Teac CS-X8 User manual

9A10000102
;;
;;
;;
OWNER’S MANUAL
Micro Hi-Fi System
Z
CD-X8

2
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused
for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally,
or has been dropped.
<Do not expose this apparatus to drips or splashes.
<Do not place any objects filled with liquids, such as vases, on the
apparatus.
<Do not install this apparatus in a confined space such as a book
case or similar unit.
<The apparatus draws nominal non-operating power from the AC
outlet with its POWER switch in the off position.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

3
Optical pickup:
Type : CMS-M95BG6
Manufacturer : Samsung Electro-Mechanics
Laser output : Less than 0.5 mW on the objective lens
Wavelength : 760 - 800 nm
For U.S.A.
①
This product has been designed and manufactured according to
FDA regulations “title 21, CFR, chapter 1, subchapter J, based on
the Radiation Control for Health and Safety Act of 1968“, and is
classified as class 1 laser product. There is not hazardous invisible
laser radiation during operation because invisible laser radiation
emitted inside of this product is completely confined in the
protective housings.
The label required in this regulation is shown ①.
CAUTION
<DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO
EXPOSE THE ELECTRONICS. NO USER SERVICEABLE PARTS
ARE WITHIN!
<IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT,
CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE
PRODUCT UNTIL IT HAS BEEN REPAIRED.
<USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
WARNING : TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the equipment and/or the receiving
antenna.
• Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
CAUTION
Changes or modifications to this equipments not expressly
approved by TEAC CORPORATION for compliance will void the
user’s warranty.
For U.S.A.

4
Contents
Thank you for choosing TEAC. Read this manual carefully
to get the best performance from this unit.
Before Use
Read this before operation
<As the unit may become warm during operation, always leave
sufficient space around the unit for ventilation.
<The voltage supplied to the unit should match the voltage as
printed on the rear panel of the supplied subwoofer. If you
are in any doubt regarding this matter, consult an electrician.
<Choose the installation location of your unit carefully. Avoid
placing it in direct sunlight or close to a source of heat. Also
avoid locations subject to vibrations and excessive dust, heat,
cold or moisture.
<Do not place the unit on an amplifier/receiver or any other
electronic device that generates heat.
<Do not open the sealed cabinet as this might result in damage
to the circuitry or electrical shock. If a foreign object should
get inside the unit, contact your dealer or service agency.
<When removing the power plug from the wall outlet, always
pull directly on the plug, never yank the cord.
<To keep the laser pickup clean, do not touch it, and always
close the CD door.
<Do not attempt to clean the unit with chemical solvents as
this might damage the finish. Use a clean, dry cloth.
<Keep this manual in a safe place for future reference.
DO NOT MOVE THE UNIT DURING PLAYBACK
During playback, the disc rotates at high speed. Do NOT lift or
move the unit during playback. Doing so may damage the
disc or the laser assembly.
WHEN MOVING THIS UNIT
When relocating or packing the unit for moving, be sure to
remove the disc. Moving this unit with the disc loaded may
result in damage to this unit.
Beware of condensation
When the unit (or a disc) is moved from a cold to a warm
place, or used after a sudden temperature change, there is a
danger of condensation; vapor in the air could condense on
the internal mechanism, making correct operation erratic or
impossible. To prevent this, or if this occurs, leave the unit for
one or two hours with the power turned on. The unit will
stabilize at the temperature of its surroundings.
Maintenance
If the surface of the unit gets dirty, wipe with a soft cloth or
use diluted mild liquid soap. Never spray liquid directly on this
unit. Apply your cleaner to your cleaning cloth and wipe
gently. Be sure to remove any excess completely. Do not use
thinner, benzene or alcohol as they may damage the surface
of the unit. Allow the surface of the unit to dry completely
before using
CAUTION
Do not expose this unit to liquids of any kind. Keep any
objects containing liquids such as vases, water glasses, potted
plants, et cetera off the top of this unit.
Do not install this equipment in a confined space such as a
bookcase or similar unit.
IMPORTANT SAFETY INSTRUCTIONS ........................................ 2
Contents.................................................................................. 4
Before Use ............................................................................... 4
Specifications ........................................................................... 5
Discs ........................................................................................ 6
Wall Mounting......................................................................... 7
Remote Control Unit ................................................................ 7
Connection .............................................................................. 8
Use of Outdoor Antennas ........................................................ 9
Names of Each Control (Front Panel/Remote Control Unit)...... 10
Basic Operation...................................................................... 12
Listening to CDs..................................................................... 13
Programmed Playback............................................................ 15
Shuffle Playback..................................................................... 17
Repeat Playback ..................................................................... 17
Listening to the Radio ............................................................ 18
Preset Tuning ......................................................................... 19
Setting the Clock ................................................................... 20
Setting the Timer ................................................................... 21
Setting the Sleep Timer .......................................................... 22
Troubleshooting..................................................................... 23

