TeachLogic VoiceLink IV User manual

SAFETY INSTRUCTIONS ________________________
1. Read Instructions: All safety and operation instructions should be read
before operating this TeachLogic product.
2. Retain Instructions: Safety and operating instructions should be kept
for future reference.
3. Water & Moisture: This product should not be operated near water.
4. Heat Environment: Do not subject this product to excessive heat
conditions.
5. Power Source: This product must be connected to an AC power
source per the voltage input specified and marked
marked on the power supply.
6. Power Cord Caution:Power cable should be routed clear of foot traffic
and supported clear of kinking or abrasion.
7. Object Protection: Locate the operating unit so it will not be subjected
to falling objects or water entry.
8. Internal Service: User should not attempt to service this product.
All internal service must be accomplished by a
qualified technician.
9. Electric Shock:Do not adapt or modify the AC power plug thus
lifting the earth ground connection.
1

VoiceLink - Infrared Wireless Microphone System
The VoiceLink IV is an infrared wireless microphone system that can be added
to any sound system. It can be a supplement to a Bogen or TOA sound
reinforcement system or an addition to an Extron or Crestron multi-media
system. You now have the capability of using four (4) wireless microphones
anywhere in a conference room, boardroom, courtroom, or classroom.
The system is comprised of a domed sensor installed on the ceiling. The sensor
receives the IR wireless signal from the microphone/transmitter and sends a
composite signal to the receiver. The receiver transforms the composite signal
into an analog audio signal which is fed to the multi-media amplifier. The
amplifier then powers the speakers for enhanced sound distribution throughout
the room for improved the listener comfort and intelligibility for all.
The wireless transmitter gives complete freedom of movement anywhere in the
room. Two transmitters can be the Crescent style worn under the chin, a pendant
style worn around the neck or a body-pack clipped to the waist with an external
microphone plugged in thus rendering hands free mobility. In addition, two
handheld wireless microphone / transmitters can be used simultaneously by other
attendees or interactive group participation.
A noted feature of infrared signal transmission is that it is confined within the
room. The transmission signal will not penetrate walls, ceiling or floor; thus
providing 100% security. It also eliminates cross talk or interference with
adjoining rooms. An added benefit, all systems operate on the same transmission
frequencies, therefore; all transmitter / microphones will work in any room
equipped with the same VoiceLink system.
Easy to install - Easy to use
2

VoiceLink IV Receiver IR-468N
The VoiceLink IV (IR-468N) is a four channel receiver for simultaneous
reception of four Infrared wireless microphones. It receives a composite
signal from a dome sensor, processes it and produces a balanced analog
audio output for each microphone or a combined balanced output of all
microphone inputs to be fed to the input of an amplified sound system. It
features a volume control and signal presence indicator for each
microphone.
Front Panel ________________________________________________________________
Power Switch with an associate “Red” LED to indicate presence of power.
Channel: A, B, C, D volume controls for independent volume control for each
wireless IR transmitter input.
IR Transmission Indicator: A “Green” LED will light when the corresponding
transmitter for that channel is turned “ON”, informing you that a transmission
signal is being received
3

Rear Panel ______________________________________________________
Phone Jack (1/4”) is an unbalanced output of combined channels A, B, C, D.
Line / Mic Switch selects the output signal to be either “Line” or “Mic” level.
One male XLR Connector is a balanced line level output of combined channels
A, B, C, D.
Four male XLR Connectors are balanced line level outputs for each respective
channel.
Sensor Connection (RCA) Each sensor connection provides phantom power to a
sensor and receives a composite FM signal from the sensor. Four (4) sensor
inputs allow installation of multiple sensors for odd shaped or large rooms.
(Normally only one sensor is required)
Power Input Jack connects to the power supply, 12-15 volts DC, 1 Amp.
4

Infrared Dome Sensor (ICS-55)The ceiling dome sensor is a highly
sensitive infrared receptor and provides optimum performance. One dome sensor
comes with the VoiceLink IV system. The sensor needs to be installed on the
ceiling. It comes with a T-Bar twist-on mounting/support bracket and 50 feet of
plenum rated cable with RCA connector on each end. The ideal location for the
dome sensor would be in the center of the ceiling. This will provide a clear signal
path for IR transmission from the transmitter to the dome sensor without
obstruction. In addition, you will have 360°
coverage and will minimize the transmission
distance for more reliable performance. It collects
the infrared transmission signal via 6 large
detecting diodes with magnifying lens. The sensor
is connected to the mixer/amplifier via the plenum
rated dual shielded cable.
5

