TE-Group mr Handsfree Blue Alert Gold User manual

GB
Quick Reference Guide
NL FR ES IT D

Hereby,
declares that:
Is in compiance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
The product has been tested against the following standards and specifications, applying versions valid on Feb 11, 2009:
EN 301489-17 V1.3.2, EN 301489-1 V1.8.1, EN 300 328 V1.7.1, EN 300 487 + A1 and EN 60950-1.
Joseph Van Oosterum, CEO TE Group NV, 03-11-2011
Company: TE-GROUP nv
Address: Kapelsestraat 61, 2950 Kapellen - BELGIUM
Product Name: mr Handsfree Blue Alert (Gold)
Product Type: Bluetooth®carkit and GPS Alert
DECLARATION OF CONFORMITY

Illustration I
9
8
2
3
5
1
4
12
10
13
7
11
6
Illustration II

AB AB
Illustration V
Illustration III Illustration IV

HAN DSF REE
CALLING
=+
GPS
GB
1
INTRODUCTION
The mr Handsfree Blue Alert Gold is a unique 2-in-1 device that combines a Bluetooth®handsfree carkit with a legal GPS
speed camera warning system.
FOLLOW THESE STEPS WHEN USING THE BLUE ALERT GOLD FOR THE
FIRST TIME:
Place the battery.
Charge the battery.
Set the device ON.
Important!
You have 3options:
Option 1: The Blue Alert Gold can be used as Bluetooth®carkit ONLY.
(No speed camera warnings will be given in this setting!)
 →Seep.5CENTRALBUTTON–Turningon’.
Option 2: The Blue Alert Gold can be used as Bluetooth®carkit + GPS warning system.
 →Seep.6GPSSWITCH–SwitchingtheGPSfunctionoff’.
Option 3: the Blue Alert Gold can be used as GPS warning system ONLY.
It is possible to use the Blue Alert Gold without a connection with your mobile phone during 1 hour (for camera warnings only).
After 1 hour the unit will turn off automatically (to save the battery).
To re-start this “GPS only” function without mobile phone/Bluetooth®connection, press and hold the CENTRAL BUTTON to
continue your trip for another hour.
1.
2.
3.

2
4. Choose / select language.
The GPS warning system of the Blue Alert Gold can be programmed into 5 different languages:
English, French, German, Italian and Spanish.
Set the language of the GPS warning system
→ See p.8MENUBUTTON–Language’.
5. Pair the mobile phone to the Blue Alert Gold.
→ Seep.5.CENTRALBUTTON–Pairing’
6. Install the Blue Alert Gold software on your PC.
You can find this CD in the box. This CD contains download software. This software enables your PC to download the data-
base with camera locations into your Blue Alert Gold.
7. Go to www.mrhandsfree.com to download the database into your Blue Alert Gold.
8. Connect the Blue Alert Gold with the USB cable to your PC.
9. Download the database into your Blue Alert Gold.
See separate sheet ‘DOWNLOADDATABASELOCATIONS’.
10. Mount the Blue Alert Gold on the dashboard of your car.
→ See below ‘INSTALLATIONOFTHEBLUEAlertGold’.

GB
3
INSTALLATION OF THE BLUE ALERT GOLD
You have 2 installation options: on the sun visor (a) and on the dashboard (b)
a) On the sun visor (see illustration II): you need holder + clip
=> How to change display for sun visor position?
In the menu, there is an option to turn the information
on the display in the good position for sun visor mounting.
• Press the MENU-button 12 times until “Ud.OF” appears on the display
(Ud = ‘Upside down’)
• Press the ADD/DEL button to change the direction (On= upside down).
=> LED brightness:
When you choose to mount the Blue Alert Gold on your car’s sun visor, the information on the display could be rather bright for
your eyes, especially when driving at night. How to adjust the LED brightness?
• Press the MENU-button 13 times until “LEd 3” appears on the display.
• Press the ADD/DEL button to set the LED brightness: 1 = low brightness, 2 = middle brightness, 3 = high brightness
b) On the dashboard (see illustration V):
Fix the Blue Alert Gold on the dashboard using the non slip rubber pads or Velcro strips (see ‘illustration V’)
1. Non slip rubber pads: The rubber pads (= non slip) will help preventing the Blue Alert Gold from slipping on the dashboard.
2. Velcro strips

