TE Connectivity 314979-1 Reference guide

©2012 Tyco Electronics Corporation, a TE Connectivity Ltd. Company
All Rights Reserved
*Trademark
TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product and/or Company names may be trademarks of their respective owners.
Customer Manual
TOOLING ASSISTANCE CENTER 
1-800-722-1111
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.te.com
1of 16
LOC B
customer manual
409-5860
READ THIS FIRST ! 2


Hydraulic Hand Pump 314979-1 03 JAN 12 Rev C
A.
1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1. Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2. Functional Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1. Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2. Attaching Crimping Head to Hose and Hose to Hand Pump. . . . . . . . . . . . . . . . . . . . 8
3.3. Insertion of Crimping Dies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4. Operating Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4. ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.1. Crimping Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.2. Crimping Dies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.3. Latch Pin Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.4. Hose Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
5. INSPECTION/ADJUSTMENTS AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . .11
5.1. Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
5.2. Filling the Resevoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
5.3. Bleeding Air from the Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5.4. Pressure Relief Valve Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5.5. Filter Screen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
5.6. Pump Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
5.7. Poppet Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6. REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7. REVISION SUMMARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SAFETY PRECAUTIONS

409-5860
SAFETY PRECAUTIONS AVOID INJURY
Safeguards are designed into this application equipment to protect operators and maintenance personnel from
most hazards during equipment operation. However, certain safety precautions must be taken by the operator
and repair personnel to avoid personal injury, as well as damage to the equipment. For best results, application
equipment must be operated in a dry, dust-free environment. Do not operate equipment in a gaseous or
hazardous environment.
•Carefully observe the following safety precautions before and during operation of the equipment:
•ALWAYS wear appropriate ear protection.
•ALWAYS wear approved eye protection when operating powered equipment.
•ALWAYS keep guard(s) in place during normal operation.
•ALWAYS insert power plug into a properly grounded receptacle to avoid electrical shock.
•ALWAYS turn off the main power switch and disconnect electrical cord from the power source when
performing maintenance on the equipment.
•NEVER wear loose clothing or jewelry that may catch in moving parts of the application equipment.
•NEVER insert hands into installed application equipment.
•NEVER alter, modify, or misuse the application equipment.
TOOLING ASSISTANCE CENTER
CALL TOLL FREE 1-800-722-1111 (CONTINENTAL UNITED STATES AND PUERTO RICO ONLY)
The Tooling Assistance Center offers a means of providing technical assistance when required.
In addition, Field Service Specialists are available to provide assistance in the adjustment or repair of the
application equipment when problems arise which your maintenance personnel are unable to correct.
INFORMATION REQUIRED WHEN CONTACTING THE TOOLING ASSISTANCE CENTER
When calling the Tooling Assistance Center regarding service to equipment, it is suggested that a person familiar
with the device be present with a copy of the manual (and drawings) to receive instructions. Many difficulties can
be avoided in this manner.
When calling the Tooling Assistance Center, be ready with the following information:
1. Customer name
2. Customer address
3. Person to contact (name, title, telephone number, and extension)
4. Person calling
5. Equipment number (and serial number if applicable)
6. Product part number (and serial number if applicable)
7. Urgency of request
8. Nature of problem
9. Description of inoperative component(s)
10. Additional information/comments that may be helpful
2of 16
Rev C
DANGER
STOP

Pump Lever
Filler Plug Outlet Valve Port
Hold/Return Lever Crimping Head (Ref)
Hose (Ref)
409-5860
3of 16
Rev C
Figure 1
1. INTRODUCTION
Hydraulic Hand Pump 314979-1 combines the convenience of a hand tool with the power of a bench machine. It
is used primarily for low-volume production or at locations where electrical power sources are not readily
available. See Figure 1.
Heads and dies are available for use in this unit to crimp terminals and splices, in wire size ranges from No. 8
AWG to 1000 MCM. It should be noted that the crimping of terminals and splices in the 600 MCM to 1000 MCM
range will require additional operator effort.
The hand pump can be used as a portable crimping unit. This type of operation provides a large working radius
and accessibility to confined areas.
A complete line of precision-engineered heads and matched die sets is available from TE. Hose assemblies, in
four different lengths, are also sold separately. See Figure 8 for accessory part numbers.
When reading this manual, pay particular attention to DANGER, CAUTION, NOTE statements.
DANGER
STOP
Denotes an imminent hazard which may result in moderate or severe injury. 


!
CAUTION
Denotes a condition which may result in product or equipment damage. 


