Instruction Sheet
408-35143
24 FEB 2021 Rev A
PROPER USE GUIDELINES
Cumulative trauma disorders can result from the prolonged use of manually powered hand tools. Hand tools
are intended for occasional use and low-volume applications. A wide selection of powered application
equipment is available for extended-use production operations.
The Commercial Hand Crimping Tool is a commercial-grade tool, and is designed primarily for field installation,
repair, maintenance work, or prototyping in industrial, commercial, or institutional applications. Product crimped
with this tool meets the crimp height requirement for hand tools in the appropriate Application Specification
(114-series), but may not comply with other feature parameters of the specification.
TE Connectivity offers a variety of tools to satisfy your performance requirements. For additional information,
contact Product Information at 800-522-6752.
Figure 1: Commercial hand crimping tool
1
Stationary jaw
5
Ratchet adjustment screw
2
Die retention screws
6
Ratchet adjustment wheel
3
Movable jaw
7
Emergency ratchet release
4
Pivot pin
NOTE
All numerical values are in metric units [with U.S. customary units in brackets]. Dimensions are in millimeters [and inches].
Unless otherwise specified, dimensions have a tolerance of ±0.13 mm [±.005 in.] and angles have a tolerance of ±2°. Figures
and illustrations are for reference only and are not drawn to scale.
Commercial Hand Crimping Tool
Frame Assembly 2362810-1

408-35143
Rev A
2 of 7
1. INTRODUCTION
This instruction sheet provides application and maintenance procedures for the Commercial Hand Crimping
Tool Frame Assembly 2362810-1, shown in Figure 1. The tool is designed to accept interchangeable die
assemblies for crimping various types of products.
NOTE
In most cases, the tool frame assembly is provided with a specific set of dies and is considered a component part of a
crimping assembly. Refer to the instruction sheet packaged with the hand tool and die assembly or with the separate die
assembly for information regarding crimping procedures, crimp height inspection, and die gaging.
Read these instructions thoroughly before installing dies and using the tool frame.
Reasons for reissue of this instruction sheet are provided in Section 7, REVISION SUMMARY.
2. DESCRIPTION
The tool frame consists of two crimping jaws, an adjustable ratchet, spring-actuated handles, two die retaining
screws, and an emergency ratchet release. The slotted design of the tool jaws permits easy installation and
removal of dies. The adjustable ratchet allows handle pressure to be set for optimum die performance.

408-35143
Rev A
3 of 7
3. DIE INSTALLATION AND REMOVAL
Select a die assembly, remove the die retention screws from the tool jaws, and proceed as follows:
3.1. Shouldered dies
1. Place the upper die in the stationary jaw of the tool frame (Figure 2).
2. Insert a die retention screw through the jaw and die.
3. Tighten the screw so that the die is held in place, but that the screw is not completely tighten at this
point.
NOTE
Install die assemblies with center contact crimping chamber with the center contact crimp chamber toward the front of the tool
jaws as shown in Figure 2. If indicated otherwise in another document, follow the specific die requirements demonstrated in
that document.
4. Place the lower die in the moving jaw of the tool frame.
5. Install a die retention screw through the jaw and die.
6. Tighten the screw so that the die is held in place. Do not tighten the screw completely.
7. Slowly close the tool handles, allowing the dies to mate or align, until the ratchet makes the seventh
click.
8. Tighten both die retention screws until snug.
NOTE
The tool ratchet has detents that click eight times as the handles are closed. The ratchet releases on the eighth click.
To remove the die assembly, close the tool handles until the ratchet releases and allow the handles to open
fully. Loosen and remove the die retention screws and slide the dies out of the tool jaws.
Figure 2: Shouldered dies
1
Lower die
2
Center contact crimping chamber
3
Upper die
4
Tool frame
5
Die retention screws

408-35143
Rev A
4 of 7
3.2. Pinned dies
1. Install the wire and insulation anvil dies with the chamfers facing the front of the tool and the die
markings facing outward into the movable jaw of the tool frame (Figure 3).
2. Insert the die retaining pins and the short die retention screw. Do not tighten the screw completely.
3. Install the wire and insulation crimper dies with the chamfers facing the front of the tool and the die
markings facing outward into the stationary jaw of the tool frame.
4. Insert the die retaining pins and the long die retention screw. Do not tighten the screw completely.
5. Slowly close the tool handles, allowing the dies to mate or align. Continue closing the tool handles
until the ratchet makes the seventh click.
6. Tighten both die retention screws until snug.
NOTE
The tool ratchet has detents that click eight times as the handles are closed. The ratchet releases on the eighth click.
7. Install the locator assembly and tighten the hex nut.
Reverse these steps to remove the die assembly.
Figure 3: Pinned dies
1
Anvil dies
5
Locator
2
Chamfers
6
Tool frame
3
Crimper dies
7
Die retention screws
4
Nut
8
Die retention pins