5
Specifications
AMPLIFIER section
Output Power (L+R)................................................... 5W+5W
Output Power (Subwoofer) ............................................. 15W
Input Sensitivity........................................................... 300mV
Frequency Response...................................... 50 to 20,000 Hz
TUNER Section (FM)
Frequency Range .................................. 87.50 to 108.00 MHz
Sensitivity (S/N30dB) .............................................. 20dBµV/m
TUNER Section (AM)
Frequency Range.......................................... 520 to 1710 kHz
Sensitivity (S/N20dB) .............................................. 54dBµV/m
CD PLAYER Section
Frequency Response............................20 to 20,000 Hz (±1dB)
Signal-to-Noise Ratio...................................................... 55dB
Wow and Flutter .............................................. Unmeasurable
SPEAKER SYSTEM Section
L&R speakers:
Type .......................................................... Full range flat type
Impedance.................................................................. 4 ohms
Subwoofer:
Impedance.................................................................. 8 ohms
<Design and specifications are subject to change without
notice.
<Weight and dimensions are approximate.
<Illustrations may differ slightly from production models.
GENERAL
Power Requirements ............................................ 120V, 60Hz
Power Consumption ...................................................... 80 W
Dimension ( W x H x D )
Main Unit...............................................6.3” x 8.9” x 3.4”
(160 x 226 x 86 mm)
L & R Speakers .......................................5.5” x 8.9” x 2.4”
(140 x 226 x 61 mm)
Subwoofer ..............................................6.3” x 9.2” x 13”
(160 x 234 x 330 mm)
Weight
Main Unit .................................................2.1 lbs (0.96 kg)
L & R Speakers.................................... 1.3 lbs (0.6 kg) each
Subwoofer ............................................... 11.7 lbs (5.3 kg)
Standard Accessories
Remote Control Unit (RC-962) x 1
Subwoofer Cable x 1
Speaker Cable x 2
FM Antenna x 1
AM Antenna x 1
Battery for Remote Control x 1
Wall Mount Adaptor x 3
Wall Mount Screw x 10
Tapered Plastic Wall Anchor x 10
Template for Wall Mounting x 1
Owner’s Manual x 1
Warranty Card x 1
trademark of New Transducers Ltd.

