Teac CT-M5929STC User manual

MODEL NO: CT-M5929STC
SYSTEM: PAL/BG W/SCART/CCD/F.TXT/G. STEREO/FRONT
AV IN 240V SAA
PART NUMBER DESCRIPTION QTY.
24
1
155-R63308-05-04 HANDSET ASS'Y RC:R633 CCD/F.TT/FINE TUNE
BATT.DOOR-TEAC DESIGN RC-717 CT-M5929STC
180-825B00-01-MP COM PART FOR 825B MECH ASS'Y
(MATCH GOLDSTAR,SAMSUNG CRT)
180-825BT3-26-03 NON-COM PART ASS'Y (PAL/BG W/SCART/CCD/
F.TXT/G.STEREO/FRONT AV IN) 40PROG.
180-825BT3-26-CP COM PART ASS'Y (PAL/BG W/SCART/CCD/F.TT/
G.STEREO/FRONT AV IN)
183-825B00-00-CD COM PART FOR (FASTEXT FOR SAA5281 P/E W/
CCD) ASS'Y

MODEL NO: CT-M5929STC
SYSTEM: PAL/BG W/SCART/CCD/F.TXT/G. STEREO/FRONT
AV IN 240V SAA
PART NUMBER DESCRIPTION QTY.
24
2
155-R63308-05-04 HANDSET ASS'Y RC:R633 CCD/F.TT/FINE TUNE
BATT.DOOR-TEAC DESIGN RC-717 CT-M5929STC
107-800455-46 455K HZ RESONATOR "KYOCERA" 1
CF701
113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% 2
R704,706
113-102005-17 CARBON FILM RESISTOR 1K OHM 1/16W +-5% 1
R705
113-103005-17 CARBON FILM RESISTOR 10K OHM 1/16W +-5% 1
R702
113-109005-17 CARBON FILM RESISTOR 1 OHM 1/16W +-5% 1
R709
113-473005-17 CARBON FILM RESISTOR 47K OHM 1/16W +-5% 1
R703
113-682005-17 CARBON FILM RESISTOR 6.8K OHM 1/16W +-5% 1
R701
127-476042-03 ELECT. CAP. 47 MFD 16V +-20% 1
C701
130-600101-00 INFRARED EMITTER EL-1L1 KODENSHI 1
LED701
131-210719-19 TRANSISTOR 2SA719S FO SHAN 1
Q702
131-230945-00 TRANSISTOR 2SC945 NEC 1
Q701
133-803010-33 I.C. SAA3010T PHILIPS 1
IC701
172-726000-99 BARE WIRE 54MM 0
W701
190-R63301-P2 REMOTE P.C.B. (050896) 1
516-260408-10 SELF-TAPPING SCREW 2.6 X 8 P/T (HARDEN) 2
FOR HANDSET
774-R63301-00 BATTERY SPRING (+VE) 1
774-R63302-00 BATTERY SPRING (-VE) 1
774-R63303-00 BATTERY SPRING (+-VE) 1
810-041104-13 POLYBAG 4" X 11" X 0.04MM W/RE-CYCLING MARK 1
FOR HANDSET
849-R63301-00 KEY PAD {FULL 40 KEYS} 1
892-R63301-07 DIAL KEY PLATE -W/FASTEXT/CCD /FINE-TUNE/EFFECT 1
(15 KEYS)
900-R63302-03 HANDSET TOP CABINET -MATT BLK. SPRAYED W/SILVER 1
{MATCH W/902-R63302-03}
8001C S.S.
902-R63302-03 HANDSET BOTTOM CABINET -MATT BLACK SPRAYED 1
{MATCH W/900-R63302-03}
910-R63301-90 BATTERY DOOR -TEAC DESIGN 1
(RC-717)(CT-M5929STC)(BLK)
973-R63301-00 VOLUME/CHANNEL KNOB -MOULDED BLACK 1