408-35143
Rev A
5 of 7
3.3. Flip-style locator
1. Make sure the die retention pins are installed and the die retention screw is secured (Figure 4).
2. Position the flip locator over the screw and locate it on the protruding die retention pins.
3. Install the locking nut and torque it to 56 N-cm.
NOTE
Each flip-style locator is specific to the die, and its operation is explained in the instruction sheet for that die.
Figure 4: Flip-style locator
1
Flip-style locator
2
Locking nut
3
Die retention screw
4
Die retention pins

408-35143
Rev A
6 of 7
4. CRIMP HEIGHT ADJUSTMENT
The tool frame features a ratchet mechanism and adjustment wheel with a range of settings. The ratchet
mechanism ensures that the tool has completed the cycle. The adjustment wheel controls the amount of handle
pressure exerted on the jaws and dies during the crimping procedure. The ratchet is preset prior to shipment,
but the crimp height must be verified.
Use and wear can also cause the tool to go out of adjustment. Quality control personnel should inspect and
adjust the crimp height on a regular basis.
NOTE
This is a general explanation of the adjustment. For specific information, refer to the instruction sheet packaged with the die
assembly.
1. Crimp a connector onto a properly-prepared wire of correct size.
2. Adjust the crimp height as needed.
If the crimp height is greater than recommended, remove the ratchet wheel adjustment screw and
rotate the adjustment wheel counter-clockwise to a higher setting. Repeat as required.
If the crimp height is less than recommended, remove the ratchet wheel adjustment screw and
rotate the adjustment wheel clockwise to a lower setting.
3. Repeat as required.
If the crimp cannot be made to conform to the dimensions provided in the applicable product application
specification, the tool or dies are defective and must be replaced.
5. MAINTENANCE AND INSPECTION
5.1. Initial inspection
The hand crimping tool frame assembly is inspected prior to shipment. Inspect it on arrival to ensure that it has
not been damaged during shipping.
5.2. Daily maintenance
Operators of the tool must be made aware of, and responsible for, the following daily maintenance
requirements:
Remove dust, moisture, and any other contaminants from the tool with a clean, soft brush, or a clean,
soft, lint-free cloth. Do not use hard or abrasive objects that could damage the tool.
Make certain that the pivot pins are in place and secured with retaining rings.
Protect all pins, pivot points, and bearing surfaces with a thin coat of any good SAE 20 motor oil. Do
not oil excessively.
When the tool is not in use, keep the handles closed to prevent objects from becoming lodged in the
jaws.
Store the tool in a clean, dry area.

408-35143
Rev A
7 of 7
5.3. Periodic inspection
Regular inspections of the tool should be performed by quality control personnel. A record of scheduled
inspections must remain with the tool or be supplied to personnel responsible for the tool. Base the inspection
frequency on amount of use, working conditions, operator training and skill, and established company
standards.
1. Remove all lubrication and accumulated film by immersing the tool (handles partially closed) in a
suitable commercial degreaser that will not affect paint or plastic material.
2. Make certain that all pivot pins are in place and secured with retaining rings.
3. Close the tool handles until the ratchet releases and then allow them to open freely. If they do not
open quickly and fully, the spring is defective and must be replaced. See section 6, REPLACEMENT
AND REPAIR.
4. Inspect the tool frame for wear or damage, paying particular attention to the jaws and pivot points.
If damage is evident, see section 6, REPLACEMENT AND REPAIR.
If the tool is acceptable, lubricate it and return it to service.
6. REPLACEMENT AND REPAIR
To obtain a new tool frame or die assembly, refer to the appropriate instruction sheet or customer manual and
order parts through your TE representative. You can also order parts by any of the following methods:
Go to TE.com and click the Shop TE link at the top of the page.
Call 800-522-6752.
Write to:
CUSTOMER SERVICE (038-035)
TE CONNECTIVITY CORPORATION
PO BOX 3608
HARRISBURG PA 17105-3608
For customer repair services, call 800-522-6752.
7. REVISION SUMMARY
Initial release