6
Discs
<Never use such chemicals as record sprays, antistatic sprays or
fluid, benzene or thinner to clean the discs. Such chemicals
will do irreparable damage to the disc’s plastic surface.
<Discs should be returned to their cases after use to avoid dust
and scratches that could cause the laser pickup to “skip.”
<Do not expose discs to direct sunlight or high humidity and
temperature for extended periods. Long exposure to high
temperatures will warp the disc.
<CD-R discs are more sensitive to the effects of heat and
ultraviolet rays than ordinary CDs. It is important that they are
not stored in a location where direct sunlight will fall on them
and which is away from sources of heat such as radiators or
heat-generating electrical devices.
<Printable CD-R discs aren’t recommended, as the label side
might be sticky and damage the unit.
<Do not stick papers or protective sheets on the discs and do
not use any protective coating spray.
<Use a soft oil-based felt-tipped pen to write the information
on the label side. Never use a ball-point or hard-tipped pen,
as this may cause damage to the recorded side.
<Never use a stabilizer. Using commercially available CD
stabilizers with this unit will damage the mechanisms and
cause them to malfunction.
<Do not use irregular shape CDs (octagonal, heart-shape, etc.).
CDs of this sort can damage the unit.
Discs that can be played on this unit:
•Commercial audio CD’s bearing the “Compact Disc Digital
Audio” logo:
?
•Properly finalized CD-R discs
Note:
<Depending on the quality of the disc and/or the condition of
the recording, some CD-R discs may not be playable.
<CD-RW discs cannot be played on this unit.
<Copy-protected discs and other discs which do not conform
to the CD standard may not play back correctly in this player.
If you use such discs in this unit, TEAC Corporation and its
subsidiaries cannot be responsible for any consequences or
guarantee the quality of reproduction. If you experience
problems with such non-standard discs, you should contact
the producers of the disc.
<Always load the disc with the label side facing you. (Compact
discs can be played or recorded only on one side.)
<To remove a disc from its storage case, press down on the
center of the case and lift the disc out, holding it carefully by
the edges.
How to remove the disc How to hold the disc
<Should the disc become dirty, wipe the surface radially with a
soft, dry cloth. Never clean the disc using a circular motion.
<If you are in any doubt as to the care and handling of a CD-R
disc, read the precautions supplied with the disc, or contact
the disc manufacturer directly.

7
Wall Mounting Remote Control Unit
Remove the battery compartment cover.
Put in the lithium battery (CR2032, 3V).
Close the cover.
Battery Replacement
If the distance required between the remote control unit and
main unit decreases, the battery is exhausted. In this case, replace
the battery with a new one.
Precautions concerning batteries
<Do not heat or disassemble batteries and never dispose of old
batteries by throwing them in a fire.
3
2
1
The provided Remote Control Unit allows the unit to be operated
from a distance.
When operating the remote control unit, point it towards the
remote sensor on the front panel of the unit.
<Even if the remote control unit is operated within the effective
range, remote control operation may be impossible if there
are any obstacles between the unit and the remote control.
<If the remote control unit is operated near other products
which generate infrared rays, or if other remote control
devices using infrared rays are used near the unit, it may
operate incorrectly. Conversely, the other products may also
operate incorrectly.
Battery Installation
1
2
3
You can mount the center unit and/or the left and right speakers
on a wall.
Option: Attatch the supplied adapter brackets.
Precautions
<Be aware that the length of the speaker cable is
approximately 10 feet (3 m). Do not attempt to mount the
speakers too far from the main unit.
<Drill holes into solid wall support, such as wooden frame or
concrete wall.
<As a convenience, a set of tapered plastic anchors is supplied.
If you chose to use these anchors, drill a pilot hole using
either a 1/4" or 6mm drill bit then tap the anchor into the
pilot hole.
Only use these anchors if they are appropriate for the
materials onto which the unit is to be mounted. Consult your
local hardware store if you are uncertain.
<TEAC supplies these brackets as a convenience to the product
owner. Consult your local building codes and exercise all
necessary caution when mounting these brackets. If you are
unsure how to use the supplied brackets, consult with a local
tradesmen or building supply expert.
To hook on the wall
Use the supplied template to determine drilling points.
Secure the brackets on the wall.
Scew the mounting tabs into the brackets.
Note:
Before going on, make connections between the main unit
and the speakers by referring to the next page.
Hang the main unit and/or the speakers to the mounting
tabs.
4
3
2
1
SP UNIT ADAPTER
MAIN UNIT ADAPTER