Drop-in Battery Chargers
The battery chargers are specifically designed to recharge NiMH batteries. They
charge the batteries at an optimum rate and turn “off” at end of charge. The
chargers feature a recycle function, which is used to restore the battery charge
capacity and extend their service life.
BRC-50 charger recharges the Crescent (IRT-
30) or Body-Pack transmitter (IRB-30) and
Handheld (IRT-35). You merely place the
Crescent, Body-Pack, Handheld in their respective
slot. Connection will be made and charging will
commence. Charger will automatically control the
rate and maintain the charge.
BRC-101 provides a charging port for the pendant
or a handheld microphone. In addition, a tray
provides insertion of two “AA” NiMH batteries for
recharging.
BRC-202 is a dual charger for charging two
pendants or two handheld microphones or one of
each.
All drop-in chargers feature regulated charging rate, full charge maintenance,
recycle function and auto protection against incorrect battery insertion.
FOR USE WITH RECHARGEABLE NiMH BATTERIES ONLY.
6

Infrared Transmitters
Crescent (IRT-30)
The Crescent is a lightweight
microphone/transmitter designed to be
worn under the chin suspended by an
adjustable lanyard. The Crescent shape
was designed for efficient performance
and user comfort. The dual internal
microphones render optimum voice
pick up and quality reproduction. The
Crescent provides an auxiliary input
(3.5mm) to accommodate the insertion
of an iPod™ or similar device for supplementary program material.
A soft touch mute button cuts the microphone “off” for private conversation (the
power LED will flash in the mute position). A volume control allows adjustment
of the microphone volume. The external battery contacts accommodate the
convenient use of a drop-in charger.
An optional Plug-in microphone (LM-300) can be plugged into the aux input for
enhanced performance. Although the built-in microphones give satisfactory
performance, the plug-in microphone has a unidirectional element resulting in
additional sensitivity for more gain (more volume) before feedback.
Pendant Transmitter (IRT-89) with built-in microphone. The pendant
transmitter is usually worn around the neck for hands free movement.
However, it can easily be removed from the lanyard and used as a
handheld microphone. Two lanyards are provided: one with fixed
length and safety breakaway clasp and a longer adjustable cord style.
The 10 transmitting diodes are located in the top portion for very
efficient IR transmission. The power switch is accompanied by a
battery level LED (Green=Useable, Red=Needs Charge). The A-B
switch selects the transmission channel. The pendant is conveniently
inserted in either the BRC-101 or BRC-202 for recharging.
An optional Plug-in microphone (LM-300) can be plugged into the top
of the pendant for enhanced performance. Although the built-in
microphone gives satisfactory performance, the plug-in microphone is
a unidirectional element resulting in better vocal quality and much
more gain (more volume) before feedback.
7

Body-Pack Transmitter (IRB-30), usually worn on
the waistband, is the component that transmits the IR
signal to the sensor. The IRB-30 has 10 emitting
diodes on its front panel and is powered by two
rechargeable NiMH batteries. Controls include a
power “on/off” switch and a mic gain control. Battery
level indicator LED: Green = useable charge, Red =
low battery.
It is required to plug in an external microphone. There
are several optional microphones available and they
plug into the top of the IRB-30. The IRB-30 is
equipped with a belt clip for waist attachment.
Caution: The body-pack cannot be placed in pocket. The red window cannot be
obstructed, those are the emitting diodes.
Plug-in Microphone (LM-300) is a small capsule size microphone that
plugs directly into the top of the IRB-30 body-pack. A lanyard cord is
provided to accommodate wearing the body-pack transmitter around the
neck and utilizing it as a pendant microphone. A windscreen is included to
prevent breath pops when used in close proximity to the mouth.
Ultra Lite Microphone (ULM-835) is a miniature boom style microphone
supported by a wire around the left ear. The mic boom extends along side of face
and has a unidirectional microphone with windscreen. The small ring on the
boom prevents perspiration from entering the mic
element. Aside from comfort, the boom style mic
renders the best performance in terms of sound
quality and is not prone to feedback.
Caution: The boom can be formed to fit but it is not
a flexible boom. Do not bend back and forth. IT
WILL BREAK !
8