NOTE
i
Highlights special or important information. 

NOTE
i
409-5860
4of 16
Rev C
Allnumerical valuesare inmetric units[withU.S. customaryunits inbrackets]. Dimensionsarein millimeters [andinches].
Unlessotherwisespecified, dimensionshave a toleranceof ±0.13[.005] andangles havea tolerance of±2°. Figuresand
illustrations are for identification only and are not drawn to scale.
2. DESCRIPTION
2.1. Physical Description
The hydraulic hand pump features a two-speed hydraulic pumping unit. This unit will deliver 4.75 ml [.29 cu in.]
per stroke at high pressure (up to 58608 kPa [8500 psi]), and 120.4 ml [7.35 cu in.] per stroke at 0 to 1379 kPa
[200 psi] for fast ram advance and return. See Figure 2 for hand pump specifications.
Figure 2

409-5860
5of 16
Rev C
The pump is shipped with hydraulic fluid in the reservoir. Refer to Section 5, INSPECTION/ADJUSTMENTS
AND MAINTENANCE, for refilling instructions. If additional fluid is required, it is essential that the proper grade
of high-quality hydraulic fluid be used. Recommended hydraulic fluids and manufacturers of high-grade fluid for
use in the hand pump are listed in Figure 3.
CAUTION
!
NEVER use brake fluid as a substitute for the recommended hydraulic fluid.
HYDRAULIC FLUID MANUFACTURER
COSMOLUBRIC † No. 1500 E.F. Houghton & Co.
CLAVUS‡} 27 Shell Oil Co.
Duro 160 Sinclair Refining Co.
HAVOLINE▲10 Texaco Inc.
GARGOYLE ARCTIC C♦Mobile Oil Co.
† COSMOLUBRIC is a trademark of E.F. Houghton & Co.
‡ CLAVUS is a trademark of Shell Oil Co.
▲HAVOLINE is a trademark of Texaco Inc.
♦GARGOYLE ARCTIC C is a trademark of Mobil Oil Co.
Figure 3
2.2. Functional Description (Figure 4)
On the intake stroke (up-stroke) of two-section piston (H and L), hydraulic fluid is drawn from the reservoir (K)
and into intake line (A). See Detail A of Figure 4. The fluid flows past low-pressure intake poppet (B) into the low-
pressure chamber, and it flows past high-pressure intake poppet (F) into the high-pressure chamber.
On the pressure stroke (down-stroke) of two-section piston (H and L), hydraulic fluid in the low-pressure
chamber is directed through spool (C), past outlet poppet (D), and through outlet valve (J) to the crimping head.
See Detail B of Figure 4. Simultaneously, the hydraulic fluid in the high-pressure chamber is directed through
high-pressure outlet poppet (G), past outlet poppet (D), and through outlet valve (J) to the crimping head. This
action causes the moving die to close, holding the terminal or splice in crimping position.
When approximately 1379 kPa [200 psi] is developed (see Detail C of Figure 5), hydraulic fluid from the high-
pressure chamber will cause outlet poppet (D) to shift spool (C), allowing low-pressure hydraulic fluid to be
discharged into reservoir (K). High-pressure hydraulic fluid continues to flow through high-pressure outlet poppet
(G), past outlet poppet (D) and outlet valve (J), and into the crimping head, completing the crimp.
The high-pressure system has a pressure relief valve (M) which is set at the factory to release at between 55160
and 57918 kPa [8000 and 8400 psi]. If the pressure buildup in the high-pressure system exceeds this setting,
pressure relief valve (M) will open, causing the hydraulic fluid to be discharged into reservoir (K).
NOTE
i
DO NOT alter the setting of the pressure relief valve.
Turning the hold/return lever to the return position advances plunger (P) which opens poppet (X). See Detail D of
Figure 5. When poppet (X) opens, hydraulic fluid returns from the crimping head to reservoir (K), for as long as
the lever is in the return position.