8
Connection
LINE OUT
RL
MAIN UNIT
DVD, CDR, etc.
SUBWOOFER
SPEAKER (R) SPEAKER (L)
A
B
C
F
D
E

9
AM loop antenna
Position the antenna for the best sound.
If you want, you can hook the AM antenna on a wall as
shown below:
FM antenna
While in FM mode, tune in an FM station and extend the
lead to find the best position for reception. This antenna
may need to be repositioned if you move your unit to a new
location.
Subwoofer
Make the connection between the “TO SUBWOOFER” and
“FROM MAIN” sockets using the supplied cable.
AUX IN
You can connect a DVD player, VCR etc. to this unit.
Connect the component with RCA pin cords.
Make sure to connect the white plug to the white jacks
(Left) and the red plug to the red jacks (Right).
SPEAKERS
Connect the left speaker’s plug to L, and the right speaker’s
plug to R.
<When using speakers other than those supplied with the
system, the impedance should be 3 ohms or more.
<Do not connect anything other than speakers to these
terminals.
AC Power Cord
Plug this AC power cord into an AC wall socket.
F
E
D
C
B
A
CAUTION
Turn off the power of all the equipment before making
connections.
Read instructions of each component you intend to use with
this unit.
<Be sure to insert each plug securely. To prevent hum and
noise, do not bundle the connection cords with the power
cord.
Use of Outdoor Antennas
Outdoor FM Antenna (75Ω)
FM Outdoor Antenna
In an area where FM signals are weak, it will be necessary to use
a 75-ohm unbalanced-type outdoor FM antenna using an
optional (not supplied) matching transformer connected to an
external antenna. Generally, a 3-element antenna will be
sufficient; if you live in an area where the FM signals are
particularly weak, it may be necessary to use one with 5 or more
elements.

Names of Each Control
10

11
POWER
Press this switch to turn the unit on or off (standby).
The main unit is powered via the subwoofer. You need to first
turn on the subwoofer.
FUNCTION
Use this button to select a source (CD, AUX or TUNER).
FM/AM
Use this button to select AM or FM.
Remote Sensor
When operating the remote control unit, point it towards
here.
MEMORY/CLOCK SET
In CD mode, use this button to program tracks.
In TUNER mode, use this button to store preset channels into
memory.
This button is also used for clock adjustment.
REPEAT
In CD mode, use this button for repeat playback.
STEREO/MONO
In FM TUNER mode, use this button to select stereo or
monaural.
Skip (.//) / TUNING
In CD mode, momentarily press this button to skip tracks.
Hold down this button to search for a part of a track.
In TUNER mode, momentarily press this button to tune in
stations.
In Standby mode, these buttons are used to set or adjust the
clock and the timer.
Stop (H)
Use this button to stop playback of CD.
Play/Pause (y/J)
Use this button to start or pause playback of CD.
J
I
H
G
F
E
D
C
B
ACD door
Display
VOLUME
Press the up (“+”) or the down (“–”) button to adjust the
volume.
OPEN/CLOSE
Use this button to open and close the CD door.
TIMER
Use this button together with the and buttons to set
the timer.
BASS
Use these buttons to adjust the bass sound up or down.
TREBLE
Use these buttons to adjust the treble sounds up and down
PRESET
In TUNER mode, use this button to select preset stations.
SLEEP
Use this button to set sleep timer.
SHUFFLE
Use this button for shuffle playback.
MUTING
Use this button to mute the sound.
U
T
S
R
Q
P
O
N
M
L
K
Note:
To simplify explanations, instructions refer to names of
buttons and controls on the front panel, making no mention
of the use of remote control unit.
The equipment draws a nominal amount of power from the
AC outlet even with its POWER switch in the OFF position.