Collar Microphone (CM-835) is a flexible rod that is
formed around the neck. The end with the microphone and
windscreen is then contoured up toward the mouth. The
cord exits the rod in the center in back, out of the way, and
is plugged into the body-pack. The collar mic utilizes a
unidirectional mic element to minimize feedback and
renders quality voice reproduction.
Lapel Microphone (LM-835) is a small capsule microphone with a spring clip
for securing on to a clothing edge. The lapel microphone is well suited for out of
sight application. However; as a result of the microphone being
farther away from the mouth, more gain is required
for adequate volume. An omni-directional
microphone element is used to pick up from all
directions. These two factors make the lapel
microphone most prone to feedback when used
near or under a speaker.
Handheld Microphone Transmitter (IRH-35 channels “A” and
“B”) is most applicable for presenter’s use or audience participation. It
has an “on/off” switch and a battery level indicator LED; Green=useable
charge, Red=low battery. The transmitter has 10 emitting diodes around
the top and bottom of the handle. The metal housing provides low
handling noise and insures durable longevity.
Handheld Microphone Transmitter (IRH-40 with blue collar ring
utilizes channels “C” and “D”) is most applicable for presenter’s use
or audience participation. It has an “on/off” switch and a battery level
indicator LED; Green=useable charge, Red=low battery. The
transmitter has 10 emitting diodes around the top and bottom of the
handle. The metal housing provides low handling noise and insures
durable longevity.
9

Body – Pack Transmitter and its Features
•An external microphone needs to be plugged into the Body-Pack
oThe Plug-in microphone (LM-300) is a small capsule that
plugs directly into the top of the body-pack transmitter. Slip
the lanyard over your head and clip Body-Pack to lanyard, use
as a pendant type microphone.
oThe Lapel microphone (LM-835) plugs into the mic input and
then the lapel mic is clipped to your clothing.
oThe Collar microphone (CM-835) plugs into the mic input
and the collar is formed around the neck with the microphone
element oriented toward your mouth.
oThe Ultra Lite microphone (ULM-835) is fitted around the ear
and the cable plugged into the mic input.
•The Body-Pack is powered by two rechargeable NiMH batteries
which need to be fully charged for optimum performance
•Turn “on” the Body-Pack via slide switch on side of the Body-Pack
•Observe the Green LED on top of transmitter indicating a useable
charge on battery.
•Also observe the LED next to either A or B channel volume control,
indicating IR signal being received when the Body-Pack is turned
“on”
•To change channel, remove the battery cover and slide the channel
selector switch to A or B.
•Speak into the microphone and adjust the volume using the gain
control on top of the Body-Pack.
•While talking, walk around the perimeter of the room to verify
100% reception of the signal.
•Upon completion of test, put the Body-Pack in the charger for
recharging
Drop-in Battery Charger (BRC-50)
The battery charger is a rather sophisticated charger. It will charge the
NiMH batteries at the optimum charge rate, maintain full charge, and will
recycle the batteries for extended battery service life.
•Place handheld microphone and/or body-pack transmitter into their
appropriate slot
•When a microphone is being charged, a Red LED will light
indicating unit is being charged
•When the batteries are fully charged, the LED will change to Green.
•There is an audible buzzer which will buzz an alert when the
batteries are fully charged. The buzzer can be turned “on or off”
with the slide switch located on the bottom of the charger. (The
charger is normally shipped with the switch in the “off” position).
10

