Teac W-780R User manual

TEAC
3D0002100A
W-780
Double Cassette Deck
Thanks for buying a TEAC. Read this manual carefully to get the best
performance from this unit.
Nous vous remercions pour I'achat d'un appareil TEAC.
Lire ce manuel avec attention pour obtenir les meilleures performances
possibles de cet appareil.
Vielen Dank fiir den Kauf dieses TEAC-Gerats.
Bitte lesen Sie diese Anleitung sorgfaltig durch, um die Leistungs-
fahigkeit dieses Gerats optimal nutzen zu kinnen.
Grazie per aver acquistato un prodotto TEAC.
Leggere attentamente questo manuale per ottenere le migliori
prestazioni da questo apparecchio.
Enhorabuena por la adquisicién de un TEAC.
Lea detenidamente este manual a fin de obtener el mejor rendimiento de
esta unidad.
Dank u voor de aanschaf van een TEAC.
Lees deze gebruiksaanwijzing aandachtig door teneinde de beste
prestaties van dit toestel te verkrijgen.
OWNER’S MANUAL .. 4
MANUEL DU PROPRIETAIRE . 9
BEDIENUNGSANLEITUNG... 14
MANUALE DI ISTRUZIONI ..
MANUAL DEL USUARIO
GEBRUIKSAANWIJZING
CAUTION
RISK OF ELECTRIC SHOCK
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DO NOT OPEN
The lightning flash with arrowhead symbol, within equilateral triangle,is intended to alert
the user to the presence of uninsulated “dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
A
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
This appliance has a serial number located
on the rear panel. Please record the model
number and serial number and retain them
for your records.
Model number
Serial number
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
O696U + M-1229A

Fig. 1 Connections/Raccordements de base/Grundsatzliche Anschliisse/ Fig. 2
Abb, 1 ©9!legamenti di base/Conexiones basicas/Basisaansluitingen Abb.2 Bandes fra ee
Afb. 1 Afb. 2 Nestr normal
Stereo Amplifier
Amplificateur stéréo
Stereo-Verstarker
Amplificatore stereo
Amplificador estereofénico
Stereo-versterker
Cintas normales
Normale cassettes
Chrome (Cobalt) Tapes
Bandes au chrome
(Cobalt)
Chrombander (Kobalt)
Nastri al cromo (Cobalto)
Cintas de cromo (cobalto)
Chroom (kobalt) cassettes
Metal Tapes
Bandes metal
Metallbander
Nastri di metallo
Cintas de metal
Metaalcassettes
Tape position identification holes
Trous d'identification de type de bande
© Bandsorten-identifikationsoffnungen
© Fori di identificazione del tipo
© Orificios de identificacion del tipo de cinta
© Bandsoortidentifikatiegaten
Fig. 3
‘Synchro
cable
WR-7000
(optional)
Abb.
3
Battery
installation
Cable
synchro WR-7000
(en
option)
Mise
en
place
de
piles
CD player Synchro-Kabel WR-7000 (Sonderzubehér) Afb. 3
Einlegen der Batterien
Inserimento delle batterie
Cambio de pilas
Vervangen van de batterijen
LecteurCD avo di sincronizzazione WR-7000 (opzionale)
CD-Player Cable de sincronizacién WR-7000 (opcional)
Lettore CD ‘Synchro-kabel WR-7000 (los verkrijgbaar)
Reproductor de CO
CD-speler
Fig.
4
Fig.
5
inch
roller
Abb.
4
Abb.
5
Geet
presseur
Afb.
4
Afb.
5
ule
drpresa
Rodillo de presion
Aandrukrol
Capstan
Cabestan
Capstan
Cabestano
Cabrestante
Within 7 m.
Inférieur & 7 m
Innerhalb 7 m
Ameno di 7m
Dentro de los 7m
Vanaf maximaal 7 m
Erase head Record/playback head
Téte d'effacement Téte d'enregistrement/lecture
Loschkopf AufnahmeWiedergabe-Kopf
Testina di cancellazione _ Testina di registrazione/riproduccion
Cabeza de borrado Cabeza de grabacién/reproduccion
Wiskop Opname/weergavekop

Reference Illustrations/Illustrations de référence/Bezugsabbildungen/IIlustrazioni di riferimento/
Illustraciones de referencia/Referentieafbeeldingen
Fig. 6/Abb. 6/Afb. 6
Front Panel/Panneau avant/Frontplatte/Pannello anteriore/Panel frontal/Voorpaneel
9
@
©
08
9
98
©
@
|
|
|
=
Remote Control Unit
Boitier de telecommande
Fernbedienung
Unita per il comando a distanza
Unidad de control remoto
Afstandsbedieningseenheid
Display
Fenétre d'affichage
Displayteld
Displayvenster

Precautions
——
Environment
Avoid using the deck in the following
conditions:
© At high temperatures (near a heater,
exposed to direct sunlight, etc.).