4
Installation tips:
• Make sure the dashboard is clean and free of dust or grease before sticking the Velcro strips! (for dashboard mount)
• Make sure the unit is clean and free of dust or grease before placing the non slip parts. (for dashboard mount)
• For optimal performance, the microphone should always be located at a maximum distance of 50 cm from the driver’s mouth.
• The LED-screen with built-in microphone should be directed to the driver.
Make sure that the mounting cannot cause any damage to your body or your passengers body in case of an accident or
unexpected movement !
CHARGING THE BATTERY
The Blue Alert Gold comes with a rechargeable battery. Open the battery compartment cover and place the battery
(See illustration III). Make sure that the Blue Alert Gold is fully charged before using the device!
Important!
Only use the original chargers included in the packaging to avoid damages.
The Blue Alert Gold offers 2 charging options:
1. Via the USB cable: connected to your computer
2. Via the car charger: connected to the cigarette lighter
The LED indicator (5) will light red when the charging process begins.
The battery is fully charged when the red LED indicator (5) turns off.
Important!
If the Blue Alert Gold has not been used for a long time, it might take some time before the red LED indicator (5) will turn on.
To ensure optimal battery quality, you should always charge the battery when the red LED indicator (5) is ashing.
•
•

GB
5
PARTS & FUNCTIONS
SEE ILLUSTRATION I
1. CENTRAL BUTTON
(=ON/OFF-button and button for Pairing / Answer a call / End a call / Reject a call / Voice dialing / Redial / 2nd call )
Turning on:
Press and hold (3 sec) the Central button (1) until you hear a melody and the blue LED indicator (4) starts flashing.
Turning off:
Press and hold (3 sec) the Central button (1) until you hear a melody and the red LED indicator (4) lights up briefly before
turning off again.
Attention!
The Blue Alert Gold will also turn off automatically if there has been no Bluetooth®connection between the Blue Alert Gold
and another mobile device for more than 1 hour.
Pairing:
You are required to pair the BlueAlert Gold with your mobile phone before using it! Make sure that the BlueAlert Gold is turned off
(LED indicator = off). → Make sure that the Bluetooth® function of your mobile phone is turned on and let your phone search
for Bluetooth®devices. → Press and hold the Central button (1) of the Blue Alert Gold until the LED indicator (5) starts flash-
ing by blue and red colours alternately.
Your mobile phone, which is still in search mode, will show the Blue Alert Gold in the list of found Bluetooth® devices.→ Select
the Blue Alert Gold in your mobile phone and enter the PIN code 0000 to pair both devices. →The blue LED indicator (5) will
start flashing again. You will hear a long beep.
•
•
•

GPS
6
Answer a call:
Press the Central button (1) to answer a call.
End a call:
Press the Central button (1) to end the current call.
Reject a call:
Press the Central button (1) for 3 seconds to reject the call.
Voice dialing:
Press the Central button (1) until you hear a tone that indicates that you can pronounce the desired name (=’voice tag’).
→ Say the voice tag. →The phone will now play the voice tag and starts dialing the related phone number.
Redial:
Press the Central button (1) 2 x quickly. → The phone will dial the last dialed number.
2nd call:
Double press the Central button (1) once shortly to answer the 2nd call and to put the current call on hold. Press the Central
button (1) twice to switch between two calls. Press the Central button (1) once during the 2nd call, to end one of the two
calls.
2.GPS SWITCH
(to switch the GPS warning system function on or off)
To switch the GPS warning system function on:
Slide the GPS Switch (2) to the right. Your unit is in ON position (Blue LED indicator is flashing).
You will hear “Fasten your seatbelt. Be careful.”
(= ‘ready’) will now appear on the display.
•
•
•
•
•
•
•