Basic Operation
1
2
3
Press the POWER switch on both the subwoofer and the
main unit.
1
Select a source by pressing the FUNCTION button.
2
Play the source and adjust the volume using the
VOLUME buttons.
3
Muting
To mute the sound temporarily, press the MUTING button.
Press the MUTING button again to restore the sound.
A
<While muting is engaged, the VOLUME level indicators blink.
Headphones
For private listening, insert the headphones plug into the
PHONES jack, and adjust the volume using the VOLUME
buttons. The sound from the speakers is cut off while the
headphone jack is inserted.
B
12

13
Listening to CDs 1
1
3
5
2 4
Press the FUNCTION button to select “CD”.
1
Press the OPEN/CLOSE button.
2
Put a disc onto the center spindle of the player with the
label side facing you. Press the disc onto the spindle
until a slight “click” is heard indicating the disc is
mounted correctly.
3
<Never put more than one disc in the mechanism at a time.
<Ensure that the disc is correctly mounted on the spindle and
locked in place.
Press the OPEN/CLOSE button to close the CD door.
4
<It takes a few seconds for the unit to load the disc. No
buttons will work during loading. Wait until the total number
of the tracks and the total play time of the disc are displayed.
<When no disc is loaded in the CD player, “NO DISC” is
displayed.
Press the Play/Pause (y/J) button to start playback.
5
Playback starts from the first track of the disc.
When the playback of all the tracks has finished, the unit
stops automatically.

A
B
DC
Listening to CDs 2
To suspend playback temporarily
(pause mode)
A
To stop playback
Press the Stop button to stop playback.
B
To skip to the next or a previous track
C
Press the Play/Pause button during playback. Playback stops
at the current position. To resume playback, press the
Play/Pause button again.
During playback, press the Skip button (.or/)
repeatedly until the desired track is found. The selected
track will be played from the beginning.
In the stop mode, hold down the Skip button (or press the
button repeatedly) and release it when the track you want
to listen to is found. Press the Play/Pause (G/J) button to
start playback from the selected track.
<When the .button is pressed during playback, the track
being played will be played from the beginning. To return to
the beginning of the previous track, press the .button
twice.
<During programmed playback, the next or previous track in
the program is played.
Search for a part of a track
During playback, hold down the Skip button (.or/)
and release it when the part you want to listen to is found.
D
14

15
Programmed Playback 1
1
2
45
3
Up to 64 tracks can be programmed in the desired order.
Shuffle and Repeat functions don’t work during programmed
playback.
Press the FUNCTION button to select “CD”.
1
Press the MEMORY button.
2
“MEMORY” lights up in the display.
<To cancel the program mode, press the STOP button.
Press the Skip button (.or/) repeatedly to select
a track.
3
Press the MEMORY button.
4
The track is programmed, and “P-02” is displayed.
<Repeat steps and to program more tracks.
<You can program up to 64 tracks.
When the selection of track numbers is completed,
press the Play/Pause button to start program playback.
5
43
<When the playback of all the programmed tracks has finished,
or if one of the following buttons is pressed, the MEMORY
indicator will go off and the program mode will be cancelled:
STOP, FUNCTION, POWER
The program is retained in memory until the “OPEN/CLOSE”
button is pressed or the power is interrupted. You can return
to the programmed playback by pressing the MEMORY
button and the Play (G/J) button. (If another source was
selected, select the CD mode by pressing the FUNCTION
button beforehand.)

To check the programmed order
In the stop mode, press the MEMORY button repeatedly. The
track number and program number will be shown on the
display.
To add a track to the end of the program
In the stop mode, press the MEMORY button repeatedly until
“00” appears on the display. Select a track number using the
Skip button (.or/) and then press the MEMORY
button. The track is added to the end of the program.
To overwrite the program
In the stop mode, press the MEMORY button repeatedly until
the program number to be changed appears on the display.
Select a new track number using the Skip button and then
press the MEMORY button.
To clear program
To clear the programmed contents, press the MEMORY and
the STOP button in the stop mode.
<If the OPEN/CLOSE button is pressed, the programmed
contents will also be cleared.
<If the unit is disconnected from the power supply, the
programmed contents will be cleared.
Programmed Playback 2
16