© At extremely low temperatures.
© Where there is excessive humidity.
© In a dusty atmosphere.
@ Where power line voltage fluctuations
are severe (in which case the use of a
voltage regulator may be advisable).
Cassette Tape (Fig.2)
Tape Sele
For the automatic tape select function to
work properly, metal and chrome (cobalt)
tapes must have identification holes.
Tape Handling:
Do not store tapes in the following places:
© On top of heaters, exposed to direct
sunlight or in any other places with high
temperatures.
@ Near speakers, on TV sets or amplifiers
or where they would be exposed to
strong magnetic fields.
@ Where humidity is high and in dirty,
dusty places.
© Avoid dropping or subjecting cassettes
to excessive shocks.
Connections (Fig.1)
Turn off the power switches of all
equipment before making connections.
e@Read the instructions of each
component you intend to use with the
deck.
OUTPUT terminals
OUTPUT Terminals on the tape deck should
be connected to the TAPE PLAY or LINE IN
jacks on the amplifier/receiver.
LINE IN terminals
LINE IN Terminals on the tape deck should
be connected to the REC OUT jacks on the
amplifier/receiver.
Power cord
Be sure to connect the power cord to an
AC outlet which supplies the correct
voltage, as set by the voltage selector.
IMPORTANT (for U.K. Customers)
DO NOT cut off the mains plug from this
equipment. If the plug fitted is not
suitable for the power points in your
home or the cable is too short to reach
@ power point, then obtain an
appropriate safety approved extension
lead or consult your dealer.
If nonetheless the mains plua is cut off,
remove the fuse and dispose of the plug
immediately, to avoid a posible shone shock
hazard by inadvertent connection to the
mains supply.
If this product is not provided with a
mains plug, or one has to be fitted, then
follow the instructions given below:
IMPORTANT. DO NOT make any
connection to the larger terminal which
is marked with the letter E or by the
safety earth symbo = or coloured
GREEN or GREEN-and-YELLOW.
The wires in the mains lead on this
product are coloured in accordance
with the following code: |
BLUE: NEUTRAL |
BROWN: LIVE |
As these colours may not correspond
with the coloured markings identifying
the terminals in your plug proceed as
follows:
The wire which is coloured BLUE must
be connected to the terminal which is
marked with the letter N or coloured
BLACK.
The wire which is coloured BROWN
must be connected to the terminal
which is marked with the letter L or
coloured RED.
h lacing the fi nt
Correctly rated approved type should
be used and be sure to re-fit the fuse
cover.
IF IN DOUBT — CONSULT A
COMPETENT ELECTRICIAN.
*Dolby noise reduction and HX Pro
headroom extension manufactured under
license. from Dolby Laboratories
Licensing Corporation. HX Pro originated
by Bang & Olufsen.
DOLBY’, the double-D symbol OO and
“HX PRO" are trademarks of Dolby
Laboratories Licensing Corporation.
Features and Controls (Fig. 6)
Front Panel/Remote Control Unit
@ Power Switch
Note: If you switch the power off, be sure
to wait for more than 3 seconds before
switching it on again.
© Cassette Holder
(TAPE I/TAPE I)
(See page 5.)
© EJECT Button (TAPE I/TAPE I!)
© COUNTER CLEAR Button
(TAPE I/TAPE Il)
Pressing the COUNTER CLEAR Button
resets the multi-counter to "0000".
© REMOTE SENSOR
(Infrared Signal Reception Window)
© Display Window
@) Peak Level Meter
») Direction & Pause Indicators
© Multi Counter
@ SYNC REV Indicator
©) Mode Indicators
1) Dubbing Indicators
9 CD SYNC Indicator
@ Tape Operation Buttons
(TAPE I/TAPE II)
<< : Rewind Button
> : Fast Forward Button
STOP Button
<<: Reverse Play Button
> =: Forward Play Button
© CD SYNC Button
(See page 8.)
© DOLBY NR Select Switch
OFF: Set to this position when you do not
want to use any noise reduction
system.