GB
7
3. (+) AND (-) VOLUME BUTTON
(Adjusting the volume of the Bluetooth®carkit / Restoring default settings of the Bluetooth®carkit)
Adjusting the volume of the Bluetooth®carkit:
Press (+) to increase the volume level.
Press (-) to decrease the volume level.
Restoring default settings of the Bluetooth®carkit:
In Standby mode, press and hold both Volume buttons (+) & (-) simultaneously for 10 seconds. You will hear two beeps and the
blue and red LED indicator will flash alternately.
4. MODE BUTTON
(Activate Mute mode / Transferring calls from the Blue Alert Gold to the mobile phone and back)
Activate Mute mode:
During a conversation, press and hold the MODE button (4) for 3 seconds to temporarily turn off the microphone of the
Blue Alert Gold. The red and blue LED indicator will flash alternately.
Deactivate Mute mode:
Press and hold the MODE button (4) for 3 seconds.
Transferring calls from the Blue Alert Gold to the mobile phone and back:
During a conversation, press the MODE button (4) twice to continue the conversation through your mobile phone. To con-
tinue the conversation through the Blue Alert Gold, press the MODE button (1) twice again.
•
•
•
•
•

8
5. LED INDICATOR
(Can turn red/blue or red & blue)
Red indicator: - Flashes in Standby mode: low battery capacity (+ warning tones)
- Lights continuously while charging the battery or when in mute mode
Blue indicator: - Flashes in Standby mode
- Lights continuously during a call
Red + blue indicator: - Flash alternately in Pairing mode
- Flash alternately after restoring default settings
6. MICROPHONE
At all times, please point the microphone (6) (located in the LED screen) towards your mouth. For optimal perform-
ance, the microphone should be located at a maximum distance of 50 cm from the drivers’ mouth. Make sure no
objects are located in front of the microphone.
7. MENU BUTTON
Using this button you enter into the menu where various settings for the GPS warning system can be pro-
grammed.
Conrmation of requested setting is done by the ‘ADD/DEL button (9)’ (see next chapter).
•
•
•

If no button is pressed within 5 seconds, the unit exits the menu!
GB
9
Press the button What can be programmed? Display indication
1 (once) GPS voice volume (from 1 up till 8) VOL 1/…/8
2 (twice) Maximum speed (from 30 up till 250) M 30/…/250
3 (…) Sound on or off S. On/OFF
4 (…) Language (English / French / Spanish / Italian / German) L - Gb/Fr/SP/it/dE
5 (…) Odometer (= total traveled distance from a selected moment) O
6 (…) Average speed A 0
7 (…) Clock on or off H. On/OFF
8 (…) Speed indication: Km/h or M/h SI:00/01
9 (…) Time zone t
10 (…) Version software U
11 (…) Date database 8:9
12 (...) Direction display Ud. On/OF
13 (...) LED Brightness Led 1/2/3

USB
USB
10
8. ADD/DEL BUTTON
(To conrm preferred settings / To manually add/delete personal locations)
To conrm preferred settings:
Press the MENU button (8) to enter the menu.
Press the ADD/DEL (9) button to conrm the preferred setting.
To manually add personal locations:
Press the ADD/DEL button (9) while passing the location you would like to add.
will now appear on the display.
To manually delete personal locations:
Press the ADD/DEL button (9) while passing the location you would like to delete.
will now appear on the display.
9. USB PORT
(To place the USB cable)
This allows you:
To charge the Blue Alert via the USB cable: connected to your computer.
To charge the Blue Alert via the car charger: connected to the cigarette lighter.
To download database for xed camera locations into the Blue Alert. (Seeseparatesheet‘Downloaddatabase
locations’tondouthowtodownloadandupdatethedatabaseforxedcamerasintoyourBlueAlert!)
•
•
•
•
•
•

10. DISPLAY
You find useful information on the Blue Alert’s LED display: speed of the vehicle, maximum speed, distance between
your vehicle and the speed control, clock, …
What appears on the display, including various announcements:
While starting up the GPS warning system:
While not moving:
GB
11
Visual warning Vocal warning Meaning
Fasten your seatbelt. Be careful! GPS is searching for the satellites.
/ / Clock or speed indication + Satellites
were found.
Srch
7:16 55
Visual warning Vocal warning Meaning
/ Clock
7:16

12
While driving:
Visual warning Vocal warning Meaning
/Your driving speed, if you have chosen to hide the clock in the menu
(see “MENUBUTTON-Clockonoroff”)
/The clock, if you have chosen to show the clock in the menu
(see “MENUBUTTON-Clockonoroff”)
Camera There’s a speed camera within 500 meters of your current position
Camera close There’s a speed camera within 300 meters of your current position
Section control There’s a section control within 500 meters of your current position
Section control close There’s a section control within 300 meters of your current position
Section control end End of the section control
Dangerous spot There’s a dangerous spot within 500 meters of your current position
Personal location There’s a personal location (=location you added yourself) within 500 meters of
your current position
55
7:16
C 500
C 500
C 500
C 500
C 300
C 300
C 0