Handheld Microphone Transmitter IRH-35 channels A & B
•The handheld microphone is powered by two rechargeable NiMH
batteries which need to be fully charged for optimum performance
•Turn “on” the microphone with slide switch and observe the Green
LED
•Also, observe the LED next to Ch. B volume control indicating IR
signal being received when the microphone is turned “on”
•If the Ch. A LED turns “on”, unscrew the bottom half of the
handheld and slide the channel selector switch to Ch. B.
•Speak into the microphone and adjust the volume using Ch. B
volume control on the VoiceLink IV.
•While talking, walk around the perimeter of the room to verify
100% reception of the signal.
•Upon completion of test, put the microphone in the charger for
recharging
Handheld Microphone Transmitter IRH-40 channels C & D
Blue collar handheld transmitter/handheld microphone
•The handheld microphone is powered by two rechargeable NiMH
batteries which need to be fully charged for optimum performance
•Turn “on” the microphone with slide switch and observe the Green
LED
•Also, observe the LED next to Ch. D volume control indicating IR
signal being received when the microphone is turned “on”
•If the Ch. C LED turns “on”, unscrew the bottom half of the
handheld and slide the channel selector switch to Ch. D.
•Speak into the microphone and adjust the volume using Ch. D
volume control on the VoiceLink IV.
•While talking, walk around the perimeter of the room to verify
100% reception of the signal.
•Upon completion of test, put the microphone in the charger for
recharging
11

Installation of System
Location of receiver is primarily determined by user accessibility and availability
of an electrical outlet. Location of the sensor and routing of the sensor cable is a
more critical issue. It is important to observe a central location for the sensor and
adherence to the guidelines for the routing the sensor cable
Location of Receiver
Select a location that is close to a standard wall electrical outlet
Receiver on a shelf or cabinet
Under shelf or shelf mount with SM-700 shelf mount kit
Rack mount kit RM-468
Route sensor cable from dome sensor to receiver
Interface to Amplifier with shielded audio cable
12

Installation of the Dome Sensor
The ideal location for the dome sensor would be in the center of the ceiling.
This will provide a clear signal path for the IR transmission from the
transmitter to the dome sensor without obstruction. In addition, you will
have 360º coverage and will minimize the transmission distance for more
reliable performance.
13

Final Connection of the VoiceLink IV to Audio System
•Power supply plugged into AC outlet, DC plug plugged into receiver
•Dome sensor plugged into sensor input, coil extra cable neatly and place out
of view
•Connect receiver output to amplifier or media sound system
oEach male XLR jack is a balanced line level output from each
channel
oCh A-D mixed is a balanced composite line level output
oUnbalanced ¼” phone jack, switchable to either “Line” or “Mic”
level output
Sleeve - negative / ground
Tip – positive
14

System Operation
Now that the system is installed and connected, we are ready to turn the system
“ON” and test its performance. The testing will be done using an IR transmitter
(Body-Pack, Pendant or Handheld) to confirm good connectivity and quality
audio.
Turn the VoiceLink IV “ON” , Red power LED
Confirm power to sensor, Green LED light in center of sensor
Set volume of each channel “A” “B” “C” & “D” to mid scale (12’’clock)
Using a Transmitter (Handheld, Pendant, or Body-Pack with microphone)
Select channel “A”
oPendant: “A – B” switch on front panel
oBody-Pack: (open battery compartment) observe “ A – B” slide
switch
oHandheld: unscrew sleeve: Observe “A – B” or “C – D” switch on
side of battery compartment
Switch “ON” transmitter (Pendant, Body-Pack, or Handheld)
Observe power LED (Green) - use fully charged batteries only
Observe signal presence, Green LED on receiver adjacent to the channel
“A” “B” “C” or “D” knob
Performing test with a Body-Pack with mic plugged in or Pendant
Transmitter
oSlowly adjust volume control while talking into mic
oUsing Handheld transmitter, adjust volume on receiver
Walk around the room while talking into microphone to confirm good IR
connectivity
Caution: Be aware of walking under or in front of a speaker, feedback can
occur
Switch transmitter to channel “B” or “D” and repeat above performance
test
Upon completion of performance test, the installation is complete.
15