B: Set to this position when making a
recording using the Dolby B noise
reduction system, or playing back
tapes recorded with Dolby B NR.
C: Set to this position when making a
recording using the Dolby C noise
reduction system, or playing back
tapes recorded with Dolby C NR.
@ SYNC REV (Reverse) Button
(See page 6.)
@® REV (Reverse) MODE Switch
(See page 5.)
@® DUB (Dubbing) START Button
(See page 6.)
To enter the dubbing mode using the
remote control, press the two DUB START
buttons simultaneously.

@® REC (Record) LEVEL Control
(TAPE II only)
(See page 6.)
@© RECORD Button (TAPE II only)
(See page 6.)
To enter the record mode using the remote
control, press the two RECORD buttons
simultaneously.
@® BALANCE Control (TAPE II only)
(See page 6.)
@® PAUSE Button (TAPE II only)
@® PHONES Jack
Connect 8-ohm stereo headphones to this
jack for private listening or monitoring.
® REC (Record) MUTE Button
(TAPE II only)
(See page 6.)
® Display Button
If the DISPLAY button (on the remote
control only) is pressed, all display
indications will go out. Even if indications
are blank, each button remains operable.
Operations
Loading a Cassette Tape
1. Use your finger or a pencil to turn the
cassette's hub and take up any slack
tape.
Note: Avoid touching the tape.
Fingerprints attract dust and dirt.
2. Press the eject button (4)* to open
the cassette compartment door.
3. Load the cassette tape with its open
edge facing down.
4. Gently close the compartment door.
“Notes:
eThe cassette holder cannot be
opened during recording or playback.
lf the power has been switched off
during play or recording, ejecting the
cassette may be impossible. In such a
case, switch the power on and press
the eject button again.
Tape Travel Depending on Setting of REV MODE Switch
Setting Tape Travel
Beginning _ Side B End
— Start Stop When the tape reaches the end, playback or
— Ses sua recording is released.
End Side A Beginning
® During forward play or recording, when
inning Side8 the end of tape is reached, the direction
Beginning @ End of tape running is reversed to play or
Slstop record in the opposite direction.
‘Start Reverse play or recording will continue
_— © stor to the end of the other side, at which
point play or recording is released.
End ; Beginning @® During reverse play or recording, when
Side A the tape reaches the end, play or
recording is released.
PLAY mode (Tapes loaded in TAPE | or Il)
Beginning
i0¢8
During
either
forward
or
reverse
play,
when
eginning End the end of tape is reached, the direction of
tape running is reversed and play continues
in the opposite direction. In this way, the
two sides of the tape are played back
continuously, the tape will stop after 5
End Sidea Penning cycles
PLAY mode (Tapes loaded in TAPE | and I!)
Continuous Playback Operation
TAPE! TAPE II
® ®
Beginning S9°8 = ® Eng Beginning Side8 End
Stop = @ é !Stop
start dual Start
End Beginning End Beginning
oO Side A Side A
tt ®
@@®When playback starts in the (2) Controlis transferred to TAPE Il.
forward direction, at the end of @ Playback starts in the forward direction;
tape, the tape is reversed to play at the end of tape, it is reversed and the
the other side. At the end of this other side is played back.
side, playback is released. @ At the end of tape, control is transferred
® back to TAPE |, which plays both sides.
® When playback starts in the
reverse ‘Greco, at the end of This sequence ©—@ is repeated for 5
tape, TAPE lis released. cycles
RECORD mode (TAPE II only)
ae Side 8
Beginning End
© Operation is same as =.
End Sidea Beginning

Playback with TAPE | or TAPE Il
1. Press the POWER switch to ON.
2. Set the REV MODE switch to the
required tape travel mode, referring to
the chart “Tape Travel Depending on
Setting of REV MODE Switch" on page 5.
3. Load a pre-recorded cassette in TAPE |
orll.
4. Select the appropriate DOLBY NR
system.
5. Press the <4 or > button for TAPE | or
Il to start playback.
6. Adjust the volume with the amplifier's
volume control.
@ To stop playback, press the STOP
button.
Continuous Playback
1. Load pre-recorded cassettes in TAPE |
and TAPE Il.
2. Set the necessary controls and
switches but not the <4 or ® button,
referring to "Playback with TAPE | or
TAPE II".
3. Set the REV MODE switch to the (C=>)
position.
4. Press the <4 or & button of the deck
to be played back first.