GB
13
Add
dEL
/ Speed alert
This ‘Speed Alert’ could mean one of the following:
1) You are exceeding the maximum driving speed that you have selected in the
menu (see“MENUBUTTON-MaximumSpeed”)
2) You are exceeding the maximum driving speed that is allowed at the location
of the camera you are approaching (according to our database).
Added You have added a personal location
Deleted You have deleted a personal location

14
11. SPEAKER
12. BATTERY COMPARTMENT COVER
ACCESSORIES IN THE BOX
Car charger
USB charging cable
Rubber pads (for dashboard mounting)
Velcro strips (for dashboard mounting)
Holder (for sun visor mounting)
Clip (for sun visor mounting)
1.
2.
3.
4.
5.
6.
6
5

GB- GUARANTEE
Mr Handsfree is a registered trademark of TE-Group NV. The mr Handsfree brand stands for superior product quality and
outstanding customer service. That is why mr Handsfree warrants this product against all defects in material and workmanship
for a period of two (2) years from the date of original purchase of the product. The conditions of this guarantee and the extent of
responsibility of mr Handsfree under this guarantee can be downloaded from our website: www.mrhandsfree.com.
NL- GARANTIE
Mr Handsfree is een gedeponeerd handelsmerk van TE-Group NV. Het merk mr Handsfree staat voor producten van superieure
kwaliteit en een uitstekende klantenservice. Daarom garandeert mr Handsfree dat dit product vrij is van materiaal- en
fabricagefouten gedurende een periode van twee (2) jaar na de oorspronkelijke aankoopdatum van het product. De voorwaarden
van deze garantie en de omvang van de verantwoordelijkheid van mr Handsfree onder deze garantie kunt u downloaden van de
website: www.mrhandsfree.com.
FR- GARANTIE
Mr Handsfree est une marque déposée de TE-Group NV. La marque de mr Handsfree est synonyme de produits de qualité
supérieure et d’un service après-vente excellent. C’est la raison pour laquelle mr Handsfree garantit ce produit contre tout défaut
de matériel ou de fabrication pour une période de deux (2) ans à compter de la date d’achat initiale. Les conditions de cette
garantie et l’étendue de la responsabilité de mr Handsfree en vertu de cette garantie sont disponibles en téléchargement sur
notre site Internet www.mrhandsfree.com.
82

ES- GARANTÍA
Mr Handsfree es una marca registrada de TE-Group NV. La marca mr Handsfree representa una calidad de producto superior
y una excelente atención al cliente. Por esto es por lo que mr Handsfree garantiza este producto contra todos los defectos
materiales y de mano de obra durante un periodo de dos (2) años a partir de la fecha de compra original del producto. Las
condiciones de esta garantía y el alcance de la responsabilidad de mr Handsfree bajo esta garantía están disponibles en
www.mrhandsfree.com.
I- GARANZIA
Mr Handsfree è un marchio di fabbrica di TE-Group NV. Il marchio mr Handsfree indica la qualità superiore del prodotto e un
eccellente servizio di assistenza ai clienti. È per questo che mr Handsfree garantisce il prodotto per qualsiasi difetto nei materiali e
nella fabbricazione, per un periodo di due (2) anni dalla data di acquisto originale del prodotto. Condizioni della presente garanzia
e Ambito della responsabilità di mr Handsfree puo essere trasferito su www.mrhandsfree.com.
D- GARANTIE
Mr Handsfree ist ein eingetragenes Markenzeichen der TE-Group NV. Die mr Handsfree-Marke steht für überragende Qualität
und hervorragenden Kundenservice. Aus diesem Grund gibt mr Handsfree auf dieses Produkt eine Garantie von zwei (2) Jahren
auf alle Material- und Verarbeitungsfehler ab Originalkaufdatum des Produktes. Die Bedingungen dieser Garantie und der
Verantwortlichkeitsumfang von mr Handsfree in dieser Garantie können Sie nden auf: www.mrhandsfree.com.
83