409-5860
6of 16
Rev C
Figure 4

409-5860
7of 16
Rev C
Figure 5

409-5860
8of 16
Rev C
3. OPERATION
CAUTION
!
NEVER operate hand pump without having hose and crimping head attached. Refer to Figure 6.
3.1. Preparation
1. Check level of hydraulic fluid in reservoir, and add fluid if required. Refer to Paragraph 5.2.
2. Protective caps are put on crimping heads and hose fittings to prevent dirt from entering the hydraulic
system. Ensure that caps are placed on head and hose fittings when they are disassembled.
CAUTION
!
Never store hand pump without having head or protective cap attached to the hose fittings.
Lever
Filler Plug Outlet Valve Port
Hose (Ref)
Crimping Head (Ref)
Figure 6
3.2. Attaching Crimping Head to Hose and Hose to Hand Pump
CAUTION
!
Always have lever in the return position when connecting or removing hose couplings or crimping heads.
A. To attach the crimping head, proceed as follows:
1. Thoroughly clean coupling area of hose assembly and crimping head.
2. Remove protective caps.
3. Mate coupling halves and tighten collar (refer to Figure 7).
B. To attach hand pump to hose, proceed as follows:
CAUTION
!
Make sure that the lever is in the return position while connecting coupling halves.

Crimping Head
Hose Female
(Cylinder Half)
Male
(Hose Half)
409-5860
9of 16
Rev C
Figure 7
1. Thoroughly clean coupling area of hose assembly and hand pump.
2. Remove protective caps.
3. Mate coupling halves and tighten collar (refer to Figure 7).
4. After the hose has been attached to head and pump, bleed all air from the hydraulic system. Refer to
Paragraph 5.3.
3.3. Insertion of Crimping Dies
The instruction materials packaged with the dies give detailed instructions for die insertion, die adjustments, and
die removal when the dies are used with crimping heads as listed. Insert required crimping dies as instructed.
NOTE
i
All listed die numbers are for complete die sets except for those identified as nests or indenters for SOLISTRAND*
connectors. The interchangeability of nests and indenters for SOLISTRAND connectors requires that these dies be
identified separately.
3.4. Operating Procedure
1. Be certain that crimping dies are properly installed in head. Refer to instruction material packaged with
crimping dies for die insertion instructions.
2. Place terminal or splice in crimping dies. Refer to instruction material packaged with crimping dies for exact
terminal or splice location in dies.
NOTE
i
BE SURE latch pin has been fully inserted before operating pump.
3. Pump lever to activate unit. Continue pumping lever until ram moves up and holds terminal or splice firmly
in place. A sudden decrease in effort required to push lever down will be observed during the initial buildup of
pressure.
4. Insert stripped wire into terminal or splice.
5. Continue pumping until pressure relief valve is activated. A slight decrease in effort required to push lever
down indicates that maximum required crimping pressure has been reached and that crimp is now complete.
6. Move the lever to the return position, and hold the lever in this position. Ram in crimping head will return to
DOWN position, and crimped terminal or splice can be removed.
7. To make additional crimps, repeat Steps 2 through 6 as required.
NOTE
i
Holdlever inthe returnposition longenoughtoallowram tomove downjust enoughtoremove crimpedterminal orsplice.
Return the lever to the hold position for the next cycle.

CAUTION
!
409-5860
10 of 16
Rev C
DO NOT allow hand pump to remain under pressure for extended periods of time.
4. ACCESSORIES
4.1. Crimping Heads
The hand pump uses interchangeable crimping heads. Each crimping head uses interchangeable crimping dies
(with the exception of crimping head 69069, which has integral dies designed for that particular head). The
products to be crimped in each head are listed in the instructions covering the head.
4.2. Crimping Dies
Each crimping head, except as noted in the preceding paragraph, uses interchangeable crimping dies designed
for that particular head. The instructions packaged with the dies give complete information.
4.3. Latch Pin Kit
Latch pin kits are available as accessories for the crimping heads as listed and shown in Figure 8. This kit was
designed to eliminate the possibility of misplacing the standard latch pin furnished with the head.
4.4. Hose Assemblies
Hoses are sold separately as accessories and are available in different lengths, which are listed with the part
numbers in Figure 8.
HEAD
NUMBER
LATCH PIN
KIT nUMBER
HOSE aSSEMBLY NUMBER
PART NUMBER LENGTH m [Ft.]
69051 69709 59909-3 .914 [3]
69065 69709-2 59909-7 2.134 [7]
69066 69709-3 1-59909-5 14.572 [5]
69067 69709-4 2-59909-1 6.401 [21]
Figure 8