5. Tapes will be played back continuously,
according to the chart. (See page 5.)
@ To stop continuous play before 5 cycles
have been completed, press the STOP
button of either deck.
Recording with TAPE Il
Recording from a stereo system:
1, Press the POWER switch to ON.
2. If you want to make a bi-directional
recording, set the REV MODE switch to
the = position.
. Load a recordable cassette in TAPE Il.
@ Check that the safety tabs on the spine
of the cassette are in place. If they have
been broken off, block the holes with
adhesive tape.
4. Select the desired DOLBY NR system.
5. Press the RECORD button and the deck
enters the record-pause mode. ( (REC
and BI indicators light).
6. Adjust the recording level with the REC
LEVEL control so that the loudest sound
to be recorded just makes the meters
briefly reach around the "0 dB" point (for
Normal or Chrome tapes) or the “+3 dB"
point (for Metal tapes).
7. To adjust the balance of the input
signal, use the BALANCE control.
8. Press the PAUSE button again to start
recording.
© To stop recording temporarily, press the
PAUSE button. To restart the tape, press
it again.
@ To stop recording, press the STOP
button.
rx)
Erasing
Anything previously recorded on the tape
will automatically be erased when you
make a new recording on it. It can also be
erased by “recording" on it with the REC
LEVEL control set to "0".
Record Muting Operation
© Automatic spacing operation for 4-
second blanks (during recording)
Press the REC MUTE button during
recording. The tape movement
continues and a blank space of about 4
seconds is recorded (the RECORD
indicator blinks). The deck then enters
the record-pause mode automatically
(both the RECORD and PAUSE indicators
light).
To restart recording, press the PAUSE
button (the PAUSE indicator goes off).
© Automatic spacing operation for 4-
second blanks (during record-pause)
In the record-pause mode, pressing the
REC MUTE button will initiate the above
record-muting operation automatically.
The deck then returns to the record-
pause mode.
For a blank of more than 4 seconds
During recording, hold the REC MUTE
button depressed for longer than 4
seconds. A blank space will be left as
long as the button is pressed. Release
the button to enter the record-pause
mode. To restart recording, press the
PAUSE button.
For a blank of less than 4 seconds
After pressing the REC MUTE button
during recording, press the PAUSE
button before 4 seconds has elapsed.
The deck will stop and enter the record-
Pause mode at the point at which the
PAUSE button is pressed. To restart
recording, press the PAUSE button
again.
Note:
© During record muting operation (while
the RECORD indicator is blinking),
pressing the REC MUTE button again will
release the record muting operation and
recording will restart without stopping
the tape.
Dubbing (Copying from TAPE I to
TAPE Il) :
To dub the entire recorded section of a
pre-recorded cassette
1, Press the POWER switch to ON.
2. Load the pre-recorded cassette into
TAPE | and a recordable cassette into
TAPE II.
3. Fully rewind both cassettes so their
tapes are taken up on their left reels.
4. Set the REV MODE switch to the desired
position.
== : Dubbing will be performed for one
side only.
=> : Dubbing will be stopped after both
sides have been dubbed.
. Set both decks to the ® direction.
. Press the DUB START HIGH or NORMAL.
button to start dubbing. The indicator
corresponding to the button pressed
will light.
NORMAL: Dubbing is performed at
normal speed.
HIGH: Dubbing is performed at
twice normal speed.
7. The peak level meter indicates the TAPE
| signal levels; the recording levels of
TAPE II will be set automatically (at the
same levels as TAPE |).
8. After dubbing is completed, both decks
stop automatically, according to the
setting of the REV MODE button.
9. To stop dubbing, press either of the
STOP buttons.
on
Synchro reverse dubbing
The SYNC REV button allows both decks to
be reversed at exactly the same time
during dubbing. This function is convenient
when using tapes with different lengths, to
dub a tape with exactly the same contents
as the original.
1. Set the tape running direction of both
decks to the (forward) direction, and
set the REV MODE switch to the —>
position.
. Press the SYNC REV button.
3. Press either of DUB START buttons
(HIGH or NORMAL).
4. The tapes in TAPE | and II travel as
illustrated in the chart "Synchro
Reverse Dubbing Operation" on page 7.
Note:
© If the original tape is shorter than the
dubbed tape, blank sections will be left
at both ends of the dubbed tape. To
prevent this, use tapes with the same
length as far as possible.