17
Shuffle Playback
The tracks can be played randomly. Press the SHUFFLE button
during playback or when in the stop mode. “SHUFFLE” will
then light up in the display.
<If you press the /button during shuffle playback, next
track will be randomly selected and played. If you press the
.button, the currently played track will be played from
the beginning. A track cannot be replayed during shuffle
playback.
<Shuffle playback doesn’t work during programmed playback.
<If one of the following buttons is pressed, shuffle mode will
be cancelled:
SHUFFLE, STOP, FUNCTION, POWER, OPEN/CLOSE
Repeat Playback
Every time the REPEAT button is pressed, the mode is
changed as follows:
Repeat one track
Press the REPEAT button once during playback. “REPEAT”
lights.
The track being played will be played repeatedly. If you press
the Skip button and select another track, the track you
selected will be played repeatedly.
It is also possible to select a track to be repeated in the stop
mode. Press the REPEAT button, select a track using the Skip
button (.//), and then press the Play/Pause button to
start playback.
Repeat all the tracks
All the tracks will be played repeatedly.
Press the REPEAT button twice. “REPEAT ALL” lights.
During programmed playback, programmed tracks will be
played repeatedly.
<If one of the following buttons is pressed, repeat mode will
be canceled:
STOP, FUNCTION, OPEN/CLOSE, POWER
Repeat 1 Repeat All
(off)

Listening to the Radio
3
2
1
STEREO/MONO
Select “TUNER” by pressing the FUNCTION button.
1
Press the FM/AM button to select a band.
2
Select the station you want to listen to (auto selection).
3
Hold down the TUNING Up or Down button until the
frequency display begins to change. When a station is tuned
in, the tuning process will stop automatically.
<Press the Up or Down button to stop the auto selection.
Selecting stations which cannot be tuned automatically
(manual selection)
When the Up or Down button is pressed momentarily, the
frequency changes by a fixed step.
Press the Up or Down button repeatedly until the station you
want to listen to is found.
STEREO/MONO button
Pressing this button alternates between Stereo mode and
Mono mode.
Stereo:
FM stereo broadcasts are received in stereo and the
“STEREO” indicator will light.
Mono:
In weak FM stereo reception areas, select this mode.
Reception will now be forced to monaural, reducing
unwanted noise.
If the reception is poor
Reposition the AM or FM antenna for the best possible
reception. It may also be necessary to connect an external
antenna in extremely weak reception areas (see page 9).
18

19
Preset Tuning
3 5
2
4 5
1
You can store FM and AM stations into preset channels 1 to 10
respectively.
If the power switch of the subwoofer turned off, the
settings kept in memory (clock, preset stations, timer
setting) will be erased.
Press the FUNCTION button to select “TUNER”.
1
Select a band by pressing the FM/AM button.
2
Select the station you want to listen to.
3
Press the MEMORY button.
4
Within 5 seconds, select a preset channel to store the
station using the PRESET buttons, and then press the
MEMORY button.
5
The station is stored and the MEMORY indicator goes off.
To store more stations, repeat steps to .
52
Select a band by pressing the FM/AM button.
1
Press the PRESET button repeatedly until the desired
preset station is found.
2
How to select preset stations
2
1
preset channel

20
Setting the Clock
3 5
126 4
<If the unit is on, press the POWER switch to turn it off.
If the power switch of the subwoofer turned off, the
settings kept in memory (clock, preset stations, timer
setting) will be erased.
Press and hold down the CLOCK SET button.
”12 HOUR” or ”24 HOUR” blinks. If you want to change the
hour mode, press the .or/button.
1
Press the CLOCK SET button once more.
The ”hour” value blinks.
2
Press the Up or Down button to set the current hour.
3
Press the CLOCK SET button.
The “minute” value blinks.
4
Press the Up or Down button to set the current minute.
5
Press the CLOCK SET button.
The clock starts.
6