TROUBLE SHOOTING GUIDE ____________________________________
Note: Most problems are directly related to low battery power. So please
verify that the batteries are fully charged and less than two years old.
No Sound Check for power. Red LED next to power switch.
(Nothing works) Verify that AC outlet has power.
Verify that the sound system works
Verify dome sensor is receiving power, Green
LED in center of sensor
Body-Pack or Handheld Check batteries, Green LED when turned “on”
Transmitter does not work Check microphone cable, wiggle back & forth at
microphone and at connector end.
Verify signal reception from transmitter to
receiver, LED (green) adjacent to volume
control.
Static, Noisy, or fuzzy Sound Check charge on batteries.
CheckHi/Loswitch inside battery compartment
(Place in “Hi” position)
Along side of battery barrel on handheld
Verify that no other transmitter is turned “on” on
the same channel.
Bright sunlight, high intense fluorescent or
halogen lights near sensor.
Dropouts Verify that the infrared beam transmitted from
the transmitter (dark red window) is not being
obstructed by clothing or other solid objects.
Dark colored walls have a tendency to absorb
infrared and do not reflect efficiently.
Glass windows and doors allow competing
infrared light which weakens IR transmission.
Persistent dropouts may require installation of an
additional sensor.
16

Feedback (Mic Squeals) Feedback is the result of a resonant sound
coming from the speaker into the microphone
creating a self generating closed audio loop.
This can only be avoided by not walking under or
directly in front of the speaker.
Relocation of speaker is another consideration to
prevent the close proximity of microphone to
speaker.
Lapel microphones are the most prone to
feedback because of distance from mouth to
microphone. Therefore, if the problem persists,
you may want to consider using another
microphone such as a collar, headband with a
boom, or a unidirectional microphone plugged
into the pendant or body-pack with a lanyard
worn around the neck.
To reiterate: Batteries in the transmitter is our greatest grievance. Life
expectancy of “Duracell” batteries given conscientious care is about two years.
We have experienced much shorter service life from other brands.
Batteries should be stored in a fully charged condition and stored in a cool place.
Evidence of weakening batteries: (1) shortened service per charge, (2) batteries
won’t take a charge, (3) lack of output, causing noisy operation.
17

SPECIFICATIONS
IR-468N RECEIVER
Receiver Input
Modulation
Reception Frequencies
Infrared Wavelength
Pilot Tone Signal
De-emphasis
Frequency Response
S/N Ratio
THD
Nominal Deviation
Maximum Deviation
External Sensor Input
Connectivity Coverage
Line Output
Individual Balanced, XLR
Composite Balanced, XLR
Composite Unbalanced
¼” phone jack
Power Supply
Dimensions
Weight
Infrared FM
FM Wide-band
Ch. A: 2.08 MHz
Ch. B: 2.54 MHz
Ch. C: 2.30 MHz
Ch. D: 2.80 MHz
850 nm
Ch. A: 32.768 KHz
50 µs
40 Hz, -18KHz, ± 3dB
›65 dB
‹1% @1KHz
± 10 KHz
± 25 KHz
Four, RCA
2,500 Sq. Ft.
Ch A, Ch B, Ch C, Ch D
Ch A - D
Ch A - D
Switchable Line/Mic Level
15VDC / 1.5A / 15W
17" W x 1 ¾ " H x 7 1/4 " D
2.2 lbs.
18

GENERAL TRANSMITTER SPECIFICATIONS
Transmission Carrier
Transmission Frequencies
User Channel Switchable
Transmitting Diodes
Modulation
Pilot Tone Frequency
Peak Deviation
Operating Range
Power Switch (Slide)
Battery Charge Level (LED)
Battery Life
External Battery Contact
Infrared
IRH-35 2.08 MHz, 2.54 MHz
IRH-40 2.30 MHz, 2.80 MHz
Ch A or B (Crescent, Pendant, Body-Pack)
Ch A or B IRT-35 Handheld
Ch C or D IRT-40 Handheld
Ten
FM Wide-Band
32.768 KHz
± 25KHz
2500 Ft². 60 Ft. line of sight
On/Off
Green, (Useable Charge)
Red, (Needs Charging)
Approx. 7 Hr./Charge
Charger Connection
IRT-89 PENDANT TRANSMITTER
Adjustable Lanyard
Transmission Angle
Input
Microphone Input
Waist Band Clip
Dimensions
Weight
LM-300
Mic Type
Pick-Up Pattern
Connector
Frequency Response
Windscreen
Safety Breakaway Clasp
180°
Top/Center
3.5mm Jack, Lo-z
Tension Wire
5.25" H x 1.5" W x 1" D
4.8 oz. w/ Batteries
Plug-In Microphone
Electret/Condenser
Unidirectional
Male, 3.5 mm
100 Hz – 16 kHz
Pop Filter
19