N

Synchro Reverse Dubbing Operation
TAPE | tape shorter than TAPE II
TAPE | tape longer than TAPE Il
TAPE |
Play ®
Side B
Re
everse (" bea
® Play
TAPE Il
Recording _@
Reverse (" eee
@ = Side A
7) Recording
No signal recording
® When TAPE | reaches the end of the forward
side, TAPE | stops and TAPE II enters the "no
signal recording’ mode.
(@ When TAPE II reaches the end, both TAPE |
and II are reversed simultaneously then TAPE
| resumes reverse play and TAPE II resumes
recording.
@ When TAPE | reaches the end of the reverse
side, both TAPE | and II stop simultaneously.
TAPE!
Play ®
oo
Reverse ("| sice8
Oe Sse
® Play
TAPE II
Recording @)
side 8
Reverse ("| Pe
ide
@ Recording
@ When TAPE II reaches the end of forward
side, TAPE Il enters the record-pause mode
for the reverse side, while TAPE | continues
playback.
@ When TAPE | reaches the end, TAPE | and Il
start reverse play and recording simultane-
ously.
@ When TAPE II reaches the end of the reverse
side, both TAPE | and II stop simultaneously.
Notes:
@ The settings of the REC LEVEL control
and DOLBY NR switch are ignored
during dubbing as they have no effect.
e@ The <<, <, >» and >> buttons do
not function during NORMAL speed or
HIGH speed dubbing. Also, REC MUTE
and PAUSE do not function during HIGH
speed dubbing.
The sound quality of the dubbed tape
may be slightly worse than that of the
original tape. For this reason,
multigeneration dubbing is not
recommended.
If there is a TV set near the cassette
deck during high speed dubbing, it is
possible that the TV's horizontal
scanning frequency may be recorded on
the tape. If this occurs or to prevent it in
advance, dub at normal speed, switch
off the television or keep the deck a
reasonable distance away from the TV.
Manual editing with REC MUTE and
PAUSE
During normal-speed dubbing, you can edit
the dubbed tape as required using the REC
MUTE and PAUSE buttons. For example,
you can record only the required tunes
from TAPE | to TAPE II skipping unwanted
tunes.
© During normal-speed dubbing, when the
PAUSE button is pressed, TAPE I! enters
the record-pause mode while TAPE |
continues playback. While listening to
the sound from TAPE I, when it reaches
a section you want to dub, press the
PAUSE button again to restart recording
on TAPE Il.
During normal-speed dubbing, when the
REC MUTE button is pressed, TAPE II
enters the record muting operation as in
normal recording. To restart recording
on TAPE II, press the PAUSE button.
CD synchro dubbing operation
Start of CD synchro dubbing:
The shaded portions (==) in the following indicate the CD synchro dubbing mode.
Deck's CD SYNC button ON
Deck operation
Stop
CD player operation Stop
(A: Operation at the deck)
STOP button ON
CD SYNC button ON
Deck operation
CD player operation
Stop
Return to the beginning | _
of the tune, then
pause.
Deck operation
CD player
Rec/pause
Stop
STOP button ON =}
PLAY button ON

CD Synchro Dubbing (Fig. 1)
By connecting the deck to a TEAC CD
synchro compatible CD player which has a
CD/DECK SYNC terminal on its rear panel,
dubbing (recording) synchronized with the
CD player is possible.
Frowarstog
Connect the deck's CD/DECK SYNC
terminal to the CD player's CD/DECK
SYNC terminal using an optional cable.
2. Perform programming of the ‘time edit’,
etc. functions of the CD player
beforehand (refer to the instructions of
the CD player).
3. Set the source to CD using the
amplifier's source select buttons.
4, Set the recording level.
5. Set the deck and the CD player to the
stop mode.
6. Press the CD SYNC button of the deck.
The CD player will start automatically
approx. 1 sec after the deck starts
recording and dubbing will be
performed. (The CD SYNC indicator
lights.) (See page 7.)
To stop temporarily during dubbing:
To temporarily stop CD synchro dubbing
(A) Press the STOP button of the deck. The
CD player will return to the beginning
of the current tune and pause there. To
restart, press the deck's CD SYNC
button.
(B) Press the stop button of the CD player.
The deck enters the rec/pause mode.
To restart, press the CD player's play
button.
When the CD player has entered the
pause mode, it stands by after returning
to the beginning of the tune that has just
been played.
When recording is done up to the end of
the tape, the CD player stands by after
returning to the beginning of the tune
that has just been played.
