die
assemblies.
Installation
1. Remove the battery from the crimping tool.
2. Remove the two die retaining screws from the crimping head.
3. Slide the upper die into the stationary jaw of the crimping head. Orient the upper die so that the
indenters face inward, with the largest indenter entering first, and the screw holes align. See Figure 4.
4. Insert the upper die retaining screw into the screw hole of the stationary jaw and through the screw
hole of the upper die. Tighten the screw just enough to hold the die in place. Do NOT tighten the
screw completely at this time.
Greenlee is a trademark.

409-32031
Rev D
7 of 9
5. Slide the lower die into the movable jaw of the crimping head. Orient the lower die so that the anvils
face inward, with the largest anvil entering first, and the screw holes align. See Figure 4.
6. Insert the lower die retaining screw into the screw hole of the movable jaw and through the screw hole
of the lower die. Tighten the screw just enough to hold the die in place. Do NOT tighten the screw
completely at this time.
7. Re-install the battery, then pulse the trigger to slowly close dies, making sure the crimping chambers
are properly aligned.
8. When the crimping chambers are aligned, tighten the die retaining screws.
Figure 4
Removal
1. Remove the battery from the crimping tool.
2. Remove the die retaining screws, then slide the dies out of the jaws of the crimping head.
Crimping
DANGER
To avoid personal injury, keep fingers clear of the crimping area.
1. Position the product to be crimped in the appropriate crimping chamber.
2. Depress the trigger to advance the ram. This closes the jaws to hold the product to be crimped in
place. Do not deform the wire barrel.
3. Insert a stripped wire in the wire barrel of the product to be crimped; making sure that the wire
insulation does not enter the wire barrel.
CAUTION
Do not use wires with nicked or missing conductor strands.
Stationary Jaw of
Crimping Head
Movable Jaw of
Crimping Head
Lower Die
Upper Die
Upper Die
Retaining Screw
Lower Die
Retaining Screw
Largest Anvil
Largest Indenter

409-32031
Rev D
8 of 9
4. Hold the wire in position, then depress and hold the trigger to complete the crimp. The crimping tool
will return automatically to the first position of its cycle when the crimp is complete.
NOTE
If it is necessary to retract the ram before a crimping cycle is completed, push the release switch. Pushing the release switch
will result in the complete retraction of the ram. Only kits -1 and -2 have a release switch.
CAUTION
This tool is not designed for continuous operation. After 100 cycles, allow the crimping tool to cool for 15 minutes.
CAUTION
Do not re-terminate the crimped product.
PREVENTIVE MAINTENANCE
Daily Maintenance
Perform the following maintenance daily:
1. Inspect the crimping head jaws and dies for wear or damage such as cracks, gouges, or chips.
2. Inspect the tool for damage or leaks. If damage is detected, return the tool to TE for repair.
3. Clean the tool, removing accumulations of dirt and grease from the crimping head, particularly in
areas where the crimping head is installed and the product is crimped. Wipe the entire tool frequently
with a clean, lint-free cloth.
Yearly Maintenance
Once per year or every 10,000 cycles (whichever comes first), the crimping tool should be returned to TE for
inspection.
Lubrication
Lubricate all pins, pivot points, and bearing surfaces with a high-quality grease. TE recommends the use of
Molykote paste, which is a commercially available lubricant.
Lubricate the crimping head in accordance with the following schedule:
Crimping head used in daily production: lubricated daily
Crimping head used occasionally in daily production: lubricate weekly
Crimping head used weekly: lubricate monthly
TROUBLESHOOTING
Prior to Beginning Troubleshooting Procedures, Verify Battery is Operational
1. Be sure that the battery is charged. Re-check the battery after several minutes to ensure that the
battery is holding its charge.
2. Use a nonflammable contact cleaner or pencil eraser to clean the electrical contacts on the battery
and crimping tool.
3. Re-install the battery, and check the crimping tool again.
Molykote is a trademark.

409-32031
Rev D
9 of 9
Refer to Figure 5 for Problems, Probable Cause(s), and Solution
PROBLEM
PROBABLE CAUSE
SOLUTION
Tool is inoperative
Dirt, contaminants, etc., in ram area of tool
Return tool to TE for evaluation
Tool battery contacts damaged
Reform the contacts
Tool components are worn or damaged
Return tool to TE for evaluation
Jaws stop
during operation
Oil level is low
Return tool to TE for evaluation
Air in the hydraulic system
Pull trigger and hold retract button
simultaneously. Hold for approximately 10 seconds
Tool loses oil
Damaged internal seal
Return tool to TE for evaluation
Figure 5
REPLACEMENT AND REPAIR
DANGER
To avoid personal injury, ALWAYS remove the battery cartridge from the tool BEFORE performing any maintenance on the
crimping tool.
Kit replacement parts are identified in Figure 6. Order replacement parts through or return parts to your TE
representative, or call 1-800-526-5142, or send a facsimile of your purchase order to 717-986-7605. Or write to:
CUSTOMER SERVICE (038-035)
TE CONNECTIVITY CORPORATION
PO BOX 3608
HARRISBURG PA 17105-3608
PART NUMBER
DESCRIPTION
2217332-1
Battery
2217331-1
Charger, 120 V, North America
2217331-2
Charger, 220 V, Europe
Figure 6
DECOMMISSIONING
In compliance with the regulations in force in the country where the tool is used, the user must make sure that
waste produced during operation is disposed of correctly. Disposal of lubricants and parts removed must be
carried out in compliance with the standards in force in the country where the tool is used.
RESTRICTION ON HAZARDOUS SUBSTANCES (RoHS) INFORMATION
Information on the presence and location of any substances subject to RoHS can be found at
http://www.te.com/customersupport/rohssupportcenter/
1. Click “Check Product Compliance and Get Statements of Compliance (SoC)”
2. Then click “Check Product Compliance Search Tool”
REVISION SUMMARY
Updated to current TE format, logo, and enterprise name
Added NOTE at end of Section 1