409-5860
11 of 16
Rev C
5. INSPECTION/ADJUSTMENTS AND MAINTENANCE
DANGER
STOP
Before performing any maintenance, MAKE SURE that the hold/return lever is in the return position.
5.1. Troubleshooting
The hand pump is thoroughly tested before it leaves the factory, and it should be in excellent operating condition
when it reaches the user. However, damage may occur during shipment. While unpacking the hand pump,
carefully inspect it for damage. If damage is evident, file a claim against the carrier and notify Tyco Electronics,
Harrisburg, PA.
If, at any time, the pump does not function properly, the troubleshooting chart (Figure 9) and the rest of the
material in Section 5 should be used to locate and correct the trouble. (Refer to Figure 14 for parts identification.)
If the problem cannot be corrected with the aid of the troubleshooting chart, contact your local Field Service
Specialist or Tyco Electronics, Harrisburg, PA 17105.
SYMPTOM CAUSE REMEDY
1.Hand pump does not develop
pressure.
Low hydraulic fluid level. Fill reservoir. Refer to Paragraph
5.2.
Loose pump body fittings Tighten pump body fittings. Refer
to Paragraph 5.6.
Improper seating of poppets. Correct poppet seating. Refer to
Paragraph 5.7.
2.Hand pump does not develop
high pressure High-pressure poppets or spool
not seating properly. Correct poppet seating. Refer toParagraph 5.7.
3.Hand pump does not develop
full crimping pressure.Pressure relief valve not
functioning properly. Checkpressurereliefvalve.Refer
to Paragraph 5.4. Replace if
necessary.
4.Slow die return.
Dirt or foreign matter in hydraulic
system Replace damaged filter. Refer to
Paragraph 5.5.
Dirt or foreign matter in spool or
poppets. Check poppets. Refer to
Paragraph 5.7.
Weak piston return spring in.. Remove crimping head and refer to separate instruction sheet for
the crimping head.
5.Pump does not draw fluid from
reservoir.Low hydraulic fluid level. Fill reservoir. Refer to Paragraph
5.2..
6.Handle feels “spongy" when
pumped. Air in hydraulic system. Bleed air from hydraulic system.
Refet o Paragraph 5.3.
Figure 9
5.2. Filling the Reservoir
To check fluid level:
1. Use a clean cloth to remove all dust and grit from area around filler plug. See Figure 6.
2. Remove filler plug, and check fluid level by measuring depth with a clean rod or screwdriver. Fluid level
should be approximately 25.4 [1.000] to 38.1 [1.500] from top of filler hole.
NOTE
i
Minimum fluid level to provide proper operation is approximately 38.1 [1.500] from bottom of reservoir.
3. If fluid level is satisfactory, replace filler cap. If fluid level is too low, add fluid.

CAUTION
!
409-5860
12 of 16
Rev C
NEVER use brake fluid as a substitute for the recommended hydraulic fluid.
To add fluid:
1. Use a clean cloth to remove all dust and grit from area around filler plug. See Figure 6.
2. Remove filler plug, and insert a clean funnel, with filter, into filler hole.
3. Fill reservoir with recommended hydraulic fluid. See Figure 3.
4. Replace cap and be certain that breather hole in cap is open.
5.3. Bleeding Air from the Hydraulic System
If air gets into the hydraulic system (indicated by a "spongy" action of the handle when it is pumped), the air
should be removed as follows:
NOTE
i
Hand pump should always be elevated above crimping head when bleeding air from hydraulic system.
1. Make sure that the hold/return lever is in the return position.
2. Pump the lever several times to fill hydraulic pump.
3. Move the lever to the hold position.
4. Pump the lever until ram (moving die holder) advances.
5. Position the lever to remove air from the hydraulic system.
6. Repeat Steps 4 and 5 about three times to ensure that all air is removed from hydraulic system.
7. Check hydraulic fluid supply after bleeding the system. Fill if necessary, according to Paragraph 5.2. Hand
pump is now ready for use.
5.4. Pressure Relief Valve Check
NOTE
i
This procedure should be performed with crimping head and hose attached.
The pressure relief valve is preset at the factory to open at 55160 to 57918 kPa [8000 to 8400 psi]. This valve
should be checked periodically, depending on use. Proceed as follows:
CAUTION
!
Make sure that the hold/return lever is in the return position.
1. Remove pipe plug and install gage. See Figure 10.
2. Pump lever until the bypass is activated. A slight decrease in effort required to move the lever indicates that
maximum required crimping pressure has been reached.
3. Take pressure reading to ensure that pressure is within acceptable range.
4. Position lever to release all hydraulic pressure from pump.
5. Remove gage and replace pipe plug.
CAUTION
!
NEVER alter the setting of the pressure relief valve. If the valve does not open at the required pressure, it should be
replaced.