Note:
If the CD player is connected to the stereo
amplifier using an optical cable, synchro
dubbing is not possible. If synchro dubbing
is required, you must connect the deck's
analog output using pin plug cords.
CAUTION:
Recording pre-recorded tapes, records,
or other published or broadcast
material may infringe copyright laws.
Check these laws before recording.
Remote-Controlled Operation
When operating the remote control unit,
point it towards the remote sensor on the
front panel of the unit (Fig. 4).
Battery Installation (Fig. 3)
1, Remove the battery compartment cover.
2. Insert two “AAA (R03, UM-4) dry
batteries.
Make sure that the batteries are
inserted with their positive ® and
negative © poles positioned correctly.
Close the cover until it clicks.
»
Battery replacement
If the operation range from the unit to the
amplifier begins to decrease, the batteries
are nearly exhausted and both should be
replaced.
© Be sure to insert the batteries correctly,
as shown in the battery compartment.
© Do not use old and new batteries
together.
@ Rechargeable and non-rechargeable
batteries can be used. Refer to the
precautions on their labels.
@ When the remote control unit is not to
be used for a long time (more than a
month), remove the batteries from the
remote control unit to prevent them from
leaking.
Maintenance (Fig. 5)
The heads and tape path should be
cleaned and demagnetized periodically.
Cleaning Tape Path
© Apply head cleaning fluid* to a cotton
bud or soft cloth, and lightly rub the
heads, capstan and all metal parts in the
tape path.
© Also clean the pinch roller using rubber
cleaning fluid*.
* Both are available in TEAC Tape
Recorder Cleaning Kits HC-2 and RC-2 in
the U.S.A. or TZ-261 in other areas.
Demagnetizing Heads
Be sure that the power is off, then
demagnetize the heads using a TEAC E-3
demagnetizer. For details of its use, read its
instructions.
Caution:
If the surface of the unit gets dirty, wipe
with a soft cloth or use diluted neutral
cleaning liquid. Be sure to remove any fluid
completely. Do not use thinner, benzine or
alcohol as they may damage the surface of
the unit.
Troubleshooting
Basic troubleshooting of a cassette tape
deck is similar to troubleshooting any other
electrical or electronic equipment. Always
check the most obvious possible causes
first. To give you a few ideas of what to
look for, check the following:
@ No power: Is the power cord
connected?
© No audio output: Have all connections
been made correctly?
© Low sound quality: Are the heads dirty
or magnetized? Are you using good
quality tape? Has the correct NR System
been selected?
© Impossible to enter the record mode:
Are the record protection tabs of the
cassette in place?
Specifications
Track System : 4-track, 2-channel stereo
Heads : 3; Deck |; 1 Playback (rotating)
Deck Il; 1 Erase and 1
Record/Playback (rotating)
‘Type of Tape : Cassette tape C-60 and
C-90(Philips type)
Tape Speeds : 4.76 cm/sec (1-7/8 ips)
9.5 cm/sec (3-3/4 ips)
(In Hi-Speed Dub)
Motors : 2 DC Servo motors (1 ea. Deck)
Wow and Flutter (WRMS) : 0.06%
Frequency Response (Overall, -20 dB):
25 - 19,000 Hz, Metal tape
25 - 18,000 Hz, CrO: tape
25 - 17,000 Hz, Normal tape
Signal-to-Noise Ratio (Overall) :
59 dB (NR off, 3% THD Level, Weighted)
69 dB (Dolby B NR on, over 5 kHz)
79 dB (Dolby C NR on, over 1 kHz)
Fast Winding Time :
Approximately 110 seconds for C-60
Inputs : Line; 100 mV, 50k ohms.
Outputs : Line; 0.46 V for load impedance of
50k ohms or more
Headphones; 0.95 mW/8 ohms
Power Requirements :
230 V AC, 50 Hz (Europe Model)
Power Consumption : 14 W
Dimensions (W x H x D):
435 x 147 x 297.5 mm
(17-1/8" x 5-13/16" x 11-3/4")
Weight (net) : 4.6 kg (10-2/16 Ibs.)
Standard Accessories :
Remote control unit (RC-622) x 1,
Battery (SUM-4, “AAA”, “R03” type) x 2,
Input-output connection cord x 1
© Specifications were determined using
metal tape except as noted.
@ Improvements may result in
specification or feature changing
without notice.

Précautions a observer
Environnement
Eviter d'utiliser l'appareil dans les
conditions suivantes:
@ Température élevée (par exemple, un
radiateur, les rayons directs du soleil).
© Températures extrémement basses.
@ Humidité excessive.
@ Atmosphére poussiéreuse.
© Dans les endroits oui les fluctuations de
la tension de ligne d'alimentation sont
importantes (I'utilisation d'un régulateur
de tension est recommandée dans
certains cas).
Bandes (Fig. 2)
Sélection de bande:
Pour que la fonction de sélection
automatique de bande agisse
correctement, les bandes a formule métal
et chrome (cobalt) doivent posséder des
trous d'identification.
Manipulation des bandes:
Ne pas entreposer des bandes dans les
endroits suivants:
© Sur des radiateurs, au soleil ou dans un
endroit ol la température est élevée.
@ Prés de haut-parleurs, sur des
téléviseurs ou amplificateurs ou encore
prés de champs magnétiques puissants.
© Dans des endroits ou I'humidité est
élevée ou poussiéreux et sales.
© Eviter aux cassettes les chutes et les
chocs excessifs.
Réduction de bruit Dolby et HX Pro
headroom extension fabriqués sous
license de Dolby Laboratories Licensing
Corporation. HX Pro est d'origine Bang
& Olufsen.
DOLBY, le symbole double-D OO et HX
PRO sont des marques de Dolby
Laboratories Licensing Corporation.
Raccordements (Fi
e@ Couper |'alimentation de tous les
appareils avant d'effectuer les
raccordements.
@ Lire les instructions concernant chacun
des appareils que vous avez l'intention
d'utiliser avec cette platine.
Prises de sortie (OUTPUT)
Connecter les prises de lecture de bande
(TAPE PLAY) ou d'entrée de ligne (LINE IN)
de l'amplificateur a ces prises.
Prises d'entrée de ligne (LINE IN)
Connecter les prises de sortie
denregistrement (REC OUT) de
'amplificateur a ces prises.
Cordon d’alimentation
Le brancher a une prise secteur murale,
etc. La tension requise par cet appareil est
indiquée sur la face arriére.
Caractéristiques et commandes
(Fig. 6)
Panneau avant/
Boitier de télécommande
@ Interrupteur d'alimentation
(POWER)
Remarque: En remettant |'alimentation
aprés l'avoir coupée, bien attendre plus de
3 secondes.
@ Porte-cassette
(PLATINE I/PLATINE 11)
(Voir page 10.)
© Touche d'éjection (EJECT)
(PLATINE I/PLATINE I!)
© Touches COUNTER CLEAR
(PLATINE I/PLATINE 11)
Une pression sur la touche CLEAR remet le
compteur multiple a "0000".
© Fenétre de telecommande
(REMOTE SENSOR)
© Fenétre d'affichage
@) Indicateur de niveau créte
b) Indicateurs de sens de défilement
de la bande et pause
©) Affichage du compteur
@) Indicateur SYNC REV
@) Indicateurs de mode
1) Indicateurs de copie
9) Indicateur CD SYNC
@ Touches de commande de bande
(PLATINE I/PLATINE 11)
<4 : Touches de réembobinage
me : Touches d'avance rapide
STOP: Touches d'arrét
<<: Touches de lecture inverse
> : Touches de lecture avant
© Touche de synchronisation CD
(CD SYNC)
(Voir page 13.)
© Commutateur de réduction de bruit
(DOLBY NR)
OFF: Le mettre sur cette position lorsqu’il
n'est pas souhaitable d'utiliser le
circuit de réduction de bruit
incorporé.
B: Le mettre sur cette position en cas
d'enregistrement ou de lecture
avec le circuit Dolby de type B.
C: Le mettre sur cette position en cas
d'enregistrement ou de lecture
avec le circuit Dolby de type C.
@® Touche d'inversion synchronisée
(SYNC REV)
(Voir page 11.)
@ Commande de mode d'Inversion
(REV MODE)
(Voir page 10.)
@® Touche de lancement de copie
(DUB START)
(Voir page 11.)
Pour passer en mode de copie en utilisant
la télécommande, appuyer simultanément
sur les deux touches DUB START.
® Commande de réglage du niveau
d'enregistrement (REC LEVEL)
(PLATINE I! uniquement)
(Voir page 11.)
@® Touche d'enregistrement
(RECORD) (PLATINE I! uniquement)
Pour passer en mode d'enregistrement en
utilisant la télécommande, appuyer
simultanément sur les deux touches
RECORD.