Plug-RemovetoInstall
Pressure Gauge 3/8 NPTF
Hydraulic Pressure Gauge
0-10,000 PSI Range
(OTC Y5-B‡, or Equivalent)
‡ MANUFACTURED BY OWATONNA TOOL CO., OWATONNA, MINNESOTA 55060
409-5860
13 of 16
Rev C
Figure 10
5.5. Filter Screen Maintenance
All hydraulic fluid entering the hydraulic system must pass through the filter screen. The filter screen prevents
dirt and any other foreign matter in the reservoir from entering the hydraulic system.
The hand pump should never be operated with a dirty filter screen, a damaged filter, or without a filter screen.
The reservoir and filter screen should be cleaned periodically, and the hydraulic fluid replaced, to ensure
operating efficiency. New filter screens can be obtained from TE. (Refer to Section 6, REPLACEMENT PARTS.)
If the hand pump does not operate at a consistent speed, the problem may be caused by a dirty or damaged
filter screen.
A. Cleaning Filter Screen
To clean the filter screen:
1) Refer to Figure 11. Remove six pump assembly screws, holding reservoir cover to reservoir, and
carefully lift pump assembly from reservoir.
Pump Assembly Screws
Reservoir
Pump Assembly Screws
Figure 11

409-5860
14 of 16
Rev C
2) Refer to Figure 12, and remove the retaining ring, band, and filter screen.
3) Clean the filter screen in an appropriate solvent.
4) Replace the filter screen, band, and retaining ring.
5) Carefully lower the pump assembly into the reservoir.
CAUTION
!
Care MUST BE taken to prevent damage to the filter screen. DO NOT operate the hand pump with a damaged filter
screen or without a filter screen.
6) Insert and tighten pump assembly holding screws.
B. Replacing Filter Screen
To replace the filter:
1) Remove pump assembly from reservoir as described in Steps 1 through 3 of Paragraph 5.5, A.
2) Refer to Figure 12, and remove the retaining ring, band, and filter screen.
3) Install a new filter screen and replace the band and retaining ring.
4) Re-assemble the pump assembly.
Pump Assembly
Screw
Plug
Band
Filter Screen
Retaining Ring
Figure 12
5.6. Pump Maintenance (Refer to Figure 14)
If the hand pump does not develop pressure, the trouble may be caused by loose pump body fittings. To tighten
these fittings, proceed as follows:
1. Disconnect hydraulic hose from hand pump.

409-5860
15 of 16
Rev C
2. Refer to Figure 11. Remove the six pump assembly screws, holding the reservoir cover to the reservoir, and
carefully lift the pump assembly from the reservoir.
Pump Body
Assembly Screws
Pump Body
Assembly Screws
Figure 13
3. Tighten the four pump body assembly screws. Refer to Figure 13.
4. Refer to Figure 12. Remove the retaining ring, band, and filter screen, and then tighten screw and plug.
5. Replace the filter screen, band, and retaining ring.
6. Carefully insert the pump assembly into the reservoir; replace and tighten the six pump assembly screws.
7. Re-assemble return lever linkage (if lever was removed) and attach return spring.
8. Actuate hand pump to determine if pump will develop pressure. If hand pump does not function properly,
return the pump to TE for repair. Contact your TE representative for assistance.
5.7. Poppet Maintenance (Refer to Figure 14)
If the hand pump does not develop pressure, and the hydraulic fluid level (Paragraph 5.2) is satisfactory, and all
pump body fittings (Paragraph 5.6) are properly tightened, check the condition of poppets and poppet seats.
Contact your TE representative for assistance.
6. REPLACEMENT PARTS
Figure 14 contains an exploded-view drawing of Hydraulic Hand Pump No. 314979-1, with references for items
included in Repair Kit 314980-1. Refer to the parts list included with Repair Kit 314980-1 for part number and
quantity information.
When ordering replaceable parts, be sure to specify the correct part number, description, and quantity required.
Refer to Section 4 for accessory part numbers.
7. REVISION SUMMARY
Since the previous release of this manual:
•The logo was updated and the format was updated to the current corporate requirements; and
•A backup bushing in Figure 14 was referred to as a PTFE Backup Busing.

Wiper Ring (1)
End Cap 
Gasket (2)
Retaining Ring (3)
Cover Plate
Gasket (14)
Backup Washer (4)
Retaining Ring (5)
O-Ring (6)
PTFE Backup
Washer (7)
Compression
Spring (8)
Filter (10)
Soft Copper
Washer (9)
Soft Copper
Washer (11)
Compression
Spring (13)
Compression
Spring (12)
409-5860
16 of 16
Rev C
Figure 14