® Commande de réglage de balance
(BALANCE) (PLATINE I! uniquement)
(Voir page 11.)
® Touche PAUSE
(PLATINE I! uniquement)
© Prise de casque d'écoute
(PHONES)
Brancher un casque d'écoute stéréo 8
ohms a cette prise pour une écoute privée
ou le monitorage.
© Touche d'enregistrement silencieux
(REC MUTE) (PLATINE II uniquement)
(Voir page 11.)
® Touche DISPLAY
Si la touche DISPLAY (sur la
télécommande seulement) est pressée,
toutes les indications d’'affichage
s'éteignent. Méme si les indications sont
vierges, chaque touche reste
opérationnelle.

Défilement de la bande en fonction du réglage du commutateur REV MODE
Fonctionnements
Réglage Défilement de la bande
Début Face B Fin Chargement d'une cassette
= Marche ‘Arrét_ _La lecture ou l'enregistrement s'arréte a la 1. Utiliser un doigt ou un crayon pour
Arrét Marche fin de la bande. tourner le moyeu de la cassette et
rattraper le jeu de la bande.
¢§—_______—_ :
L Date Remarque: Eviter de toucher la bande.
ms Face A vont Les empreintes digitales
attirent la poussiére et les
saletés.
@ En mode de lecture ou d'enregistrement 2. Appuyer sur la touche d'éjection
Face
B
le
sens
de
défilement
est
inversé
(4)*
pour
ouvrir
le
volet
du
Début @ Fin a la fin de la bande et la lecture ou =I, Pe
a lenregistrement continue en sens compartiment cassette.
ret
inverse.
Le
mode
d'enregistrement
ou
3.
Charger
la
cassette
avec
son
cété
=_ che de lecture inverse continue jusqu’a la ouvert dirigé vers le bas.
Hing det rautte fece:,00 Je” mode ; ext 4. Fermer gentiment le volet du
Fin Début @ En mode de lecture ou d'enregistrement compartiment.
Face A inverse, le mode est désactivé a la fin
de la bande.
co
Mode de lecture (Avec bande dans la Platine | ou I!)
Face B
En mode de lecture avant ou inverse, le
sens de défilement est inversé a la fin de la
bande et la lecture continue dans le sens
opposé. Les deux faces de la bande sont
ainsi lues d'une maniére continue. La
lecture s‘arréte au bout de 5 cycles.
Face A
Mode de lecture (Avec bandes dans la Platine | et dans la Platine I!)
Lecture continue (CONTINUOUS PLAYBACK)
Platine! Platine I
3
Face B ® Face B
in Début Fin
Arrét @ Arrét
March
®marche => poate? Marche
Fin
Face A Face A
t el
@® Lorsque la lecture de la bande
est lancée dans le sens avant,
le sens de défilement est
inversé & la fin de la bande et
la lecture continue sur l'autre
face. A la fin de cette face, la
lecture s'arréte.
@La commande est transférée & la
Platine Il.
@ La lecture commence dans le sens
avant; le sens de défilement est
inversé a la fin de la bande et la
lecture continue sur l'autre face.
@A la fin de la bande, la commande
@® Lorsue la lecture de la bande est transféré a nouveau a la Platine |
est lancée dans le sens et les deux faces de la bande sont
inverse, la Platine | s'arréte a la lues.
fin de la bande.
Mode d'enregistrement (RECORD) (Platine I uniquement)
Face B
Début Fin
© Le fonctionnement est le méme
que pour la position >.
Face A
~10-
*Remarques:
© Le porte cassette ne peut pas étre
ouvert pendant |'enregistrement ou
la lecture.
© Si l'alimentation a été coupée
pendant la lecture ou
lenregistrement, I'éjection de la
cassette peut étre impossible. Dans
ce cas, remettre |’alimentation et
appuyer & nouveau sur la touche
d'éjection.
Presser l'interrupteur POWER sur ON.
2. Régler le commutateur REV MODE sur
le mode de défilement de bande voulu,
en se reportant au tableau “Défilement
de la bande en fonction du réglage du
commutateur REV MODE" sur la
qauche.
. Mettre une cassette préenregistrée
dans la Platine | ou Il.
. Sélectionner le systéme de réduction
de bruit DOLBY voulu.
. Appuyer sur la touche < ou & de la
Platine | ou I! pour lancer la lecture.
. Régler le volume avec la commande de
l'amplificateur.
Pour arréter la lecture, appuyer sur la
touche STOP.
